1About this Document
The SkyeModule M1 is designed for low power RFID applications that require less than 4 inches of read
range when using the internal antenna of the M1. Alternatively, the M1 can directly drive an
external antenna to provide up to 10 inches of read range. For applications that require more than 10
inches of read range, a power amplifier can be used to drive an external antenna.
The SkyeModule M1 comes with an integrated internal antenna. The M1 will also work with standard
external antenna modules, such as the SkyeRead EA1. However, many customers will need to
design custom external antennas to best fit their specific application requirements.
SkyeTek and its partners also provide custom RFID antenna design services.
Figure 1-1: Example Prototype Antenna

SkyeModule M1 Antenna Design Guide Page | 7
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
1.1 Revision History
Revision
Author
Change
100112
Brad Alcorn
Releasing new format with minor edits.
Table 1-1: Revision History

SkyeModule M1 Antenna Design Guide Page | 8
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
2Overview
This antenna design guide provides some basic theory as well as several practical examples of how
to design high performance cost effective RFID antennas for use with the SkyeTek M1 RFID reader
module.
All antenna connections are made at the Antenna Connector J2.
Figure 2-1: Antenna Connector
J2
Pin
Name
Description
1
GND
Antenna Ground.
2
ANT
Antenna Output pin. ANT provides 50 ohms output for matching an
external antenna. Jumper ANT to INT to enable the on-board antenna.
3
INT
Internal Antenna pin. Jumper INT to ANT to enable the on-board
antenna. Remove the jumper between INT and ANT to disable the on-
board antenna and connect an external antenna.
Table 2-1: J2 Pin Descriptions

SkyeModule M1 Antenna Design Guide Page | 9
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
Using an oscilloscope, the typical waveform at ANT of the M1 can be observed. It should look like
a 13.56MHz sine wave, approximately 10Vpp. Note that typically the antenna drive signal at the ANT
pin of J2 is generated when a host first sends a tag command to the M1 in which the RF_F is set (see
SkyeTek Protocol V2 Guide for more details on RF_F).
2.1 Internal Antenna
The internal antenna of the SkyeModule M1 provides 70mm read range and 100mm x 100mm read
coverage. Connect ANT to INT to enable the internal antenna.
2.2 External Antenna
Figure 2-2: The SkyeRead EA1 External Antenna

SkyeModule M1 Antenna Design Guide Page | 10
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
Figure 2-3: The SkyeRead EA1 Circuit
In the figure above, inductor L1 is the physical antenna loop. Zp forms a resonant circuit tuned at
13.56MHz, so there is an amplification of the ANT signal at B. You can measure and compare the
amplitudes of the sine waves at points A and B as you first adjust C3 to get a maximum amplitude
on the signal at B, and then adjust C4 to further maximize the amplitude of the signal at B.

SkyeModule M1 Antenna Design Guide Page | 11
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
3Custom Antennas
Inductive loop RFID antennas can be made from any electrically conducive material such as tape,
wire, or tubing. The basic requirement is that the antenna is a “loop” with one or more turns. As a
general rule, circular and square antenna loops are optimal geometries. The length to width ratio of a
rectangular antenna should not exceed about 3:1. You can design a custom antenna to provide more
read range and more read coverage than you can get from the internal antenna of the M1.
L1 is the RFID loop antenna. The antenna can be made from wire, copper tape, copper tubing, or
other conductive materials.
ANT has a typical output impedance of 50-ohm at 13.56MHz. The external antenna should be
matched to this 50-ohm output drive impedance. The series capacitance Zs provides the matching
adjustment.
3.1 Design Procedure
The following antenna design procedure can be used. Start with a measured or calculated
inductance for L1, then calculate the capacitor values, then measure and adjust for optimal
performance.
1. Determine the inductance of L1.
a. Build and measure the inductance of L1.
b. Design and calculate the inductance of L1.
2. Determine the capacitance Cp. Pick appropriate values for C2 and C3.
3. Determine the capacitance Cs for matching the M1 output impedance to the antenna input
impedance. Pick appropriate values for C1 and C4.
The resonant frequency of the parallel impedance Zp circuit is governed by the following equation
where,
L1 is the inductance of the antenna loop
R4 is ignored Cp = C2 || C3 ƒ = 13.56MHz is the desired resonant frequency.

SkyeModule M1 Antenna Design Guide Page | 12
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
3.1.1 Example 1
Here are the component values of the SkyeRead EA1 external antenna:
C1 = 22pF 0805 ceramic chip capacitor DigiKey p/n PCC220CNCT-ND
C4 = 3 to 10pF variable capacitor DigiKey p/n SG1015-ND
C2 = 100pF 0805 ceramic chip capacitor DigiKey p/n PCC101CGCT-ND
C3 = not present
R4 is not present
L1 = 1.05uH is the loop inductance of the 2-turn PCB antenna trace approximately 95mm x 95mm.
3.1.2 Example 2 –The Internal Antenna of the M1
For the internal antenna of the M1, the component values are as follows:
C1 = 0 ohm resistor
C4 = ___
C2 = 1000pF 0805 NPO ceramic chip capacitor DigiKey p/n PCC101CGCT-ND
C3 = ___
R4 = ___
L1 = 15-nH is the loop inductance of the single-turn PCB antenna trace

SkyeModule M1 Antenna Design Guide Page | 13
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
3.1.3 Example 3 –Copper Tape External Antenna
Figure 3-1: Example Antenna Layout
L1 is 1-turn rectangle loop copper tape
X = 170mm
Y = 30mm
W = 10mm
C1 = 47pF dipped mica capacitor
C4 = ___
C2 = 800pF dipped mica capacitor (470||330)
C3 = ___
R4 = ___
While monitoring A and B with an oscilloscope, you will see how this antenna is susceptible to detuning
from mounting on metal and even from the presence of one or more tags. In order to design the
antenna so that you could mount it onto either metal or non-metal and see similar performance, the
antenna can be designed with a ground ring or a shield on a top and bottom layer. The next example
shows a ground ring around the antenna. See the following drawing and picture.

SkyeModule M1 Antenna Design Guide Page | 14
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
Figure 3-2: Improved Antenna with Ground Shield
X = 170mm
Y = 30mm
W = 10mm
C1 = 220pF dipped in mica capacitor
C4 = ___
C2 = 1810pF dipped mica capacitor (470||560||560||220)
C3 = ___
R4 is not present

SkyeModule M1 Antenna Design Guide Page | 15
Skyetek Inc
1525 Market St. Ste 200
Denver, CO 80202
www.skyetek.com
Main 720.328.3425 Fax:[phone]
The following pictures are examples of how to build a prototype antenna. If you will mount the
antenna on metal, then you should design the antenna on metal as shown in Figure 3-3.
Figure 3-3: Design antenna on metal
Figure 3-4: Points A and B shown
