Skil 6900 User manual

HAMMER DRILL
6900 (F0156900 . . )
6901 (F0156901 . . )
SKIL Europe BV - Konijnenberg 60 08/08 2610399286
4825 BD Breda - The Netherlands
www.skileurope.com
ME77
ORIGINAL INSTRUCTIONS . . . . . . . . . . . . . 9
NOTICE ORIGINALE . . . . . . . . . . . . . . . . . 11
ORIGINALBETRIEBSANLEITUNG . . . . . . 15
ORIGINELE GEBRUIKSAANWIJZING. . . . 18
BRUKSANVISNING I ORIGINAL . . . . . . . . 21
ORIGINAL BRUGSANVISNING . . . . . . . . . 24
ORIGINAL DRIFTSINSTRUKS. . . . . . . . . . 27
ALKUPERÄISET OHJEET . . . . . . . . . . . . . 30
MANUAL ORIGINAL . . . . . . . . . . . . . . . . . 33
MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 36
ISTRUZIONI ORIGINALI . . . . . . . . . . . . . . 39
EREDETI HASZNÁLATI UTASÍTÁS. . . . . . 42
PÒVODNÍM NÁVODEM K POUÎÍVÁNÍ . . . 46
OR‹J‹NAL ‹fiLETME TAL‹MATI . . . . . . . . . 48
INSTRUKCJÑ ORYGINALNÑ. . . . . . . . . . . 51
ОДЛИННИК РУКОВОДСТВА
ПО ЭКСПЛУАТАЦИИ . . . . . . . . . . . . . . . . 55
ОРИГІНАЛЬНА ІНСТРУКЦІЯ
З ЕКСПЛУАТАЦІЇ . . . . . . . . . . . . . . . . . . . 58
ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ . . . . . . 62
INSTRUCØIUNI DE FOLOSIRE
ORIGINALE . . . . . . . . . . . . . . . . . . . . . . . . 65
ОРИГИНАЛНО РЪКОВОДСТВО
ЗА ЕКСПЛОАТАЦИЯ . . . . . . . . . . . . . . . . 68
PÔVODN¯ NÁVOD NA POUÎITIE. . . . . . . 72
ORIGINALNE UPUTE ZA RAD . . . . . . . . . 75
ORIGINALNO UPUTSTVO ZA RAD. . . . . . 78
IZVIRNA NAVODILA. . . . . . . . . . . . . . . . . . 81
ALGUPÄRANE KASUTUSJUHEND. . . . . . 83
ORI˛INÅLÅ LIETO·ANAS PAMÅC±BA . . . 86
ORIGINALI INSTRUKCIJA . . . . . . . . . . . . . 90
GB
F
D
NL
S
DK
N
FIN
E
P
I
H
CZ
TR
PL
RU
UA
GR
RO
BG
SK
HR
SRB
SLO
EST
LV
LT

2
KJ
F
DAB C
EG
HL
L
L
2
6900
1
0-3250
13 20 40mm 0-52000
p/min
3
2,6 kg
EPTA 01/2003
900
Watt
6901
0-3250
13 20 40mm 0-52000
p/min
2,6 kg
EPTA 01/2003
900
Watt

3
5
6
4
7

4
E
8
G
9

5
0
!@
6900 6901

6
#
$
PHILLIPS
POZIDRIV
SLOTTED
HSS

7
% ^
& *
(

8
2610397256
In Deutschland nicht lieferbar
2610073400
ACCESSORIES
2610397119
Ø 2, 3, 4, 5, 6 mm
Ø 4, 5, 6, 8, 10 mm
Ø 4, 5, 6, 8, 10 mm
Ø 1.5, 2, 2.5, 3, 3.5,
4, 4.5, 5, 5.5, 6, 8 mm
Ø 4, 5, 6, 6, 8 mm
Ø 3, 4, 5, 6, 8 mm

9
GB
Hammer drill 6900/6901
INTRODUCTION
• This tool is intended for hammer drilling in brick,
concrete and stone as well as for drilling in wood, metal,
ceramic and plastic; tools with electronic speed control
and left/right rotation are also suitable for screwdriving
and thread cutting
• Read and save this instruction manual 3
TECHNICAL SPECIFICATIONS 1
TOOL ELEMENTS 2
ASwitch for on/off and speed control
BWheel for maximum speed control
CButton for switch locking
DSwitch for changing direction of rotation
EIndicator of selected direction of rotation
FSwitch for selecting drilling function
GIndicator of selected drilling function
HCable clip
JAuxiliary handle
KDepth gauge
LVentilation slots
SAFETY
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or under
the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.

10
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
SAFETY INSTRUCTIONS FOR HAMMER DRILLS
• Wear ear protectors with hammer drills (exposure to
noise can cause hearing loss)
• Use auxiliary handles supplied with the tool (loss of
control can cause personal injury)
• Hold the power tool only by the insulated gripping
surfaces when performing an operation where the
accessory may contact hidden wiring or its own
power cord (contact with a “live” wire will also make
exposed metal parts of the power tool “live” and shock
the operator); always use auxiliary handle J 2
• Use suitable detectors to find hidden utility lines or
call the local utility company for assistance (contact
with electric lines can lead to fire or electrical shock;
damaging a gas line can result in an explosion;
penetrating a water pipe will cause property damage or
an electrical shock)
• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working
• Always keep the cord away from moving parts of the
tool
• Secure the workpiece (a workpiece clamped with
clamping devices or in a vice is held more securely than
by hand)
• When you put away the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill
• Use completely unrolled and safe extension cords with
a capacity of 16 Amps (U.K. 13 Amps)
• In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug
• SKIL can assure flawless functioning of the tool only
when original accessories are used
• Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool
• This tool should not be used by people under the age of
16 years
• Do not work materials containing asbestos (asbestos
is considered carcinogenic)
• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause
allergic reactions and/or respiratory diseases to the
operator or bystanders); wear a dust mask and work
with a dust extraction device when connectable
• Certain kinds of dust are classified as carcinogenic
(such as oak and beech dust) especially in conjunction
with additives for wood conditioning; wear a dust
mask and work with a dust extraction device when
connectable
• Follow the dust-related national requirements for the
materials you want to work with
• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug
• Never use tool when cord is damaged; have it replaced
by a qualified person
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools
with a rating of 230V or 240V can also be connected to
a 220V supply)
• If the drill bit becomes unexpectedly jammed (causing a
sudden, dangerous reaction), immediately switch off the
tool
• Be aware of the forces that occur as a result of jamming
(especially when drilling metals); always use auxiliary
handle J 2and take a secure stance
• Always disconnect plug from power source before
making any adjustment or changing any accessory
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut off the cord of this
tool, it must be disposed of safely and not left
unattended
USE
• On/off 4
• Switch locking for continuous use 5
• Speed control for smooth starting 6

11
• Maximum speed control 7
With wheel B 2the maximum speed can be adjusted
from low to high
- switch on the tool
- lock the switch
- turn wheel B to select maximum speed
• Changing direction of rotation 8
- when not properly set in left/right position, switch
A 2cannot be activated
- indicator E shows the selected direction of rotation
! change direction of rotation only when tool is at a
complete standstill
• Normal drilling/screwdriving versus hammer drilling 9
- indicator G shows the selected drilling function
! select drilling function only when tool is switched
off and plug is disconnected
• Changing bits 0
- insert the bit as deep as possible in the chuck
! do not use bits with a damaged shank
• Adjusting drilling depth !
• Cable clip @
For easy and convenient storage
• Holding and guiding the tool #
! while working, always hold the tool at the grey-
coloured grip area(s)
- always use auxiliary handle J 2(can be adjusted
as illustrated)
- keep the ventilation slots uncovered
- do not apply too much pressure on the tool; let the
tool do the work for you
APPLICATION ADVICE
• Use the appropriate bits $
! only use sharp bits
• For drilling in concrete or stone a steady pressure on
the drill is required
• When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
• When turning in a screw at/near the cross cut end or an
edge of wood, pre-drill a hole in order to avoid cracking
of the wood
• Splinterfree drilling in wood %
• Dustfree drilling in walls ^
• Dustfree drilling in ceilings &
• Drilling in tiles without skidding *
• For more tips see www.skileurope.com
• Vibration level
The vibration emission level stated at the back of this
instruction manual (indicated by an asterisk) has been
measured in accordance with a standardised test given
in EN 60745; it may be used to compare one tool with
another and as a preliminary assessment of exposure to
vibration when using the tool for the applications
mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories, may
significantly increase the exposure level
- the times when the tool is switched off or when it is
running but not actually doing the job, may
significantly reduce the exposure level
! protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially the
ventilation slots)
! disconnect the plug before cleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skileurope.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol $will remind you of this when the need for
disposing occurs
F
Perceuse à percussion 6900/6901
INTRODUCTION
• Cet outil est conçu pour les travaux de perçage en
frappe dans la brique, le béton et dans la pierre
naturelle ainsi que le perçage dans le bois, le métal, la
céramique et les matières plastiques; les outils avec
réglage électronique de la vitesse et rotation à droite/à
gauche sont également appropiés pour le vissage et le
filetage
• Lisez et conservez ce manuel d’instructions 3
SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 2
AInterrupteur de marche/arrêt et réglage de vitesse
BMolette de réglage de la vitesse maximum
CBouton de blocage de l’interrupteur
DCommutateur pour inverser le sens de rotation

✎
94

✎
95

96
CE DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following
standards or standardized documents: EN 60 745, EN 55 014, in accordance with the provisions of the directives 2006/95/EC,
2004/108/EC, 98/37/EC (until Dec. 28, 2009), 2006/42/EC (from Dec. 29, 2009 on).
NOISE/VIBRATION Measured in accordance with EN 60 745 the sound pressure level of this tool is 96 dB(A) and the sound power
level 107 dB(A) (standard deviation: 3 dB), and the vibration ✱m/s2(hand-arm method).
Technical file at: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre propre responsabilité que ce produit est en conformité avec les
normes ou documents normalisés suivants: EN 60 745, EN 55 014, conforme aux réglementations 2006/95/CE, 2004/108/CE,
98/37/CE (jusqu’au 28.12.2009), 2006/42/CE (à partir du 29.12.2009).
BRUIT/VIBRATION Mesuré selon EN 60 745 le niveau de la pression sonore de cet outil est 96 dB(A) et le niveau de la puissance
sonore 107 dB(A) (déviation standard: 3 dB), et la vibration ✱m/s2(méthode main-bras).
Dossier technique auprès de: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortung, daß dieses Produkt mit den folgenden Normen oder
normativen Dokumenten übereinstimmt: EN 60 745, EN 55 014, gemäß den Bestimmungen der Richtlinien 2006/95/EG,
2004/108/EG, 98/37/EG (bis 28.12.2009), 2006/42/EG (ab 29.12.2009).
GERÄUSCH/VIBRATION Gemessen gemäß EN 60 745 beträgt der Schalldruckpegel dieses Gerätes 96 dB(A) und der
Schalleistungspegel 107 dB(A) (Standard- abweichung: 3 dB), und die Vibration ✱m/s2(Hand-Arm Methode).
Technische Unterlagen bei: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product voldoet aan de volgende normen of normatieve documenten:
EN 60 745, EN 55 014, overeenkomstig de bepalingen van de richtlijnen 2006/95/EG, 2004/108/EG, 98/37/EG (tot 28-12-2009),
2006/42/EG (vanaf 29-12-2009).
GELUID/VIBRATIE Gemeten volgens EN 60 745 bedraagt het geluidsdrukniveau van deze machine 96 dB(A) en het
geluidsvermogen-niveau 107 dB(A) (standaard deviatie: 3 dB), en de vibratie ✱m/s2(hand-arm methode).
Technisch dossier bij: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att denna produkt överensstämmer med följande norm och
dokument: EN 60 745, EN 55 014, enl. bestämmelser och riktlinjema 2006/95/EG, 2004/108/EG, 98/37/EG (till 28.12.2009),
2006/42/EG (from 29.12.2009).
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 60 745 är på denna maskin 96 dB(A) och ljudeffektnivån 107 dB(A)
(standard deviation: 3 dB), och vibration ✱m/s2(hand-arm metod).
Teknisk tillverkningsdokumentation finns hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt ansvar, at dette produkt er i overensstemmelse med følgende
normer eller normative dokumenter: EN 60 745, EN 55 014, i henhold til bestemmelserne i direktiverne 2006/95/EF, 2004/108/EF,
98/37/EF (indtil 28.12.2009), 2006/42/EF (fra 29.12.2009).
STØJ/VIBRATION Måles efter EN 60 745 er lydtrykniveau af dette værktøj 96 dB(A) og lydeffektniveau 107 dB(A) (standard
deviation: 3 dB), og vibrationsniveauet ✱m/s2(hånd-arm metoden).
Teknisk dossier hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt ansvar at dette produkt er i samsvar med følgende standarder eller
standard- dokumenter: EN 60 745, EN 55 014, i samsvar med reguleringer 2006/95/EF, 2004/108/EF, 98/37/EF (frem til 28.12.2009),
2006/42/EF (fra 29.12.2009).
STØY/VIBRASJON Målt ifølge EN 60 745 er lydtrykknivået av dette verktøyet 96 dB(A) og lydstyrkenivået 107 dB(A) (standard
deviasjon: 3 dB), og vibrasjonsnivået ✱m/s2(hånd-arm metode).
Tekniske underlag hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen
standardien ja standardoimisasiakirjojen vaatimusten mukainen EN 60 745, EN 55 014, seuraavien sääntöjen mukaisesti
2006/95/EY, 2004/108/EY, 98/37/EY (28.12.2009 asti), 2006/42/EY (29.12.2009 alkaen).
MELU/TÄRINÄ Mitattuna EN 60 745 mukaan työkalun melutaso on 96 dB(A) ja yleensä työkalun äänen voimakkuus on 107 dB(A)
(keskihajonta: 3 dB), ja tärinän voimakkuus ✱m/s2(käsi-käsivarsi metodi).
Tekninen tiedosto kohdasta: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra sola responsabilidad que este producto está en conformidad
con las normas o documentos normalizados siguientes: EN 60 745, EN 55 014, de acuerdo con las regulaciones 2006/95/CE,
2004/108/CE, 98/37/CE (hasta el 28.12.2009), 2006/42/CE (a partir del 29.12.2009).
RUIDOS/VIBRACIONES Medido según EN 60 745 el nivel de la presión acústica de esta herramienta se eleva a 96 dB(A) y el nivel
de la potencia acústica 107 dB(A) (desviación estándar: 3 dB), y la vibración a ✱m/s2(método brazo-mano).
Expediente técnico en: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
GB
F
D
NL
S
N
FIN
E
08 SKIL Europe BV A. v.d. Kloot
DK

97
08 SKIL Europe BV A. v.d. Kloot
ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной ответственностыо заявляем, что это изделие соответствует следующим
стандартам или станда ртизованным документам: EN 60 745, EN 55 014, в соответсувии с инструкциями 2006/95/EC,
2004/108/EC, 98/37/EC (до 28.12.2009), 2006/42/EC (начиная с 29.12.2009).
ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co стандартoм EN 60 745 уровень звукового давления для этого
инструмента составляет 96 дБ (A) и уровeнь звуковой мощности - 107 дБ (A) (стандартное отклонение: 3 dB), и вибрации -
✱м/с2(по методу для рук).
Техническая документация у: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
RU
CE ВІДПОВІДНІСТЬ Ми заявляємо, що відповідність даного продукту наступним стандартам і регулюючим документам
повністю нашою відповідальністю: EN 60 745, EN 55 014, відповідно до положень директив 2006/95/EG, 2004/108/EG,
98/37/EG до 28.12.2009 p.), 2006/42/EG (після 29.12.2009 p.).
ШУМ/ВІБРАЦІЯ Зміряний відповідно до EN 60 745 рівень тиску звуку даного інструменту 96 дБ(А) i потужність звуку
107 дБ(А) (стандартне відхилення: 3 дБ), i вібрація ✱м/с2(ручна методика).
Технічні документи в: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
UA
CE ∆ΗΛΩΣΗ ΣYMBATOTΗΤΑΣ ∆ηλώνουµε υπευθύνως τι το προϊν αυτ είναι κατασκευασµένο σύµφωνα µε τους εξής
κανονισµούς ή κατασκευαστικές συστάσεις: EN 60 745, EN 55 014, κατά τις διατάξεις των κανονισµών της Κοινής Αγοράς
2006/95/EK, 2004/108/EK, 98/37/EK (έως 28.12.2009), 2006/42/EK (απ 29.12.2009).
ΘΟΡYΒΟ/ΚΡΑ∆ΑΣΜΟYΣ Μετρηµένη σύµφωνα µε EN 60 745 η στάθµη ακουστικής πίεσης αυτού του εργαλείου ανέρχεται
σε 96 dB(A) και η στάθµη ηχητικής ισχύoς σε 107 dB(A) (κοινή απκλιση: 3 dB), και ο κραδασµς σε ✱m/s2(µεθοδος
χειρς/βραχίονα).
Τεχνικς φάκελος απ: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
GR
OÂWIADCZENIE ZGODNOÂCI CE Niniejszym oÊwiadczamy ponoszàc osobistà odpowiedzialnoÊç, ˝e produkt wykonany jest
zgodnie z nast´pujàcymi normami i dokumentami normalizujàcymi: EN 60 745, EN 55 014, z godnie z wytycznymi 2006/95/EU,
2004/108/EU, 98/37/EU (do 28.12.2009), 2006/42/EU (od 29.12.2009).
HA¸ASU/WIBRACJE Pomiarów dokonano zgodnie z normà EN 60 745 ciÊnienie akustyczne narz´dzia wynosi 96 dB(A) zaÊ poziom
mocy akustycznej 107 dB(A) (poziom odchylenie: 3 dB), zaÊ wibracje ✱m/s2(metoda d∏oƒ-r´ka).
Dokumentacja techniczna: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
PL
CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa exclusiva responsabilidade que este producto cumpre as
seguintes normas ou documentos normativos: EN 60 745, EN 55 014, conforme as disposições das directivas 2006/95/CE,
2004/108/CE, 98/37/CE (até 28.12.2009), 2006/42/CE (a partir de 29.12.2009).
RUÍDO/VIBRAÇÕES Medido segundo EN 60 745 o nível de pressão acústica desta ferramenta é 96 dB(A) e o nível de potência
acústica 107 dB(A) (espaço de erro: 3 dB), e a vibração ✱m/s2(método braço-mão).
Processo técnico em: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
P
CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo la piena responsabilità di tale dichiarazione, che il prodotto è
conforme alle seguenti normative e ai relativi documenti: EN 60 745, EN 55 014 in base alle prescrizioni delle direttive 2006/95/EG,
2004/108/EG, 98/37/EG (fino al 28.12.2009), 2006/42/EG (a partire dal 29.12.2009).
RUMOROSITÀ/VIBRAZIONE Misurato in conformità al EN 60 745 il livello di pressione acustica di questo utensile è 96 dB(A) ed il
livello di potenza acustica 107 dB(A) (deviazione standard: 3 dB), e la vibrazione ✱m/s2(metodo mano-braccio).
Fascicolo tecnico presso: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
I
CE MINÖSÉGI TANUSITVANY Teljes felelösségünk tudatában kijelentjük, hogy jelen termék a következö szabványoknak vagy
kötelezö hatósági elöírásoknak megfelel: EN 60 745, EN 55 014, a 2006/95/EK, 2004/108/EK, 98/37/EK (2009.12.28-ig), 2006/42/EK
(2009.12.29-tŒl kezdve) elöírásoknak megfelelöen.
ZAJ/REZGÉS Az EN 60 745 alapján végzett mérések szerint ezen készülék hangnyomás szintje 96 dB(A) a hangteljesítmény szintje
107 dB(A) (normál eltérés: 3 dB), a rezgésszám ✱m/s2(kézre-ható érték).
A mıszaki dokumentáció a következŒ helyen található: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
H
CE STRVZUJÍCÍ PROHLÅ◊ENÍ Potvrzujeme na odpovπdnost, Ωe tento v¥robek odpovídå nåsledujícím normåm nebo normativním
podkladüm: EN 60 745, EN 55 014, podle ustanovení smπrnic 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od
29.12.2009).
HLUÇNOSTI/VIBRACÍ Mπ®eno podle EN 60 745 çiní tlak hlukové vlny tohoto p®ístroje 96 dB(A) a dávka hluçnosti 107 dB(A)
(standardní odchylka: 3 dB), a vibrací ✱m/s2(metoda ruka-paΩe).
Technická dokumentace u: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CZ
CE STANDARDIZASYON BEYANI Ye¤ane sorumlu olarak, bu ürünün afla¤ıdaki standartlara veya standart belgelerine uygun
oldu¤unu beyan ederiz: EN 60 745, EN 55 014, yönetmeli¤i hükümleri uyarınca 2006/95/EG, 2004/108/EG, 98/37/EG (28.12.2009
tarihine kadar), 2006/42/EG (29.12.2009 tarihinden itibaren).
GÜRÜLTÜ//T‹TREfiIM Ölçülen EN 60 745 göre ses basıncı bu makinanın seviyesi 96 dB(A) ve çal›flma s›ras›ndaki gürültü 107 dB(A)
(standart sapma: 3 dB), ve titreflim ✱m/s2(el-kol metodu).
Teknik belgelerin bulundu¤u merkez: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
TR

98
08 SKIL Europe BV A. v.d. Kloot
DECLARAØIE DE CONFORMITATE CE Declaråm pe proprie råspundere cå acest product este conform cu urmåtoarele standarde
sau documente standardizate: EN 60 745, EN 55 014, în conformitate cu regulile 2006/95/CE, 2004/108/CE, 98/37/CE (pânå la
28.12.2009), 2006/42/CE (începând cu 29.12.2009).
ZGOMOT/VIBRAØII Måsurat în conformitate cu EN 60 745 nivelul de presiune a sunetului generat de acest instrument este de
96 dB(A) iar nivelul de putere a sunetului 107 dB(A) (abaterea standard: 3 dB), iar nivelul vibraøiilor ✱m/s2(metoda mînå - braø).
Documentaøie tehnicå la: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
RO
CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
2006/95/EG, 2004/108/EG, 98/37/EG (до 28.12.2009), 2006/42/EG (от 29.12.2009).
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 96 dB(A) а
нивото на звукова мощност е 107 dB(A) (стандартно отклонение: 3 dB), а вибрациите са ✱m/s2(метод ръка-рамо).
Подробни технически описания при: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
BG
CE IZJAVA O USKLA ĐENOSTI Izjavljujemo uz punu odgovornost da je ovaj proizvod usklađen sa slijedeçim normama i
normativnim dokumentima: EN 60 745, EN 55 014, prema odredbama smjernica 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
BUCI/ VIBRACIJAMA Mjereno prema EN 60 745, prag zvuãnog tlaka ovog elektriãnog alata iznosi 96 dB(A) a jakost zvuka
107 dB(A) (standardna devijacija: 3 dB), a vibracija ✱m/s2(postupkom na ‰aci-ruci).
Tehniãka dokumentacija se moÏe dobiti kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
HR
CE IZJAVA O USKLA ĐENOSTI Pod punom odgovorno‰çu izjavljujemo da je ovaj proizvod usklađen sa sledeçim standardima ili
standardizovanim dokumentima: EN 60 745, EN 55 014, u skladu sa odredbama smernica 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
BUKA/VIBRACIJE Mereno u skladu sa EN 60 745, nivo pritiska zvuka ovog alata iznosi 96 dB(A), a jaãina zvuka 107 dB(A)
(normalno odstupanje: 3 dB), a vibracija ✱m/s2(mereno metodom na ‰aci-ruci).
Tehniãka dokumentacija kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SRB
IZJAVA O USTREZNOSTI CE Odgovorno izjavljamo, da je ta izdelek v skladu z naslednjimi standardi ali standardnimi dokumenti:
EN 60 745, EN 55 014, v skladu s predpisi navodil 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od 29.12.2009).
HRUP/VIBRACIJA Izmerjeno v skladu s predpisom EN 60 745 je raven zvoãnega pritiska za to orodje 96 dB(A) in jakosti zvoka
107 dB(A) (standarden odmik: 3 dB), in vibracija ✱m/s2 (metoda ‘dlan-roka’).
Tehniãna dokumentacija se nahaja pri: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SLO
CE VASTAVUSDEKLARATSIOON Kinnitame ainuvastutajana, et see toode vastab järgmistele standarditele või
normdokumentidele: EN 60 745, EN 55 014 vastavalt direktiivide 2006/95/EÜ, 2004/108/EÜ, 98/37/EÜ (kuni 28.12.2009),
2006/42/EÜ (alates 29.12.2009) nõuetele.
MÜRA/VIBRATSIOON Vastavalt kooskõlas normiga EN 60 745 läbi viidud mõõtmistele on antud seadme helirõhk 96 dB(A) ja
helitugevus 107 dB(A) (standardkõrvalekalle: 3 dB), ja vibratsioon ✱m/s2(käe-randme-meetod).
Tehniline toimik saadaval aadressil: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
EST
CE DEKLARÅCIJA PAR ATBILST±BU STANDARTIEM Mïs ar pilnu atbild¥bu pazi¿ojam, ka ‰is izstrÇdÇjums atbilst standartiem vai
standartizÇcijas dokumentiem EN 60 745, EN 55 014 un ir saska¿Ç ar direkt¥vÇm 2006/95/ES, 2004/108/ES, 98/37/ES (l¥dz
28.12.2009) un 2006/42/ES (no 29.12.2009).
TROKSNIS/VIBRÅCIJA Saska¿Ç ar standartu EN 60 745 noteiktais instrumenta rad¥tÇ trok‰¿a ska¿as spiediena l¥menis ir 96 dB(A)
un ska¿as jaudas l¥menis ir 107 dB (A) (pie tipiskÇs izkliedes: 3 dB), un vibrÇcijas intensitÇte ir ✱m/s2(strÇdÇjot rokas reÏ¥mÇ).
TehniskÇ lieta no: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
LV
CE ATITIKTIES DEKLARACIJA Mes atsakingai parei‰kiame, kad ‰is gaminys atitinka tokius standartus ir normatyvinius
dokumentus: EN 60 745, EN 55 014 pagal reglament˜ 2006/95/EB, 2004/108/EB, 98/37/EB (iki 2009-12-28), 2006/42/EB
(nuo 2009-12-29) nuostatas.
TRIUK·MINGUMAS/VIBRACIJA ·io prietaiso triuk‰mingumas buvo i‰matuotas pagal EN 60 745 reikalavimus keliamo triuk‰mo
garso slògio lygis siekia 96 dB(A) ir akustinio galingumo lygis 107 dB(A) (standartinis nuokrypis: 3 dB), ir vibracijos pagreitis rankos
pla‰takos srityje tipiniu atveju yra maÏesnis, kaip ✱m/s2.
Techninò byla laikoma: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
LT
CE PREHLÁSENIE O ZHODE Vÿhradne na na√u vlastnú zodpovednos† prehlasujeme, Ωe tento vÿrobok zodpovedá nasledujúcim
normám alebo normovanÿm dokumentom: EN 60 745, EN 55 014, v súlade s predpismi 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
HLUKU/VIBRÁCIÁCH Merané pod¬a EN 60 745 je úroveµ akustického tlaku tohto nástroja 96 dB(A) a úroveµ akustického vÿkonu je
107 dB(A) (√tandardná odch¥lka: 3 dB), a vibrácie sú ✱m/s2(metóda ruka - paΩa).
Súbor technickej dokumentácie sa nachádzajú na adrese: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SK

99
123
When drilling in metal When drilling in concrete Uncertainty (K)
Pendant le perçage du métal Pendant le perçage du béton Incertitude (K)
Beim Bohren in Metall Beim Bohren in Beton Unsicherheit (K)
Bij het boren in metaal Bij het boren in beton Onzekerheid (K)
För borrning i metall För borrning i betong Onoggrannhet (K)
Ved boring i metal Ved boring i beton Usikkerhed (K)
Ved boring i metall Ved boring i betong Usikkerhet (K)
Metalliin porattaessa Betoniin porattaessa Epävarmuus (K)
Al taladrar en metal Al taladrar en hormigón Incertidumbre (K)
Ao perfurar en metal Ao perfurar em betão Incerteza (K)
Nella foratura nel metallo Nella foratura nel cemento Incertezza (K)
Fém fúrásakor Beton fúrásakor Szórás (K)
Pfii vrtání do kovu Pfii vrtání do betonu Nepfiesnost (K)
Metalde delerken Betonde delerken Tolerans (K)
Podczas wiercenia w metalie Podczas wiercenia w betonie B∏àd pomiaru (K)
Пpи свеpлении в металле Пpи свеpлении в бетонe Недостоверность (K)
При свердлінні в металі При свердлінні в бетоні Похибка (K)
Oταν τρυπάτε σε µέταλλo Oταν τρυπάτε σε µπετν Ανασφάλεια (K)
Când gåuriøi în metal Când gåuriøi în beton Incertitudine (K)
Пpи пpобиване в метал Пpи пpобиване в бетон Неопределеност (K)
Pri v⁄taní do kovu Pri v⁄taní do betónu NepresnosÈ (K)
Kod bu‰enja u metalu Kod bu‰enja u betonu Nesigurnost (K)
Pri bu‰enju metala Pri bu‰enju betona Nesigurnost (K)
Pri vrtanju v kovino Pri vrtanju v beton Netoãnost (K)
Metalli puurimisel Betooni puurimisel Mõõtemääramatus (K)
Veicot urb‰anu metÇlÇ Veicot urb‰anu betonÇ Izkliede (K)
Gr´Ïdami metalo Gr´Ïdami betonà Paklaida (K)
LT
LV
EST
SLO
SRB
HR
SK
BG
RO
GR
UA
RU
PL
TR
CZ
H
I
P
E
FIN
N
DK
S
NL
D
F
GB
✱
6900/6901
18,5 m/s2
217,4 m/s2
31,5 m/s2

This manual suits for next models
3
Table of contents
Other Skil Drill manuals

Skil
Skil 6410 User manual

Skil
Skil PWRCORE 12 DL629A-00 User manual

Skil
Skil 6389 User manual

Skil
Skil 2467 User manual

Skil
Skil 1021 User manual

Skil
Skil 6239 User manual

Skil
Skil 6002 User manual

Skil
Skil 2895 Assembly instructions

Skil
Skil 2487 2587 2887 Assembly instructions

Skil
Skil Masters 6545 User manual
