Skoda 2013 Rapid User manual

SIMPLY CLEVER
ŠKODA Rapid
Owner's Manual

Layout of this Owner's Manual
(explanations)
This Owner's Manual has been systematically designed to make it easy for you to
search for and obtain the information you require.
Chapters, table of contents and subject index
The text of the Owner's manual is divided into relatively short sections which are
combined into easy-to-read chapters. The chapter you are reading at any particular
moment is always specified on the bottom right of the page.
The Table of contents is arranged according to the chapters and the detailed Sub-
ject index at the end of the Owner's Manual helps you to rapidly find the informa-
tion you are looking for.
Direction indications
All direction indications such as “left”, “right”, “front”, “rear” relate to the direction of
travel of the vehicle.
Units of measurement
All values are expressed in metric units.
Explanation of symbols
Denotes a reference to a section with important information and safety
advice in a chapter.
Denotes the end of a section.
Denotes the continuation of a section on the next page.
Indicates situations where the vehicle must be stopped as soon as possi-
ble.
® Denotes a registered trademark.
Notes
WARNING
The most important notes are marked with the heading WARNING. These
WARNING notes draw your attention to a serious risk of accident or injury.
CAUTION
A Caution note draws your attention to the possibility of damage to your vehicle
(e.g. damage to gearbox), or points out general risks of an accident.
For the sake of the environment
An Environmental note draws your attention to environmental protection aspects.
This is where you will, for example, find tips aimed at reducing your fuel consump-
tion.
Notice
A normal Note draws your attention to important information about the operation
of your vehicle.

Preface
You have opted for a ŠKODA – our sincere thanks for your confidence in us.
You have received a vehicle with the latest technology and range of amenities. Please read this Owner's
Manual carefully, because the operation in accordance with these instructions is a prerequisite for proper use
of the vehicle.
If you have any questions about your vehicle, please contact a ŠKODA Partner.
We hope you enjoy driving your ŠKODA, and wish you a pleasant journey at all times.
Your ŠKODA AUTO a.s. (hereinafter referred to only as ŠKODA or manufacturer) 

On-board literature
The on-board literature for your vehicle consists of this “Owner's Manual” as well
as a “Service schedule” and a Help on the road.
Depending on the vehicle model and equipment, other additional operating man-
uals and instructions may be provided (e.g. an operating manual for the radio).
If one of the documents listed above is missing, please contact a ŠKODA Partner.
Terms used
The on-board literature contains the following terms relating to the service work
for your vehicle.
›“Specialist garage” - a company that carries out specialist service tasks for
ŠKODA vehicles A specialist can be a ŠKODA partner, a ŠKODA service partner,
as well as an independent workshop.
›“ŠKODA service partner” - A Workshop that has been contractually authorized
by the manufacturer ŠKODA AUTO a.s. or its sales partner to perform service
tasks on ŠKODA vehicles and to sell ŠKODA Genuine Parts.
›“ŠKODA partner” - A company that has been authorized by the manufacturer
ŠKODA AUTO a.s. or its sales partner to sell new ŠKODA vehicles and, when ap-
plicable, to service them using ŠKODA Genuine Parts and sell ŠKODA Genuine
Parts.
The owner's manual
This Owner's manual describes all possible equipment variants without identify-
ing them as special equipment, model variants or market-dependent equipment.
Consequently, this vehicle does not need to contain all of the equipment compo-
nents described in this owner's manual.
The scope of equipment of your vehicle relates to your purchase contract for the
vehicle. For more information, contact your local ŠKODA retailer.
The illustrations can differ in minor details from your vehicle; they are only inten-
ded for general information.
The service schedule:
›Contains vehicle data including information on service work carried out;
›Is intended as proof of services carried out;
›Is intended for records relating to the mobility warranty (only valid for some
countries);
›Serves as a warranty certificate from the ŠKODA Partner where your vehicle
was purchased.
Therefore please always present the service schedule when you take your vehicle
to a specialist garage.
If the service schedule is missing or in poor condition, please contact the special-
ist garage that regularly services your vehicle. You will need to request a dupli-
cate, in which the specialist garage will confirm the service work previously car-
ried out.

Table of Contents
Abbreviations
Usage
Cockpit 6
Overview 6
Instruments and Indicator Lights 7
Instrument cluster 7
Warning Lights 9
Information system 13
Driver information system 13
Multifunction display (MFA) 14
Unlocking and opening 17
Unlocking and locking 17
Luggage compartment lid 20
Electric power windows 21
Lights and visibility 23
Lights 23
Interior light 25
Visibility 26
Windscreen wipers and washers 27
Rear mirror 28
Seats and useful equipment 30
Adjusting the seats 30
Practical equipment 32
Transport 36
Heating and air conditioning system 37
Heating, ventilation, cooling 37
Driving
Starting-off and Driving 41
Steering 41
Start and turn off the engine 42
Brakes 44
Manual gear changing and pedals 46
Automatic transmission 47
Running in 49
Economical driving and environmental
sustainability 50
Avoiding damage to your vehicle 54
Driving abroad 55
Safety
Passive Safety 56
General information 56
Correct seated position 57
Seat belts 60
Using seat belts 60
Inertia reels and belt tensioners 63
Airbag system 65
Description of the airbag system 65
Airbag overview 66
Deactivating airbags 67
Transporting children safely 69
Child seat 69
General Maintenance
Taking care of and cleaning the vehicle 72
Washing your car 72
Taking care of your vehicle exterior 73
Taking care of the interior 77
Modifications, repairs and technical alterations 79
Inspecting and replenishing 82
Fuel 82
Engine compartment 84
Engine oil 87
Coolant 89
Brake fluid 91
Vehicle battery 92
Wheels 96
Tyres and wheel rims 96
Do-it-yourself
Emergency equipment and self-help 102
Emergency equipment 102
Changing a wheel 103
Jump-starting 106
Towing the vehicle 107
Remote control 109
Emergency unlocking/locking 110
Replacing windscreen wiper blades 111
Fuses and light bulbs 112
Fuses 112
Bulbs 113
Technical data
Technical data 117
Vehicle data 117
Index
3
Table of Contents

Abbreviations
Abbreviation Meaning
rpm Engine revolutions per minute
ABS Anti-lock brake system
AG Automatic gearbox
CO2 in g/km discharged quantity of carbon dioxide in grams per driven kilo-
meter
ECE Economic Commission for Europe
EPC EPC fault light
EU European Union
kW Kilowatt, measuring unit for the engine output
MFD Multifunction display
MG Manual gearbox
MPI Petrol engine with multi-point fuel injection
Nm Newton meter, measuring unit for the engine torque
TDI Diesel engine with turbocharger 
4Abbreviations

5
Abbreviations

Usage
Cockpit
Overview
Fig. 1 Cockpit
 Rear window heater 26
Button for hazard warning light system 25
Air outlets in the central part of the dash panel 38
Operating lever: Turn signal lights and main beam, headlight flash-
er 24
Horn
Instrument cluster 7
1
2
3
4
5
6
Operating lever:
›Windscreen wiper and wash system 28
›Information system 13
Air outlet vents on the driver's side 38
Electric exterior mirror adjustment 29
 Central locking system 19
Bonnet remote release 86
Light switch 23
Lights and visibility 23
Ignition lock 43
Steering wheel and driver's front airbag 66
Lever for adjusting the steering wheel 41
Distribution board cover. 113
Depending on equipment fitted:
›Operating controls for the air conditioning system 38
›Operating controls for Climatronic 39
Radio 
7
8
9
10
11
12
13
14
15
16
17
18
19
6Usage

Instruments and Indicator Lights
Instrument cluster
Introduction
This chapter contains information on the following subjects:
Overview 7
Engine revolutions counter 8
Fuel gauge 8
Counter for distance driven 8
Digital clock 9
Fault display
If there is a fault in the instrument cluster, the Error message will appear in the
display. Have the fault rectified as soon as possible by a specialist garage.
WARNING
■Concentrate fully at all times on your driving! As the driver you are fully re-
sponsible for road safety.
■Never operate the controls in the instrument cluster while driving, only
when the vehicle is stationary! 
Overview
Fig. 2 Instrument cluster
First read and observe the introductory information and safety warn-
ings on page 7.
Revolutions counter with warning lights » page 8
Display:
›With counter for distance driven » page 8
›With service interval display » page 14
›With digital clock » page 9
›with multifunction display (MFA) » page 14
›With information system » page 13
Speedometer with warning lights
Button for display mode:
›Setting the hours/minutes » page 9
›Service intervals - Display of the number of days and kilometres remaining
until the next service» page 14
Button for:
›switch between the odometer and the trip odometer display » page 8
›Reset trip odometer » page 8
›Set hours/minutes » page 9 

1
2
3
4
5
7
Instruments and Indicator Lights

Engine revolutions counter
First read and observe the introductory information and safety warn-
ings on page 7.
The red scale of the rev counter 1 » fig. 2 on page 7 indicates the range in which
the system begins to limit the engine speed. The system automatically restricts
the engine speed to a steady limit.
You should shift into the next higher gear before the red scale of the revolution
counter is reached, or select mode D on the automatic gearbox.
Follow the recommended gear to prevent engine speeds that are too high or too
low » page 13.
For the sake of the environment
Correct shifting up has the following advantages.
■It helps to reduce fuel consumption.
■It reduces the operating noise.
■It protects the environment.
■It benefits the durability and reliability of the engine. 
Fuel gauge
Fig. 3
Fuel gauge
First read and observe the introductory information and safety warn-
ings on page 7.
The fuel gauge only operates if the ignition is switched on.
The fuel tank has a capacity of about 55 litres. If the amount of fuel reaching the
reserve area, the indicator lights  » page 11 on.


The reserve area is indicated by the display of only the last two segments
scale » fig. 3 .
CAUTION
Never drive until the fuel tank is completely empty! The irregular supply of fuel
can cause misfiring. This can result in considerable damage to parts of the engine
and the exhaust system. 
Counter for distance driven
Fig. 4 With counter for distance driven
First read and observe the introductory information and safety warn-
ings on page 7.
The change between the odometer and the trip odometer display is done by
pressing the button 5 » fig. 2 on page 7 .
Odometer
The odometer » fig. 4  indicates the total distance the vehicle has travelled.
Daily trip counter (trip)
The daily trip counter » fig. 4  shows the distance driven since the time the
counter was last reset - in steps of 100 m.
Reset trip odometer
›With the 5 key » fig. 2 on page 7 choose the odometer display.
›Press and hold the 5 button. 

8Usage

Digital clock
First read and observe the introductory information and safety warn-
ings on page 7.
The clock is set with the buttons 4 and 5 » fig. 2 on page 7.
Button 4 - Select the display you want to change (hours or minutes).
5 button - change the display value. 
Warning Lights
Introduction
This chapter contains information on the following subjects:
 Handbrake 9
 Braking system 9
 Generator 10
 Open door 10
warning light 10
 Coolant 10
 Power steering 11
 Antilock brake system (ABS) 11
 The rear fog light 11
 Exhaust inspection system 11
 Glow plug system (diesel engine) 11
 EPC fault light (petrol engine) 11
 Fuel reserve 11
 Airbag system 12
  Turn signal system 12
 Selector lever lock 12
 Main beam 12
The indicator lights show certain functions/faults and may be accompanied by au-
dible signals.

WARNING
■If illuminated indicator lights and the corresponding descriptions and warn-
ing notes are not observed, this may result in severe injuries or major vehicle
damage.
■The engine compartment of your car is a hazardous area. There is a risk of
injuries, scalding, accidents and fire when working in the engine compart-
ment, e.g. inspecting and replenishing oil and other fluids. It is essential to ob-
serve safety notes » page 84, Engine compartment.
 Handbrake
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  comes on if the handbrake is applied. An audible warning is
also given if you drive the vehicle for at least 3 seconds at a speed of more than
6 km/h. 
 Braking system
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  illuminates if the brake fluid level in the braking system is
too low or there is a fault in the ABS.
Stop the vehicle, switch off the engine, and check the level of the brake flu-
id » page 91.
WARNING
■If you have to stop for technical reasons, then park the vehicle at a safe dis-
tance from the traffic, switch off the engine and activate the hazard warning
light system » page 25.
■The following guidelines should be observed when opening the bonnet and
checking the brake fluid level » page 84, Engine compartment.


9
Instruments and Indicator Lights

WARNING (Continued)
■If the warning light  is displayed simultaneously with warning light
 » page 11,  Antilock brake system (ABS),  do not continue your jour-
ney! Seek help from a specialist garage.
■A fault to the ABS system or the braking system can increase the vehicle's
braking distance – risk of accident! 
 Generator
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light lights up  when the engine is running, the vehicle battery is
not being charged.
Seek help from a specialist garage. The electrical system requires checking.
WARNING
If you have to stop for technical reasons, then park the vehicle at a safe dis-
tance from the traffic, switch off the engine and activate the hazard warning
light system » page 25, Hazard warning light systemHazard warning light
system.
 Open door
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  comes on, if one or several doors are opened. 
warning light
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  light (low oil pressure)
Stop the vehicle, switch off the engine, and check the level of the engine
oil » page 88.



Even if the oil level is correct, do not drive any further if the indicator light is
flashing . Also do not leave the engine running at an idling speed.
Seek help from a specialist garage.
WARNING
If you have to stop for technical reasons, then park the vehicle at a safe dis-
tance from the traffic, switch off the engine and activate the hazard warning
light system » page 25.
 Coolant
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up or flashes, either the coolant temperature is too
high or the coolant level is too low.
Stop the vehicle, switch off the engine, check the level of the coolant » page 90,
and refill the coolant if necessary » page 90.
Do not continue driving if the warning light is lit, even though the coolant level
is correct and the fuse for the fan is in working order!
Seek help from a specialist garage.
WARNING
■If you have to stop for technical reasons, then park the vehicle at a safe dis-
tance from the traffic, switch off the engine and activate the hazard warning
light system » page 25.
■Carefully open the coolant expansion bottle. If the engine is hot, the cooling
system is pressurized - risk of scalding! It is therefore best to allow the engine
to cool down before removing the cap.
■Do not touch the radiator fan. The radiator fan may switch itself on auto-
matically even if the ignition is off.
CAUTION
Additional headlights and other attached components in front of the air inlet im-
pair the cooling efficiency of the coolant. 

10 Usage

 Power steering
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, there is a fault in the engine control.
The power steering operates with reduced steering assist or does not function at
all.
Seek help from a specialist garage.
When the indicator  does not light up after starting the engine and traveling a
short distance, then the help of a professional operation must not be used.
If the battery is disconnected and reconnected, it is a short distance with a speed
of 15 - 20 km / h reading down. 
 Antilock brake system (ABS)
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, there is a fault in the ABS.
The vehicle will only be braked by the normal brake system without the ABS.
Seek help from a specialist garage.
WARNING
■If you have to stop for technical reasons, then park the vehicle at a safe dis-
tance from the traffic, switch off the engine and activate the hazard warning
light system » page 25.
■A fault to the ABS system or the braking system can increase the vehicle's
braking distance – risk of accident! 
 The rear fog light
First read and observe the introductory information and safety warn-
ings on page 9.
The warning light  comes on when the rear fog lights are operating » page 25.



 Exhaust inspection system
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, there is a fault in the exhaust inspection system.
The engine control unit allows the vehicle to run in emergency mode.
Seek help from a specialist garage. 
 Glow plug system (diesel engine)
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  comes on after the ignition has been switched on. The en-
gine can be started immediately after the pre-glow indicator light goes out.
If the indicator light  lights up, there is a fault in the engine control.
Seek help from a specialist garage. 
 EPC fault light (petrol engine)
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, there is a fault in the engine control.
Seek help from a specialist garage. 
 Fuel reserve
First read and observe the introductory information and safety warn-
ings on page 9.
If the amount of fuel reaching the reserve area, the indicator lights  on. 




11
Instruments and Indicator Lights

CAUTION
Never drive until the fuel tank is completely empty! The irregular supply of fuel
can cause misfiring. This can result in considerable damage to parts of the engine
and the exhaust system. 
 Airbag system
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, there is a fault in the airbag system.
WARNING
If there is a fault, have the airbag system checked immediately by a specialist
garage. Otherwise, there is a risk of the airbag not being activated in the
event of an accident. 
  Turn signal system
First read and observe the introductory information and safety warn-
ings on page 9.
Either the left  or right  indicator light flashes depending on the position of
the turn signal lever.
If a turn signal light fails, the indicator light flashes at twice its normal rate.
Switching off the hazard indicator light system is switched on will cause all of the
turn signal lights as well as both indicator lights to flash.
Further information » page 24, Turn signal and main beam.
 Selector lever lock
First read and observe the introductory information and safety warn-
ings on page 9.
If the indicator light  lights up, operate the brake pedal. 



 Main beam
First read and observe the introductory information and safety warn-
ings on page 9.
The indicator light  comes on when the main beam or headlight flasher are se-
lected » page 24.

12 Usage

Information system
Driver information system
Introduction
This chapter contains information on the following subjects:
Ice warning 13
Gear recommendation 13
Service Interval Display 14
The information system provides the driver with alerts and messages about in-
dividual vehicle systems. This information and instructions are displayed on the
display of the instrument cluster.
The information system provides the following information.
›Ice warning » page 13.
›Recommended gear » page 13.
›Multi-function display (MFA) » page 14.
›Warning against excessive speed » page 16.
›Service interval display » page 14.
›Selector lever positions for an automatic gearbox » page 47.
WARNING
Concentrate fully at all times on your driving! As the driver you are fully re-
sponsible for the operation of your vehicle. 
Ice warning
First read and observe the introductory information and safety warn-
ings on page 13.
If the outside temperature while driving drops to below +4°C, the temperature
display » page 15, Outside temperature will show up with the following icon in
front . An audible signal is emitted.
If the outside temperature is already below +4°C when turning the ignition on,
the temperature display and the  icon appear immediately. An audible signal is
emitted.

WARNING
Even at temperatures of around +4 °C, black ice may still be on the road sur-
face! You should therefore not only rely on the outside temperature display
for accurate information as to whether there is ice on the road.
Notice
Applies to cars with the multi-function display (MFA). 
Gear recommendation
First read and observe the introductory information and safety warn-
ings on page 13.
In order to minimise the fuel consumption, a recommendation for shifting into an-
other gear is indicated in the display.
Symbol Importance
The selected gear is optimal.
Recommends that you shift to a higher gear.
Recommends that you shift to a lower gear.
CAUTION
The driver is always responsible for selecting the correct gear in different driving
situations, such as overtaking.
For the sake of the environment
The journey with useful gear can positively impact fuel consumption.
Notice
Produced when the clutch pedal is not recommended gear indicator. 

13
Information system

Service Interval Display
First read and observe the introductory information and safety warn-
ings on page 13.
If a service due date, then the following information is displayed for about 10 sec-
onds.
›Icon  and the days remaining until the next service interval
›Icon  and the days remaining until the next service interval
The kilometre indicator or the days indicator reduces in steps of 100 km or, where
applicable, days until the service due date is reached.
As soon as the due date for the service is reached, the flashing key symbol  and
the text  appears in the display for about 20 seconds after the ignition has
been switched on.
Display the days and distance until the next service interval
You can press button 5 » fig. 2 on page 7 continuously to display the remaining
distance and days until the next service interval whenever the ignition is switch-
ed on.
Notice
■Information is retained in the Service Interval Display even after the vehicle bat-
tery is disconnected.
■If the instrument cluster is exchanged after a repair, the correct values must be
entered in the counter for the Service Interval Display. This work is carried out by
a specialist garage.
■For more information on the service intervals » service schedule, chapter serv-
ice intervals.
Multifunction display (MFA)
Introduction
This chapter contains information on the following subjects:
Operation 14
Memory 15
Information overview 15
Warning against excessive speeds 16

The driving data is displayed on the multifunction display.
The multifunction display can only be operated when the ignition is switched on.
After the ignition is switched on, the function that was last selected before
switching off the ignition is displayed.
WARNING
■Concentrate fully at all times on your driving! As the driver you are fully re-
sponsible for the operation of your vehicle.
■Even at temperatures of around +4 °C, black ice may still be on the road sur-
face! You should therefore not only rely on the outside temperature display
for accurate information as to whether there is ice on the road. 
Operation
Fig. 5
Buttons on the control lever
First read and observe the introductory information and safety warn-
ings on page 14.
The multi-function display can be operated with the buttons on the control lev-
er » fig. 5 .
Description of the operation
Button Action Operation
Apush up or down briefly Select data / set data values
Bpress briefly Show indication / confirm information 

14 Usage

Memory
Fig. 6
Multi-function display - Display
example of the memory
First read and observe the introductory information and safety warn-
ings on page 14.
The multifunction display is equipped with two automatic memories, 1 and 2. The
selected memory is shown in the Display » fig. 6.
Single-trip memory (memory 1)
The single-trip memory collates the driving information from the moment the ig-
nition is switched on until it is switched off. New data will also flow into the cal-
culation of the current driving information if the trip is continued within 2 hours
after switching off the ignition. If the trip is interrupted for more than 2 hours,
the memory is automatically erased.
Total-trip memory (memory 2)
The total distance driven memory gathers data from any number of individual
journeys up to a total of 19 hours and 59 minutes driving or 1 999 kilometres driv-
en. The memory is deleted when either of these limits is reached and the calcula-
tion starts all over again.
Unlike the single-trip memory, the total-trip memory is not deleted after a period
of interruption of driving of 2 hours.
Select memory
›Select the corresponding element of the multi-function display » page 14, Oper-
ation.
›Press the button B » fig. 5 on page 14 for longer.
Reseting
›Select the corresponding element of the multi-function display » page 14, Oper-
ation.
›Select the desired memory.

›Press the button B » fig. 5 on page 14 for longer.
The following values of the selected memory are set to zero.
›Average fuel consumption.
›Distance driven.
›Average speed.
›Driving time
Notice
All information in the memory 1 and 2 is erased if the battery of the vehicle is dis-
connected. 
Information overview
First read and observe the introductory information and safety warn-
ings on page 14.
Outside temperature
The current outside temperature is displayed.
Driving time
The driving time which has elapsed since the memory was last erased appears in
the display. If you want to measure the time travelled from a particular moment in
time on, at this moment, reset the memory by setting the button to
zero » page 15, Memory.
The maximum distance indicated in both memories is 19 hours and 59 minutes.
The indicator is set back to zero if this period is exceeded.
Current fuel consumption
The current fuel consumption level is displayed in litres/100 km. You can use this
information to adapt your driving style to the desired fuel consumption.
The display appears in litres/hour if the vehicle is stationary or driving at a low
speed.
Average fuel consumption
The average fuel consumption since the memory was last erased is displayed in
litres/100 km.
If you wish to determine the average fuel consumption over a certain period of
time, you must set the memory at the start of the new measurement to
zero » page 15, Memory. After erasing the memory, no value is displayed until you
have driven approx. 300 m. 

15
Information system

The display is updated regularly while you are driving.
Range
The estimated range is displayed in kilometres. It indicates the distance you can
still drive with your vehicle based on the level of fuel in the tank and the same
style of driving.
The display is shown in steps of 10 km. After lighting up of the indicator light 
the display is shown in steps of 5 km.
The fuel consumption over the last 50 km is used to calculate the information.
The range will increase if you drive in a more economical manner.
If the memory is set to zero (after disconnecting the battery), a fuel consumption
of 10 l./100 km is calculated for the range; afterwards the value is updated ac-
cording to the style of driving.
Distance travelled
The distance travelled since the memory was last erased is displayed » page 15,
Memory. If you want to measure the distance travelled from a particular moment
in time on, at this moment, reset the memory by setting the button to
zero » page 15, Memory.
The maximum distance indicated in both memories is 999 km. The indicator is set
back to zero if this period is exceeded.
Average speed
The average speed since the memory was last erased is displayed in km/
hour » page 15, Memory. To determine the average speed over a certain period of
time, set the memory to zero at the start of the measurement » page 15, Memory.
After erasing this data, no value appears in the display until you have driven ap-
prox. 300 m.
The display is updated regularly while you are driving.
Current speed
The current speed, which is identical to the display of the speedometer 3 » fig. 2
on page 7 is displayed.
Warning against excessive speeds
The warning that the speed limit is being exceeded can be enabled / disa-
bled » page 16, Warning against excessive speeds in the display. 
Warning against excessive speeds
First read and observe the introductory information and safety warn-
ings on page 14.
Adjust the speed limit while the vehicle is stationary
›Select the  menu item.
›Activate the speed limit option by confirming this menu item1).
›Set the desired speed limit, e.g. 50 km/h.
›Store the speed limit by confirming the set value, or wait several seconds; your
settings will be saved automatically.
The speed limit can be adjusted from 30 km/h to 250 km/h in 5 km/h increments.
Adjusting the speed limit while the vehicle is moving
›Select the  menu item.
›Drive at the desired speed, e.g. 50 km/h.
›Confirm the current speed as the speed limit.
If you wish to adjust the set speed limit, you can do so in 5 km/h intervals (e.g. the
accepted speed of 47 km/h increases to 50 km/h or decreases to 45 km/h).
›Store the speed limit, or wait several seconds; your settings will be saved auto-
matically.
Change or disable speed limit
›Select the  menu item.
›By confirming the stored value, the speed limit is disabled.
›By reconfirming, the option to change the speed limit is activated.
If the set speed limit is exceeded, an audible signal will sound as a warning. At
the same time the menu item is displayed  with the set threshold.
The set speed limit value remains stored even after switching off the ignition. 

1) If no value is set the output value 30 km/h is automatically displayed.
16 Usage

Unlocking and opening
Unlocking and locking
Introduction
This chapter contains information on the following subjects:
Vehicle key 17
Unlocking/locking with the key 18
Unlock/lock with remote control 18
Locking/unlocking the vehicle from the inside 19
Child safety lock 19
Opening/closing a door 20
Your car is equipped with a central locking system.
The central locking system allows you to lock and unlock all doors, the fuel filler
flap and tailgate at the same time based on the current setting.
The following is true after unlocking.
›The doors, the boot lid and the fuel filler flap are unlocked.
›The interior light, which is switched by the door contact, comes on.
›The indicator light in the driver door stops flashing.
The following is true after locking.
›The doors, the boot lid and the fuel filler flap are locked.
›The interior lights switched by the door contact come on.
›The indicator light in the driver door begins flashing.
Automatic locking
All the doors and the boot lid are locked automatically once the car reaches a
speed of about 9 km/h.
Displaying an error
If the indicator light in the driver's door initially flashes quickly for around 2 sec-
onds, and then lights up for 30 seconds without interruption before flashing
again slowly, you will need to seek the assistance of a specialist garage.
Notice
■In the event of an accident in which the airbags are deployed, the locked doors
are automatically unlocked in order to enable rescuers to gain access to the vehi-
cle.
■Only the driver's door can be unlocked or locked using the key if the central
locking system fails » page 18. The other doors can be notverriegeln or emer-
gency release » page 110 . 
Vehicle key
First read and observe the introductory information given on page 17.
Two keys are provided with the vehicle.
The transmitter with the battery is housed in the handle of the remote control
key. The receiver is located in the interior of the vehicle. The operating range of
the remote control key is approx. 30 m. But this range of the remote control can
be reduced if the batteries are weak.
The remote control key has a fold-open key bit which can be used for unlocking
and locking the car manually and also for starting the engine.
WARNING
Always withdraw the key whenever you leave the vehicle - even if it is only for
a short time. This is particularly important if children are left in the vehicle.
Otherwise, the children might start the engine or operate electrical equipment
(e.g. power windows) – risk of injury!
CAUTION
■Each key contains electronic components; therefore it must be protected
against moisture and severe shocks.
■Keep the groove of the keys absolutely clean. Impurities (textile fibres, dust,
etc.) have a negative effect on the functionality of the locking cylinder and igni-
tion lock.
■The battery must be replaced if the central locking only reacts to the remote
control at less than 3 metres away » page 109.

17
Unlocking and opening

Notice
■The spare key must by initialised by a specialist garage after repair or replace-
ment of the receiver unit. Only then can the remote control key be used again.
■If you lose a key, please contact a specialist garage, who will be able to provide
you with a new one. 
Unlocking/locking with the key
Fig. 7
Right side of the vehicle: Locking
cylinder
First read and observe the introductory information given on page 17.
Unlocking
›Turn the key in the locking cylinder of the driver's door in the direction of arrow
B .
Locking
›Turn the key in the locking cylinder of the driver's door in the opposite direction
of travel (lock position) B .
CAUTION
If the driver's door has been opened, the vehicle cannot be locked. 

Unlock/lock with remote control
Fig. 8
Remote control key
First read and observe the introductory information given on page 17.
Explanation of graphic
Unlocking the vehicle
Locking the vehicle
Unlocking the boot lid
Folding out/folding up of the key bit
Indicator light for battery condition
Unlocking
The turn signal lights flash twice as confirmation that the vehicle has been un-
locked.
If the vehicle is unlocked and opened within the next 30 seconds with no door or
the boot lid, the vehicle is automatically locked again. This function is intended to
prevent the car being unlocked unintentionally.
Locking
The turn signal lights flash once as confirmation that the vehicle has been locked.
If the doors or the boot lid remain open after the vehicle has been locked, the
turn signal lights do not flash until they have been closed.
Checking the battery condition
The battery is empty if the red warning icon B » fig. 8 does not flash when you
press a button on the remote control key. Replace the battery » page 109.




A
B
18 Usage
