SImx FAN6855 User manual

Allinstallations and electrical work must comply with current local and national
electrical and building regulations as applicable. Electrical work should only be
carried out by a registered electrician.
Ensure that the unit is installed on a suitably rated fused circuit with the supply
isolating switch having a minimum contact separation of at least 3mm.
The product has an internal 10A fuse.
If the supply cord is damaged, it must be replaced by the manufacture, its
service agent or similar qualified persons in order to avoid a hazard.
This dryer is not intended for use by young children or infirm persons without
supervision.
Young children should be supervised to ensure that they do not play with this
appliance.
Do not insert objects intothe air outlets. Doing somay be hazardous and could
result in electrical shock.
Do not obstruct the air inlets or outlets in anyway.
Service hand dryer at regular intervals.
The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience or knowledge,
unless they have been given supervision or instruction.
INSTALLATION INSTRUCTIONS
Rapid Dry Stainless Steel Hand Dryer
FAN6855
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING
THEINSTALLATION
Technical Specification:
Voltage: 220 – 240 VAC
Power: 500W
Input: 1150 – 1350W
Air Speed: 216 km/hr
Drying Distance: 15-20 cm
Safety: Class I
Protection Class: IPX1
Dimensions: 253 (H) x 172 (W) x 145 mm (D)
IMPORTANT

Figure A
Figure B
Countersunk
screws
Allen key
Shell
Menʼs Washrooms 1200mm
Womenʼs Washrooms 1150mm
Disabled Washrooms 950mm
Childrenʼs Washrooms
10-13 years 1000mm
7-10 years 900mm
4 - 7 years 800mm
Floor
Product Special Features
The stainless steel shell is a 1.2mm single piece “no-welds” construction providing
robust resistance in vandal-prone locations.
This hand dryer is equipped with an automatic heating system. When air
temperature is above 25ºC, the heating system will not operate, but the fan will
continue as normal. This provides an automatic power reduction of 650 watts.
When below 25ºC, the heating system will automatically operate.
To avoid misuse and any chance of overheating, the auto stop function will stop the
unit after 40 seconds (approx).

Servicing and Maintenance
• This unit must be isolated from the power supply during routine maintenance.
• This unit should be serviced every 3 months or more frequentlyto remove dust,fluff
or any other build up from the filter inlet and outlet grill areas (see label on unit).
• Do not attempt to disassemble internal unit as this may void the product warranty.
• Clean housing with a soft cloth and neutral detergent. Acidic or alkali cleaners will
affect surface finish and are not recommended.
Installation Instructions:
Important: This product should be installed by a registered electrician.
Warning: Isolate the power before installation.
Note:This unit must be fixed to a solid supporting wall. Mounting above shelves or
over stainless steel/reflective surface counters may interfere with sensor operation
and is not recommended.
To ensure the ease of installation and subsequent maintenance of this unit, the
horizontal distance to any adjacent wall should not be less than 200mm.
1. Unscrew front shell from the base of the unit using the Allen key provided (Fig A).
2. Align base of unit on desired wall location and mark mounting hole locations for
correct height above the floor (Fig B).
3. Drill holes and installed supplied wall plugs.
4. Fix base to the wall using screws provided.
5. Ensure power cable is connected (plug or permanent) correctly for the site.
6. Re-attach the shell to the base of the unit using the Allen key provided.
7. Reconnect power supply.
8. Check hand dryer operations.
The installation of an RCD having a rated operating current not exceeding 30mA is
advisable for indoor use only.

PUB1449 1805
We reserve the right to change specification without prior warning.
Distributed by: Simx Limited
Ph: [phone] | Technical Support Ph: [phone]
Email: [email protected] | www.simx.co.nz
MANUFACTURERS EXTENDED WARRANTY
This product is guaranteed by SIMX Ltd for 24 MONTHS from the date of purchase
against faulty materials or workmanship which affects its designed ability to switch
and operate.
During this period if the product has a defect of this nature it will be repaired or
replaced free of charge by SIMX with the same item, or a similar one of higher
specification. ON THE CONDITIONS THAT:
The buyer returns it to the seller from whom it was bought, freight paid.
The product has been bought by the user. ie a receipt/sales invoice is produced as
proof of purchase.
The product has not been misused or handled carelessly, installed in anyway
contrary to the installation instructions, or installed in any unusually exposed or harsh
environmental conditions.
This guarantee excludes liability for discolouration of paint or plastic, or any user
replaceable parts. It does not confer any rights other than those expressly set out
above and does not cover any claims for consequential loss or damage.
Our Goods come with guarantees that cannot be excluded under the Australian and
New Zealand Consumer Law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the Goods repaired or replaced if the Goods fail to be of
acceptable quality and the failure does not amount to a major failure.
