Sistemalux MINIREEF User manual

MINIREEF / REEF
MODELS : S5210, S5213, S5223, S5233 / S5217, S5227, S5237, S5277
INSTRUCTIONS SHEET PAGE: 1 of 4
INS-587
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
CL - R1Last update: September 02, 2020
C
180mm
(7
1
⁄
16
") 242mm
(9½")
9mm
(⅜")
107mm
(4¼")
R4
9mm
(⅜")
R4
22.5mm
(⅞") 32mm
(1¼")
A- UNSCREW THE (4) SCREWS AROUND THE HEAD FIXTURE USING THE ALLEN KEY (INCLUDED).
B- REMOVE THE HEAD FIXTURE SLOWLY FROM THE BASE AND DISCONNECT THE LED QUICK CONNECTOR AND GROUND.
C- PREPARE SURFACE FOR INSTALLATION (SEE DRAWING BELOW FOR ORIENTATION).
SURFACE INSTALLATION ON 4"JUNCTION BOX.
INTEGRAL DRIVER (120V - 277V)
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
4 FIXING
HOLES 4 FIXING
HOLES
2 CABLE
ENTRIES
2 CABLE
ENTRIES
79mm
(3⅛")
REEF
MINIREEF
A + B
GROUND
CONNECTOR
B
A
SCREWS
FIXTURE HEAD
LED QUICK
CONNECTOR
ALLEN KEY
(INCLUDED)
FIXTURE
BASE
2x90°
A
180°
A
360°
A
DISCONNECT THE MAIN LINE BEFORE INSTALLATION TO AVOID ELECTRICAL SHOCK OR DAMAGE TO LED ARRAY.

MINIREEF / REEF
MODELS : S5210, S5213, S5223, S5233 / S5217, S5227, S5237, S5277
INSTRUCTIONS SHEET PAGE: 2 of 4
INS-587
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
CL - R1Last update: September 02, 2020
JUNCTION BOX
(NOT INCLUDED)
WATERTIGHT TWIST CONNECTORS
(NOT INCLUDED)
D- MAKE ALL NECESSARY CONNECTIONS (FOLLOWING WIRING DIAGRAM) USING TWIST CONNECTORS (NOT INCLUDED).
E- SCREW THE FIXTURE BASE TO THE SURFACE WITH (4) SCREWS (NOT INCLUDED).
F- RECONNECT THE FIXTURE HEAD TO THE BASE, USING THE LED QUICK CONNECTOR.
G- TIGHTEN THE (4) SCREWS AROUND THE HEAD.
WIRING DIAGRAM
FIXTURE CABLES
LIVE
(black)
NEUTRAL
(white)
GROUND
(green)
NO DIMMING
D + E
F + G
SCREW
LED QUICK
CONNECTOR
D
E
F
G
CLICK
GROUND
ALLEN KEY
(INCLUDED)
QUICK
CONNECTOR
8-32 OR 10-32 SCREWS
(NOT INCLUDED)

MINIREEF / REEF
MODELS : S5210, S5213, S5223, S5233 / S5217, S5227, S5237, S5277
INSTRUCTIONS SHEET PAGE: 3 of 4
INS-587
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
CL - R1Last update: September 02, 2020
OK
90°
NO
8⅞"
(225mm)
CONCRETE
FLANGE
SCREW
ELECTRICAL
CONDUIT
A
A- UNSCREW THE (4) SCREWS AROUND THE HEAD FIXTURE USING THE ALLEN KEY (INCLUDED).
B- REMOVE THE HEAD FIXTURE SLOWLY FROM THE BASE AND DISCONNECT THE LED QUICK CONNECTOR AND THE GROUND.
C- DIG A HOLE (SEE DIMENSION BELOW), PUT THE FLANGE AND ELECTRICAL CONDUIT INTO THE GROUND. POUR CONCRETE AND MAKE
SURE IT IS LEVELED WITH THE FLANGE.
* DEPENDING ON MODEL ORDERED, SEE DRAWING BELOW TO POSITION FLANGE FOR OPTIMAL BEAM ORIENTATION.
D- RECONNECT THE FIXTURE HEAD TO THE BASE, USING THE LED QUICK CONNECTOR.
E- TIGHTEN THE (4) SCREWS AROUND THE HEAD.
GROUND INSTALLATION IN CONCRETE WITH FLANGE (S5301, S5200, S5203).
INTEGRAL DRIVER (120V - 277V)
2x90°
A
180°
360°
FLANGE
A
A
C + D + E
B
E
D
ALLEN KEY
(INCLUDED)
CLICK
A + B
A
SCREWS
FIXTURE HEAD
ALLEN KEY
(INCLUDED)
NO
GROUND
CONNECTOR
LED QUICK
CONNECTOR
FIXTURE
BASE
B
Flange dimensionsFlange code
S5200
10
1
⁄
16
" x 8⅞" (250 x 225mm)
7½" x 8⅞" (190 x 225mm)
S5203
MINIREEF S.5240, S5243, S5253, S5263
REEF S.5247, S5257, S5267, S5297
Model Model Code
DISCONNECT THE MAIN LINE BEFORE INSTALLATION TO AVOID ELECTRICAL SHOCK OR DAMAGE TO LED ARRAY.

MINIREEF / REEF
MODELS : S5210, S5213, S5223, S5233 / S5217, S5227, S5237, S5277
INSTRUCTIONS SHEET PAGE: 4 of 4
INS-587
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
CL - R1Last update: September 02, 2020
B
88mm
(3½") 110mm
(4⅜")
120mm
(4¾")
420mm
(16½")
RUBBER MALLET
1
PHILLIPS
SCREWS
(INCLUDED)
A- 1- USE A RUBBER MALLET TO INSERT STAKE INTO THE GROUND.
2- INSERT STAKE TO THE FIRST DISC TO INSURE A LEVELED POSITION WITH THE GROUND.
B- ALIGN THE (4) FIXING HOLES UNDER THE FIXTURE BASE TO THE TOP OF THE STAKE.
C- FEED THE 3' CABLE THROUGH THE STAKE’S CABLE ENTRY HOLE AND USE (4) PHILLIPS SCREWS (INCLUDED) TO INSTALL THE FIXTURE
ON THE STAKE. SCREW THE POWER CABLE TO THE STAKE USING THE CABLE LOCK (INCLUDED).
D- BRING THE 3' POWER CABLE TO THE JUNCTION BOX (SUPPPLIED BY CONTRACTOR).
GROUND INSTALLATION ON STAKE (S.3554, S.5424).
INTEGRAL DRIVER (120V - 277V)
A
2
CABLE ENTRY
HOLE
FIXING HOLES
FIXTURE
BASE
STAKE
POWER
CABLE
FIXTURE
HOLES
CABLE LOCK
(INCLUDED)
CABLE LOCK
(INCLUDED)
C
D
C + D
2x90°
A
180°
A
360°
A
