SIRETTA QUARTZ-GOLD Series User manual

QUARTZ-GOLD
Quick Start Guide
Rev 1.0

Whats in the Box?
This quick start guide is intended for the Siretta QUARTZ-GOLD Series Routers.
If you ordered a router with accessories, you will also receive the following items:
Common Accessories
Ethernet Cable Power Adaptor

Cellular Antenna Power Cable and Connector
The QUARTZ-GOLD DIN Rail
adapter does not come as a
standard part of the accessories
kit, but is available separately.
Please specify when ordering

If you ordered a router with accessories and have opted for either WiFi and/or GPS
variants, then you will also receive one or both of the following items:
Optional Accessories
You will require the following items for conguring your router:
»3G or 4G SIM card with APN details
»Paperclip or SIM card Removal Tool to eject the SIM tray
»PC to congure the router
Additional Items
NOTE -Please ensure your antenna and SIM card are appropriate for the router you are using.
WiFi Blade
(For routers with Wi-Fi antenna)
GPS Antenna
(For routers with GPS option)

Step 1: Use a paperclip or Sim Card Removal Tool to eject the SIM tray on the router.
Step 2: Insert a SIM card into the SIM tray. Close the SIM tray, ensuring it is seated
back in place.

Step 3: ANTENNA CONNECTIONS: Screw the cellular antenna to the main antenna
connector on the router. Twist the antenna connector clock-wise until the antenna is
rmly connected.
Connect the 2 Wi-Fi antennas marked “Wi-Fi1” and “Wi-Fi2” by twisting the
antenna connector clock-wise until the antenna is rmly connected.
If you have a GPS router, connect the GPS antenna to the GPS connector on the
router.
GPSWi-Fi 2 Wi-Fi 1 Cellular

Step 4: LAN CONNECTION: Connect one end of the Ethernet cable into the router
LAN port, connect the other end of the cable into an Ethernet port on your PC.
Step 5: POWER: Plug the green power connector on the power adapter cable into
the router as shown below. Plug the 2.1mm centre pin connector from the plug-top
power supply in to the other end of the power adapter cable.

Table 1. Router LED indication
Step 6: POWER: Select connector type for your power adaptor depending on your
geographical location (UK/EU/USA/AU). Plug the power adaptor to the mains.
Step 7: POWER: Switch on the power. See table below for LED indications when
router is powered on.
Label Colour Status Indication
Cellular
Red Fast blink (0.5s) Cellular ofine
Red Slow blink (1.0s) 3G / UMTS connection
online, poor cellular signal
Red Solid 4G / LTE connection online,
poor cellular signal
Green Slow blink (1.0s) 3G / UMTS connection
online, good cellular signal
Green Solid 4G / LTE connection online,
good cellular signal
WLAN
Green Off WLAN not enabled
Green Fast blink Data transfer
Green Solid Enabled, no data ow

Step 8: IP ADDRESS: Obtain the IP address of your router. You can nd this on the
silver label on the back of your router. Type the IP address of your router into your PC
browser. When prompted for your user name and password use the following:
User name: admin
Password: admin
These credentials are factory defaults. You can set your own user name and password
in the router settings.
Label Colour Status Indication
LAN / WAN
Green Off Not connected
Green Blinking Data transfer
Green Solid Connected, no data ow
Table 1. Router LED indication continued

Step 9: APN SET-UP: On successful login, navigate to the Basic Network > Cellular
tab.
When you arrive at the ‘Cellular Settings’ page, you will need to enter the APN details
for the network provider of your SIM card.
In the image below, we have used the APN details relevant for “EE”. These being:
• APN: everywhere
• Username: eesecure
• Password: secure
You are not required to enter any ‘Proxy’ or ‘Port’ details.

NOTE -If you cannot access the router GUI, please check your local area network settings.
Step 10: CONNECTING TO NETWORK: Click “Save”. Your router will reboot itself. The
router will then connect to the network and is ready for use with your application.
Further Information
For more information when using your router, a range of application notes, hardware
and software user manuals are available to download. You can request these from your
Siretta representative, alternatively these can be downloaded from www.siretta.com
