SImx CHM0155 User manual

1
PLUG-IN Digital Door Chime
Model No: CHM0155
CONTENTS
NAMES FOR PARTS
INSTALLATION INSTRUCTIONS
Instruction Manual x1Transmitter x1 Belt Clip x1
A “screw-on”
belt clip for
portable use
Battery x1
Type 23A12V
Receiver x1
Receiver front side Receiver back side Transmitter
(1) LED Indicator
(2) Speaker
(3) Hanging Hook
‘Receiver’ means the Indoor Chime unit. ‘Transmitter’ means the Exterior Door Press.
Please install and operate this product according to the following instructions.
13
4
5
6
7
2
(4) Auto Learn Button
(5) Melody Selector
(6) Volume Selector
(7) Battery Cover
(8) Door Press
(9) New Plate & Cover
8
9

Receiver Unit
Transmitter Unit
What is Auto-learning Code?
The Transmitter sends a wireless signal to the Receiver. The Receiver would automatically register and
memorize the signal as an operation code. So the Transmitter can work with the Receiver by this code.
Auto-learning Code Set Up
1. Operation for 1 Transmitter and 1 Receiver
• Firstly install the batteries to the Transmitter and Receiver.
• Now press and hold the top button on rear of the Receiver until the front LED is lit,
indicating the device is ready to pair.
• Immediately press the transmitter button once. Pairing will be confirmed by playing of
selected melody.
NOTE: Interference from another similar door chime operating nearby (For example, Receiver sounds for no reason):
• Remove batteries for approx. 2 minutes will wipe the pairing memory. Repeat steps above to re-pair.
• It is important to remember that when you replace the run-out battery with new one that you may
need to follow the same procedure of the auto-learning code set-up as above.
• Product cannot be paired with multiple Receivers or Transmitters.
Insert 3 x AA Alkaline batteries into the compartment at rear of the Receiver.
INSTALLING THE BATTERY
SETUP THE AUTO-LEARNING CODE
Before fixing the products, check your desired locations can communicate first. The product is rated to
operating up to a range of 80 metres in free air. The operating range will be reduced if the signal
is transmitted through a number of walls or ceilings.
NOTE: Common barriers to avoid completely include mounting to any metal surface or UPVC door frames.
Avoid positioning above heat sources such as radiators, or in damp areas such as a kitchen or bathroom.
Do not expose either unit directly to rain or immerse in water. Do not locate either unit close to fireplace
or expose to high temperatures.
Note the Receiver is suitable for Indoor use only. The Transmitter is rated for sheltered exterior locations.
SELECTING YOUR MOUNTING LOCATIONS
• To open the housing, firstly remove the name plate cover. Using a flat head screwdriver,
insert this into the slot on the base of the unit. The rear should pop open. Lever the cover off.
• Insert the supplied 23A12V battery into the holder at the bottom of the Transmitter,
ensuring polarity of battery on installation. Reassemble the Transmitter, ensuring the rear had
clicked into place.
2

3
There are 36 different melodies to select from. Scroll through these using the middle button
on the rear of the Receiver to select your preferred melody. This can be changed at any
time using the re-pairing steps.
There are 4 volume settings to select from. Scroll through these using the bottom button on
the rear of the Receiver for the appropriate volume for your location. This can be changed at
any time without re-pairing.
• The Receiver can be hung on a wall with a screw, table top mounted,
or portable with the (included) belt clip.
• Affix the door press to a smooth surface with double sided tape and screws as required.
Before you drill any hole in the wall, please make sure there are not cables
or pipes that may be accidentally damage.
SELECTING YOUR PERSONAL SETTINGS
OPERATION
Press the push button on the Transmitter unit once, it sends a wireless signal to the Receiver which will
play the selected melody. The sound will stop as soon as the melody ends. For repeat sound, press the
button again. Holding the Transmitter button IN will NOT repeat the sound.
AFFIXING THE PRODUCTS
The doorbell contains 36 melodies:
1. DING-DONG sounds
2. Westminster Bell
3. FOR Alice
4. Memory
5. DING-DONG sounds *
6. Turkey March
7. Yankee Doodle
8. Island of Capri
9. Cuckoo! Cuckoo!
10. Rhythm of the Rain
11. LONDON Bridge
12. A lullaby
13. Ten little Indians
14. Oh Susannah
15. Ballade Pour Adeline
16. The Snail and the Oriole Birds
17. Love Story
18. DING-DONG sounds*
19. Little Star
20. Happy Birthday to You
21. Jingle Bells
22. Love is Blue
23. Starry Sky
24. Rainbow Younger Sister
25. DAYS OF MY PAST
26. Long Long Ago
27. Osmanthus Blooming in August
28. Colourful Clouds Chasing the Moon
29. Santa Clause is Coming to Town
30. The Dying Swan
31. Throw the Handkerchief
32. A Beautiful Sunset of Life
33. The Happy song
34. Mary Had a Little Lamb
35. Moscow Nights
36. Waltz

If the Receiver does not sound, please check the following:
• Flat batteries in either the Transmitter or Receiver -change the battery.
• Wrong battery polarity in either the Transmitter or Receiver-reinsert the battery.
• Units are out of range-relocate the Receiver within the operation range.
• If leaving the chime unused for long periods, remove the battery from devices to prevent leakage.
• Dispose of old batteries in accordance with the relevant legislation.
USER HINTS
TECHNICAL SPECIFICATIONS
ELECTRICAL COMPLIANCE
Receiver
Battery (not included) 3 x AA 1.5V Alkaline batteries
Operating Frequency 433.92 MHz
Operating Range (Free Air) Up to 80 metres
Sound dB(A) 60-85 dB(A)
Transmitter
Battery (included) 1 x 23A12V battery
Enclosure rating IP44 – sheltered exterior locations only
Operating Temperature -20°C to +40°C
4
This product complies to all relevant NZ/AU compliance standards.
An SDOC (supplier compliance declaration) is available on www.simx.co.nz
Type the product code into Search on the home page, this takes you to the item product page,
a download link is located below the product details on that page.
IMPORTANT: PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE WHEN REPLACING BATTERIES
USER HINTS
Distributed by:Simx Limited
Ph:[phone] | Technical Support Ph: [phone]
Email: [e-mail] | www.simx.co.nz
PUB1720 2112
