Simrad GC80 EXPANDED User manual

INSTRUCTION MANUAL
SIMRAD GC80/85
EXPANDED
Gyro Compass
20221529C English

Simrad GC80/GC85 Expanded Gyro Compass
ii 20221529 / C
Document revisions
Rev Date Written by Checked by Approved by
A 08.01.04
B 17.02.05
C 05.12.05
Document history
Rev. A First issue.
Rev. B Updated for new software release (Master compass: V.1.03, Control
unit: V.1.04).
Rev. C New procedure for how to adjust true heading, updated dimensions for
remote panel, other minor updates to text throughout the manual.

INSTRUCTION MANUAL
20221529 / C iii
About this manual
This manual is intended as a reference guide for installing, operating and maintaining
Simrad GC80 and GC85 Expanded Gyro compasses.
The manual assumes that the operator is a qualified ship officer, or is under supervision
of a qualified person.
In this manual, references to buttons on the operator panels are written in boldface, but
in a different text style (e.g. SET button, DISP button, GYRO button).
Important text that requires special attention from the reader is emphasized as follows:
Note! Used to draw the reader’s attention to a comment or some
important information.
Caution Used for warning the reader that a risk of damage to the
equipment exists if care is not exercised.
WARNING Used when it is necessary to warn personnel
that a risk of injury or death exists if care is
not exercised.

Simrad GC80/GC85 Expanded Gyro Compass
iv 20221529 / C
This manual is divided in the following sections:
1. System overview
An overview of the GC80/GC85 Expanded gyro system and it’s components.
2. User interface
Overview of GC80 Expanded Control unit and the user interface.
3. Operation
Main operating procedures for using the GC80/GC85 Expanded Gyro compass.
4. Maintenance
Simple maintenance procedures that should be performed by the system operator,
together with a complete procedure for how to replace the sensitive element and fuses.
5. Installation
Mechanical installation, cable connection, and software configuration for the
GC80/GC85 Expanded gyro system.
6. Advanced settings
A description of parameters that can be entered or changed in the Extension menu.
7. Technical specifications
Specifications for the system and for all separate units in the GC80/GC85 Expanded gyro
system.
8. Drawings
Outline drawings and wiring diagrams for the GC80/GC85 Expanded gyro system.
9. Spare part list
List of all standard and optional units that are used in the GC80 and GC85 Expanded
gyro systems.
10. Terminal layout
List of all terminal pins and terminal labelling with details on GTERM board in the
GC80 Control unit.
11. Dip switch settings
Drawings and references of jumpers and dip switches for the different printed circuits
boards in the Control unit.
12. Alarm messages and corrective actions
A description of how system errors are indicated, and corrective actions that can be
performed by the operator.

INSTRUCTION MANUAL
20221529 / C v
Contents
1SYSTEM OVERVIEW...........................................................1
1.1 Introduction.......................................................................2
1.2 Precaution in use................................................................3
1.3 System components............................................................4
1.4 Bearing repeaters ...............................................................4
2USER INTERFACE ..............................................................5
2.1 GC80 Expanded Control unit ................................................6
3OPERATION.......................................................................9
3.1 System Start-up and Shut-down......................................... 10
Start-Up .................................................................... 10
Turning the Gyro compass OFF...................................... 11
3.2 Selecting active compass ................................................... 12
3.3 Adjusting dimming level .................................................... 12
3.4 Displaying present settings ................................................ 13
3.5 Confirming present settings ............................................... 15
True bearing............................................................... 15
Latitude ..................................................................... 15
Speed........................................................................ 16
3.6 Pendulum function ............................................................ 18
3.7 Alarm messages ............................................................... 19
Acknowledging an alarm .............................................. 20
4MAINTENANCE ................................................................21
4.1 General........................................................................... 22
4.2 Precautions...................................................................... 22
4.3 Cleaning the operator panels and the cabinet surface ............ 22
4.4 Checking the connectors.................................................... 22
4.5 Checking mechanical installation......................................... 22
4.6 Preventive maintenance intervals........................................ 23
4.7 Replacing the Sensitive element ......................................... 23
Mechanical installation ................................................. 23
Verifying the element’s tilt angle ................................... 27
Parameter updates ...................................................... 28

Simrad GC80/GC85 Expanded Gyro Compass
vi 20221529 / C
Balancing the Horizontal ring ........................................ 29
4.8 Replacing the Fuses .......................................................... 30
Master Compass.......................................................... 30
Expanded Control unit.................................................. 31
5INSTALLATION................................................................33
5.1 Unpacking and handling .................................................... 34
5.2 Mechanical installation ...................................................... 34
Control unit ................................................................ 35
Master compass .......................................................... 37
5.3 Cabling ........................................................................... 38
Power supply .............................................................. 39
5.4 Grounding the units .......................................................... 40
5.5 Dip-switch settings ........................................................... 40
Configuring the Control unit.......................................... 41
External heading sensor ............................................... 42
Pendulum function....................................................... 43
5.6 Installing the Sensitive element .......................................... 44
Verifying the element’s tilt angle ................................... 46
5.7 System start-up and software configuration ......................... 48
System Start-up ......................................................... 48
Configuring the gyro system ......................................... 49
Setting the Latitude input system .................................. 51
Setting the Speed input system..................................... 52
5.8 Balancing the Horizontal ring.............................................. 53
Adjusting True heading ................................................ 53
6ADVANCED SETTINGS .....................................................55
6.1 General........................................................................... 56
6.2 Using the Extension menu ................................................. 56
6.3 The Extension menu overview ............................................ 57
7TECHNICAL SPECIFICATION ...........................................63
7.1 Accuracy ......................................................................... 64
7.2 General specification ......................................................... 64
7.3 Input specification ............................................................ 65
7.4 Output specification .......................................................... 66
7.5 Physical Dimensions.......................................................... 67

INSTRUCTION MANUAL
20221529 / C vii
GC80/GC85 Master Compass ........................................ 67
GC80 Expanded Control Unit......................................... 67
7.6 Power ............................................................................. 68
GC80/GC85 Master Compass ........................................ 68
GC80 Expanded Control Unit......................................... 68
7.7 Environmental Specification ............................................... 68
GC80/GC85 Master Compass ........................................ 68
GC80 Expanded Control unit ......................................... 68
8DRAWINGS .....................................................................69
8.1 Drawings included ............................................................ 70
9SPARE PART LIST............................................................77
9.1 GC80 Expanded Gyro system ............................................. 78
9.2 GC85 Expanded Gyro system ............................................. 78
9.3 Optional equipment, GC80/85 Expanded system ................... 79
10 TERMINAL LAYOUT .........................................................81
10.1 GTERM board ................................................................... 82
TB1 ........................................................................... 82
TB2 ........................................................................... 84
11 DIP SWITCH SETTINGS ...................................................87
11.1 Expanded control unit ....................................................... 88
GPOWER board ........................................................... 89
GTERM board.............................................................. 90
SCC board.................................................................. 91
SIFC board ................................................................. 95
12 ALARM MESSAGES AND CORRECTIVE ACTIONS.............101
12.1 The alarm system........................................................... 102
12.2 Acknowledging an alarm.................................................. 103
12.3 Fault finding .................................................................. 104
Main power failure..................................................... 104
Internal power failure in Control unit............................ 105
Inverter failure ......................................................... 105
Zero cross failure ...................................................... 105
System communication failure .................................... 106
GPS communication or data failure .............................. 106

Simrad GC80/GC85 Expanded Gyro Compass
viii 20221529 / C
Internal communication failure .................................... 107
External bearing sensor failure .................................... 107
LOG (serial) communication or data failure ................... 107
Repeater failure ........................................................ 108
Failure when powering ON the gyro compass ................ 108
12.4 Complete alarm code list ................................................. 109

SYSTEM OVERVIEW
20221529 / C 1
1SYSTEM OVERVIEW
This section provides an overview of GC80 and GC85
Expanded Gyro compasses and their components.

Simrad GC80/GC85 Expanded Gyro Compass
220221529 / C
1.1 Introduction
GC80 and GC85 Expanded Gyro compasses have been
designated for any size of vessels to enhance the navigation
capabilities and reliability. The gyro compasses eliminate the
inconvenience and limitations of magnetic compasses, and
provide a variety of electrical outputs to supply accurate and
consistent heading information to other navigational equipment.
-A GC80 Expanded gyro is designed for vessels with speed
up to 30 knots. The system complies with IMO A.424 (11)
and Wheel Mark Specifications.
-A GC85 Expanded gyro system is suitable for high speed
vessels with speed up to 70 knots. It complies with IMO
A.821 (19) HSC.
GC80 and GC85 Expanded gyro systems have different
sensitive elements, but use the same GC80 Expanded Control
unit. The systems are identified with divergent dip switch
settings in Master compass and in the Control unit.
Note! A GC80 or GC85 system is identified by the labelling on top of
the Master compass’ case as shown on the figure below.
The labelling on the control unit is identical for both gyro
systems.
pfjo^a=d`UR
_lt

SYSTEM OVERVIEW
20221529 / C 3
1.2 Precaution in use
The GC80/GC85 Expanded Gyro compass displays and outputs
bearing information. Although the system continually checks for
faults while the system is running, failures or malfunctions may
occur.
Any errors in input information will generate an alarm. These
errors may also cause large jumps in the output bearing from the
gyro compass. If this happens, any external equipment
depending on the bearing output from GC80/GC85 should be
operated manually or switched to other bearing sensors.
To assure long time safe operation, the following precautions
should be taken:
-Assure that the operator is familiar with the use of the
gyro compass
-Perform daily check to maintain normal system operation.
Refer MAINTENANCE, page 21 onwards
-If any unusual behavior is observed during daily
inspection, the cause should be found and corrected. If
necessary, the local Simrad dealer should be contacted
-If any alarm is generated, verify the reason for the alarm

Simrad GC80/GC85 Expanded Gyro Compass
420221529 / C
1.3 System components
A GC80/GC85 Expanded Gyro compass includes the following
units:
-Master Compass with Sensitive Element
-Expanded Control unit
Note! For details, refer TECHNICAL SPECIFICATION, page 63.
1.4 Bearing repeaters
GC80 and GC85 outputs step and serial signals used for
repeaters. Even when the gyro compass is supplied by the
emergency power supply, the connected repeaters will be driven
by the repeater backup function included in GC80/GC85.
If the serial output signal not is used for repeaters, the following
serial signal may be output:
-IEC61162-1 ed.2, close in comparison with NMEA0183
version 2.30 (4800 baud)
-IEC61162-2, based upon NMEA0183 version 2.30
(38400 baud, 9600 baud possible)
These signals may be set separately for each circuit.
For connection of repeaters, refer to wiring diagrams, page 74
onwards.
EXTERNAL HEADING SENSOR
GPS
SPEED
10 X NMEA
4X 24V STEP
3 X ROT
110/220V AC POWER INPUT
MASTER
COMPASS
EXPANDED
CONTROL
UNIT
ALARM CONTACT
24V DC BACKUP SUPPLY

USER INTERFACE
20221529 / C 5
2USER INTERFACE
This section gives an overview of the GC80 Expanded
Control unit and the user interface.

Simrad GC80/GC85 Expanded Gyro Compass
620221529 / C
2.1 GC80 Expanded Control unit
The Control unit includes the control panel for the gyro
compass.
A flush mount kit (part number 27101757) may be ordered from
Simrad for remote installation of the control panel. Refer Flush
mounting the control panel, page 35.
^i^oj
dvol
buq
afpm pbq
afj i^jm
qbpq
^`h
bkq
pfjo^a=d`UM
POWER Button
mltbo
Used for switching the gyro system ON. The button will be lit to
indicate that power is applied to the system. Refer System Start-
up and Shut-down, page 10.
Display
The LCD displays data in two rows: the Data indicator row and
the Mode indicator row.
-The Data indicator consists of four 7-segments red
LEDs. The indicator is used for displaying the vessel’s
bearing, latitude and speed. Refer Displaying present
settings, page 13.
The Data indicator is also used for displaying alarm
codes as described from page 18 onwards.
-The Mode indicator consists of three 7-segments green
LEDs. The Mode indicator displays codes used for
identifying input type for bearing, latitude and speed.
GYRO Button
dvol
Used for selecting the gyro compass as the active heading
reference system. The status lamp is lit to indicate that the gyro
system is active.
Refer Selecting active compass, page 12.
EXT Button
buq
Used for selecting the external heading system as the heading
reference. The status lamp will be lit to indicate that the external
heading reference system is active.
Refer Selecting active compass, page 12.

USER INTERFACE
20221529 / C 7
DISP Button
afpm
Used for displaying data on the LCD. Refer Displaying present
settings, page 13.
SET Button
pbq
Used for changing data and input systems. Refer System start-up
and software configuration, page 48 onwards.
ACK/ENT Button
^`h
bkq
Used for confirming a change in data and input systems. Refer
System start-up and software configuration, page 48 onwards.
The button is also used for acknowledging an alarm as described
in Acknowledging an alarm, page 20.
Arrow Buttons
afj i^jm
qbpq
Used for increasing or decreasing a parameter value. Refer
System start-up and software configuration, page 48 onwards
Also used for lamp test and for setting the display illumination
as described in page 12.
Alarm Indicator
^i^oj
Used for indicating an alarm situation. Refer Alarm messages,
page 19.

Simrad GC80/GC85 Expanded Gyro Compass
820221529 / C
THIS PAGE INTENTIONALLY LEFT
BLANK

OPERATION
20221529 / C 9
3OPERATION
This section describes the main operating procedure used
when operating the GC80/GC85 Expanded Gyro compass.

Simrad GC80/GC85 Expanded Gyro Compass
10 20221529 / C
3.1 System Start-up and Shut-down
A GC80/GC85 Expanded gyro system is usually left with power
on. If the system has to be shut down and restarted, the
procedures in the following sections should be followed.
Start-Up
Caution Before the gyrocompass is turned into normal operation, it has
to be configured according to the description in System start-
up and software configuration, page 48 onwards.
mltbo
1Turn ON the gyro system by pressing the POWER button
on the Control panel. The following start-up sequence will
be run:
Control unit type (GC80 Std, or GC85 HSc), SW version for
Control unit and for Master compass is displayed in rapid
succession. Examples of display text are shown below:
OR
GC80 CONTROL
UNIT
STD VERSION
GC80 CONTROL
UNIT
HIGH SPEED
VERSION
SW VERSION
CONTROL UNIT
SW. VERSION
MASTER COMPASS
dvol
2If the rotor not was completely stopped when the POWER
button was pressed, a rotor break function will be activated
to stop the rotor.
Active rotor break is indicated with flashing display.
3The sensitive element starts rising horizontally, and the
compass rotates 360° clockwise. The display shows
decreasing bearing as the compass is rotating.
dvol
4When the rotation is stopped, start bearing is indicated
with flashing text in the display. The start bearing will be
the same as active bearing when the compass was turned
OFF.

OPERATION
20221529 / C 11
dvol
5The indicated start bearing is accepted by pressing the
ACK/ENT button, or increased/decreased by using the
arrow buttons and then pressing the ACK/ENT button. If
no action is taken within 3 minutes, the start-up process
will continue with the indicated start bearing.
The bearing indication stops flashing when the start
bearing is accepted, while the lamp remains flashing.
6The rotor will now start rotating, and reaches pre-described
number of revolutions after maximum 30 minutes.
dvol
7When the rotor has reached full speed, the compass starts
the north seeking rotation. The display will now change to
show the compass’ actual heading, and from now on
bearing output will be available.
The lamp beside the GYRO button change from flashing to
steady light.
The GC80/GC85 will be settled within 3 hours when started
with a deviation angle less than 5°. With a larger deviation
angle, the compass will be settled within 4 hours.
Turning the Gyro compass OFF
mltbo
1Press the POWER button on the Control panel. The light in
the POWER button will be switched off.
dvol
2Repress the POWER button to activate the rotor break
function. The light in the POWER button will be lit again.
Active rotor break is indicated by:
-flashing display as shown on the figure
-a soft clicking sound heard from the gyrocompass
The rotor break function will be active for maximum 4
minutes.
Caution It is very important that the rotor break is activated to stop the
rotor rotation. If not, the sensitive element may be damaged!
mltbo
3Press the POWER button again to shut down the
gyrocompass when both the data and the dot in the display
change from flashing to steady light.
The light in the POWER button will now be turned OFF.

Simrad GC80/GC85 Expanded Gyro Compass
12 20221529 / C
3.2 Selecting active compass
If an external heading sensor is connected to GC80/GC85, it is
possible to switch between gyro and external heading sensor as
active steering sensor.
The gyro system will normally be used with the gyro compass
selected as active compass. An external heading sensor should
only be used as active compass when the gyro compass not is
working properly.
dvol
buq
+
^`h
bkq
By pressing the GYRO or the EXT and the ACK/ENT buttons
simultaneously, the GC80/GC85 will toggle between using the
gyrocompass or an external sensor as active sensor.
When the active sensor is changed, an audible alarm will sound
three times.
Active compass is identified with light in the button’s indicator
lamp, and with active compass type in the LCD as shown in the
figures below.
dvol
j^d
buq
dvol
j^d
buq
GYRO COMPASS SELECTED AS
ACTIVE STEERING SENSOR
EXTERNAL HEADING SENSOR
SELECTED AS
ACTIVE STEERING SENSOR
WARNING Changing active compass may result in large
change of true bearing. No changes should
therefore be made when the system is in
operation.
3.3 Adjusting dimming level
afj
The display illumination and the light intensity in the indicator
lamps can be increased or decreased in 5 steps by pressing the
arrow buttons.
When the illumination is set to lowest level, a faint light is still
present in the display, Alarm indicator, status lamp and Power
button.
Panel lamps and display segments may be tested by pressing
both arrow buttons simultaneously. All lamps and display
segments will be lit, and a short audible alarm will be activated.
