Sirius XM RAdio XSG2NA-X1 User manual

INFOTAINMENT CENTER
Owner’s Manual
Before using this product, please read this manual fully to ensure correct operation.
Keep the manual at hand for future reference.
XSG2NA-X1

2
THIS IS A DISCLAIMER OF LIABILITY AND DAMAGE RESPONSIBILITY AS
REGARDS TO THE INFOTAINMENT CENTER MANUFACTURER
AND YOUR USE OF THE PRODUCT.
YOU ASSUME TOTAL RESPONSIBILITY AND RISK FOR USING THIS SYSTEM.
Failure to properly focus on the operation of your motor vehicle can result in death, serious injury and
property damage. The Infotainment Center should never be used at a time or in a manner that distracts you
from properly focusing on operation of the motor vehicle in which it is installed.
Always operate the vehicle in a safe manner and in full compliance with speed limits, road safety signs and all
other laws and devices which regulate operation of a motor vehicle.
Always remain aware of driving conditions at all times when using this system while operating a motor vehicle.
Operation of this unit, including its camera, navigation, audio and other features, can be distracting to your
operation of the motor vehicle. While the system is intended to provide both entertainment and helpful
vehicle and navigation information, it is not intended to, nor should you allow it to, distract you from properly
focusing on operating the motor vehicle in which it is installed. It is up to you to minimize or prevent such
distraction.
Learn how to use this system before placing the vehicle in operation. Minimize the amount of time spent
viewing the screen of the unit while driving and use voice prompts whenever possible. Do not attempt to
adjust settings of the system or resolve any malfunction with it while driving. Instead, pull off the road in a safe
and legal manner, and then adjust its settings or deal with any malfunction.
In the event of serious malfunction, disable the unit (turn power off or remove power from the system) and
contact a qualified service personnel.
Your optional navigation feature is intended to assist you with guidance to your destination. The navigation
is NOT intended to replace, supersede or take precedence over any traffic signs, street signs, hazard signs,
etc. IT IS YOUR RESPONSIBILITY TO ENSURE THE ROADS YOU ARE TRAVELLING ARE APPROPRIATE FOR THE
VEHICLE YOU ARE DRIVING.
Do not enter destinations, change settings or access any functions requiring prolonged use of the controls of
the unit while operating your motor vehicle. For safety, pull off the road before making any adjustments to the
system or resolving any navigation discrepancies or questions.
If your Infotainment Center includes optional navigation features please refer to your navigation user manual
for further specific information regarding its features, warnings, instructions and disclaimers.

3
IMPORTANT SAFETY INFORMATION
Safety Information
Read the operating instructions for the Infotainment Center and all other components of the system carefully
before using the system. FAILURE TO OBSERVE THE INSTRUCTIONS GIVEN IN THIS MANUAL MAY CAUSE
INJURY OR DAMAGE AND VOID THE WARRANTY.
Warnings
Observe the following warnings when using this unit:
•The driver should neither watch the display nor operate the system while driving.
Watching the display or operating the system will distract the driver from looking ahead of the vehicle
and can cause accidents. Always stop the vehicle in a safe location and use the parking brake before
watching the display or operating the system. While navigating please use voice prompts.
•Use the proper power supply.
This product is designed for operation with a negative grounded 12 V DC battery system.
Never operate this product with other battery systems, especially not with a 24 V DC battery system.
•Protect the DVD loader mechanism.
Do not insert any foreign objects into the slot of this unit. Only insert appropriate CD or DVD
products.
•Do not disassemble or modify the unit.
Do not disassemble or modify the unit, or attempt to repair the product yourself. This may cause
serious injury or damage and your warranty will be null and void. If the product needs repair, consult
your dealer or contact technical support (see page 5).
•Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an abnormal state (has foreign objects in it, is
exposed to water, is smoking, or smells), turn it off immediately and consult your dealer.
•Refer installation to qualified personnel.
USA-Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference; and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the equipment and the receiver.
- Connect the equipment to outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

4
Notes on Use: Video Sources and On-Screen Display
•Your Infotainment Center is designed to only display video when the parking brake is fully engaged.
•Never attempt to circumvent, defeat or bypass any of these safety features. These designs are
intended to reduce driver distractions.
•Failure to use the safety features as designed could lead to serious injury, death and property
damages. Your manufacturer and partners will not be liable for any injury or loss.
Notes on Use: Liquid Crystal Panel
•Do not cause impact to the liquid crystal panel. Only use your finger to gently touch the LCD panel.
•Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be
hazardous to your health or fatal. If the liquid crystal fluid from LCD contacts your body or clothing,
wash it off with soap immediately.
•When the temperature is very cold or very hot, the image may appear unclear or may move slowly.
•In order to protect the liquid crystal panel, keep it out of direct sunlight while the unit is not in use.
•Sudden changes in the temperature inside the vehicle such as those which occur immediately after
the vehicle’s air conditioner or heater has been turned on may cause condensation (droplets of
water) to form and, as a result, the panel may not work properly. Do not use the unit while these
symptoms are in evidence but leave the unit standing for about an hour and then resume or start use.
•To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff cloth or
volatile solvents such as paint thinner and alcohol.
CAUTION: THIS DVD VIDEO RECORDER IS A CLASS 1 LASER PRODUCT. USE OF CONTROLS, ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR THE PLAYER YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
CAUTION: FOLLOW THE LAWS AND REGULATIONS OF YOUR STATE, PROVINCE OR COUNTRY FOR INSTALLATION.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

5
Customer Feedback
Your Infotainment Center has been designed specifically for use in Recreational Vehicles.
This system has been designed to offer a rich and intuitive feature set that is simple to use
and even easier to enjoy. We have engineered this system based off input from real RV’ers
like you!
We want your feedback. Do you have comments on your Infotainment Center? Questions
about operating the system, suggestions or concerns? Send us a note or talk to one of our
Infotainment Specialists and give us your comments. You can find our contact information at
the bottom of this page.
Product Registration
Please take a moment to fill out your Infotainment Center Registration Card and mail it to
the address provided on it or contact us by phone or email at the address below.
By registering your product you will be kept up to date on any enhancements to the
Infotainment Center. It will also help us expedite any service or support needs you may
have.
River Park Inc.
21953 Protecta Drive
Elkhart, IN 46516
1-800-442-7717
www.riverparkinc.com
For Technical and Warranty questions please contact our Technical Department at the
number above or email us at [email protected]

6
Contents
1Features..............................................................................................................7
2Main Unit Display................................................................................................8
3Setup.................................................................................................................10
3.1 General Settings...........................................................................................10
3.2 Video Setup..................................................................................................11
3.3 Audio Setup..................................................................................................11
4Radio Operation................................................................................................12
5CD Player Operation.........................................................................................13
6USB - MP3/WMA/MP4 Player Operation ..........................................................14
7DVD/VCD Player Operation..............................................................................15
7.1DVD System Settings...................................................................................15
8Bluetooth Operation..........................................................................................17
8.1 Bluetooth Setup............................................................................................17
8.2 Pairing your Phone.......................................................................................17
8.3 Incoming Calls..............................................................................................19
8.4 Outgoing Calls..............................................................................................19
8.5 AV (A2DP Audio Playback over Bluetooth).................................................20
9SiriusXM Satellite Radio....................................................................................21
9.1 Subscribing to SiriusXM Satellite Radio .......................................................21
9.2 Operating SiriusXM Satellite Radio..............................................................21
9.3 Tuning to a channel......................................................................................22
9.4 Parental Control Channel Locking and Channel Skipping............................22
9.4.1 Lock Code...........................................................................................22
9.4.2 Lock Mode/Unlock Mode.....................................................................22
9.4.3 Mature Channel Locking......................................................................23
9.4.4 Channel Locking..................................................................................23
9.4.5 Channel Skip.......................................................................................23
9.5 Artist & Song Alerts.....................................................................................23
9.5.1 Setting Alerts.......................................................................................23
9.5.2 Viewing & Managing Alerts..................................................................23
9.5.3 My Artists & My Songs Virtual Categories...........................................24
9.6 Replay..........................................................................................................24
9.7 SiriusXM Settings Menu...............................................................................24
9.8 Understanding SiriusXM Advisory Messages...............................................25
10 iPod and iPhone AV Interface...........................................................................26
11 Camera (Optional).............................................................................................27
12 Navigation (Optional) ........................................................................................28
13 Premium Remote Control Accessory (Optional) ...............................................29

7
1Features
Motorized 6.95” Touch Screen LCD Display
Picture in Picture (PIP) Display
Audio Information Bar for Navigation Mode
GPS Navigation (Optional)
SiriusXMTM Satellite Radio Ready
AM/FM/RDS Stereo Radio
iPod/iPhone Interface and Control1
DVD R/RW, CD R/RW, VCD Compatible
MP3, WMA, MPEG Audio/Video File Compatible
Bluetooth Hands-Free Calling and Streaming Audio Player (A2DP)2
Rearview Camera Connectivity3
Auxiliary Monitor Support4
USB Input
ESP-Electronic Shock Protection for DVD, MP3, CD
High Power MOSFET Speaker Output 4 X 50W
Steering Wheel Control Compatible
Premium Remote Control (Optional Accessory)
Temperature Sensor/OS Display (Optional Accessory)
Compass Heading Display (Optional)
1iPod/iPhone device not included
2 Compatible mobile phone required
3Will connect to vehicle camera system composite video/audio output
4Auxiliary monitor sold separately

8
2Main Unit Display
The buttons located on the Infotainment Center front display are assigned the same reference here below.
Main unit buttons
1 PWR (Power On/Off) or MUTE 6 PIP (Picture in Picture)
2 Mode (Main Menu) 7 Navigation
3 DIM 8 Eject
4 Volume Down 9 Bluetooth Microphone
5 Volume Up 10 IR Receiver
POWER
1. Turn on the ignition to power up the Infotainment Center. The buttons on the front of the unit light
up. When the Infotainment Center is started up, it will immediately go to the last mode (memory on
playback) before it was turned off.
2. In order to put the unit in standby mode, please press the Power button (PWR) for more than 2
seconds. During standby, the display will show your vehicle graphic or be off. Your preference can be
set in the Settings menu (See page 10). Press the Power button again to start up again.
3. In order to turn the unit off completely remove ignition key and/or ensure any auxiliary battery power
to the system is turned off.
4. Quickly pressing the Power button will mute the audio on your system. Press again or a volume
button to resume audio.
MODE
1. Touch the Mode button to go to the Main Menu.
2. When in the Main Menu, use the touch screen to select the desired functionality.
3. You can also access the Main Menu from any screen by touching the function icon in the top left of
the current screen.
NOTE: When viewing video in full screen please touch the screen once to bring up the screen header
which will display the function icon. Touch the icon to return to the Main Menu.
DIM
1. Press to manually adjust the brightness of the LCD.
-/+ VOLUME CONTROL
1. The volume level can be adjusted on the front of the Infotainment Center display by using the volume
up and volume down buttons or by the steering wheel control buttons (optional).
2. The volume level can be muted completely by briefly pressing the PWR button on the front of the
Infotainment Center. The MUTE logo will appear the display.
6
1
2
3
4
7
8
9
1
0
5

9
PIP (Picture in Picture)
1. Your Infotainment Center is equipped with PIP. This button will toggle between PIP and full screen of
the active source (see page 11 for more details on this feature).
NAV
1. Press the NAV button to go to the navigation system.
2. While viewing your navigation press the NAV button to return to your active source. If you are
running a navigational route, audio voice prompts will continue to be heard over your speakers
according to the NAV audio settings you have selected in the settings menu (see page 11).
3. To hear only your navigation audio voice prompts press and hold the NAV button for 2 seconds. This
will mute your current audio source until you leave the navigation screen.
EJECT
1. By pushing the EJECT button, the LCD display will move to its lowest position. When a CD/DVD is in
the player, it will be ejected automatically. When the display is in the lowest position, a CD/DVD can
be inserted. Please note that the display will automatically go up again after a series of beep tones
unless beep tone has been turned off (see page 10).
Main Menu
The Infotainment Center is designed for simple
maneuvering throughout. The screen shown on the right
is the MAIN MENU screen. From here you can choose
which function to access by touching the appropriate
icon on the LCD display. To return back to the Main
Menu or change the active source touch the icon in the
top left corner of any screen.
If the device is left idle on the Main Menu or on any
system settings screen the video will revert back to the
active source (radio, etc.) after 15 seconds.
Information Bar
The top area of the screen is the audio information bar.
This area will display the current audio source, time,
Bluetooth connection status and optional
TEMP/Compass information.
To return back to the main menu touch the audio source
icon.
To view the information bar during video playback or
manual camera view, touch the screen once to display.
Touch the audio icon to return to the main menu.

10
3Setup
3.1 General Settings
Access the System Settings by using the Settings icon in the Main Menu. The first screen
shown is the first page of the system setup. The pages of the Settings menu can be
changed by using the on-screen button in the top right corner. To exit the Settings menu
at any time, press the Settings icon in the top left of the screen.
System Settings page one (1/3):
Tilt Position: This option allows the manual control of
the tilt mechanism behind the LCD screen. Here you can
set the angle of the LCD display.
Tilt Movement: The LCD panel will close during power
down and return to its set position if Auto is selected.
AUX Zone: This option selects the AV source for a display
connected to the AV output. The following sources can
be selected: Current/DVD/CAM/NAV/AUX/OFF. Audio
only sources of Radio/SIRIUSXM/iPod may be selected.
Control of most functions must be done from the main
screen.
Language: Here the language of the User Interface can be selected (English, Spanish, French).
Beep Tone: Turn ON/OFF audible sound when touching the LCD screen. The Beep Tone will also provide
warning of LCD display closing and other cues.
Rear View: This option selects whether a rear view camera is connected. When ON the display will
automatically switch to camera mode when the reverse gear is engaged or a trigger signal is received. When
no camera is connected, select OFF.
NOTE: Please use all available safety features and procedures to ensure proper driving to avoid damage and/or
injury.
System Settings page two (2/3):
Standby Screen: Selecting ON, the Infotainment Center
will display your clock when the unit is powered off by
press and hold the PWR button while the vehicle remains
on.
Auto Dim: Set to Auto, LCD will dim with your vehicle
lighting, if equipped.
Temperature: Select units to display temperature
(optional).
Compass Display: Select Direction or Bearing (Optional)
Touch Adjustment: This option allows the user to
calibrate the touch screen accuracy. Follow the on-
screen directions step by step to complete the procedure. This procedure is only necessary when the accuracy
of the touch screen is not good.
Time Set: This option allows setting the time in the system displays. Select Auto to allow your time to be
maintained by the GPS.
System Settings page two (3/3):
Factory Set: With this option, the Infotainment Center can be reset to factory default.
Note: All stored settings, presets, SIRIUSXM content alerts, etc., will be erased and return to original factory
settings. Locked/Skipped channels, lock code in SIRIUSXM will remain unchanged.
