SImx DECOR CHIME CHM10157 User manual

1
Please install and operate this product according to the following instructions.
INSTALLATION INSTRUCTIONS
Click-in base
of Receiver x1
Transmitter x1
Include white address
label insert
Instruction Manual x1CR2032 x1Receiver x1
13
12
11
10
9
8
7
6
5
4
3
2
1
DÉCOR CHIME Wireless Digital Door Chime
Model No: CHM10157, CHM0158
CONTENTS
‘Receiver’ means the Indoor Chime unit. ‘Transmitter’ means the Exterior Door Press.
NAMES FOR PARTS
Receiver front side Receiver back side Transmitter front
cover outside
Transmitter back
cover outside
(1) LED Indicator
(2) Melody Selector
(3) Volume Button
(4) Sound-and-Flash Switch
(5) Speaker
(6) Click-in base of Receiver
(7) Hanging Hole
(8) Auto-learning Code Button
(9) Battery Cover
(10) Nameplate
(11) Push Button
(12) Standby holes for screws
(13) Opening Tab

Receiver Unit
1. Before installation and operation, you will require a drill, a cross-headed screwdriver, a flat head
screwdriver, 2xAA 1.5V size batteries, fixing screws and wall plugs.
2. Avoid positioning the Transmitter on metal frames.
3. Avoid positioning above heat sources such as radiators, or in damp areas such as a kitchen or bathroom.
NOTES BEFORE INSTALLATION
Remove the rear cover of the Receiver, and insert 2 x AA Alkaline batteries (not included).
Ensure polarity of batteries on installation.
INSTALLING THE BATTERIES
2
2x1.5V AA
Alkaline Battery
1x CR2032
Before fixing the products, check your desired locations can communicate first. The product is rated
to operating up to a range of 80 metres in free air. The operating range will be reduced if the signal
is transmitted through a number of walls or ceilings.
NOTE: Common barriers to avoid completely include mounting to any metal surface or UPVC door
frames. Avoid positioning above heat sources such as radiators, or in damp areas such as a kitchen
or bathroom. Do not expose either unit directly to rain or immerse in water. Do not locate either unit
close to fireplace or expose to high temperatures.
Note the Receiver is suitable for Indoor use only. The Transmitter is rated for sheltered exterior
locations only, not where direct rain may fall.
SELECTING YOUR MOUNTING LOCATIONS

Transmitter Unit
• Using a flat screwdriver, insert into the small slot at the base of the unit to facilitate this.
Remove the circuit board (it may be secured with a small screw). Insert the supplied CR2032
into the battery holder, ensuring polarity of battery on installation (positive facing outwards).
Reinsert the circuit board with screw in place.
• Close the Transmitter enclosure by setting the fastening tab of the top cover into the slot
on the base. Then carefully press the top cover onto the base. It should click neatly into place,
ensuring the waterproof rating of the Transmitter.
What is Auto-learning Code?
The Transmitter sends a wireless signal to the Receiver. The Receiver would automatically register and
memorize the signal as an operation code. So the Transmitter can work with the Receiver by this code.
Auto-learning Code Set Up
1. Operation for 1 Transmitter and 1 Receiver
• (A) After battery installation on both Transmitter and Receiver, press the Transmitter once to generate
a new operation code. The Receiver will sound, which indicates that a new operation code is registered
and memorized.
• (B) Alternatively, press the auto-learning code button on the back of the Receiver once and it will be
ready to receive signal sent from the Transmitter. Press the button of the Transmitter, the Receiver will
sound to indicate that new operation code is registered and memorized.
Expanding your system or up to 4 Receivers to a single Transmitter
• You can pair up to 4 Receivers to a single Transmitter, by repeating Step B above for each Transmitter
(one at a time).
• Please note these items are only sold in New Zealand/Australia as a complete kit of both Transmitter
and Receiver together. These are not available for purchase as individual items.
• Paring multiple Transmitters to a single Receiver, the Transmitter will ring the same melody only.
• Paring multiple Receivers to a single Transmitter, select different melodies is allowable when pairing.
NOTE: Interference from another similar door chime operating nearby (For example, Receiver sounds for no reason):
• Remove the batteries from the Receiver and rest for 60 seconds. This will erase the memory.
Insert the batteries again, and then the Transmitter and the Receiver are ready for the new code
registration. Repeat Step B above to re-pair.
• It is important to remember that when you replace the run-out batteries with new ones that you
will need to follow the same procedure of the auto-learning code set-up as above.
SETUP THE AUTO-LEARNING CODE
3

There are 36 different melodies to select from. Scroll through these using the top button on the Receiver
to select your preferred melody. This can be changed at any time.
There are 3 volume settings to select from. Scroll through these using the bottom button on the Receiver
for the appropriate volume for your location. This can be changed at any time.
You can select between Melody only, Strobe only (useful for hard of hearing persons or locations)
or select both functions together. These are set using the Slide button on the Receiver.
Melody only LEFT position
Strobe only MIDDLE position
Melody & Strobe RIGHT position
• The Receiver can be mounted to a wall on a screw, or fitted with the supplied click in base
for free standing.
• Affix the door press to a smooth surface with double sided tape and screws as required.
Before you drill any hole in the wall, please make sure there are not cables or pipes that
may be accidentally damaged.
There is a nameplate position on the Transmitter. User needs to remove the nameplate cover
and put a suitable size label with their name or other information. Then reassemble.
SELECTING YOUR PERSONAL SETTINGS
AFFIXING THE PRODUCTS
4
The doorbell contains 36 melodies:
1. Ding dong(2 times)
2. Westminster Bell
3. To Alice
4. Tap-Tap
5. Rain Drops
6. Romance de Amor
7. Sonata One
8. Lullaby
9. Memory
10. Jingle Bells
11. Memories of Childhood
12. Turkish March
13. The First Noel
14. Santa Claus is Coming to Town
15. Moon River
16. Yellow Rose of Germany Golden
17. Minuet
18. Cuckoo
19. Cuckoo Waltz
20. My Old Kentucky Home
21. Merry Christmas
22. Sonata Two
23. The Blue Danube
24. Susanna
25. William Tell Overture
26. Radetzky March
27. Turkey in the Straw
28. Spanish Lady
29. Mariage Dha Amour
30. Doraemon
31. Picnic
32. Cancan Remix
33. Auld Lang Syne
34. Happy Birthday
35. Greensleeves
36. The Star-Spangled Banner

5
OPERATION
Press the push button on the Transmitter unit once, it sends a wireless signal to the Receiver which will
play the selected melody. The sound will stop as soon as the melody ends. For repeat sound, press the
button again. Holding the Transmitter button IN will NOT repeat the sound.
If the Receiver does not sound, please check the following:
• Flat batteries in either Transmitter or Receivers-change the batteries.
• Wrong battery polarity in either Transmitter or Receivers-reinsert the batteries.
• Units are out of range-relocate the Receiver within the operation range.
• If leaving the chime unused for long periods, remove the battery from compartment to prevent leakage.
• Dispose of old batteries in accordance with the relevant legislation.
USER HINTS
TECHNICAL SPECIFICATIONS
Receiver
Operating Frequency 433.92 MHz
Operating Range (Free Air) Up to 80 metres
Battery (not included) 2 x AA 1.5V Alkaline batteries
Sound dB(A) Up to 75dB(A)
Strobe Light Yes
Transmitter
Battery (included) 1 x CR2032 Lithium battery
Enclosure rating IP44 - protection from light rain and splashing
Operating Temperature -20°C to +40°C

6
ELECTRICAL COMPLIANCE
This product complies to all relevant NZ/AU compliance standards.
An SDOC (supplier compliance declaration) is available on www.simx.co.nz
Type the product code into Search on the home page, this takes you to the item product page,
a download link is located below the product details on that page.
Distributed by:Simx Limited
Ph:[phone] | Technical Support Ph: [phone]
Email: [e-mail] | www.simx.co.nz
PUB1336 2112
IMPORTANT: PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE WHEN REPLACING BATTERIES
