Singer Studio S18 User manual

1
Extra-Large Sewing Space
With almost 9” x 6” of bed
space to the right of the
needle, the long arm design
allows you to manage quilts
and other large projects with
ease.
Large Back-Lit LCD Screen
Clearly see important
information like a picture of the
selected stitch, recommended
presser foot, tension settings
and more.
Advanced Features Add A Professional Touch
Computerized Sewing Machine with Memory & Editing
Create stitch pattern combinations with the built-in Mem-
ory. Store up to 50 stitch pattern and retrieve them even
after the machine has been turned off. Edit the stitches for
unique project embellishments.
Extension Table Included
The extra-large extension table measure 23” in length by
15” in width. The convenient ruler allows you to make
quick measurements up to 18”.
Large Back-Lit LCD Screen
Clearly see important information like Selected Mode,
Number and Image of Selected Stitch, Stitch Length,
Stitch Width, Single or Twin Needle Settings, Letter and
Image of Recommended Presser Foot, Recommended
Tension Setting, Recommended Presser Foot Pressure
settings. Change the screen’s brightness according to
your room’s lighting. Choose from 10 language options.
Independent Bobbin Winding System
Continue to sew while filling a bobbin! Simply follow the
numbered diagram printed on the top of sewing machine
and your bobbin is full in no time!
The SINGER S18 Studio computerized sewing & quilting
machine provides you with the high performance of a
dealer-grade sewing machine for a fraction of the cost.
Boasting over 400 Built-In Stitches including 7 Styles of
Fully Automatic 1-Step Buttonholes the possibilities are
limitless. This computerized sewing machine allows you
to store up to 50 stitch pattern combinations and recall
them at the touch of a button. With block and script let-
ters and numbers available in 5mm and 7mm sizes, you
can create custom quilt labels appropriate for the project
size. Advanced features like Programmable Needle Up /
Down for quilting and appliquéing, Pattern Elongation,
Stitch Memory with Editing and Automatic Thread Cutter
ensure that this is a sewing machine you will love for
years to come.

2
Easy Threading with
Automatic Needle Threader
Sewing’s biggest timesaver
easily threads the needle
without eye strain. Simply
follow the instructions printed
on the machine for accurate
threading.
Presser Foot Sensor
Ensures the presser foot is in
the proper position for an easy
start. The machine will not
begin to sew if the presser foot
is raised, reducing the chance
of thread bunching.
Automatic Settings Eliminate Guesswork
Automatic Electronic Thread Trimmer
Simply press the scissors button and the top and bobbin
threads are trimmed. You can even program this sewing
machine to automatically trim the threads at the end of a
programmed stitch combinations.
Automatic Stitch Length & Width
Optimal settings for stitch length and width are
automatically set, but can be overridden for more
personalized sewing.
Variable Speed Control
Use the Speed Control lever to set the maximum sewing
speed for precise topstitching or beginner sewing.
Sewing at a maximum speed of 1,000 stitches per minute
allows you to finish your projects efficiently.
Extra-High Presser Foot Lifter
Offers more clearance when sewing bulky fabric.
Top Drop-In Bobbin System
The bobbin loads from the top, so it is easy to insert the
bobbin. Simply follow the illustrations pictured on the
machine. The clear cover makes it easy to monitor the
bobbin thread supply.
Complete Stitch Control
The Electronic Foot Controller provides you with precision
at lower speeds and helps maintain smooth and even
sewing at all speeds. You can sew through multiple layers
of denim and thick quilts at low speeds without worry.
Dual Spool Pins with Retractable Guide
The right spool pin is a must-have with utilizing the
independent bobbin winding system. The retractable spool
guide handles cones of thread with optimal thread tension.
Adjustable Thread Tension
Ensures stable stitch quality regardless of fabric type.
Simply turn the dial on the top of the machine for even
stitches. Consult the LCD screen for recommended thread
tension setting.
Knee Lifter Included
The knee lifter allows for
hands-free raising and
lowering of the presser foot
and is vital when pivoting
and quilting.
Independent Bobbin
Winding System
Continue to sew while filling a
bobbin! Simply follow the
numbered diagram printed on
the top of sewing machine and
your bobbin is full in no time!

3
Specialty Needle Plate
Create perfect seam
allowances on your projects.
Gridlines in Metric and Imperial
measurements are etched into
the stainless steel needle
plate.
Specialty Needle Plate
Seam allowance measurements are etched into the
needle plate and printed on the bobbin cover for precise
stitching. Angular markings including 30, 45, 60, 90 and
120 degrees are perfect for quilting .
Adjustable Presser Foot Pressure
Adjustable presser foot pressure allows you to adjust the
amount of pressure exerted on your fabric while sewing.
The setting of 3 will be optimal for most fabrics, but
decrease the setting for delicate fabrics like chiffon or
increase the setting for high pile fabrics. With up to 11
pounds of presser foot pressure, you never have to worry
about fabric shifting.
Drop Feed with Box Feed Motion
Lower the feed dogs for free-motion embroidery,
monograms and for sewing buttons. The feed dogs move
in a box motion ensuring perfect feeding throughout the
entire feed process.
Mirror Imaging
With just a touch of a button
select stitches can be mirror
imaged, adding even more
stitch variety.
Unleash Your Creativity
15 Needle Positions
Needle position can be changed for individual projects like
inserting zippers or cording and topstitching.
7mm Stitch Width
Most stitches can be set for a maximum width of 7mm
creating attractive satin and decorative stitches.
Locking Stitch Button
Auto-lock decorative and utility stitches with just a push of
the Locking Stitch Button. Three tiny tacking stitches
reinforce patterns and stitches to prevent unraveling.
Automatic Twin Needle Mode
Select stitches automatically adjust for twin needle sewing
with just the touch of a button.
Programmable Needle
Up / Down
The needle can be
programmed to stop in the
highest up position, making it
easier to remove fabric from
the machine. The needle can
be programmed to stop in the
down position which is ideal for
pivoting.
Stitch Elongation
Select the elongation button
and a variety of stitches can be
made two to five times longer
without losing stitch density.

4
Included Presser Feet
All-Purpose Foot
Button Sewing Foot
Overedge Foot
Narrow Rolled Hem Foot
Zipper Foot
Satin Stitch Foot
Blind Hem Foot
Cording Foot
Overcasting Foot
Buttonhole Foot
Darning / Freehand Foot
Quarter Inch Foot
Even Feed / Walking Foot
Open Toe Foot
Included Accessories
Screwdrivers (2)
Needles
Lint Brush
Seam Ripper
Thread Spool Caps (2)
Bobbins (5)
Edge / Quilting Bars (2)
Adjustable Seam Guide
Knee Lifter
Instruction Manual
Quick Start Guide
Power Cord
Foot Controller
Accessory Storage Box
Soft-Sided Dust Cover
Answers At Your Fingertips
Toll-Free Helpline 1-800-4-SINGER (1-800-474-6437)
Monday through Friday, 8:00 a.m. to 4:00 p.m. C.T.
Online Support available any time at singerco.com
Social Media Support allows you to connect with other
sewers for tips and tricks!
YouTube.com/SingerSewingCompany offers a variety of
helpful videos tutorials including the following topics:
Threading, Presser Feet Training, Maintenance and
Troubleshooting.
Put Your Mind at Ease
The SINGER S18 Studio quilting and sewing machine
comes with a limited 25-Year Warranty.
Help Button
Press this button to view alternative applications of certain
stitches and the recommended presser foot.
Specifications
Weight: 26 pounds
Dimensions: 20” length x 9” width, 14” height
Sewing Space Light: 12 V, 5 W
Heavy Duty Metal Frame
Continue to sew while filling a
bobbin! Simply follow the
numbered diagram printed on
the top of sewing machine and
your bobbin is full in no time!

5
7 Fully Automatic Built-In
Buttonhole Styles
Buttonhole sewing is a fully
automatic one-step simple
process providing reliable
results every time.
Quilting Stitches Included
Perfect for all types of quilting!
Modern Quilts, Crazy Quilts,
Traditional Quilts & more.
Push-Button Stitch Selection
Ten of the most popular
stitches are accessible with
one touch. The rest of the
stitches are just a few clicks
away.
Stitches
400+ Built-In Stitches with Stitch Reference Chart
This chart located on the upper lid of the machine allows
you to quickly see all of the 408 built-in stitches and
choose the perfect stitch for your project.
Quick Reference Board
A handy, removable Quick Reference Board easily
attaches to the back of the machine to provide visual
references for each stitch.
2 Styles of Alphabets & Numerals
Personalize projects by adding a monogram, name or
phrase with the built-in block or script style numbers and
alphabets, both available in upper and lower case, stitched
at 5mm or 7mm stitch width.
10 Direct Selection Stitches
80 Quilting Stitches
60 Utility Stitches
258 Alphanumeric Stitches
SINGER, the Cameo “S” Design and STUDIO are exclusive trademarks of The Singer Company Limited S.à r.l or its Affiliates. ©2014 The Singer Company Limited S.à r.l.
or its Affiliates. All rights reserved.
