Skytech firegear Outdoors LOF-30-P-LF User manual

Linear Outdoor Fire
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
INSTALLATION PRECAUTION:
This Linear Outdoor Fire pit requires a minimum 18-square inches (per side) of cross
ventilation. Failure to provide proper ventilation can void the warranty.
Match Throw Description
LOF-30-P-LF 30-inch stainless burner & pan
MODELS
For Technical Service Call:
1-888-672-8929
Fax: [phone]


 
DANGER


Ifyousmellgas:

1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away
from the appliance and
immediately call your gas
supplier or fire department.

WARNING


Donotstoreorusegasolineorother
flammablevaporsandliquidsinthe
vicinityofthisorotherappliance.

AnLPcylindernotconnectedforuse
shallnotbestoredinthevicinityofthis
oranyotherappliance.

DANGER
  
CARBONMONOXIDEHAZZARD

Thisappliancecanproducecarbonmonoxide
whichhasnoodor.

Usingitinanenclosedspacecankillyou.

Neverusethisapplianceinanenclosedspace
suchasacamper,tent,carorhome.

WARNING:Iftheinformationintheseinstructionsisnotfollowedexactly,afireor
explosionmayresultcausingpropertydamage,personalinjuryordeath.

FORYOURSAFETY
Donostoreorusegasolineorotherflammablevaporsandliquidsinthevicinityof
thisoranotherappliance.


 
WARNING

Improperinstallation,adjustment,
alteration,serviceormaintenancecan
causeinjuryorpropertydamage.Read
theinstallation,operatingand
maintenanceinstructionsthoroughly
beforeinstallingorservicingthis
equipment
WARNING
Donotleaveunattendedduringuse.
Donotuseforcooking.
Followallgasleakproceduresinthis
manualpriortooperation.
REV. 5-31-14 Page 1
Lloyd Flanders
Tighten All Fings and Test
for Leaks with Soapy Water
Before First Use

SPECIFICATIONS
Table1. Linear Pan Dimensions
36”
96”
24”
Maximum
Overhang
Center of Flame

A
B
C
.875 TYP. (usable flat lip)
*
*
D
Ground Level
Figure 1. Linear Pan dimensions; refer to Table 1.
Figure 2. Clearance to Combustibles
(Not to be used in an enclosed space)
REV. 5-31-14 Page 2
Model Btu’s
Natural/Propane (LP)
Factory
Orice
LOF-30-P-LF 36,531 Btu’s #51
NG LP
Min.
Inlet
5.0”WC 11.0”WC
Max.
Inlet
10.5”WC 13.0”WC
Table 3. Gas Pressures
Model A
Pan Depth
B
Min/Max Opening Width - Length
C
Inside Pan
D
Ground Level
LOF-30-P-LF 2.75” 6.25”- 7.5” W x 30.25” - 31.75” L 30” 6”
Note: Linear Outdoor Fire’s are rated at maximum Btu’s which is dependent upon proper gas pipe sizing. Flex line
size also affect Btu’s. As a result your Btu’s will may vary from Table 2 specications listed above.
Table 2: Btu Specications based on 7.0”WC - NG and 10.0”WC -LP
Lloyd Flanders
NOTE:
THIS FIRE PIT COMES EQUIPPED WITH LIQUID PETEROLUM (LP) GAS ONLY.
AN OPTIONAL NATURAL GAS CONVERSION KIT IS AVAILABLE BUT MUST BE
PURCHASED SEPERATELY.
ORDER: Part# OAS-NG42 (35,240 BTU/H at 7.0”WC)

REV. 5-31-14 Page 3
WARNING: Proper clearances from combustible, construction and materials must be maintained from all sides, top and
bottom of this appliance. This appliance should never be placed on any combustible surface. This appliance should
never be placed under any combustibles closer then 96-inches. This appliance should never be placed closer than
36-inches from any side to any combustible construction or materials (See g. 2, pg. 3).
PREPARING A NON-COMBUSTIBLE STRUCTURE
The Linear Outdoor Fire is to be installed on a at, stable surface, away from any combustible materials. Install Linear
Outdoor Fire on any level, outdoor non-combustible surface. NOTE: Do not place Linear Outdoor Fire directly on grass,
dirt, or rocks this may prevent proper ventilation (Fig. 3). Ensure proper water drainage is also incorporated into the
Linear Outdoor Fire enclosure.
HARD PIPING TO Linear Outdoor Fire pit WITHOUT GAS PROXIMITY
NOTE: We recommend using a minimum ¾” black iron pipe however refer to the NFPA54 (National Fuel Gas Code) for
proper pipe sizing when exceeding 20-feet in length for Linear Outdoor Fire’s rated above 100,000 Btu’s.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply Teon tape or pipe sealant to the steel ttings before making any
connection. BE CAREFUL! Ensure all gas connections are snug, but not over tighten!
2. Extend the gas supply system using minimum of ¾” black iron pipe or an approved exible gas line from existing house
supply. This can be accomplished by teeing off or tapping into a convenient gas line connection. Install necessary pipe
for the distance required and then install a manual shut-off valve at the exterior house wall. If pipe is to pass through a
foundation or house wall, make sure to re-seal the area around the pipe with weather sealant.
3. From manual valve, extend gas pipe to the Linear Outdoor Fire location. NOTE: If pipe is to be placed in an under-
ground trench, check with local codes for required depth and materials needed.
4. Install a ¾” female x ½” male ared brass tting to the end of the ¾” black iron pipe. Be sure to clean the pipe threads
and use Teon tape or pipe sealant.
5. Connect the ½” female ared ex connector from the Linear Outdoor Fire to the ½” male ared brass tting secured to
the black iron pipe. Note: Flare to are connections do not require Teon tape or pipe sealant.
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
The appliance and its manual shutoff valve must be disconnected from the gas supply piping system during any
pressure testing of the system at test pressure testing of the system at test pressures in excess of ½ psig (3.5kPa).
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½ psig (3.5kPa)
NOTE: LP conversion kits are available in the Accessory/Con-
version Kit section of this manual. When converting a Linear
Outdoor Fire ensure you follow the instructions supplied with the
conversion kit.
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Linear Outdoor Fire’s are subjected to many outdoor
elements such as rain, snow, wind, heat or cold. A minimum
of 18 square inches of cross ventilation (2 sides) is
required to keep the components in good working order.
Use gure 3 as guide to assist to incorporate proper
ventilation. NOTE: Ventilation is not required at the bottom, it
may also be incorporated in the upper portion of an enclosure.
Figure 3. Cross Ventilation Example
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0-4500 feet in
Canada and the U.S. If elevation exceeds 4500 feet it may be
necessary to decrease the input rating by changing the exist-
ing burner orice to a smaller size. Input should be reduced
4% for each 1000 feet beyond the 4500 feet above sea level.
Check with your local gas utility for assistance in determining
the proper orice in your location. In some cases the heating
value may already be reduced and downsizing the orice may
not be necessary.
Fire Pit
Enclousure
2”x3”
Linear Pan
Examples of Cross Ventilation
3 - 2”x3” Slots Per Side or
2- 1” x 9” Slots Per Side
Cross Flow Ventilation
(Min. 18 Sq. In. Per Side)
Lloyd Flanders

FIRE TABLE ASSEMBLY GUIDE
Tools Needed: Crescent Wrench
REV. 5-31-14 Page 4
Lloyd Flanders
Fig. 4 Place table base on at
surface.
Fig. 5 Use levelers as needed to
keep base level.
Fig. 6 Insert Chrome ange into
exterior bracket hole.
Fig. 7 Place manual valve into gas
valve bracket.
Fig. 11 Chrome ange should “sit” as
pictured.
Fig. 8 Bracket and valve as seen
from outside base.
Fig. 9 Insert chrome ange into
exterior bracket hole.
Fig. 10 Tighten chrome ange by
hand.
Fig. 12 Place table top on base,
centering it over the base.

REV. 5-31-14 Page 5
Lloyd Flanders
FIRE TABLE ASSEMBLY GUIDE CONTINUED
Fig. 15 Attach ½” ex connector to ½”
ared tting on bottom of pan, secure
and gently lower pan into place.
Fig. 14 Attach end of ½” ex
connector to manual gas valve.
Fig. 13 Attach pressure regulator
hose to manual gas valve.
Fig. 16 Remove tank access door
with handle (Pull out, lift up). Fig. 17 Place LP tank in cradle. Lift
cradle slowly until tank is upright.
Fig. 18 Secure pressure regulator to
LP gas tank.
Fig. 19 Ensure all connections are
tight and leak free. Fig 20 Install tank acess door
(Drop down, push in).
THIS IS A QUICK SET-UP GUIDE ONLY. ENSURE ALL GAS FITTINGS ARE PROPERLY LEAK TESTED
ROUND BURNER SHOWN FOR
REFERENCE
Fig. 21 Add regear reglass to
burner providing adequate coverage*.
*Three (3) bags of regear reglass are recommended for adquate coverage of the burner pan.
ROUND BURNER SHOWN FOR
REFERENCE

REV. 5-31-14 Page 6
Lloyd Flanders
LIGHTING INSTRUCTIONS
Ensure air shutter nut (under burner pan) is positioned correctly for fuel being used (See examples A & B).
Fig. 22 Turn ON LP tank by turning
knob (counter-clockwise)
Fig. 23 Locate chrome ange and
insert key. DO NOT TURN.
Fig. 25 Slowly turn key (counter
clockwise) to ON. Burner will light.
Fig. 24 Light a butane lighter at edge
of burner pan.
ROUND BURNER SHOWN FOR
REFERENCE
If you are experiencing any problem lighting the burner, close all valves and do not attempt
ignigion an further. Inspect for leaks and contact Technical Service.

REV. 5-31-14 Page 7
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the Linear Outdoor Fire unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause sever burns if contacted.
2. Do not burn any solid fuels in this appliance.
Lloyd Flanders
LIGHTING INSTRUCTIONS
Key
Fig. 27 Inserting Key into Valve
ON
OFF
Fig. 26. Key Valve Face
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE
ATTEMPTING TO LIGHT FIRE PIT
CAUTION: Ensure you have leak tested the re pit before operating.
TURNING ON FIRE PIT
1. Insert key into shut-off valve and secure into square end (see gs 26 & 27).
2. Light a long match or butane lighter and hold it near the burner (see g. 28).
3. Turn the key counter-clockwise in gas valve (until it stops) to allow gas to ow and
simultaneously apply the long burning match or Butane lighter as close to the end
burner as possible to light the re pit.
4. Gas should ignite within 10 seconds or less. If re pit does not light within 10 seconds
turn key clockwise to turn OFF the gas supply. Ensure there is not too much media on
top of the burner that might inhibit gas ow and try again in 5 minutes.
TURNING OFF FIRE PIT
1. Insert key into shut-off valve and secure into square end.
2. Turn key clockwise until it stops.
3. After cooling off install cover.
Butane Lighter
Fig. 28. Lighting the re pit.

REV. 5-31-14 Page 8
REPLACEMENT PARTS
1
2
3
5
ON
OFF
6
7
1 30” Line of Fire Burner & Pan 1 LOF-30
2 Washer 4 ST3-113-1026
3Flex Connector ½”OD (⅜”ID) X 22:, ½ OD Flare Nuts 1 T200-9898-22
4Propane Orice/Air Shutter (#51) (36,531BTU/H) 1 OAS-LP51
5Std. Capacity Straight Key Valve (Rated 158,000BTU/H @½PSI) 1 BVS
6 Chrome Cover Plate for BVS Key Valve 1 FP.BV.CR.B
7 3-inch Polished Chrome Key for BVS Key Valve 1 NKY.3.CR.B
Item Description Qty. Part Number
Lloyd Flanders
For Technical Service Call:
1-888-672-8929
4
DRAWINGS NOT TO SCALE

MAINTENANCE
1. The Linear Outdoor Fire should be inspected and cleaned before initial use annually by a qualied eld service person.
2. Any component that is found faulty must be replaced with an approved component.
3. Any tampering or modifying with the Linear Outdoor Fire is dangerous and voids all warranties.
4. During winter months in cold climates and various seasons operation the Linear Outdoor Fire may be affected by
weather conditions. It is recommended to use a ventilated cover overtop of your Linear Outdoor Fire to protect it from
humid/rainy weather conditions when not in use. Heavy rains/downpours could affect the Linear Outdoor Fire operation if
not covered; if this occurs ensure you allow the Linear Outdoor Fire time to dry out before attempting to operate. NOTE:
If a combustible type cover is used over the Linear Outdoor Fire when not in use be sure to remove it before operation to
prevent a severe safety hazard.
5. Carbon (soot) may build up on the surface of logs (if installed) during heavy use. Sooting may also occur periodically
on the screen of the ignitor hood. To clean, brush off with a dry bristle brush or cloth. Keep soot away from clothing or
furniture.
6. Over time stainless steel parts discolor when heated, usually a golden or brown hue. This discoloration is normal and
does not affect the performance of the appliance.
REV. 5-31-14 Page 9
TROUBLE SHOOTING
Sympton Remedy
LOF Won’t Light 1. Bleed gas line.
2. Ensure all gas supply lines are turned ON.
3. Ensure there is not too much media overtop of burner; it can inhibit gas from owing.
Low Flame 1. Ensure the base media is at least 1-inch in diameter and top media is no more than 1-inch over
top of burner.
2. Adjust air shutter at bottom of Linear Outdoor Fire pit pan.
3. Ensure all shut-off valves and key valve is fully open.
Water in Fire Pit 1. Excess dust/sand material from media may be blocking the weep holes to relieve water.
Remove all media and unplug weep holes. Clean or install new media free of dust and dirt.
2. Ensure Linear Outdoor Fire pit enclosure has proper drainage for water and proper ventilation
to dry out.
Lloyd Flanders

FOR TECHNICAL SERVICE, CALL: regear Outdoors
9230 Conservation Way
Fort Wayne, IN 46809
[phone] Fax [phone]
WEB SITE: www.regearusa.com
REV. 5-31-14 Page 10
CONVERSION KITS
Lloyd Flanders
OPTIONAL ACCESSORIES
The following accessories are available from your local regear dealer/distributor. Each accessory comes with a separate
installation manual. Read each instruction thoroughly before installing.
Lava Boulders 3” to 6” size (30lbs.)
Model: FG-LB30
Not to scale
NG Orice Air Shutter #42 Conversion
Lava Stones 1” to 2” size. (20lbs.)
Model: FG-LS20
Stainless Lid for LOF-30-P-LF
Model: LID30L
LP regulator with 3/8” MPT adapter
Model: FG-LPRK
3/8” Quick connect 12’ hose for NG or
LP gas Model: FG-12QDK
OAS-NG42

REV. 5-31-14 Page 11
regear Outdoors, a division of Skytech Products Group
hereby warrants to the ORIGINAL PURCHASER of this
Linear Outdoor System, that it will be free from material
and workmanship defects that prevent safe and correct
operation of the product commencing from date of
purchase from Fire Gear Outdoors.
Consumer/Non-Commercial Applications
Stainless Steel Burner Pan 5 Years
Stainless Steel - Burner Tube 5 Years
Manual Valve 1 Year
Commercial Applications
Stainless Steel Burner Pan 1 Year
Stainless Steel - Burner Tube 1 Year
Manual Valve 1 Year
When assembled, installed and operated in accordance
with the accompanying printed instructions.
Fire Gear may require reasonable proof of your date of
purchase. YOU SHOULD RETAIN YOUR SALES SLIP
OR INVOICE AND RETURN THE
WARRANTY REGISTRATION CARD WITHIN 30 DAYS
OF PURCHASE.
This Limited Warranty shall be valid and limited to,
the original purchaser only, within the connes of
the original site installation.
WARNING: Any modication to this product will
void the warranty!
This Limited Warranty shall be limited to the repair
and/or replacement of parts that prove defective
under normal use and service and which on
examination shall indicate, to Fire Gear Outdoor’s
satisfaction, that they are defective. Before
returning any parts, contact Fire Gear Outdoors
Customer Service Center. If Fire Gear Outdoors
conrms the defect and approves the claim, Fire
Gear Outdoors will replace such parts without
charge.
The Owner must provide a bill of sale, cancelled
check, or payment record to verify purchase
date and establish warranty period. Travel,
diagnostic cost, service labor to repair the defect
and freight charges on warranty parts to and from
the factory will be responsibility of the owner. Fire
Gear Outdoors will not be responsible for labor
charges and/or damage incurred in installation,
repair, and replacement or for incidental or
consequential damages.
This Limited Warranty does not cover any failures
or operating difculties due to accident, abuse,
misuse, alteration, misapplication, vandalism,
improper installation or improper maintenance or
service, or failure to perform normal and routine
maintenance.
Damage due to severe weather conditions such
as Hail, Hurricanes, Earthquakes, Tornadoes, Acts
of Terrorism, Discoloration due to over heating,
Exposure to chemicals (including salt), either
directly or in the atmosphere, or Very high
humidity, is not covered by this Limited Warranty.
There are no other express warranties except as
set forth herein and any applicable implied
warranties of merchantability and tness are
limited in duration to the period of coverage of this
express written Limited Warranty. Some states do
not allow limitation on how long an implied
warranty lasts, so this limitation may not apply to
you.
Fire Gear Outdoors is not liable for any special,
indirect or consequential damages. Fire Gear
Outdoor’s liability is limited to the purchase price
of this Fire Gear Linear Outdoor Fire pit System.
Some states do not allow the exclusion or
limitation of incidental or consequential damages,
so this limitation or exclusion may not apply to you.
Fire Gear Outdoors does not authorize any person
or company to assume for it any other obligation
or liability in connection with the sale, installation,
use, removal, return, or replacement of its
equipment; and no such representations are bind-
ing on Fire Gear Outdoors
This Warranty applies only to products sold at retail
and manufactured by:
LIMITED WARRANTY
Lloyd Flanders
