Clarion Nx706e User manual

DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION &

7 ’’ TOUCH PANEL CONTROL

Owner’s manual

NX706E

English

English Owner’s Manual

CAUTIONS:

!CAUTION

ADVARSEL.

OBS!

VAROITUS

This appliance contains a laser system

and is classified as a “CLASS 1 LASER

PRODUCT”. To use this model properly, read

this Owner’s Manual carefully and keep this

manual for your future reference. In case of

any trouble with this player, please contact

your nearest “AUTHORIZED service station”.

To prevent direct exposure to the laser beam,

do not try to open the enclosure.

Apparaten innehåller laserkompo-

nenten som

avger laserstrålning överstigande

gränsen för laserklass 1.

Suojakoteloa si saa avata.

Laite sisältää

laserdiodin, joka lähettää

näkymätöntä

silmille vaarallista lasersäteilyä.

USE OF CONTROLS OR ADJUSTMENTS

OR PERFORMANCE OF PROCEDURES

OTHER THAN THOSE SPECIFIED IN THE

OWNER’S MANUAL MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

Denne mærking er anbragt udvendigt på

apparatet og indikerer, at apparatet arbejder

med laserstråler af klasse 1, hvilket betyder,at

der anvendes laserstråler af svageste klasse,

og at man ikke på apparatets yderside kan

blive udsat for utilladelig kraftig

stråling.

APPARATET BØR KUN ÅBNES AF

FAGFOLK MED SÆRLIGT KENDSKAB TIL

APPARATER MED LASERSTRÅLER!

Indvendigt i apparatet er anbragt den her

gengivne advarselsmækning, som advarer

imod at foretage sådanne indgreb i apparatet,

at man kan komme til at udsaætte sig for

laserstråling.

2NX706E

English

English Owner’s Manual

Contents

1. FEATURES...........................................................................................................4

Expanding Systems ..............................................................................................4

2. PRECAUTIONS....................................................................................................5

3. CAUTIONS ON HANDLING.................................................................................8

Operation Panel ....................................................................................................8

USB Port...............................................................................................................8

Cleaning................................................................................................................8

Handling Discs......................................................................................................9

4. OPERATION PANEL..........................................................................................11

Functions of Buttons...........................................................................................11

5. REMOTE CONTROL..........................................................................................12

Remote Control Functions..................................................................................13

6. MAIN MENU.......................................................................................................15

7. DVD VIDEO PLAYER OPERATIONS ...............................................................16

Discs ...................................................................................................................16

Change DVD System Settings............................................................................17

Watching to a Disc..............................................................................................17

Showing DVD Player Mode Screen ....................................................................18

Operate the DVD Player Menu............................................................................18

Showing Video Files Player Mode Screen..........................................................19

Operate the Video Files Player Menu .................................................................20

Playable Video Disc Formats..............................................................................21

8. CD PLAYER OPERATIONS ..............................................................................22

Listening to a Disc/Ejecting a Disc .....................................................................22

Showing CD Player Mode Screen ......................................................................22

Operate the CD Player Menu..............................................................................22

Listening to Compressed Audio .........................................................................23

Tag Display Function ..........................................................................................23

Playback MP3/WMA/AAC menu ........................................................................24

9. USB AUDIO OPERATIONS ..............................................................................25

Notes on Using USB Memories..........................................................................25

Select USB Audio Mode.....................................................................................25

Playing Audio Files in USB Memory ...................................................................26

10. USB VIDEO OPERATIONS..............................................................................27

Notes on Using USB Memory Device.................................................................27

Select USB Video Mode .....................................................................................27

Playing Video Files in USB Memory ...................................................................27

Playable Video Format........................................................................................27

11. iPod OPERATIONS..........................................................................................29

Notes on Using an iPod/iPhone..........................................................................29

iPod Audio Menu Operations..............................................................................29

iPod Audio ID3 Mode Screen .............................................................................29

iPod Audio Playlist Mode Screen .......................................................................30

iPod Audio List Mode Screen .............................................................................30

iPod Audio Bluetooth Mode................................................................................30

12. Bluetooth AUDIO PLAYER OPERATIONS.....................................................31

Selecting the Bluetooth Audio Mode..................................................................31

Bluetooth Audio Player Settings.........................................................................31

Registering Your Bluetooth Audio Player (Pairing) .............................................31

Selecting the Bluetooth Audio Player .................................................................32

Controlling the Bluetooth Audio Player...............................................................32

13. Bluetooth

TELEPHONE OPERATIONS ............................................................33

Select the BT Phone Mode.................................................................................33

NX706E

English

English Owner’s Manual

Bluetooth Telephone Settings ............................................................................33

Registering Your Phone (Pairing)........................................................................34

Select the Phone.................................................................................................34

Get the Phone Book Data...................................................................................34

Telephone Operations ........................................................................................34

Using Siri Eyes Free Function.............................................................................36

14. TUNER OPERATIONS.....................................................................................37

15. DAB

OPERATIONS.......................................................................................................39

16. TV

OPERATIONS

..............................................................................................41

17. HDMI MODE ....................................................................................................42

Wire Connection of HDMI Mode.........................................................................42

Select HDMI Source ..........................................................................................43

18. AUX .................................................................................................................44

19. CAMERA INPUT OPERATIONS .....................................................................44

20. REAR SOURCE OPERATIONS.......................................................................45

DVD Video in Rear ..............................................................................................45

DVD Video Rear Source Control Info Mode. ......................................................45

DVD Video Rear Source Control Direct Mode. ..................................................45

AUX Video in Rear...............................................................................................46

21. FULL DIGITAL SOUND SYSTEM....................................................................46

22. SETTING OPERATIONS..................................................................................47

General Setup Menu...........................................................................................47

Video Setup Menu ..............................................................................................48

Audio Setup Menu ..............................................................................................48

Navigation Setup Menu ......................................................................................48

Others Setup Menu.............................................................................................49

Set the Anti-Theft Code......................................................................................49

23. TROUBLESHOOTING .....................................................................................50

General................................................................................................................50

DVD Player..........................................................................................................50

USB Device.........................................................................................................51

Bluetooth ............................................................................................................51

TFT Screen..........................................................................................................52

24. ERROR DISPLAY.............................................................................................53

DVD/CD Player ...................................................................................................53

25. SPECIFICATIONS............................................................................................54

26. WIRE CONNECTION GUIDE...........................................................................56

4NX706E

English

English Owner’s Manual

1. FEATURES

Expanding Systems

NOTE:

•

The items listed outside of the frames are the commercial products generally sold.

• CCA-771, CCA-802:Sold separately.

Optical Digital Output

6ch RCA Output with HPF/LPF and 15 Band Graphic Equalizer

FLAC(Free Lossless Audio Codec) Compatible with ID3-TAG Display

iPod

Expanding Visual Features

Rear Monitor Rear Vision Camera

Expanding Audio Features

External Power

Amplier

External Sound

Processor

iPhone

USB

Memory

Bluetooth

Telephone

iPhone/Smartphone via HDMI

Approved

Checked

Designed

Unit

Quantity

Tolerance

Scale

Model

Name

Finished

Material

Revision record

0.60

0.30

0.40≥50~100

0.20

ANGLE

≥100

40′

90′

0.50

0.60

20′

0.30

180′

1.00

≥5~20

≥20~50

0~5

0.15

0.20

0.30

0.10

0.15

0.10

0.15

0.07

SIZE

TOLERANCE

0.30

0.40

0.20

BCD E F

Date

Approved

DO NOT SCALE

Designed

1机器线框图

CNE-8288C-CL

Full

Digital

Sound

READY

Connect via CCA-771, CCA-802

Expanding tuner/

TV feature

NX706E

English

English Owner’s Manual

2. PRECAUTIONS

WARNING

• For your safety, the driver should not watch any video sources and/or operate the controls while driving.

Please note that watching and operating any video sources while driving are prohibited by law in some

countries. Also, while driving, keep the volume to a level at which external sounds can be heard.

• Do not disassemble or modify this unit. It may cause an accident, re, or electric shock.

• Do not use this unit when a trouble exists, such as no screen content appears or no sound is

audible. It may cause an accident, re, or electric shock. For that case, consult your authorized

dealer or a nearest Clarion service center.

• In case of a problem, such as any material has been entered in the unit, the unit gets wet, or

smoke or strange smells come out of the unit, etc., stop using this unit immediately, and consult

your authorized dealer or a nearest Clarion service center.

Using it in that condition may cause an accident, re, or electric shock.

• Use a fuse with the same specication only when replacing the fuse.

Using a fuse with a different specication may causes a re.

• For the installation of this unit or a change in the installation, ask your authorized dealer or a

nearest Clarion service center for safety. Professional skills and experiences are required to do

so.

• This navigation system should not be used to replace your own judgment. No itinerary suggested

by this navigation system should ever override any highway regulations, your own judgment, or a

knowledge of safe driving practices. Do not follow the navigation system’s suggested itinerary if it

would cause you to perform a dangerous or illegal act, place you in a dangerous situation, or take

you into an area you consider unsafe.

• The advice provided by the navigation system is to be regarded as a suggestion only. There may

be times when the navigation system displays the vehicle’s location incorrectly, fails to suggest

the shortest route, or fails to direct you to your desired destination. In such instances, rely on your

own driving judgment, taking into account the driving conditions at the time.

• Do not use the navigation system to locate emergency services. The database does not contain

a complete listing of emergency services such as police stations, re halls, hospitals and walk-in

clinics. Please show discretion and ask for directions in such instances.

• As the driver, you alone are responsible for your driving safety.

• In order to avoid a trafc accident, do not operate the system while driving.

• In order to avoid a trafc accident, operate the system only when the vehicle is stopped at a safe

place and the parking brake is on.

• In order to avoid a trafc accident or trafc offense, remember that actual road conditions and

trafc regulations take precedence over the information contained on the navigation system.

• The software may contain inaccurate or incomplete information due to the passage of time,

changing circumstances, and the sources of information used. Please respect current trafc

conditions and regulations at all times while driving.

• Where actual road conditions and highway regulations differ from the information contained on

the navigation system, abide by the highway regulations.

• Keep the amount of time spent viewing the screen while driving to a strict minimum.

• The navigation system does not provide, nor represent in any way information on: trafc and

highway regulations; technical aspects of the vehicle including weight, height, width, load and

speed limits; road conditions including grade, percentage of incline and surface conditions;

obstacles such as the height and width of bridges and tunnels; and other current driving or road

conditions. Always rely on your own judgment when driving a car, taking into account current

driving conditions.

6NX706E

English

English Owner’s Manual

• Changes or modications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

NX706E

English

English Owner’s Manual

NX706E

CNE-8288C-CL

杨荣

2016.03.04

1:1

机身大贴纸

技术说明：

1、大小65x75mm,红色外框线为刀模线。

2、材质，80g铜版纸,过哑胶。

3、内容印刷黑色:PANTONE Black C。

4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕；

切边务必整齐,不得歪斜。

D025034

10 R -051618

7-8288-1004-00-01

1.When the inside of the car is very cold and

the player is used soon after switching on the

heater, moisture may form on the disc (DVD/

CD) or the optical parts of the player and

proper playback may not be possible. If

moisture forms on the disc (DVD/CD), wipe it

o with a soft cloth. If moisture forms on the

optical parts of the player, do not use the

player for about one hour. The condensation

will disappear naturally allowing normal

operation.

2.Driving on extremely bumpy roads which

cause severe vibration may cause the sound

to skip.

3.This unit uses a precision mechanism. Even

in the event that trouble arises, never open

the case, disassemble the unit, or lubricate

the rotating parts.

8NX706E

English

English Owner’s Manual

3. CAUTIONS ON HANDLING

Operation Panel

• The operation panel will operate properly in a

temperature range of 0˚ to 60˚ C.

• Do not allow any liquids on the set from

drinks, umbrellas etc. Doing so may damage

the internal circuitry.

• Do not disassemble or modify the set in any

way. Doing so may result in damage.

• Subjecting the operation panel to shocks

may result in breakage, deformation or other

damage.

• Do not let cigarettes burn the display.

• If a problem should occur, have the set

inspected at your store of purchase.

• The remote control unit may not work if the

remote control sensor is exposed to direct

sunlight.

• In extremely cold weather, the display

movement may slow down and the display

may darken, but this is not a malfunction.

The display will work normally when the

temperature increases.

• Small black and shiny spots inside the liquid

crystal panel are normal for LCD products.

For a longer service life, be sure to read the following cautions.

Cleaning

• Cleaningthecabinet

Use a soft, dry cloth and gently wipe off

the dirt. For tough dirt, apply some neutral

detergent diluted in water to a soft cloth, wipe

off the dirt gently, then wipe again with a dry

cloth.

Do not use benzene, thinner, car cleaner, etc.,

as these substances may damage the cabinet

or cause the paint to peel. Also, leaving rubber

or plastic products in contact with the cabinet

for long periods of time may cause stains.

• Cleaningtheliquidcrystalpanel

The liquid crystal panel tends to collect dust,

so wipe it off occasionally with a soft cloth.

The surface is easily scratched, so do not rub

it with hard objects.

USB Port

• The USB memory sticks must be recognized

as “USB mass storage class” to work

properly. Some models may not operate

correctly.

When the memorized data is lost or

damaged by any chance, Clarion shall not

be liable for any damage.

When using an USB memory stick, we

recommend that you backup your data stored

on it before by using a personal computer etc.

• Data les may be broken when using USB

memory sticks in the following situation:

When disconnecting the USB memory stick or

turning the power off during writing or reading

data. When affected by static electricity or

electric noise. Connect/disconnect the USB

memory stick when it is not accessed.

• Connecting with the computer is not

supported.

• Connecting with the USB Hub is not

supported.

NX706E

English

English Owner’s Manual

Handling Discs

Handling

• New discs may have some roughness

around the edges. If such discs are used,

the player may not work or the sound

may skip. Use a ball-point pen or the like

to remove any roughness from the edge

of the disc.

Ball-point pen

Roughness

Never stick labels on the surface of the

disc or mark the surface with a pencil or

pen.

• Never play a disc with any cellophane

tape or other glue on it or with peeling off

marks. If you try to play such a disc, you

may not be able to get it back out of the

DVD player or it may damage the DVD

player.

• Do not use discs that have large

scratches, are misshapen, cracked,

etc. Use of such discs may cause

misoperation or damage.

• To remove a disc from its storage case,

press down on the center of the case

and lift the disc out, holding it carefully

by the edges.

• Do not use commercially available disc

protection sheets or discs equipped with

stabilizers, etc. These may damage the

disc or cause breakdown of the internal

mechanism.

Storage

• Do not expose discs to direct sunlight or

any heat source.

• Do not expose discs to excess humidity

or dust.

• Do not expose discs to direct heat from

heaters.

Cleaning

• To remove ngermarks and dust, use

a soft cloth and wipe in a straight

line from the center of the disc to the

circumference.

• Do not use any solvents, such as

commercially available cleaners, anti-

static spray, or thinner to clean discs.

• After using special disc cleaner, let the

disc dry off well before playing it.

On Discs

• Never turn off the power and remove the

unit from the car with a disc loaded.

CAUTION

For your safety, the driver should not

insert or eject a disc while driving.

Table of contents

Clarion NX706E User manual

Popular Car Video System manuals by other brands
