Sirius XM RAdio SXV100 User manual

12 3 4 5
Thank you for purchasing the SXV100 SiriusXM Connect Vehicle Tuner.
Consult your headunit User Guide for features and detailed operational
instructions.
For questions or support, please visit www.siriusxm.com or call 1-800-967-2346.
What’s In the Box? Required:
Check Your Headunit For Compatibility
SXV100 Vehicle Tuner
SXV100
VEHICLETUNER
Make the Connections
You’ll need to access the back of the SiriusXM-Ready headunit so you can plug the
SXV100 Vehicle Tuner into it. This may require you to remove the headunit from the
dashboard. If you are uncomfortable with this step, consult a professional installer.
Be sure to turn OFF the SiriusXM-Ready headunit before connecting the SXV100
Vehicle Tuner. Locate the SiriusXM connector on the headunit and connect the
SXV100. The headunit may have a panel mount type connector, or it may have a
pigtail type connector.
Plug the Satellite Radio antenna
into the SXV100 Vehicle Tuner
(sold separately). The SXV100 is
compatible with all aftermarket XM
antennas.
Secure the Tuner
Secure the SXV100 Vehicle Tuner behind the vehicle headunit location or under
the dash using wire ties (not included).
Thread the wire ties through the moulded brackets on the underside of the Tuner
as shown. Then secure it to a bracket or wiring harness using the wire ties. Avoid
brackets with sharp edges and any moving parts such as gas and brake pedals.
Reinstall the vehicle headunit if it had been removed from the dashboard.
Subscribe
You can subscribe to the SiriusXM service anytime by following these steps:
1 Make sure your vehicle headunit is turned on and that Satellite Radio is
selected. Verify that you are receiving the SiriusXM signal so that you can
hear the SiriusXM audio.
2 Make a note of your Radio ID. You can find it on channel 0, on a label on the
bottom of the packaging, and on the label on the bottom of your SXV100
Vehicle Tuner.
NOTE! The Radio ID does not use the letters I, O, S, or F.
3 Activate your service:
• Online: Go to www.siriusxm.com and click on “How Do I Activate a Radio?”
and then click on the “Activate my radio” button to subscribe.
OR
• By phone: Call 1-800-XM-RADIO (1-800-967-2346)
4 Activation usually takes 10 to 15 minutes, but may take up to an hour. We
recommend that your vehicle headunit remain on until subscribed. When
your service is activated, you will see the SUBSCRIPTION UPDATED, PRESS
ENTER TO CONTINUE or similar message displayed on the headunit. Once
subscribed, you can tune to channels in your subscription plan.
5 Activation signals can be sent again at any time by visiting
www.siriusxm.com/refresh and follow the directions to refresh your Radio.
Note: The SXV100 works on the XM Network.
PANEL MOUNT
TYPE CONNECTOR
Connector
orientation
may vary
PIGTAIL TYPE
CONNECTOR
To disconnect,
slide lock back
Products with this logo are compatible
Products with these logos are not compatible
If your headunit has the official SiriusXM-
Ready logo it is compatible with the SXV100
Vehicle Tuner. All SiriusXM-Ready headunits
include a dedicated connector, allowing for
quick and easy connection of the SXV100
tuner.
The SXV100 requires a
Satellite Radio antenna which
is sold separately. The antenna
may be purchased from
siriusxm.com/accessories or
from a SiriusXM retailer.
The SXV100 is compatible with
all aftermarket XM antennas.
Troubleshooting
The troubleshooting information listed below is for general reference. Consult
the User Guide for your SiriusXM-Ready headunit for specific instructions for
operation and advisory messages which may be displayed. Your headunit may
display slightly different messages.
If you see this on the screen: Try this:
No Signal (NoSignal) •Make sure that the vehicle is outdoors with a clear view of
the southern sky.
•Make sure the Satellite Radio antenna is mounted outside
of the vehicle.
•Move your antenna away from any obstructed area. For
example, if you are parked in an underground garage, you
should receive a signal after leaving the garage.
Check Antenna (Chek
Antenna, CHK Antena, Chek
Ant)
•Make sure that the Satellite Radio antenna cable is firmly
and securely plugged into the SXV100 Vehicle Tuner.
•Make sure the antenna cable is not bent or broken.
•Turn the headunit off, then on, to reset this message. If the
message persists, most likely the antenna cable has been
damaged. Replace the antenna.
Antenna Disconnected Check the antenna connection to make sure it is fully
plugged into the SXV100 Vehicle Tuner.
Antenna Cable Shorted Replace the antenna.
Check Tuner (Chek Tuner,
Chk Tunr)
Check the SXV100 Vehicle Tuner connection to the headunit
and make sure it is plugged all the way in.
Channel Not Available (Chan
Unavailable, Ch Unavailable,
Ch Unavail, Ch Unavl)
The channel you have selected is not available.
Channel Not Subscribed (CH
Unsubscribed, Chan Unsub,
Ch Unsub)
The channel you have selected is not part of your current
subscription plan. Call 1-800-967-2346 to subscribe.

67 8
Subscription Updated- Press
enter to continue (or similar
message)
Your subscription has been updated, press the appropriate
button (or other identified key) to continue.
If this happens: Try this:
You do not receive all the
channels to which you
subscribe
•If you have not yet activated your service, call
1-800-967-2346 .
•Go to www.siriusxm.com/refresh and follow the directions
to refresh your SXV100 Vehicle Tuner.
No song title or artist name
is displayed
The information may not be available or updates may be in
progress.
Traffic and Weather channels
sound different from other
channels
These channels use a different audio technology than
other channels, so they often sound different from other
channels.
Audio fades or has static
when listening
•Check all the cables for a firm and secure connection.
•Be sure that your headunit is correctly wired to the
vehicle electrical system.
Specifications
Tuner
Dimensions . . . . . . . . . . . . . . . . . . . . . .3.42 in (W) x 2 in (H) x 0.7 in (D)
87mm (W) x 51.8mm (H) x 17.9mm (D)
Weight...........................3oz(85g)
Pigtail Cable Length. . . . . . . . . . . . . . .25.6 in (650 mm)
Power Requirements . . . . . . . . . . . . . .12v DC, 0.3 A (MAX) supplied by headunit)
Operating Temperature . . . . . . . . . . . .-4°F to +140°F (-20°C to +60°C)
Antenna Connector . . . . . . . . . . . . . . . . .SMB
Network Operation. . . . . . . . . . . . . . . . . .XM Network Only
Specifications are subject to change without notice.
FCC Statement
The user is cautioned that changes or modifications not expressly approved by Sirius XM
Radio Inc. can void the user’s authority to operate this device. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the installation instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
 •Reorientorrelocatethereceivingantennaoftheaffectedreceiver.
 •IncreasetheseparationbetweentheSiriusXMequipmentandtheaffectedreceiver.
 •ConnecttheSiriusXMequipmentintoanoutletonacircuitdifferentfromthattowhich
the affected receiver is connected.
 •Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
WARNING! The FCC and FAA have not certified Satellite Radio Receiver use in any aircraft
(neither portable nor permanent installation). Therefore, Sirus XM Radio Inc. cannot support
this type of application or installation.
Patent Information
It is prohibited to, and you agree that you will not, copy, decompile, disassemble, reverse engineer,
hack, manipulate, or otherwise access and/or make available any technology incorporated in
this product. Furthermore, the AMBE®voice compression software included in this product is
protected by intellectual property rights including patent rights, copyrights, and trade secrets of
Digital Voice Systems, Inc. The software is licensed solely for use within this product. The music,
talk, news, entertainment, data, and other content on the Services are protected by copyright
and other intellectual property laws and all ownership rights remain with the respective content
and data service providers. You are prohibited from any export of the content and/or data (or
derivative thereof ) except in compliance with applicable export laws, rules and regulations.
The user of this or any other software contained in a SiriusXM radio is explicitly prohibited from
attempting to copy, decompile, reverse engineer, hack, manipulate or disassemble the object code,
or in any other way convert the object code into human-readable form.
Environmental Information
Follow local guidelines for waste disposal when discarding packaging and electronic
appliances.
This product is packaged with cardboard, polyethylene, etc., and does not contain any
unnecessary materials.
WARNING: This product contains chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
Copyrights and Trademarks
©2011 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of
Sirius XM Radio Inc. and its subsidiaries. Visit www.siriusxm.com/xmlineup for updates. All
programming/channel lineup/XM service subject to change or preemption. All other marks and
logos are the property of their respective owners. All rights reserved.
Important Legal Notice About Your Subscription
Hardware, subscription and activation fee required. Other fees and taxes will apply. Hardware
and subscription sold separately. Service automatically renews for additional periods of the
same length as the Plan you choose, at the then current renewal rate unless you call to
cancel. Pricing and programming subject to change. Subscription governed by the Customer
Agreement (see www.siriusxm.com). SiriusXM U.S. Satellite Service available only to those
at least 18 years of age in the 48 contiguous USA and DC, with Sirius also available in PR
(with coverage limitations), while SiriusXM Internet Radio is available throughout our satellite
service area and also in AK and HI.
Important Legal Notice About Installation
Installation instructions are provided for your convenience. You must determine if you have
the knowledge, skills, and ability required to properly perform installation. Professional
installation is recommended. SiriusXM shall have no liability for damage/injury resulting from
the installation/use of any SiriusXM or other products. You must ensure that all products
are installed in adherence with local laws and regulations and in such a manner as to allow
a vehicle to be operated safely and without distraction. SiriusXM product warranties do not
cover the installation, removal, or reinstallation of any product.
www.siriusxm.com
Sirius XM Radio Inc.
1221 Avenue of the Americas
New York, NY 10020
1.800.967.2346
© 2011 Sirius XM Radio Inc.
SXV100B Installation Guide (SXV100IG1010) 031111b
SXV100
SiriusXM Connect
Vehicle Tuner
For Special Market Applications
Installation Guide
