Sistemalux MEGAZIP S8500 User manual

A
A- PREPARE THE DESIRED DRAINING EQUIPMENT TO ENSURE COMPLETE BACK BOX DRAINAGE IN UNDER 30 MINUTES:
NEW INSTALLATION: 8" TO 12" (20-30cm) OF GRAVEL UNDER THE BACK BOX.
OVER EXISTING SURFACES: INSTALL A DRAINING PIPE TO THE BACK BOX.
B- REMOVE THE DESIRED KNOCKOUT AND INSTALL AN APPROPRIATE ELECTRICAL CONDUIT (NOT INCLUDED) INTO THE BACK BOX.
C- FEED CABLE THROUGHT THE ELECTRICAL CONDUIT.
D- POUR CONCRETE IN AND MAKE SURE THAT THE BACK BOX OPENING IS FLUSH WITH THE CONCRETE.
A + B + C
D
scale 1:12
BACK BOX INSTALLATION
MEGAZIP
WALK-OVER ROUND MODELS: S8500, S8501, S8502, S8568, S8570, S8571, S8572, S8578
WALK-OVER SQUARE MODELS: S8580, S8581, S8582, S8588, S8590, S8591, S8592, S8598
INSTRUCTIONS SHEET PAGE: 1 of 2
INS-685
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
JP - R0Last update: April 28, 2021
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
8" - 12"
(20 - 30cm)
BACK BOX
DRAINING PIPE
NO!
OK!
NO!
C
B
CABLE
ELECTRICAL CONDUIT
(NOT INCLUDED)
KNOCKOUT
GRAVEL
BACK BOX
A
CONCRETE
CONCRETE WITH DRAINING PIPE CONCRETE WITH GRAVEL
BEAM
ORIENTATION
WALL
SPOT, NARROW FLOOD,
FLOOD & ASSYMETRIC OPTIC
BEAM ORIENTATION
90°

WIRING DIAGRAM
DIMMING 0-10V (D10)
120-277V
MEGAZIP
WALK-OVER ROUND MODELS: S8500, S8501, S8502, S8568, S8570, S8571, S8572, S8578
WALK-OVER SQUARE MODELS: S8580, S8581, S8582, S8588, S8590, S8591, S8592, S8598
INSTRUCTIONS SHEET PAGE: 2 of 2
INS-685
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
JP - R0Last update: April 28, 2021
FIXTURE INSTALLATION
INTEGRAL DRIVER (120-277V)
DIMMING 0-10V (15%)
ONLY FOLLOW STEP A TO C FOR SPOT, NARROW FLOOD, FLOOD AND ASYMMETRICAL OPTIC ADJUSTEMENTS.
A- UNSCREW THE (4) COVER RING PHILLIPS SCREWS FROM UNDER THE FIXTURE BODY AND PULL OUT THE GLASS WITH SILICONE GASKET.
B-
FOR MODELS WITH SPOT, NARROW FLOOD, FLOOD AND ASYMMETRIC OPTICS:
SET TO THE DESIRED ANGLE (±15°) BY PUSHING ON THE OPTIC NOTCHES.
C- REASSEMBLE THE FIXTURE (REVERSE STEP A).
D- MAKE THE NECESSARY WIRE CONNECTIONS (FOLLOWING WIRING DIAGRAM) USING WATERTIGHT CONNECTORS (SOLD SEPARATELY) .
E- SCREW THE (4) FIXTURE PHILLIPS SCREWS IN THE BACK BOX.
A + B + C
D
PHILLIPS SCREW
(INCLUDED)
BACK BOX
E
A
C
A
C
±15°
OPTIC NOTCH
FIXTURE OPTIC
B
COVER RING
FIXTURE BODY
PHILLIPS SCREW
GLASS WITH
SILICONE GASKET
COVER RING
FIXTURE CABLES
LIVE
(black)
NEUTRAL
(white)
DIM +
(red)
DIM -
(brown)
GROUND
(green)
WATERTIGHT
CONNECTOR
(SOLD SEPARATELY)
