DESCRIPTION
Shure PA Series UHF Antenna Combiners combine antenna outputs
from upto four PSM wireless transmitters to a single antenna, minimizing
intermodulation distortion and reducing rack clutter.
CONNECTIONS
1. Using the cables supplied with each PSM Transmitter, connect
the ANTENNA OUT of each PSM Transmitter to the INPUTS of
the PA Antenna Combiner.
2. Attach the antenna (one supplied with each PSM Transmitter), or
an optional directional antenna such as the Shure Model PA705,
to the ANTENNA OUT connector of the PA Antenna Combiner.
3. Run the supplied power cable from the power connector to a
power supply.
PA Antenna Combiner
PSM Transmitters
SPECIFICATIONS
UHF Carrier Frequency Range
Model Number Frequency Range
PA760 620 to 670 MHz
PA765 800 to 870 MHz
PA770 720 to 750 MHz
System Gain
0 dB (+2 dB, –4 dB)
Input/Output Port VSWR
Less than 1.7:1
Output Port Isolation
Greater than 23 dB
Third Order Intercept Point (3 OIP)
Greater than 25 dBm
Input AC Line Voltage
100 to 240 Vac, 50/60 Hz (country dependent)
NOTE: This product is not completely disconnected from the mains
when the power switch is in OFF position.
Maximum Input Current
0.5 Aac
Maximum RF Input Power
+20 dBm (100 mW)
Impedance
50 Ω nominal
Operating Temperature Range
–7°C to +49°C
Overall Dimensions
44.5 mm high x 197.4 mm wide x 225.6 mm deep
(1.75 in. x 7.770 in. x 8.880 in.)
Net Weight
1.34 Kg (2 lbs, 15.4 oz)
Input/Output Connector Type
BNC-type (4 input, 1 output)

ENGLISH
3
Furnished Accessories
Rack Mount Kit PA745. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 ft. Coaxial Cable (RG-58/U) UA802. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Accessories
Unidirectional Antenna (620–870 MHz) PA705. . . . . . . . . . . . . . . . . . . .
2 ft. Coaxial Cable (RG-58/U) UA802. . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 ft. Coaxial Cable (RG-58/U) PA725. . . . . . . . . . . . . . . . . . . . . . . . . .
25 ft. Coaxial Cable (RG-8/X) UA825. . . . . . . . . . . . . . . . . . . . . . . . . . . .
50 ft. Coaxial Cable (RG-8/X) UA850. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement Parts
Bulkhead Adapters 95A8647. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
120 VAC Power Line Cord 95A8389. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
230 VAC Power Line Cord 95A8247. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2403 VAC Power Line Cord (U.K.) 95A8713. . . . . . . . . . . . . . . . . . . . . .
Certifications
PA760, PA770: Type accepted under FCC Part 74. Certified by IC in Can-
ada under RSS-123. UL and cUL listed to UL813 and CSA 22.2 No. 1.
PA760, PA765, PA770: Conforms to European Union Low Voltage Direc-
tive (73/23/EEC) and EMC Directive (89/336/EEC), eligible to bear CE
marking. Meets Low Voltage Requirements: VDE GS-Certified to EN
60065. Meets EMC Emission and Immunity Requirements: EN 300 445.
Meets the essential requirements of the European R&TTE Directive
99/5/EC and are eligible to carry the marking.
Licensing
Changes or modifications not expressly approved by Shure Incorporated
could void your authority to operate the equipment. Licensing of Shure
wireless microphone equipment is the user’s responsibility, and licensabil-
ity depends on the user’s classification and application, and on the selected
frequency. Shure strongly urges the user to contact the appropriate tele-
communications authority concerning proper licensing, and before choos-
ing and ordering frequencies.
THIS RADIO EQUIPMENT IS INTENDED FOR USE IN PROFESSION-
AL ENTERTAINMENT AND SIMILAR APPLICATIONS.
NOTE: THIS EQUIPMENT MAY BE CAPABLE OF OPERATING ON
SOME FREQUENCIES NOT AUTHORIZED IN YOUR REGION.
PLEASE CONTACT YOUR NATIONAL AUTHORITY TO OBTAIN IN-
FORMATION ON AUTHORIZED FREQUENCIES FOR WIRELESS
MICROPHONE PRODUCTS IN YOUR REGION
Licensing: Note that a ministerial license to operate this equipment may
be required in certain areas. Consult your national authority for possible
requirements.
RACK MOUNTING OPTIONS
RACK MOUNTING THE PA ANTENNA COMBINER
WARNING: Do not torque the screws too tightly, or the chassis may be damaged.
Single Unit
1. Remove the screws and washers from each side of the unit.
2. Align the supplied rackmount brackets over the holes.
3. Using the screws and washers from step 1, fasten the rackmount brackets.
Dual–Mounted Units
1. Remove the screws and washers on each side of both units.
2. Placing the two units side-by-side, screw the link bars to the inside panels of each unit. The units are designed
so that the link bar on the right unit will fit directly on top of the link bar of the left unit (facing front). Use two of
the screws and washers from step 1 per link bar to fasten them.
3. Align the rackmount brackets on the outside panels of the units and fasten using four of the screws and wash-
ers from step 1.
ÑÑ
ÑÑ
ÑÑÑÑ
ÑÑ
Ñ
ÑÑÑÑ
ÑÑ
ÑÑ
ÑÑ
ÑÑ
ÑÑ
ÑÑÑ
ÑÑÑ
ÑÑÑ
ÑÑ
ÑÑ
ÑÑ
ÑÑ
ÑÑ
4. Place the two units next to each other so the link bars overlap and the screw holes on the two align.
5. Fasten the link bars together using 4 supplied screws and washers.

ENGLISH
4
Mounting in an Equipment Rack
SINGLE MOUNT DUAL MOUNT
1. Insert the unit(s) into a 19-inch equipment rack.
2. Fasten the unit(s) to the rack using all four of the supplied screws.
FRONT MOUNTING THE ANTENNA
The PA Antenna Combiner comes equipped so the antenna can be front-mounted. Front-mounting prevents antenna cables from be-
coming entangled and greatly minimizes RF interference from other cables. When a unit is located in a rack, antennas should be either
front- or remote-mounted.
1. Insert the bulkhead adapter through
the hole of either mounting bracket,
and secure it from the back using the
supplied hardware.
2. Connect the transmitter antenna out-
put to the bulkhead adapter with the
supplied RF cable.
3. Install the antenna on the bulkhead
adapter.
NOTE: The PA715 antenna, which comes supplied with the PSM transmitters, cannot be remote mounted.
Use a PA705 antenna for remote mounting.
Information to User
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
SReorient or relocate the receiving antenna.
SIncrease the separation between the equipment and receiver.
SConnect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
SConsult the dealer or an experienced radio/TV technician
for help.
