SkyLink SD-001 User manual

AUTO DIALER – MODEL SD-001 / SD-001R
1. Introduction
Congratulations on your purchase of the Auto Dialer Model SD-001R. The SD-001R
is an advanced emergency dialer which is connected to a phone line for assistance
to monitoring station during emergency thru 2-way voice conversation with Contact
ID compatibility.
Warning:
This system is designed to be installed and programmed by trained professionals.
DO NOT ATTEMPT TO MODIFY ANY SETTINGS BY YOURSELF.
The RS232 interface is used for update by maintainer. The NC/NO terminal is for the
maintainer to install the hardwired device for troubleshooting. No service parts for
the end customer.
.
Consult with your installer or dealer if you experience any problems with the system.
In this package, you should find the following:
․One Auto Dialer Model SD-001R
․One Telephone Cord
․One AC adapter
․One Rechargeable Battery for the Auto Dialer
․One User’s Instructions
2. Main Unit
Following diagram shows several key features on the main unit.
Emergency Dialer
Speaker
LED Indication
CANCEL Button.
URGENT Button
Siren / Buzzer
Microphone
Front
URGENT Button – Press this button to activate the emergency call
CANCEL Button – Press this button to terminate or cancel the emergency call
LED Indication – Displays the status of the dialer
Speaker – Speaker for 2-way voice conversation
Microphone – Speak to this microphone during 2-way voice conversation
POWER
LINE
PHONE
Back
On / Off – Turn the dialer On / Off
Power – Connect AC adapter for power
Line – Connect telephone line
Phone – Connect a telephone to share the same phone line
NC/NO - The NC/NO terminal is for the maintainer to install the hardwired device for
troubleshooting.
Warning:
DO NOT TURN OFF THE MAIN UNIT. IT SHOULD ALWAYS BE ON OTHERWISE
IT WILL NOT FUNCTION DURING ANY EMERGENCY SITUATION. DO NOT
DISCONNECT ANY OF THE PHONE LINE OR POWER ADAPTER. IF YOU SEE

ANY LOOSE CONNECTIONS, PLEASE CONTACT YOUR INSTALLER
IMMEDIATELY.
3. Remote Control (Optional Accessory)
LED
Speed Dial Button
Panic Button
Panic Button– Press this button to activate the emergency call
Speed Dial Button– Press this button to activate a speed dial call
4. Operation
Under normal standby condition, the green LED on the dialer should be on constantly.
If the red LED flashes constantly, that means you are having some failure issues.
Please refer to section 5 for System Failure.
During Emergency – Press URGENT Button
During an emergency, you may initiate a call by pressing the “URGENT” red button,
this will initiate a call with the monitoring station. You will hear the dial tone that the
dialer is calling. Once the line is picked up by the monitoring station, you may start
the voice conversation with the operator at the monitoring station. You can speak
when the orange LEDs are flashing, indicating the microphone is activated. After the
call, there is no need to disconnect the line. The operator will disconnect the line for
you. If you initiate a call by accident, press the “CANCEL” green button will stop the
call from dialing to the monitoring station.
Remote Control (Optional Accessory)
You may also initiate a call by pressing the large red button on the remote control.
When the button is pressed, LED on the remote will flash indicating a signal is being
transmitted to the dialer. Just wait for the operator to pick up the call before you can
start the voice conversation. The speed dial button allows you to call a pre-
programmed phone number (not monitoring station). When the speed dial button is
pressed, it will dial to this phone number. Please consult with your installer so they
can program a suitable speed dial number for you.
5. System Failure
The system will monitor itself for failures, such as:
1) AC power failure (No AC power from the adapter)
2) Phone line failure (No phone line is connected)
3) Backup battery failure (Backup battery is low)
During a system failure, the dialer will beep for 20 seconds and the red LED will flash.
When there is a failure condition, you should consult with the installer. You can
disable the failure beeping while it is sounding if you press the “CANCEL” green
button.
6. FCC
The Auto Dialer is approved by the FCC and it complies with Part 15 of the FCC
Rules. Its operation is subject to the following two conditions :
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undersired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
7. WARRANTY
If, within one year from date of purchase, this product should become defective
(except battery), due to faulty workmanship or materials, it will be repaired or
replaced, without charge. Proof of purchase and a Return Authorization are required.
8. Customer Service
SKYLINK TECHNOLOGIES INC.,
17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3
Email: [email protected]
Website: http://www.skylinkhome.com
© 2011 Skylink Group
