SMC Networks SMCDPCR-AP User manual

TECHNICAL SPECIFICATIONS SMCDPCR/SMCDPCR-AP
SMCDPCR-AP
ETHERNET FEATURES
• 1 x 10/100 Base-T Ethernet
interface
GATEWAY FEATURES
• DHCP Server/Client
• Static IP
• NAT/NAPT
• PPPoE
WIRELESS FEATURES
• 802.11b/g compliant
• Internal Antenna
• Auto-Channel Selection
SECURITY FEATURES
• WEP 64/128/152 bit
• WPA/WPA2 PSK
• Multiple SSID(2 SSID)
MANAGEMENT FEATURES
• Web Based Management
• FTP/TFTP/HTTP download
• SNTP
•EventLog
OUTPUT POWER
• 802.11b: 18dBm (typical)
• 802.11g: 17dBm@6Mbps ;
14dBm@54Mbps
RECEIVE SENSITIVITY
• 802.11b: -90dBm@1Mbps ;
-84dBm@11Mbps
• 802.11g: -86dBm @6Mbps ;
-68dBm@54Mbps
RADIO
• 802.11g
• 2400 ~ 2483.5 MHz
(for US, Canada)
• 2400 ~ 2483.5 MHz
(for ETSI, Japan)
• 802.11b
• 2400 ~ 2483.5 MHz
(for US, Canada)
• 2400 ~ 2483.5 MHz (for ETSI)
• 2400 ~ 2497 MHz (For Japan)
OPERATING CHANNELS
• 802.11g
• 11 channels (US, Canada)
• 13 channels (ETSI, Japan)
• 802.11b
• 11 channels (US, Canada)
• 13 channels (ETSI)
• 14 channels (Japan)
DATA RATE:
• 1/2/5.5/11 (11b) Mbps
• 6/9/12/18/24/36/48/54 (11g)
Mbps
DIMENSIONS
• 147(w) x 90(h) x 70.7(d) mm
• 5.8(w) x 3.5(h) x 2.8(d) in
POWER SUPPLY
• Input: 100~240V/0.3A
• Output:5V, 2.0A DC output
POWER CONSUMPTION
• 6.5W
SMCDPCR
POWER SUPPLY
• Input: 100~240 VAC, 0.2 A
• Output: 5 VDC, 1.0 A
DIMENSIONS
• 115 x 49 x 18 mm
• 4.53 x 1.93 x 0.71 in
TEMPERATURE
• Operating: 0 to 40 °C/
32 to 104 °F
• Storage: -20 to 70 °C/
-4 to 158 °F
HUMIDITY
• 10% to 95% (non-condensing)
SMCWPB
• Lithium ION (Li-ion) Battery
• 3.7V 1200mAh
SMCWPCH
• Input: 100~240 VAC,
50-60Hz, 0.2A
• Output: 5 VDC, 1.0 A
North America
38 Tesla
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/ Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
Skype™ is a trademark of skype
Technologies S.A.
www.smc.com
Contact
SMC's new Wi-Fi phone accessories offer users the convenience of
storing and charging their SMC Wi-Fi phone in the home or office;
and with the SMCDPCR-AP, users have the added functionality of a
built-in 802.11g access point.
The SMC Wi-Fi phone cradle charger (SMCDPCR) is compact in size
and is perfect for keeping your SMC Wi-Fi phone fully charged
when not in use. It has one LED on the front to show when your
SMC phone is being charged and rested properly in the cradle.
SMC took the desktop cradle charger one step further by adding
one 10/100Mb Ethernet port to the back of the device so that you
can also have a built-in 802.11g access point near by and the best
signal for all your VoIP calls. The SMCDPCR-AP has two SSID's; one
for regular wireless clients, and the other for your VoIP calls. This
ensures optimal performance for your voice calls over the internet.
It also has industry leading security with WPA and the new WPA2.
Configuration is made simple with the easy-to-use web interface,
along with a quick and easy setup wizard as soon as you login for
the initial setup.
