YASKAWA MOTOMAN DX100 User manual

YASKAWA
YASKAWA MANUAL NO. RE-CSO-A040
DX100
OPERATOR’S MANUAL
FOR SPOT WELDING USING MOTOR GUN
Upon receipt of the product and prior to initial operation, read these instructions thoroughly, and retain
for future reference.
MOTOMAN INSTRUCTIONS
MOTOMAN- INSTRUCTIONS
DX100 INSTRUCTIONS
DX100 OPERATOR’S MANUAL DX100
MAINTENANCE MANUAL
The DX100 operator’s manuals above correspond to specific usage.
Be sure to use the appropriate manual.
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

DX100
ii
MANDATORY
• This manual explains the various components of the DX100 system
and general operations. Read this manual carefully and be sure to
understand its contents before handling the DX100.
• General items related to safety are listed in Section 1: Safety of the
DX100 Instructions. To ensure correct and safe operation, carefully
read the DX100 Instruction before reading this manual.
CAUTION
• Some drawings in this manual are shown with the protective covers
or shields removed for clarity. Be sure all covers and shields are
replaced before operating this product.
• The drawings and photos in this manual are representative
examples and differences may exist between them and the
delivered product.
• YASKAWA may modify this model without notice when necessary
due to product improvements, modifications, or changes in
specifications. If such modification is made, the manual number will
also be revised.
• If your copy of the manual is damaged or lost, contact a YASKAWA
representative to order a new copy. The representatives are listed
on the back cover. Be sure to tell the representative the manual
number listed on the front cover.
• YASKAWA is not responsible for incidents arising from
unauthorized modification of its products. Unauthorized
modification voids your product’s warranty.
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

DX100
iii
Notes for Safe Operation
Read this manual carefully before installation, operation, maintenance, or
inspection of the DX100.
In this manual, the Notes for Safe Operation are classified as
“WARNING,” “CAUTION,” “MANDATORY,” or “PROHIBITED.”
Even items described as “CAUTION” may result in a serious accident in
some situations.
At any rate, be sure to follow these important items.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury to
personnel.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, could
result in minor or moderate injury to
personnel and damage to equipment.
It may also be used to alert against
unsafe practices.
MANDATORY
Always be sure to follow explicitly the
items listed under this heading.
PROHIBITED
Must never be performed.
NOTE To ensure safe and efficient operation at all times, be sure
to follow all instructions, even if not designated as “CAU-
TION” and “WARNING.”
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

DX100
iv
WARNING
• Before operating the manipulator, check that servo power is turned
off when the emergency stop buttons on the front door of the DX
100 and programing pendant are pressed.
When the servo power is turned off, the SERVO ON LED on the
programing pendant is turned off.
Injury or damage to machinery may result if the emergency stop circuit
cannot stop the manipulator during an emergency. The manipulator
should not be used if the emergency stop buttons do not function.
Fig. : Emergency Stop Button
• Once the emergency stop button is released, clear the cell of all
items which could interfere with the operation of the manipulator.
Then turn the servo power ON.
Injury may result from unintentional or unexpected manipulator motion.
Fig. : Release of EM
TURN
• Observe the following precautions when performing teaching
operations within the P-point maximum envelope of the
manipulator:
– View the manipulator from the front whenever possible.
– Always follow the predetermined operating procedure.
– Ensure that you have a safe place to retreat in case of
emergency.
Improper or unintended manipulator operation may result in injury.
• Confirm that no person is present in the P-point maximum envelope
of the manipulator and that you are in a safe location before:
– Turning on the power for the DX100.
– Moving the manipulator with the programming pendant.
– Running the system in the check mode.
– Performing automatic operations.
Injury may result if anyone enters the working envelope of the
manipulator during operation. Always press an emergency stop button
immediately if there are problems.
The emergency stop button is located on the right of the front door of
the DX 100 and programing pendant.
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

DX100
v
Definition of Terms Used Often in This Manual
The MOTOMAN is the YASKAWA industrial robot product.
The MOTOMAN usually consists of the manipulator, the controller, the
programming pendant, and supply cables.
In this manual, the equipment is designated as follows.
CAUTION
• Perform the following inspection procedures prior to conducting
manipulator teaching. If problems are found, repair them
immediately, and be sure that all other necessary processing has
been performed.
– Check for problems in manipulator movement.
– Check for damage to insulation and sheathing of external wires.
• Always return the programming pendant to the hook on the cabinet
of the DX100 after use.
The programming pendant can be damaged if it is left in the
manipulator's work area, on the floor, or near fixtures.
• Read and understand the Explanation of Warning Labels in the
DX100 Instructions before operating the manipulator.
Equipment Manual Designation
DX100 controller DX100
DX100 programming pendant Programming pendant
Cable between the manipulator and the
controller
Manipulator cable
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167

DX100
vi
Descriptions of the programming pendant keys, buttons, and displays are
shown as follows:
Description of the Operation Procedure
In the explanation of the operation procedure, the expression "Select • • • "
means that the cursor is moved to the object item and the SELECT key is
pressed, or that the item is directly selected by touching the screen.
Registered Trademark
In this manual, names of companies, corporations, or products are
trademarks, registered trademarks, or brand names for each company or
corporation. The indications of (R) and TM are omitted.
Equipment Manual Designation
Programming
Pendant
Character Keys The keys which have characters printed on
them are denoted with [ ].
ex. [ENTER]
Symbol Keys The keys which have a symbol printed on
them are not denoted with [ ] but depicted
with a small picture.
ex. page key
The cursor key is an exception, and a picture
is not shown.
Axis Keys
Numeric Keys
“Axis Keys” and “Numeric Keys” are generic
names for the keys for axis operation and
number input.
Keys pressed
simultaneously
When two keys are to be pressed
simultaneously, the keys are shown with a
“+” sign between them,
ex. [SHIFT]+[COORD]
Displays The menu displayed in the programming
pendant is denoted with { }.
ex. {JOB}
PAGE
GO BACK
PAGE
GO BACK
工控帮助教小舒QQ:2823408167
该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：
http://www.jisupdfeditor.com/
长沙工控帮教育科技有限公司
工控帮助教小舒QQ:2823408167
