Simrad RS87 User manual

ALWAYS AT THE FOREFRONT OF TECHNOLOGY

Instruction Manual
III
Simrad RS87
VHF Radio System
MANUAL

RS87 VHF
IV Part No. E04297 Issue 1.1 05/03/03 MDL
The technical data, information and illustrations contained in this publication were to the best of our knowledge correct at the time of
going to print. We reserve the right to change specifications, equipment, installation and maintenance instructions without notice as
part of our policy of continuous development and improvement.
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form, electronic or otherwise without
prior permission from Simrad Ltd.
No liability can be accepted for any inaccuracies or omissions in the publication, although every care has been taken to make it as com-
plete and accurate as possible.
©2003 Simrad Ltd

CONTENTS
1. GENERAL 1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 The Simrad integrated system . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Licensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4 Entering MMSI numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.5 Group ID MMSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. MAIN FUNCTIONS
2.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Switching on & Second Country mode . . . . . . . . . . . . . . . . 12
2.3 Changing channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.1 Channel Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 Volume adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5 Squelch adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.6 Dual Watch mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.7 Tri-Watch mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.8 All Scan mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.8.1 Dynamic All Scan Inhibit . . . . . . . . . . . . . . . . . . . . . . 17
2.9 Memory Scan mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.9.1 Dynamic Memory Scan Delete . . . . . . . . . . . . . . . . . . 18
2.10 Adjusting backlighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.11 Handset off cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. MENU MODE
3.1 Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.1.1 All Scan inhibit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.1.2 All Scan reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.1.3 All Scan show . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1.4 Memory Scan select . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.1.5 Memory Scan clear . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1.6 Memory Scan show . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1.7 Scan dwell time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.2 Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.2.1 Ship’s MMSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.2.2 ATIS number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.2.3 Group MMSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.3 VHF items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3.1 User channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3.2 Position view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3.3 Last used channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3.4 Interrupt intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3.5 Auxiliary audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3.6 Speaker settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Instruction Manual
V

CONTENTS ctd -
4. DSC FUNCTIONS
4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2 Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2.1 Individual Routine call . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2.2 Public Correspondence call . . . . . . . . . . . . . . . . . . . . . 32
4.2.3 All Ships Safety call . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2.4 All Ships Urgency call . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2.5 Group call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2.6 Distress Alert call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.3 Receiving a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.3.1 Individual Routine call . . . . . . . . . . . . . . . . . . . . . . . . 37
4.3.2 Public Correspondence call . . . . . . . . . . . . . . . . . . . . . 38
4.3.3 All Ships Safety call . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3.4 All Ships Urgency call . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3.5 Group call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.3.6 Distress Alert call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.3.7 Distress Alert acknowledgement . . . . . . . . . . . . . . . . 42
4.3.8 Distress Relay call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4 Viewing the Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.5 Position over 4 hours old . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5. THE DIRECTORY
5.1 Switching between the directories . . . . . . . . . . . . . . . . . . . . 46
5.2 Viewing the directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.3 Entering a number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.4 Editing a number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6. MISCELLANEOUS FUNCTIONS
6.1 Selecting Weather Watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.1.1 Weather Watch alert . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.2 Security mode (voice scrambler) . . . . . . . . . . . . . . . . . . . . . 50
6.3 Editing Latitude, Longitude and UTC . . . . . . . . . . . . . . . . . 50
6.4 Toggling between Lat/Long and UTC views . . . . . . . . . . . 51
6.5 Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.5.1 Making an intercom call . . . . . . . . . . . . . . . . . . . . . . . 52
6.5.2 Receiving an intercom call . . . . . . . . . . . . . . . . . . . . . 53
6.6 Loudhailer / Foghorn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.6.1 Loudhailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.6.2 Foghorn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.7 station speaker mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.8 iDSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
RS87 VHF
6Part No. E04297

CONTENTS ctd -
7. INSTALLATION
7.1 Physical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1.2 Transceiver installation . . . . . . . . . . . . . . . . . . . . . . . . 57
7.1.2 Handset installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1.3 Station speaker installation . . . . . . . . . . . . . . . . . . . . . 59
7.2 Electronic installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.2.1 Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.2.2 Loudspeakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.3 Intercoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.2.4 Loudhailer/Foghorns . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.2.5 Remote foghorn button . . . . . . . . . . . . . . . . . . . . . . . . 62
7.2.6 Auxiliary audio input . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.2.7 NMEA0183 input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.2.8 iDSC output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.2.9 Future options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.2.10 Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.2.11 Cable strain relief . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.3 Antenna installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.4 Electrical interference suppression . . . . . . . . . . . . . . . . . . . . 68
8. APPENDIX 8.1 Operating procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.1.1 Sending a distress alert . . . . . . . . . . . . . . . . . . . . . . . . 69
8.1.2 Acknowledging and relaying a distress alert . . . . . . 69
8.1.3 Cancelling a distress alert . . . . . . . . . . . . . . . . . . . . . . 70
8.1.4 Alerting all vessels within range . . . . . . . . . . . . . . . . 70
8.1.5 Calling a coast station . . . . . . . . . . . . . . . . . . . . . . . . . 70
8.1.6 Making an intership call . . . . . . . . . . . . . . . . . . . . . . . 70
8.2 NMEA sentences received . . . . . . . . . . . . . . . . . . . . . . . . . . 70
8.3 Transmission range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.4 Frequency of channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.5 Fault finding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8.6 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8.7 Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.8 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.9 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.10 Service & warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Instruction Manual
7
Part No. E04297

1 GENERAL
1.1 Introduction
The RS87 is a modular VHF radio and Class D Digital
Selective Calling (DSC) radio telephone system using a fully
featured telephone-style handset to access and control all func-
tions. It supports the latest GMDSS requirements for non-
SOLAS vessels from the International Maritime Organisation
(IMO). It will enable you to make digitally selected calls,
which are quicker and simpler to make than traditional voice
calls using Channel 16. Should a distress situation occur, with
the RS87 you can quickly raise an alert, indicating your identi-
ty, your position and automatically establish distress communi-
cation on the emergency voice channel.
The RS87 transceiver is robustly constructed using a pressure
die cast aluminium case for effective heat dissipation, ensuring
maximum transmission performance even after many hours
constant use.
Thank you for choosing Simrad
If you are pleased with your VHF we hope you will be interest-
ed in our range of marine electronic equipment, which is man-
ufactured to the same high standards as the RS87. Please con-
tact your nearest Simrad Agent for a catalogue showing our
increasing range of high tech navigational instruments, GPS,
autopilots, Radar, Echosounders, Chartplotters and VHF radio
sets.
Simrad operate a policy of continual development and reserve
the right to alter and improve the specification of their prod-
ucts without notice.
RS87 VHF
8Part No. E04297
WX WATCH
SPEAKER
DIR
TEL CALL
VOL
VOL ON/C
LAT/LON
CH SET
LIFT
COVER DISTRESS
16
VOLUME 1 1
SQUELCH 07
INT
Fig 1.1 - RS87 Handset

1.2 The Simrad integrated system
The standard RS87 radiotelephone can support up to two sta-
tions with full intercom facility, geographical position input
via NMEA0183 and iDSC integration with Simrad chartplotters
which enables the plotters to display DSC call information.
With the addition of the expansion board, the system can sup-
port an additional two stations, two intercom speakers and for-
ward and aft foghorn/loudhailer speakers in addition to the
standard functions.
Additional stations can either be another RS87 type telephone
handset, or an RS86 fixed panel display, with a passive tele-
phone handset or fistmike allowing great flexibility in installa-
tions (Fig 1.2) -
Instruction Manual
9
Part No. E04297
Fig 1.2 - RS87 system options
DUAL STATION SYSTEM
EXPANDED SYSTEM
BASIC SYSTEM

1.3 Licensing
NOTE Prior to use check the national licensing requirements for the
operator.
In the UK license applications and queries should be made to
the following authority -
Ship Radio Licensing
Radio Licensing Centre
The Post Office
PO Box 1495
Bristol
BS99 3QS
Aset may only be operated by, or under the supervision of a
holder of a Certificate of Competence and Authority to
Operate. This involves a simple examination and an annual
license renewal fee. The VHF only certificate is administered
by the Royal Yachting Association -
Royal Yachting Association
RYA House
Romsey Road
Eastleigh
Hants, SO5 4YA
Holders of the Restricted Certificate of Competence in Radio-
telephony (which covers MF/HF SSB etc), do not need a sepa-
rate VHF certificate.
In all other countries, please contact your regional authority for
information.
RS87 VHF
10 Part No. E04297

1.4 Entering MMSI numbers
At the time of issue of your vessel’s radio license, an MMSI
(Maritime Mobile Service Identifier) must be requested. This is
a nine digit number which must be permanently entered into
the RS87 when the radio is first set up, otherwise the DSC
functions cannot be accessed.
NOTE If the boat or the RS87 are subsequently sold, the radio must
be returned to an authorised Simrad agent for the MMSI num-
ber to be erased and the new owner’s MMSI number entered.
For European leisure vessels fitted with VHF DSC equipment, a
CEPT Short Range Certificate is required by the operator.
Additional requirements, such as GOC or ROC may apply to
operators on commercial vessels. Please enquire with your
local licensing authority for full details.
Refer to section 3.2.1 to enter the vessel’s MMSI number.
1.5 Group ID MMSI
For boats that are part of a flotilla, racing fleet or other group, a
Group ID MMSI number can also be entered which will allow
DSC communication within the group. Refer to section 3.2.3 to
enter a Group MMSI number.
Instruction Manual
11
Part No. E04297

2. MAIN FUNCTIONS
2.1 General notes
Although it has many advanced features, the RS87 has been
designed to be as simple and intuitive to operate as possible.
The Shift key is used to access the secondary functions printed
above each key - press and release Shift, then press the appro-
priate key. These secondary functions are shown in this manu-
al in italics (eg Group).
NOTE The Shift key will automatically time out of Shift Mode after
two seconds if another key is not pressed.
At any time, pressing ON/C will cancel the current operation.
The lowest occupied port is the master controller - therefore
any operations initiated on this handset will override all other
stations.
CAUTION In order for other users to be able to operate the radio, it is
imperative that the handset is replaced in the cradle after use.
2.2 Switching on & Second Country mode
To turn the radio on, press the ON/C key. The display will
show the handset software issue number two seconds, then the
station number and software issue number for the transceiver
unit for two seconds.
As a default, the radio switches on tuned to the priority chan-
nel (normally 16). If Last Channel Used mode has been set (see
section 3.3.3) the radio will switch on tuned to the previously
used channel.
The radio stores the previous volume and squelch settings and
will use these on startup.
In countries where it is permitted, the RS87 can operate on a
secondary set of channels, such as the USA channels.
To select the secondary channel table, press Shift followed by
OK. The display will show the channel set selected for two
seconds before reverting to the default display.
NOTE Channels available will depend on programming. Please
enquire with your national licensing authority for details of
permitted channel sets in your own country.
RS87 VHF
12 Part No. E04297

2.3 Changing channels
To select a channel, enter the channel number using the numer-
ic keypad (Fig 2.1) -
Instruction Manual
13
Part No. E04297
Fig 2.1 - Selecting a channel
If the channel is invalid, the display will show “Invalid
Channel” and then revert to the previous channel.
The priority channel (normally 16) can be selected by pressing
16, which will also set the radio to 25W transmit power.
The preselected User Channel can be directly selected by press-
ing the User key. The display will show “U” next to the chan-
nel number to indicate that it is the User Channel (Fig 2.2).
72
VOLUME 05
SQUELCH 03
INT
U 23
VOLUME 05
SQUELCH 03
INT
16
VOLUME 05
SQUELCH 03
INT
The default setting for the User Channel is 16. Refer to section
3.3.1 for details on setting the User Channel.
Fig 2.2 - User channel selected

2.3.1 Channel Sets
In addition to the standard International Channel, the RS87 can
also be programmed with regional Auxiliary Channels, such as
the marina channels M and M2 in the UK, the USA weather
channels and the fishing or leisure channels in Scandinavia.
To display the channel sets available, press Shift followed by
1W (Ch Set). Multiple presses of the 1W key while still in Shift
Mode will scroll through the available channel sets.
RS87 VHF
14 Part No. E04297
When the required channel set is displayed, enter the channel
number using the numeric keypad - eg “2” for M2 (Fig 2.4) -
MAR I NAAAAA
MAR I NAAAAA
INT
PR I VATE AAA
Fig 2.3 - Selecting auxiliary channel sets
(sets must be available to be displayed)
Fig 2.4 - Selecting auxiliary channel number
The only exception to this is when selecting UK marina chan-
nel M, which has no number associated with it. Simply select-
ing the marina channel set will automatically select it.
NOTE If no numeric keys are pressed within two seconds the radio
will revert to the previous working channel (except for marina
channel M as noted above).
2
MAR I NAAAAA
INT

2.4 Volume adjustment
To adjust the volume, press the VOL and VOL keys to
increase and decrease the setting respectively. Press and hold
the key to increase/decrease the setting rapidly.
The volume setting can be between 1 and 24 (loud).
2.5 Squelch adjustment
To adjust the squelch setting, press the SQ key to enter squelch
adjustment mode, then press the and (VOL) keys to
increase or decrease the squelch respectively. Press and hold
the key to increase/decrease the setting rapidly.
The squelch setting can be between 0 (open) and 10.
NOTE Squelch mode will automatically time out after two seconds if
another key is not pressed. Squelch mode can also be cancelled
by pressing the ON/C key.
2.6 Dual Watch mode
Dual Watch allows the radio to scan between the selected
working channel and the watch channel (the priority channel -
normally 16).
To enter Dual Watch, select the required working channel, then
press Shift and 3(DW) within two seconds.
If Dual Watch is selected while the handset is off cradle, the
display will show “Place back on cradle”. If the handset is
replaced within ten seconds of selecting Dual Watch, it will
automatically initiate Dual Watch when the handset is
replaced.
The display will show “D/W” - the large digits on the display
indicate the working channel, with the watch channel shown
below in small digits (Fig 2.5) -
Instruction Manual
15
Part No. E04297
6
D/WAAAAA 16
BBBBBBBBBB
INT
DW
Fig 2.5 - Dual Watch mode

If the radio detects a signal on the watch channel, it will lock
onto this and the large digits will change to show the watch
channel.
NOTE All other stations will also show the Dual Watch display.
NOTE Normal VHF functions will not be available when in Dual Watch
mode. To exit Dual Watch press 16, ON/C or lift the handset
from the cradle.
2.7 Tri Watch mode
Tri Watch allows the radio to scan between the selected work-
ing channel, the user channel and the watch channel.
NOTE Tri Watch cannot be selected if the user channel is set to Ch16.
To enter Tri Watch, select the required working channel, press
Shift and then press and hold the 3(DW) for two seconds.
If Tri Watch is selected while the handset is off cradle, the dis-
play will show “Place back on cradle”. If the handset is
replaced within ten seconds of selecting Tri Watch, it will auto-
matically initiate Tri Watch when the handset is replaced.
The display will show “T/W” - the large digits on the display
indicate the working channel, with the user channel and watch
channel shown below in small digits (Fig 2.6) -
RS87 VHF
16 Part No. E04297
Press & hold
T/WAAAAA 16
USERBBBBB6
INT 10
Fig 2.6 - Tri Watch mode
If the radio detects a signal on the user or watch channels, it
will lock onto this and the large digits will change to show the
relevant channel.
NOTE All other stations will also show the Tri Watch display.
NOTE Normal VHF functions will not be available when in Tri Watch
mode. To exit Tri Watch press 16, ON/C or lift the handset
from the cradle.

If the radio locks onto a busy channel, pressing OK will manu-
ally continue the scan. All Scan will otherwise automatically
restart when the channel becomes clear.
NOTE All other stations will also show the All Scan display.
NOTE While in scan mode, normal VHF functions are not available.
To exit All Scan press 16, ON/C or lift the handset from the
cradle.
2.8.1 Dynamic All Scan Inhibit
If the radio is constantly locking onto a busy channel when
scanning, this channel can be inhibited from the scan by press-
ing Shift then 1while locked on that channel.
The display will show “Channel Inhibited” and the channel
will no longer be included in the scan cycle.
The channel can be reinstated using the menu option described
in section 3.1.1.
2.8 All Scan mode
The scan function cycles the RS87 sequentially through each
enabled channel, pausing when a signal is detected.
Press Shift followed by 1(Scan All) to enter All Scan Mode.
If Scan is selected while the handset is off cradle, the display
will show “Place back on cradle”. This function will be can-
celled if the handset is not returned to the cradle within 10
seconds.
The display will show “Scan All” on the display. If the radio
detects a signal, it will lock onto this and the large digits will
change to show the relevant channel number (Fig 2.7) -
Instruction Manual
17
Part No. E04297
67
INT SCAN
ALL
Fig 2.7 - All Scan mode

2.9 Memory Scan mode
Memory Scan gives the option of scanning a preprogrammed
set of channels specified by the user (see sections 3.1.4 and
3.1.5).
Press Shift then 2(Scan M) to enter Memory scan mode.
If Memory Scan is selected while the handset is off cradle, the
display will show “Place back on cradle”. If the handset is
replaced within ten seconds of selecting Memory Scan, it will
automatically initiate Memory Scan when the handset is
replaced.
The display will show “Scan M” on the display. If the radio
detects a signal, it will lock onto this and the large digits will
change to show the relevant channel (Fig 2.8) -
RS87 VHF
18 Part No. E04297
68
INT SCAN
M
Fig 2.8 - Memory Scan mode
If the radio locks onto a busy channel, pressing OK will manu-
ally continue the scan. Memory Scan will otherwise automati-
cally restart when the channel becomes clear.
NOTE If only one channel has been entered into the memory then
initiating Memory Scan will retune the RS87 to the stored
channel.
NOTE All other stations will also show the Memory Scan display.
NOTE While in memory Scan mode, normal VHF functions are not
available. To exit Memory Scan press 16, ON/C or lift the
handset from the cradle.
2.9.1 Dynamic Memory Scan Delete
If the radio is constantly locking onto a busy channel when
scanning, this channel can be removed from the Memory Scan
channel set by pressing Shift then 2while locked on that
channel.
The display will show “Channel Deleted” and the channel will
no longer be included in the scan cycle.

2.10 Adjusting backlighting
The display and keypad are backlit - to set the backlighting
level press Shift followed by Call (Dimmer) to enter back-
light mode.
Use the and (VOL) keys to adjust the backlighting level
from off through to level 5..
Press Ok or ON/C to exit the backlight mode at the selected
level.
NOTE Backlighting levels will only affect this station.
2.11 Handset off cradle
When a handset is lifted off cradle, all other stations will show
“Occupied” on the display (Fig 2.9). This means that these sta-
tions are locked out until the handset is returned to the cradle,
unless the station is being called on intercom by the handset.
Instruction Manual
19
Part No. E04297
NOTE The handset plugged into the lowest numbered port is
designated the Master unit. Lifting the Master handset will
override all other stations, even if it is displaying “Occupied” -
all other stations will then display “Occupied” and be locked
out.
STAT I ONAA2
OCCUP I EDBB
INT 16
Fig 2.9 - Station 2 handset is in use

3. MENU MODE
Menu mode is used to adjust the various settings of the radio,
such as channels inhibited from the scan functions, MMSI num-
ber programming and User channel selection.
To enter Menu mode, press Shift followed by 9(Menu).
Use the the VOL and VOL keys to scroll through the
various menu options -
- Scanning (section 3.1)
Options related to the various scanning functions such as
channel inhibit, memory scan select and scan dwell time.
- Numbers (section 3.2)
Entering of ID numbers such as MMSI, Group MMSI and
ATIS number (if applicable in country of use).
- VHF Items (section 3.3)
Miscellaneous options such as selection of User channel,
last used channel, interrupt intercom and speaker settings.
To select an option, press Ok.
To return to normal radio operation, press On/C.
NOTE Entering Menu mode will inhibit the operation of the radio.
Exit Menu mode before returning the handset to the cradle to
permit normal operation.
3.1Scanning Once the Scanning menu option has been selected (see intro-
duction to section 3), use the VOL and VOL keys to scroll
through the menu options -
All Scan inhibit (section 3.1.1)
All Scan reset (section 3.1.2)
All Scan show (section 3.1.3)
Memory Scan select (section 3.1.4)
Memory Scan clear (section 3.1.5)
Memory Scan show (section 3.1.6)
Scan dwell time (section 3.1.7)
To select an option, press Ok.
To return to the main menu, press On/C.
RS87 VHF
20 Part No. E04297
