Skope PG Series User manual

PG Horizontal Series
1-1 & 2-1 Chillers & Freezers
User Manual MAN10710 Rev. 2.2 Mar. 2018
SKOPE PEGASUS
PG200HC
PG500Prep
PG800Pizza

SKOPE Warranty Protection
To activate your Warranty Protection, you must
register your product with SKOPE within 4 weeks
from date of invoice.
To register online:
Visit our website at www.skope.com/warrantyprotection
then complete and submit the online registration form.
Or alternatively contact our Customer Services team to register:
1800 121 535 (Australia)
0800 947 5673 (New Zealand)
SKOPE 1-year Extended Warranty
Extend your Warranty Protection by 1 year during registration. Please
check you have not already organised an extended warranty through
your dealer at time of purchase. For pricing information on an extended
warranty visit www.skope.com/warrantyprotection
Service & Support
We know you will get years of satisfaction from your new SKOPE
product when you follow a few simple preventative maintenance
guidelines.
Helpful information is available on our website
www.skope.com/serviceandsupport
Thank you for purchasing a SKOPE refrigeration product.

CONTENTS
1 Models
Undercounter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Prep. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Pizza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Installation
Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Locating the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Positioning the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Plinth Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Legs and Castors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Shelving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Fitting the Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Loading Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pans and Lids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fitting the Lids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Cabinets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigeration Practice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Refrigeration Pipes and Solenoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3 Operation
Automatic Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
HACCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pans and Lids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Controller Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Temperature Setpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Controller Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 Servicing
Mains Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Pans & Air Diffusers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cabinet Interior Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Advanced Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Refrigeration Unit Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

SKOPE Pegasus Horizontal Series
User Manual 4
1Models
Undercounter
Prep
Pizza
Model Part No. Config. Doors Refrigeration
unit
Operating temperature
range
PG100HC-2 JH2301 1-1 chiller 1 Integral
+1°C to +4°C up to 43°C
ambient
PG250HC-2 JH2302 1-1 chiller 2 Integral
PG400HC-2 JH2303 1-1 chiller 3 Integral
PG550HC-2 JH2304 1-1 chiller 4 Integral
PG200HC JK2301 2-1 chiller 1 Integral
PG500HC JK2302 2-1 chiller 2 Integral
PG800HC JK2303 2-1 chiller 3 Integral
PG100HCr-2 JH3301 1-1 chiller 1 Remote
PG250HCr-2 JH3302 1-1 chiller 2 Remote
PG400HCr-2 JH3303 1-1 chiller 3 Remote
PG550HCr-2 JH3304 1-1 chiller 4 Remote
PG200HCr JK3301 2-1 chiller 1 Remote
PG500HCr JK3302 2-1 chiller 2 Remote
PG800HCr JK3303 2-1 chiller 3 Remote
PG100HF-2 JH1301 1-1 freezer 1Integral
-18°C to -21°C up to
43°C ambient
PG250HF-2 JH1302 1-1 freezer 2Integral
PG400HF-2 JH1303 1-1 freezer 3Integral
PG500HF JK1302 2-1 freezer 2Integral
PG100HFr-2 JH5301 1-1 freezer 1Remote
PG250HFr-2 JH5302 1-1 freezer 2Remote
PG400HFr-2 JH5303 1-1 freezer 3Remote
PG200HFr JK5301 2-1 freezer 1Remote
PG500HFr JK5302 2-1 freezer 2Remote
Model Part No. Config. Doors Refrigeration
unit
Operating temperature
range
PG250Prep-2 JH7302 1-1 chiller 2Integral
+1°C to +5°C up to 30°C
ambient
PG400Prep-2 JH7303 1-1 chiller 3Integral
PG550Prep-2 JH7304 1-1 chiller 4Integral
PG500Prep JK7302 2-1 chiller 2Integral
PG800Prep JK7303 2-1 chiller 3Integral
PG250Prepr-2 JH8302 1-1 chiller 2Remote
PG400Prepr-2 JH8303 1-1 chiller 3Remote
PG550Prepr-2 JH8304 1-1 chiller 4Remote
PG500Prepr JK8302 2-1 chiller 2Remote
PG800Prepr JK8303 2-1 chiller 3Remote
Model Part No. Config. Doors Refrigeration
unit
Operating temperature
range
PG500Pizza JK9302 2-1 chiller 2Integral
+1°C to +5°C up to 30°C
ambient
PG800Pizza JK9303 2-1 chiller 3Integral
PG500Pizzar JK6302 2-1 chiller 2Remote
PG800Pizzar JK6303 2-1 chiller 3Remote

5
SKOPE Pegasus Horizontal Series
Installation
User Manual
2Installation
Safety First Always observe safety precautions when using any electrical appliance.
Read these instructions carefully and retain them for future reference.
When the appliance is used by or near young children or infirm persons,
close supervision is necessary, especially to ensure children do not play
with it.
Do not use this appliance for other than its intended use.
Do not cover the grilles or block the entry or exhaust of airflow by
placing objects up against the refrigeration unit.
Do not probe any opening.
Only use this appliance with the voltage specified on the rating label.
Ensure the appliance has adequate ventilation as this is essential to
economical, high performance.
Be careful not to touch moving parts and hot surfaces.
For your own safety and that of others, ensure that all electrical work is
done by authorised personnel.
If the power supply flexible cord becomes damaged, it must be replaced
by an authorised service agent or similarly qualified person in order to
avoid a hazard.
Ensure all necessary safety precautions are observed during installation
or removal of the refrigeration unit.
The appliance is not designed to be stable while in motion. Use extreme
caution when moving or transporting it.
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Please contact SKOPE customer services for advice regarding disposal
of this appliance.
CAUTION
Never overload the power supply, which could damage the
chiller and product. See the rating label inside the cabinet for
the safe power supply and current draw.
WARNING
Always disconnect the chiller from the mains power supply
before cleaning or maintenance.

6Installation
User Manual
SKOPE Pegasus Horizontal Series
Locating the Cabinet
Location When positioning the cabinet, avoid direct sunlight and warm draughts etc.
The cabinet must NOT be situated where it is affected by warm or hot air
from adjacent equipment, as this will compromise the airflow and
performance of the chiller.
The cabinet must be positioned on a level surface for the doors to shut and
seal correctly, and to prevent the condensate tray from overflowing.
Adequate allowance should be made for door opening.
Always ensure that the top of the cabinet is shielded from impact and
moisture, with either a SKOPE provided bench top, or with a custom or
existing bench top.
Prep and Pizza chillers have pan openings with lids on the top of the cabinet.
Maximum air movement around the opening area of the cabinet must not
exceed 0.3 m/s. Excessive air movement will cause failure of the air curtain
above the pans and excessive temperature rise.
When installing the cabinet
Avoid direct sunlight and warm draughts etc.
Allow adequate space for the door/s and/or drawer/s to open fully.
Ensure the cabinet is positioned on a level surface so the door/s shut
and seal correctly and to prevent the condensate tray from overflowing.
Air movement above Prep and Pizza chillers must not exceed 0.3 m/s.
Ventilation For efficient operation of the chiller, it is essential that adequate ventilation
be provided around the front of the refrigeration unit. Normal operating
conditions should not exceed the operating temperature range (see page 4).
It is critical that the hot refrigeration exhaust air is not restricted and that it
can easily flow out and away from the front of the cabinet. Never store
cardboard cartons or other items in front of the refrigeration unit. The
ventilation slots on the unit front cover must be kept clear at all times.
Power Supply The chiller is supplied with a flexible power cord and plug, which for transit
purposes is located inside a compartment in the rear of the cabinet (see
image below).
Before final positioning of the chiller, pull the power cord out from the rear
compartment and connect to the power supply. For convenience, any
surplus cord length may be left inside the cabinet compartment.
WARNING:
Do NOT overload the power supply. See the rating label inside
the cabinet for power supply and current draw.
Power cord

7
SKOPE Pegasus Horizontal Series
Installation
User Manual
Positioning the Cabinet
The cabinet is supplied ready for plinth mounting or with adjustable legs and
castors to support the cabinet.
Plinth
Mounting
1-1 cabinets are supplied with leg/castor mounting plates on the bottom of
the cabinet. Before mounting the cabinet, remove the mounting plates by
unscrewing the fixing bolts (4 per mounting plate) to provide a flat surface
on the bottom of the cabinet.
2-1 cabinets should be specified as either plinth mounted or leg/castor
mounted when ordered. 2-1 plinth mount cabinets have a flat base and are
fitted with a plinth surround, ready for positioning in place.
When installing plinth mounted remote refrigeration cabinets, refer to
seperate technical installation and specification documentation (SKOPE
part number: PRN10712).
Legs and
Castors
1-1 cabinets and 2-1 leg/castor mount cabinets are packed with a set of
adjustable height legs and a set of adjustable height castors. Either of these
sets can be fitted to the cabinet depending on specific height and
manoeuvrability requirements. The legs or castors should be fitted to the
base of the cabinet before final positioning.
The adjustable legs screw into the castor mounting plates attached to the
bottom of the cabinet. The adjustable legs can adjust the cabinet height up
to 30mm.
To adjust leg height
The adjustable castors screw into the castor mounting plates attached to the
bottom of the cabinet. The two lockable castors should be fitted to the front
of the cabinet and the non-locking castors fitted to the rear. The adjustable
castors can adjust the cabinet height up to 15mm.
To adjust castor height
1. Turn the black plastic foot
at the bottom of the leg
counter-clockwise to raise
the height or clockwise to
lower.
1. Loosen the lock nut.
2. Turn the castor counter-
clockwise to raise the
height or clockwise to
lower (see image below).
Re-tighten each lock nut
after final adjustment has
been made.
Castor
mounting plate
Adjustable leg
Plastic foot
Lock nut

8Installation
User Manual
SKOPE Pegasus Horizontal Series
Shelving
Fitting the
Shelves
The cabinet is supplied with two sets of shelves and shelf support brackets
per door. The shelves can be positioned at different heights to suit various
products.
To fit the shelves
Pans The shelf support brackets can also hold gastronorm pans. To store pans,
remove the shelves and slide the pans into the shelf support brackets.
Loading
Product
The chiller should be left running for 30 minutes before loading with product.
When loading product
Allow air space around all the product to ensure even cooling and
efficient operation of the chiller.
Do not allow products to overhang the front of the shelf as this could
prevent the doors from shutting. Leave an airspace of at least 75mm
above product loaded on the top shelf.
Do not exceed a maximum loading of 20kg per shelf.
Remove some product if the shelves are flexing or bending.
1. Unpack the shelving items from inside the cabinet.
2. Establish the desired position for each of the shelves, based on the height of
the product intended to go on each shelf.
3. Fit the shelf support
brackets into the
corresponding slots in
both the front and back
support strips. Each shelf
requires two support
brackets.
4. Slide each shelf into the
support brackets.
Shelf support strips
Shelf support
bracket
Shelf

9
SKOPE Pegasus Horizontal Series
Installation
User Manual
Pans and Lids
Prep and Pizza chillers are supplied with food preparation pans and sliding
lids which fit into openings on top of the cabinet. Refer to the tables below
for standard pan and lid quantities:
Prep cabinet
Pizza cabinet
Fitting the Lids Fit the lids into the removable rails in the well, and should alternate between
the bottom (in the rail channel) and top (on top of the rail). Orientation of the
lids is important. Ensure the notched ends meet on the inside to prevent
finger jamming. See over page for fitting instructions.
Model Doors Pans Lids
Large Small Ambient
PG250Prep-2 24 x 1/3 150mm deep
refrigerated pans - 2 -
PG400Prep-2 37 x 1/3 150mm deep
refrigerated pans 1 2 -
PG550Prep-2 410 x 1/3 150mm deep
refrigerated pans 2 2 -
PG500Prep 27 x 1/3 150mm deep
refrigerated pans 1 2 -
PG800Prep 311 x 1/3 150mm deep
refrigerated pans 3 1 -
Model Doors Pans Lids
Large Small Ambient
PG500Pizza 2
7 x 1/3 150mm deep
refrigerated pans, 2 x 1/3
65mm deep ambient pans
1 2 1
PG800Pizza 3
11 x 1/3 150mm deep
refrigerated pans, 2 x 1/3
65mm deep ambient pans
3 1 1
Lids in place
Bottom lid
(in rail channel)
Top lid (on
top of rail)
Rail
Rail channel
Notched ends meet
on the inside
PG500Prep pictured

10 Installation
User Manual
SKOPE Pegasus Horizontal Series
To fit sliding lids
For correct operation of the chiller, the sliding lids must stay closed on the
cabinet and should cover the food preparation pans when not in use.
Prep and Pizza chiller operating temperature range is +1°C to +5°C for up
to four hours in 30°C ambient with the lids off.
1. Lift the rails from the well,
leaving the ends resting
on one side of the cabinet
top.
2. Configure the lids as
required with the notched
ends meeting on the
inside, and slide the lower
lids into the rails.
Orientation of the lids is
important. Ensure the
notched ends meet on the
inside to prevent finger
jamming.
3. Lower the rails and lower lids fully into the well so that they sit on the outside
of the pan edges, and place the remaining lids on top of the rails.
IMPORTANT
Sliding lids must be in place when pans not in use. Leaving
the lids off for extended periods will compromise performance
of the chiller.

11
SKOPE Pegasus Horizontal Series
Installation
User Manual
Remote Cabinets
Refrigeration Practice
Installation must be performed by a refrigeration tradesperson, to an appropiate standard
complying with all local regulations.
Performance depends on the overall installation (including condensing unit). Cabinet suitability
must always be quantified for the application. The final responsibility for condensing unit
performance and component selection rest with the installer.
The installer must check matters such as:
Heat and refrigeration load.
Variable operating conditions (usage, ambient and humidity).
Refrigeration pipe sizing and length (distance, elevation and pressure drop).
Location and ventilation (cabinet and condensing unit).
Drainage and power supply.
Fully evacuating the unit prior to charging.
Specifications
Pegasus horizontal 1-1
Pegasus horizontal 2-1
Drain
A 350mm long, 19mm O.D. PVC drain hose is supplied. All drainage must conform to local
regulations, covering removal of condensate to waste water. Ensure the cabinet is level and the
drain is trapped with adequate fall. Venting the drain may be required for a restrictive run. Use rigid
PVC pipe for the drain and ensure the drain has a minimum fall of 50mm per metre of drain length.
Model Refrig. duty Max ambient
temp.
Mean product
temp.
Condensing
temp.
Liquid temp. Evaporating
temp. (SST)
Operation
basis
PG100HCr-2 210 Watts 43°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG250HCr-2 360 Watts 43°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG400HCr-2 485 Watts 43°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG550HCr-2 630 Watts 43°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG100HFr-2 230 Watts 43°C -18°C 45°C 40°C -30°C 18 / 24 hours
PG250HFr-2 385 Watts 43°C -18°C 45°C 40°C -30°C 18 / 24 hours
PG400HFr-2 550 Watts 43°C -18°C 45°C 40°C -30°C 18 / 24 hours
PG250Prepr-2 500 Watts 30°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG400Prepr-2 980 Watts 30°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
PG550Prepr-2 1180 Watts 30°C 3.5°C 45°C 40°C -5°C 18 / 24 hours
Model Refrigeration
duty
Max ambient
temp.
Mean product
temp.
Condensing
temp.
Liquid temp. Evaporating
temp. (SST)
Operation
basis
PG200HCr 447 Watts 43°C 3.5°C 45°C 40°C -10°C 18 / 24 hours
PG500HCr 534 Watts 43°C 3.5°C 45°C 40°C -10°C 18 / 24 hours
PG800HCr 599 Watts 43°C 3.5°C 45°C 40°C -10°C 18 / 24 hours
PG200HFr 180 Watts 43°C -18°C 45°C 40°C -30°C 18 / 24 hours
PG500HFr 364 Watts 43°C -18°C 45°C 40°C -30°C 18 / 24 hours
PG500Prepr 706 Watts 30°C 3.5°C 45°C 40°C -10°C 18 / 24 hours
PG800Prepr 706 Watts 30°C 3.5°C 45°C 40°C -10°C 18 / 24 hours

12 Installation
User Manual
SKOPE Pegasus Horizontal Series
Electrical The cabinet is supplied with a 10A flexible power cord and 3-pin plug. The
cabinet lighting and centre pillar heater elements are protected by a 3A fuse,
located in the unit junction box.
Once the chiller has been installed it can be disconnected from the mains
power supply by turning off the cabinet isolation switch and unplugging the
refrigeration unit supply isolation flexible cord - located inside the
refrigeration unit compartment (see diagram below).
Electronic
Controller
When the cabinet is connected to the power supply, the electronic controller
will display the current cabinet temperature. On the controller display, the
symbol will indicate the compressor output signal has been initiated and the
symbol will indicate the evaporator fan is on.
Refrigeration
Pipes and
Solenoid
A 1/4” liquid line and a 3/8” suction line are provided to attach pipes to. The
suction line must be insulated.
The electronic controller supplied with the cabinet can switch a solenoid. No
solenoid is supplied with the standard remote unit. If a solenoid is fitted and
controlled by the electronic controller, the solenoid will need to be connected
to the connector block inside the unit junction box.
Installation
Diagrams
Refer to the diagram below (Pegasus Horizontal 1-1) and over the page
(Pegasus Horizontal 2-1) for component locations and unit access points.
Pegasus Horizontal 1-1 installation diagram
19mm
drain tube
Mains
isolation box Service ports (bottom
of refrigeration unit
compartment)
40 147
131 159 114
Side view Front view
Bottom view
100
Cabinet
front
Cabinet
rear
Refrig. pipes
Service ports
(back of
cabinet)
50 50
Door
15

13
SKOPE Pegasus Horizontal Series
Installation
User Manual
Pegasus Horizontal 2-1 installation diagram
Cabinet
front
Cabinet
rear
Refrig. pipes
19mm
drain tube
Mains
isolation box Service port (bottom
of refrigeration unit
compartment)
115 150
252 250
Side view Front view
Bottom view
Service port
(back of
cabinet)
141 50
32

14 Operation
User Manual
SKOPE Pegasus Horizontal Series
3Operation
Automatic Start-Up
Connect the cabinet to the mains power supply and check operation of the
refrigeration unit and electronic controller.
Ensure the cabinet isolating switch, located inside the refrigeration unit
compartment, is turned on (see “Mains Isolation” on page 18).
Refrigeration
Unit
The compressor, and the condenser and evaporator fans should all operate
within two minutes from the time the cabinet is plugged in. This may be
verified by listening for compressor switch-on and checking for air
movement inside the cabinet. The compressor and condenser fan will
switch off when the cabinet internal air reaches a pre-set temperature.
Electronic
Controller
When the cabinet is connected to the power supply, the electronic controller
will display the current cabinet temperature. The compressor LED will
indicate the compressor is operating and the evaporator fan LED will
normally come on within two minutes (see “Electronic Controller” on page 15
for controller display).
To ensure efficient operation, the electronic controller forces regular
defrosts. During the defrost cycle, the compressor and condenser fan switch
off and the evaporator fan stays on.
HACCP If Hazard Analysis Critical Control (HACCP) functions are required, to
monitor food storage temperature, please contact SKOPE to arrange for an
authorised SKOPE service technician to setup the electronic controller.
Pans and Lids
For correct operation of Prep and Pizza chillers, the pan lids must stay on
the cabinet and should cover the food preparation pans when not in use.
The maximum recommended operating ambient temperature for Prep and
Pizza chillers is 30°C.
IMPORTANT
If the cabinet has been on its back, leave for 30 minutes
before running.
IMPORTANT
Lids or sliding covers must be in place when pans not in use.
Leaving the lids off for extended periods will compromise
performance of the chiller.
Pan lids

15
SKOPE Pegasus Horizontal Series
Operation
User Manual
Electronic Controller
910
11
12
43
15
14
1312
8
7
6
5
Item Icon Function
1
Mute / program: Mutes the audible alarm (buzzer) and
deactivates the alarm relay. To initiate program sets, press for 5
seconds.
2Up: To scroll settings up (in program mode).
3Set point: If pressed for more than 2 seconds displays and / or
enables changing the temperature setpoint.
4Manual defrost / down: Press for more than 5 seconds to initiate
manual defrost. To scroll settings down (in program mode).
5
Compressor: ON when the compressor and condenser fan
starts. Flashes when activation of the compressor is temporarily
delayed.
6Fan: Shows when the fan is operational.
7
Defrost: ON when the defrost is activated. Flashes when the
activation of the defrost is temporarily delayed due to procedures
in progress.
8Aux: n.a.
9Alarm: Flashes in the event of alarms.
10 Clock: n.a.
11 Light: n.a.
12 Service: Flashes in the event of malfunctions.
13 DISPLAY: Shows the cabinet temperature. Flashes when the
door is open.
14 HACCP: n.a.
15 CONTINUOUS CYCLE: On when freezer is running in continuous
run mode.

16 Operation
User Manual
SKOPE Pegasus Horizontal Series
Controller
Overview
The CAREL ir33 electronic controller controls and displays the internal
cabinet temperature. The preset temperature setting keeps the product
temperature within the operating temperature range (see page 4). The
electronic controller also signals temperature alarms (see next page).
For general operation, the electronic controller requires no initial setup or
additional programming. When the cabinet is connected to the power
supply, the electronic controller will display the current cabinet temperature.
The compressor LED will indicate the compressor is operating and the
evaporator fan LED will normally come on within 2 minutes.
Open the unit door to access to electronic controller for programming. Note:
On 2-1 cabinets the controller must also be unhooked from the unit door to
access the buttons.
Temperature
Setpoint
The chiller temperature setpoint is factory set and can be adjusted if
necessary.
SKOPE do not recommend that the setpoint be changed unless it is
absolutely necessary, and then only by small increments at a time.
To view and adjust the temperature setpoint
1. To view the setpoint:
Press and hold the key for 2 seconds, until the
setpoint value flashes.
2. To adjust the setpoint:
Press either the or keys to display the required
setpoint value.
3. Press the key again to memorise the new setpoint
value. If this is not done within 60 seconds changes will
be lost and you will need to repeat the above
procedure.

17
SKOPE Pegasus Horizontal Series
Operation
User Manual
Controller
Alarms
The following table explains messages that the electronic controller displays
and related alarms. Alarms signal unexpected operational changes in the
freezer and stop when action is taken to resolve the problem.
Code Display Alarm Action
Flashing
Product HIGH
temperature alarm
(auto reset)
1. Check the cabinet product loading to ensure
ventilation slots are not blocked, and that
product does not overhang the shelves.
Ensure the doors are closed.
2. Ensure the cabinet is installed with good
refrigeration unit ventilation.
3. Check and clean the condenser coil (see
page 19).
4. If immediate alarm recovery is required -
unplug the cabinet from the power supply for
1 minute, then reconnect to power supply. If
alarm persists, contact SKOPE.
NOTE: The ‘HI’ and ‘LO’ alarms deactivate the
cabinet lighting and trim heaters.
Flashing
Product LOW
temperature alarm
(auto reset)
Flashing
Refrigeration
system high
temperature
pre-warning (auto
reset)
1. Clean the condenser coil (see page 19).
2. Check refrigeration ventilation. Ensure clear
airpath in front of the cabinet.
3. Ensure the cabinet is installed in a suitable
environment.
4. To reset the ‘CHt’ alarm - unplug the cabinet
from the power supply for 1 minute, then
reconnect to power supply. If alarm persists,
contact SKOPE.
Flashing
Refrigeration
system and
cabinet high
temperature
shutdown (manual
reset)
Flashing
Ambient probe
fault (also flashes
‘rE’)
To reset alarm - unplug the cabinet from the
power supply for 1 minute, then reconnect to
power supply.
1. If alarm persists, contact SKOPE.
Flashing
Evaporator probe
fault
Flashing
Condenser probe
fault
None Defrost over-time
limit
Flashing
Real-time clock
fault
Flashing
Controller E prom
error
Flashing
Controller E prom
error
None Start defrost
request
None
None End defrost
request
Flashing
Door open alarm
Check that a door or drawer has not been left
open. Note: The audible alarm buzzer cannot
be turned off manually.

18 Servicing
User Manual
SKOPE Pegasus Horizontal Series
4Servicing
Mains Isolation
The chiller can be isolated from the mains power supply by turning off the
cabinet isolating switch and unplugging the unit supply plug, located inside
the refrigeration unit compartment.
To isolate the chiller from the power supply
1. Open the unit cover.
2. Switch off (O) the power at the isolation switch, located on the LH side of the
refrigeration cassette compartment, and unplug the unit supply plug.
Unit
cover
Cabinet isolation switch
Unit supply plug

19
SKOPE Pegasus Horizontal Series
Servicing
User Manual
Cleaning
Cabinet When necessary, wipe both the interior and exterior of the cabinet with a
damp cloth. Ensure the cabinet is disconnected from the mains power
supply before cleaning the cabinet.
Condenser
Coil
Integral cabinets only. The condenser coil should be brushed clean once a
month and blown clean by qualified service personnel every six months.
Over time, dust may accumulate within the condenser that cannot be
removed with a brush. If this occurs, contact SKOPE to arrange for a
SKOPE authorised service agent to clean the condenser with compressed
air. The condenser coil is located inside the refrigeration unit compartment
and is accessed by opening the unit front cover. Isolate the chiller from the
power supply (see previous page) before cleaning the condenser coil.
Pans & Air
Diffusers
Prep and Pizza cabinets only. The food preparation pans and air diffuser
panels can be easily lifted from the cabinet for cleaning.
CAUTION
Disconnect the cabinet from the mains power supply before
cleaning the condenser coil or washing the cabinet with water.
IMPORTANT
If the electronic controller display flashes ‘cht’ the condenser
coil must be cleaned immediately.
Condenser coil
Air diffuser

20 Servicing
User Manual
SKOPE Pegasus Horizontal Series
Lighting
Cabinet
Interior Lights
Pegasus 1-1 cabinets are fitted with door activated cabinet interior lights.
Depending on the cabinet size, the interior is lit by one or two 5 Watt T8 LED
tubes (Ø26 x 360mm), fitted behind the centre pillars. The single door
model, without a centre pillar, has the interior interior LED light tube fitted on
the ceiling of the cabinet.
Note: Pegasus 2-1 cabinets are not fitted with interior lights.
To replace the interior LED light tube
1. Isolate the cabinet from the power supply (see page 18).
2. Remove the diffuser by
squeezing it until it is
released from the
housing, and then push
the diffuser out of the way
(multiple door cabinet
pictured for clarity).
3. Rotate the LED tube until
the pins on the ends of the
tube align with the slots,
then slide it out. Note:
access can be made
easier by removing the
shelves.
4. Fit a new LED tube and
clip the diffuser back into
place. When fitting
vertically mounted LED
tubes, ensure the tube is
fitted with the ‘Power’ end
at the top.
Top clamp screw
