Skytech RCAF-LMF/RD User manual

INSTALLATION AND OPERATION INSTRUCTIONS
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE
MODEL: RCAF-LMF/RD
OFF
BATTERY
COMPARTMENT
BACK
FRONT
ON
This remote control system was developed to provide a safe, reliable, and user-friendly remote control system for gas heating
appliances. The system can be operated manually from the transmitter.
INTRODUCTION
TRANSMITTER
OFF
ON
OFF
ON
1
8
4
2
3
7
6
5
1. BATTERY ICON - Battery power is low. Replace batteries within two weeks.
2. ON BUTTON - Turns the appliance ON.
3. OFF BUTTON - Turns the appliance OFF.
4. FLAME ICON - Indicates the appliance is ON.
5. ROOM TEMPERATURE DISPLAY- Indicates current room temperature.
6. FAHRENHEIT OR CELSIUS - Indicates degrees Fahrenheit (ºC indicates degrees Celsius).
7. LOCK ICON - Indicates child proof lockout is activated.
8. RF SIGNAL ICON - Appears when Radio Frequency (RF) signal is being transmitted.
MANUAL FUNCTION
OFF
ON
ON OPERATION
• Touch anyplace on the screen and the screen’s blue back light will light up and stay on for 5-seconds.
• Touch the ON button on the LCD screen to turn the appliance on. The ame icon will appear on the
LCD screen.
•
OFF OPERATION
• Touch the OFF button on the LCD screen to turn the appliance off. The ame icon will disappear from
the LCD screen.
SETTING FAHRENHEIT / CELSIUS SCALE
The factory setting for temperature is ºF. To change this setting to ºC, press and hold the ON button
and the FLAME ICON on the transmitter LCD screen at the same time for 5-seconds. Follow this
same procedure to change from ºC back to ºF.
OFF
ON
KEY SETTINGS AND LIQUID CRYSTAL DISPLAY (LCD)
The transmitter operates on (4) AAA 1.5V batteries that are included.
Install the batteries supplied with the unit into the battery compartment.
It is recommended that ALKALINE batteries always be used for this
product. Be sure the batteries are installed with the (+) and (-) ends
facing the correct direction.
When you start up the remote, if a low battery signal appears or if they
LCD screen does not illuminate when you touch it, check the position
of the transmitter’s batteries, and if the batteries are fully charged.
REV. 5-16-16 Page 1
Skytech: RCAF-LMF/RD
www.FireplaceRemoteControls.com
1.888.977.6849

This remote control includes a childproof “LOCK-OUT” feature that allows the user to “lock-out” operations from the transmitters.
• To activate the “LOCK-OUT” feature, press and hold the ON and OFF icons on the
LCD screen together, for 5 seconds. The lock icon will appear on the LCD screen.
• To disengage the “LOCK-OUT”, press and hold the ON and OFF icons on the LCD
screen together, for 5 seconds. The lock icon will disappear on the LCD screen.
NOTE: If the appliance is already operating in the ON mode engaging the “LOCK-OUT”
will not cancel the operating mode.
CHILDPROOF “LOCK-OUT”
OFF
ON
RECEIVER
Install the (4) AA-size batteries supplied with the unit. It is recommended that ALKALINE batteries always be used for this product. Be
sure the batteries are installed with the (+) and (-) ends facing the correct direction.
• REMOTE: will allow use of handheld transmitter. If the system does not respond
to the transmitter on initial use, check the battery positions in the remote. If that
does not work, see the LEARNING TRANSMITTER TO RECEIVER section.
• OFF: will disable the remote receiver.
• It is suggested that the slide switch be placed in the OFF position if you will
be away from your home for an extended period of time.
The remote receiver has a 2-position slide switch for selecting the mode of operation
REMOTE/OFF
WARNING
This remote control system must be installed exactly as outlined in these instructions. Read all instructions completely before at-
tempting installation. Follow instructions carefully during installation. Any modications of this remote control or any of its compo-
nents will void the warranty and may pose a re hazard.
Do not connect any gas valve or electronic module directly to 110-120VAC power. Consult gas appliance manufacturer’s instruc-
tions and wiring schematics for proper placement of all wires. All electronic modules are to be wired to manufacturer’s specica-
tions.
The following wiring diagrams are for illustration purpose only. Follow instructions from manufacturer of gas valve and/or electronic
module for correct wiring procedures. Improper installation of electric components can cause damage to electronic module, gas
valve and remote receiver.
INSTALLATION
The remote receiver should be placed on or near the replace hearth. The remote receiver should be kept away from temperatures
exceeding 130º F. Battery life is also signicantly shortened if batteries are exposed to temperatures 130ºF or higher.
Before installation make sure the remote receiver slide switch is in the OFF position. After installation be sure that the slide switch is
moved to the REMOTE position.
HEARTH MOUNT
• The remote receiver can be placed on the replace hearth or under the re-
place behind the control access panel.
• Use the wires attached to the remote receiver to connect to the gas valve or
the electric module (Female spade connectors are provided).
REMOTE
LEARN
Requires 4-AA 1.5V
alkaline batteries
Learning
button
Remote Receiver
Battery cover slides on/off
Slide
Switch
REMOTE
OFF
OFF
REV. 5-16-16 Page 2
Skytech: RCAF-LMF/RD
www.FireplaceRemoteControls.com
1.888.977.6849

INSTALLING THE ON/OFF SOLENOID
1. Remove the two screws from the front metal faceplate on the AF-LMF valve box and set the face plate aside.
2. Take a screwdriver (at head), and remove the aluminum valve cap tting.
3. Take the ON/OFF solenoid and install it in to the threaded hole where the brass cap tting was. Do not overtighten.
4. Replace the metal faceplate on the front of the valve. Make sure that the red and black wires on the solenoid can reach out the
back of the metal box, so that they can connect to the receiver.
NOTE: KEEP THE VALVE CAP FITTING. IF THE SOLENOID IS REMOVED, THE CAP WILL NEED TO BE REPLACED.
Brass Cap
Fitting
Standard
Screwdriver
AFLMF
Valve Assembly
ON/OFF
Solenoid
Standard
Screwdriver
AFLMF
Valve Assembly
CONNECTING THE RECEIVER TO THE AF-LMF VALVE KIT
1. Connect the Black wire on the receiver with the Black wire on the solenoid.
2. Connect the Red wire on the receiver with the Red wire on the solenoid.
3. After the wires are securely connected, put the receiver shield on the receiver and place it where ambient temperatures do not
exceed 130º F.
NOTE: The colors of the wires must match, if they do not, the functions of the receiver will not work.
Remote Receiver
REMOTE
OFF
PULSE MODE
Terminals
BLACK Wire
(Female)
RED Wire
(Female)
LEARN
ADJ.
BLACK Wire
(Male)
RED Wire
(Male)
LEARNING TRANSMITTER TO RECEIVER
This transmitter has one of 1,048,576 unique security codes. It may be necessary to program the remote receiver to learn the security
code of the transmitter upon initial use, if batteries are replaced, or if using a replacement transmitter.
• Make sure the receiver’s slide switch is in the REMOTE position.
• Press and release the LEARN button on the receiver.
• When you hear the “Beep”, press and hold the ON or OFF button for about 2 seconds on the transmitter.
• You will then hear a series of “rapid” beeps that indicate your new transmitter has been accepted by the receiver.
REV. 5-16-16 Page 3
Skytech: RCAF-LMF/RD
www.FireplaceRemoteControls.com
1.888.977.6849

BATTERY LIFE
Life expectancy of the alkaline batteries in the transmitter and receiver should be at least 12 months. Check and replace all batteries:
• Annually.
• When operating range becomes reduced.
• When transmissions are not received by the remote receiver.
• If the remote receiver batteries measure less than 5.3 volts (all four batteries in combination).
• If the hand held transmitter battery measure less than 5.3 volts (all four batteries in combination).
TROUBLE SHOOTING
If you encounter problems with your replace system, the problem may be with either the replace itself or with the remote. Review
the replace manufacturer’s operation manual to make sure all connections are properly made. Then check the operation of the
remote in the following manner:
• Make sure all batteries are correctly installed in the transmitter and receiver. Also check that the batteries are fully charged.
• Check batteries in transmitter to make sure contacts are touching (+) and (-) ends of battery. Bend metal contacts in for tighter t.
• Ensure receiver and transmitter is within 20 to 25-foot operating range.
• Keep receiver from temperatures exceeding 130º F. Battery life will be shortened if exposed to high temperatures.
• If receiver is installed in a tightly enclosed metal surrounding, the operating distance will be shortened.
• Make sure the hand-held transmitter and remote receiver are communicating properly (see Learning transmitter to receiver
section).
FCC REQUIREMENTS
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODI-
FICATIONS TO THE EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT
For Technical Service, call: U.S. INQUIRIES
[phone] or [phone]
For Sales: [phone]
Web site: www.skytechpg.com
CANADIAN INQUIRIES
[phone]
MANUFACTURED EXCLUSIVELY FOR SKYTECH II, INC
