Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 1
INSTALLATION AND OPERATING INSTRUCTIONS
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE
Model: TS-R-2A
INTRODUCTION
This SKYTECH remote control system was developed to provide a safe, reliable, and user-friendly remote control system
for gas heating appliances. The system can be operated thermostatically or manually from the transmitter. The system
operates on radio frequencies (RF) within a 20-foot range using non-directional signals. The system operates one of
1,048,576 security codes that are programmed into the transmitter at the factory; the remote receiver’s code must be
matched to that of the transmitter prior to initial use.
WALL MOUNT THERMOSTAT The wall/transmitter operates on (2) 3V Button Cell (Included) which powers
the LCD screen and powers the RF signal. These batteries are made
specically for remote controls and electronic lighters. Before using the
transmitter the 3V batteries must be installed into the battery compartments
It is recommended that CR2032 lithium batteries always be used for longer
battery life and maximum operational performance.
Upon initial use, there may be a delay of ve seconds before the remote
receiver will respond to the transmitter. This is part of the system’s design.
If the LCD screen will not come ON, check the 3V Button Cell battery.
ROOM TEMP
THERMO
MODE
“SET”
ON
SET
OFF
LCD
DISPLAY
ON/UP
BUTTON
OFF/DOWN
BUTTON
SET
BUTTON
TO INSTALL BATTERIES IN THE WIRELESS THERMOSTAT
1. Remove face from backing plate this is done by sliding the face up
about 1/2” then pull the face off the base plate. As shown in Figure 1
2. Locate the (2) holders for the 3V button cell batteries.
3. Slide the button cell batteries into the battery holders. (Make sure that
the batteries are installed with the (+) plus side facing you or up.
(2) 3 Volt Button
Cell Batteries
Battery
Removal
Slots
Plus
Side
+
Plus
Side
+
Figure 1 Figure 2
ROOM TEMP
ON OFF
SET

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 2
TO REMOVE THE BATTERIES IN THE WIRELESS THERMOSTAT
1. Remove face from backing plate this is done by sliding the face up about 1/2” then pull the face off the base plate. As
shown in Figure.
2. Locate the (2) holders for the 3V button cell batteries.
3. Insert a small screwdriver into the slot above the button cell battery and push the battery out. As shown in Figure 2.
TS-R-2A THERMOSTAT OPERATION
1. ROOM TEMP – Current room temperature.
2. F° = Degrees Fahrenheit (C° = Degrees Celsius)
3. FLAME ICON – Indicates APPLIANCE IS ON.
4. SET- Indicates TS-R-2A is in thermostat mode.
5. DASHES – Indicate thermostat mode is being disabled.
Note: The word (SET) will appear when the thermostat mode is
enabled.
ROOM TEMP
12
3
SET
ROOM TEMP
5
4
1. This TS-R-2A Wall/transmitter has ON, OFF, and SET functions that
are activated by pressing the buttons on the face of the transmitter.
2. Upon initial use, there may be a delay of ve seconds before the
remote receiver will respond to the transmitter. This is part of the
system’s design. If the LCD will not come on, check the 3V-button
cell battery.
ON
SET
OFF
SETTING MANUAL OPERATION
1. When the ON button on the TS-R-2A is pressed a ame icon on the
LCD screen will appear when the appliance is ON.
2. When the appliance is OFF the ame icon will not appear.
ROOM TEMP
GENERAL INFORMATION
WALL MOUNTING THE TS-R-2A THERMOSTAT
1. Remove face from backing plate as shown in Figure 1 then locate
the TS-R-2A to where the (2) thermostat wires from the appliance
can be pulled through the hole on the backing plate and connect
them to the (2) terminal screws.
2. After locating the (2) two mounting holes and mark the holes on
the wall.
3. Use the (2) two dry wall anchors and screws (that are supplied) to
mount the base plate to the wall as shown.
4. Thermostat can also be mounted onto an existing (Plastic)
electrical box.
5. Base plate should be mounted level on the wall for best operation.
6. Reinstall the face to the backing plate this is done by sliding
the face in and down about 1/2” then check that the (2) male
terminal connectors on the face are engaged in the female
terminal connectors on the backing plate. As shown in Figure 1.
ROOM TEMP
ON OFF
SET
WALL

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 3
SETTING °F / °C SCALE
The factory setting for temperature is degrees Fahrenheit (°F) . To change this setting to Centigrade (°C), you must press
and hold both the ON and OFF buttons on the transmitter at the same time until the LCD displays the change. If you want
to convert back, repeat the above procedure.
THERMO UPDATING FEATURE
This SKYTECH wired wall thermostat has a THERMO UPDATING Feature built into its software. The THERMO
UPDATING Feature operates in the following manner, but only in the THERMOSTAT MODE:
The TS-R-2A normally reads the ROOM temperature every 2 minutes checking the ROOM temperature against the SET
temperature and then sends a signal to the appliance.
NOTE: When locating the TS-R-2A on a wall remember it should be kept away from direct sources of heat such as
heating appliance, incandescent lighting, and direct sunlight. Leaving the TS-R-2A in direct sunlight, for example, will
cause its heat-sensing diode to read the room temperature higher than it actually is; if in THERMOSTAT mode, it may not
turn ON the appliance even if the ambient ROOM temperature is below the SET temperature.
COMMUNICATION – SAFETY – TRANSMITTER – (C/S – TX)
This SKYTECH remote control has a COMMUNICATION –SAFETY function built into its software. It provides an extra
margin of safety when the TRANSMITTER is out of the normal 20-foot operating range of the receiver.
The COMMUNICATION – SAFETY feature operates in the following manner, in all OPERATING MODES – Manual ON
and THERMO.
At all times and in all OPERATING MODES, the wall transmitter sends an RF signal every fteen (15) minutes, to the
receiver, Should the receiver NOT receive a transmitter signal every 15 minutes, the IC software, in the RECEIVER, will
begin a 2-HOUR (120-minute) countdown timing function. If during this 2-hour period, the receiver does not receive a
signal from the wall transmitter, the receiver will shut down the appliance being controlled by the receiver. The
RECEIVER will then emit a series of rapid “beeps” for a period of 10 seconds. Then after 10 seconds of rapid beeping,
the RECEIVER will continue to emit a single “beep” every 4 seconds until the ON button on the wall transmitter is pressed
to reset the receiver. The intermittent 4 second beeping will go on for as long as the receiver’s batteries last which could
be in excess of one year.
To “reset” the RECEIVER and operate the appliance, you must press ON button on the wall transmitter. The ame icon
must be display on the LCD screen. By turning the system to ON, the COMMUNICATION -SAFETY operation is
overridden and the system will return to normal operation depending on the MODE selected at the wall transmitter. The
COMMUNICATION – SAFETY feature will reactivate if the transmitter’s batteries fail or be removed.
SETTING THERMOSTAT OPERATION 1. If the TS-R-2A is in the thermostat mode the word (SET) will appear
on the LCD screen.
2. When the SET button is pressed the temperature digits will begin to
ash.
3. While the temperature digits are ashing use the ON button to
increase the set temperature or use the OFF button to decrease the
set temperature to your desired temperature.
4. When the desired temperature setting is reached press the SET
button, again and the word SET will appear on the LCD screen and
now the thermostat will automatically send an ON or OFF signal to
the appliance.
5. To disengage the thermostat mode push the OFF button or push
and hold the SET button until (2) dashes appear on the LCD screen.
When you release the SET button this will disengage the thermostat
mode and the word SET will disappear from the LCD screen.
ROOM TEMP SET
ROOM TEMP SET

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 4
REMOTE RECEIVER
The remote receiver operates on (4) AA-size 1.5V batteries. It is recommended that ALKALINE batteries be used for lon-
ger battery life and maximum microprocessor performance. IMPORTANT: New or fully charged batteries are essential for
proper operation of the remote receiver.
The remote receiver houses the microprocessor that responds to commands from the transmitter to control system
operation. It emits one beep when it receives an ON or OFF command manually, but no beep when cycling ON and OFF
automatically in THERMO mode. The remote receiver has a 3-position slide switch for selecting the MODE of operation:
ON/REMOTE/OFF
• With the slide switch in the ON position (toward the
LEARN button), the system will remain on until the
slide switch is placed in the OFF or REMOTE position.
• With the slide switch in the REMOTE position
(centered), the system will only operate if the remote
receiver receives commands from the transmitter.
• With the slide switch in the OFF position (away from
the LEARN button), the system is OFF.
• It is suggested that the slide switch be placed in the
off position if you will be away from your home for
an extended period of time. If the remote receiver
is mounted out of children’s reach, placing the slide
switch in the OFF position also functions as a safety
“lock-out” by both turning the system off and rendering
the remote receiver inoperative.
REMOTE
ON
OFF
LEARN
Requires 4-AA 1.5V
alkaline batteries
Learning
button
Remote Receiver
Battery cover slides on/off
Slide
Switch
ON
REMOTE
OFF
Note: This product is designed for use with an attended hearth appliance or re feature. Adults must be present when the
Control System is operating. DO NOT program or thermostatically set this Control to operate a hearth appliance or re
feature when Adults are not physically present. Furthermore, DO NOT leave the hearth appliance or re feature burning
unattended; it may cause damage or serious injury. If an Adult is going to be away from the hearth appliance or re
feature for any length of time, then the handheld/wall mount, receiver/control module and application should be in the
“OFF” position.
THERMO- SAFETY FEATURE – RECEIVER (T/S –RX)
This SKYTECH remote control has a THERMO- SAFETY feature that is built into the system’s RECEIVER. This feature is
temperature- activated and provides an extra margin of safety when the RECEIVER is operating where ambient
temperatures exceed 130° F inside the receiver case.
The THERMO-SAFETY feature, in the RECEIVER, operates in the following manner, when the appliance is in operation.
The receiver is thermally protected from extreme heat conditions. Heat can have negative effect on the operation of the
receiver’s microprocessors.
For REMOTE RECEIVERS that operate on BATTERY POWER, these heat conditions can cause batteries to discharge
when temperatures exceed 115° F. Studies show that alkaline batteries, when exposed to a constant temperature of
120° F, can lose up to 50% of their operating power. When the battery cools down, it will partially recharge itself, but
constant heating and cooling will reduce the battery’s normal life expectancy.
When the ambient temperature at the THERMISTOR, inside the receiver case, reaches 130° F, the THERMISTOR will
automatically shut the appliance down and the RECEIVER will begin emitting a series of 2 “beeps”, every 4 seconds.
When the ambient temperature, at the RECEIVER, drops between 120° F and 130° F, the user can reactivate the
appliance by pushing the MODE button on the transmitter. The word ON must display on the LCD screen. When the ON
button is pressed, the wall THERMISTOR “resets” itself and the replace will begin operating again. However, the
“beeping” will continue, if the ambient temperature remains between 120° F and 130° F. This “beeping” alerts the user
that the RECEIVER should be repositioned so the ambient temperature drops below 120° F.
When the temperature drops below 120° F, the “beeping” will cease, providing the user has “reset” the THERMISTOR
by pushing the MODE button to ON to operate the appliance, either manually or thermally. Allow sufcient time for the
receiver to cool below 120° F, and then press MODE button to stop beeping.

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 5
INSTALLATION INSTRUCTIONS
This remote control system must be installed exactly as outlined in these instructions. Read all instructions
completely before attempting installation. Follow instructions carefully during installation. Any modications of the
SKYTECH remote control or any of its components will void the warranty and may be pose a re hazard.
Do not connect any gas valve or electronic module directly to 110-120VAC power. Consult gas appliance
manufacturer’s instructions and wiring schematics for proper placement of all wires. All electronic modules are to be
wired to manufacturer’s specications.
The following wiring diagrams are for illustration purpose only. Follow instructions from manufacturer of gas valve and/
or electronic module for correct wiring procedures. Improper installation of electric components can cause damage to
electronic module, gas valve and remote receiver.
WARNING
INSTALLATION
The remote receiver can be either wall-mounted in a standard plastic switch box or placed on or near the replace hearth.
Preferably, the remote receiver should be wall-mounted in a plastic switch box, as this will protect its electronic compo-
nents from both the heat produced by the gas appliance and potential damage or abuse that can occur if it is left exposed
on the hearth. PROTECTION FROM EXTREME HEAT IS VERY IMPORTANT. Like any piece of electronic equipment,
the remote receiver should be kept away from temperatures exceeding 130° F inside the receiver case. Battery life is also
signicantly shortened if batteries are exposed to high temperatures.
Make sure the remote receiver switch is in the OFF position. It is recommended that 18 gauge stranded or solid wires
(included) be used to make connections between the terminal wiring block on the millivolt gas valve or electronic module
and the wire terminals on the remote receiver. For the best results, use 18 gauge stranded or solid wire, with no splices
and measuring no longer than 20-feet.
WALL MOUNTING
Install (4) AA-size 1.5 ALKALINE batteries in the remote receiver. For best performance, remote receiver batteries should
be factory fresh when installed. Very little battery power is required to operate the remote receiver, but the electronics are
tuned to operate best when battery output is greater than 5.3 volts. Four new AA batteries should provide an output
voltage of 6.0 to 6.2 volts. Be sure batteries are installed with the (+) and (-) ends facing the correct direction.
To attach wall cover plate to receiver box:
1. Position the receiver as shown in diagram to the left
with lower tab on wall cover plate into groove of receiv-
er (Make sure the LEARN hole on cover plate properly
aligns with remote receiver)
2. Pull receiver up and snap into top tab of cover plate.
3. Position the wall cover plate so the word ON is facing up.
4. Install the remote receiver into the plastic switch box
using the two long screws provided. Push the slide Button
over the receiver slides witch only after making sure the
remote receiver has LEARNED the transmitter’s security
code (see LEARNING TRANSMITTER TO RECEIVER).
NOTE: Slide button covers the Learn hole when properly
installed.
Remote Receiver
Cover Plate
(Rear View)

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 6
WIRING INSTRUCTIONS
A qualied electrician or a gas technician who is familiar with the gas appliance and gas valves that will be operated by
this remote should install the remote control system. Incorrect wiring connections WILL cause damage to the gas valve or
electronic module operating the gas appliance and may also damage the remote receiver.
R
E
M
O
T
E
ON
OFF
LEARN
WALL
Plastic Switch Box
Cover Plate
Receiver
Slide
Button
NOTE: The remote receiver will only respond to the transmitter
when the 3-position slide button on the remote receiver is in the
REMOTE position. If the system does not respond to the bat-
tery transmitter on initial use, see LEARNING TRANSMITTER
TO RECEIVER, and recheck battery positions in the remote
receiver.
HEARTH MOUNT
The remote receiver can be placed on the replace hearth or under the
replace, behind the control access panel. Position where the ambient
temperature inside the receiver case does not exceed 130° F.
NOTE: Black Slide Button is used for Hearth Mount applications.
Wire terminals
Remote Receiver
Receiver
Slide
Button
REMOTE
OFF ON
LEARN
WIRING MILLIVOLT VALVES
The remote receiver is connected to the millivolt valve using
the TH (thermostat) terminals on the terminal block on the
millivolt gas valve. Connect 18 gauge stranded or solid wires
from the remote receiver to the gas valve.
Operation of the remote receiver is similar to that of a ther-
mostat in that both turn the gas valve on and off based on
input signals. A thermostat’s input signals are different tem-
peratures. The remote receiver’s input signals come from the
transmitter.
Connect each of the two wires leading from the TH and TH/
TP terminals on the millivolt gas valve to either of the two wire
terminals on the remote receiver. Normally it does not matter
which wires go to which terminal.
TERMINAL BLOCK
ON MILLIVOLT
GAS VALVES
TH
TP TP TH
THERMOPILE/
PILOT LIGHT
REMOTE
RECEIVER

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 7
The remote control receiver can be connected, in series, to
a 24VAC transformer to the TR (transformer) terminal on
the ELECTRONIC MODULE. Connect the hot wire from
the 24VAC transformer to either of the wire terminals on
the remote receiver. Connect another wire (Not included)
between the other receiver wire terminal and the TH
(thermostat) terminal on the ELECTRONIC MODULE.
WIRING ELECTRONIC SPARK IGNITIONS
ELECTRONIC MODULE
TR TH
REMOTE
RECEIVER
neutral wire
24VAC
hot wire
120VAC
110/24VAC
Transformer
SYSTEM CHECK
MILLIVOLT VALVES
Light your gas appliance following the lighting instructions that came with the appliance. Conrm that the pilot ame is
ON; it must be in operation for the main gas valve to operate.
• Slide the 3-position button on the remote receiver to the ON position. The main gas ame (i.e., the re) should ignite.
• Slide the button to OFF. The ame should extinguish (the pilot ame will remain ON).
• Slide the button to REMOTE (the center position), then press the ON button on the transmitter to change the system
to ON. The main gas ame should ignite.
• Press the ON button on the wall transmitter to change the system to OFF. The ame should extinguish (the pilot
ame will remain on).
• Press the ON button on the wall transmitter to change the system to THERMO. Advance the SET temperature on the
transmitter to a temperature of a least 2° F (1° C) above the ROOM temperature displayed on the LCD screen. With
this manual setting, the normal thermostatic cycle is overridden and the system ame will ignite. Set the SET
• temperature to at least 20 F (10 C) below the room temperature and the system ame will extinguish in a few
• seconds. Thereafter, it should continue to cycle to on and off thermostatically approximately every two minutes as the
ROOM temperature changes, but only when the temperature differential between ROOM and SET temperatures differ
at least 2° F (1° C). The 2° F differential is the factory setting.
ELECTRONIC IGNITION SYSTEMS
• Slide the 3-position button on the remote receiver to the ON position. The spark electrode should begin sparking to
ignite the pilot (the pilot may ignite after only one spark). After the pilot ame is lit, the main gas valve should open
and the main gas ame should ignite.
• Slide the button to OFF. The main gas ame and pilot ame should BOTH extinguish.
• Slide the button to REMOTE (the center position), then press the ON button on the wall transmitter to change the
system to ON. The spark electrode should begin sparking to ignite the pilot. After the pilot is lit, the main gas valve
should open and the main gas ame should ignite.
• Press the ON button on the wall transmitter to OFF. The main gas ame and pilot ame should BOTH extinguish.
• Press the ON button on the wall transmitter to change the system to THERMO. Advance the SET temperature on
the transmitter to a temperature of at least 2° F (1° C) above the ROOM temperature displayed on the LCD screen.
With this manual setting the normal thermostatic cycle is overridden and the system ame will ignite. Set the SET
temperature to at least 2° F (1° C) below the room temperature and the system ame will extinguish in a few seconds.
Thereafter, it should continue to cycle to on and off thermostatically approximately every two minutes as the ROOM
temperature changes, but only when the temperature differential between ROOM and SET temperatures differ at least
2° F (1° C). (The 2° F differential is the factory setting).

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 8
GENERAL INFORMATION
LEARNING TRANSMITTER TO RECEIVER
Each transmitter uses a unique security code. It will be necessary to press the LEARN button on the receiver to accept
the transmitter security code upon initial use, if batteries are replaced, or if a replacement transmitter is purchased from
your dealer or the factory. In order for the receiver to accept the transmitter security code, be sure the slide button on
the receiver is in the REMOTE position; the receiver will not LEARN if the slide switch is in the ON or OFF position. The
LEARN button in located on the front face of the receiver; inside the small hole labeled LEARN. Using a small screwdriver
or end of a paper clip gently press and release the black LEARN button inside the hole. When you release the LEARN
button the receiver will emit an audible “beep”. After the receiver emits the beep press the transmitter ON button and
release. The receiver will emit several beeps indicating that the transmitter’s code has been accepted into the receiver.
The microprocessor that controls the security code matching procedure is controlled by a timing function. If you are
unsuccessful in matching the security code on the rst attempt, wait 1-2 minutes before trying again – this delay allows
the microprocessor to reset its timer circuitry – and try up to two or three more times.
THERMO FUNCTION
When the transmitter is in the THERMO mode, it should be kept away from direct sources of heat such as replaces,
incandescent lighting, and direct sunlight. Leaving the transmitter in direct sunlight, for example, will cause its
heat-sensing diode to read the room temperature higher than it actually is; if in THERMO mode, it may not turn on the
appliance even if the ambient ROOM temperature is below the SET temperature.
BATTERY LIFE
Life expectancy of alkaline batteries in the SKYTECH A-TS/R-2A should be at least 12 months. Check and replace all
batteries annually. When the Wall Transmitter no longer operates or the remote receiver does not function at all, the
batteries should be checked. It is important that the remote receiver batteries are fully charged, providing a combined
output voltage of at least 5.3 volts. The length of the wire between the remote receiver and the gas valve directly affects
the operating performance of the remote system. The longer the wire, the more battery power is required to deliver
signals between the remote receiver and the gas valve. The Wall Transmitter should operate with as little as 2.4 volts of
battery power, measuring at each of the 3-volt button cell batteries.
FCC Notication
Note: This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guaran-
tee that inference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experience radio/TV technician for help

Skytech: TS-R-2A Wireless Thermostat REV. 11-14-18 Page 9
FOR TECHNICAL U.S. INQUIRIES CANADIAN INQUIRIES
SERVICE, CALL: [phone] or [phone] [phone]
Skytech Products Group
9230 Conservation Way
Fort Wayne, IN 46809
Sales Support: [phone]
Website: skytechpg.com
MANUFACTURED EXCLUSIVELY FOR SKYTECH II, INC
TROUBLE SHOOTING
Should you encounter problems with your replace system, the problem may be with the replace itself or it could be with
the SKYTECH remote control. Review the replace manufacturer’s operation manual to make sure all connections are
properly made. Then check the operation of the SKYTECH remote in the following manner:
1. Make sure receiver batteries are installed properly. If one battery is installed backward, receiver will not operate in
remote mode. Be sure battery output is 5.3 volts or more. (Slide switch is independent of battery condition.)
2. Be sure the wall transmitter’s batteries are properly installed and that the battery output is 2.4 volts each or more.
3. The wall transmitter has (2) 3 volt button cell batteries (1) button cell operates the LCD screen and the other button
cell operates sending the RF signal. If the button cell battery that controls sending the RF signal is low or defective the
LCD screen may work but the RF signal may not be sending (Check each button cell battery)
4. Check to make sure the transmitter is communicating with the receiver.
-If the receiver beeps when the ON button is depressed on the wall transmitter they are communicating.
-If the receiver does not beep when the ON button is depressed on the wall transmitter, you will need to teach the
receiver the code of the transmitter. This is done by holding the LEARN button down on the receiver (NOTE: The black
slide Button covers the LEARN access hole when installed), and at the same time depress the ON button on the wall
transmitter. A change in the beeping pattern, at the receiver indicates the transmitter’s code has been programmed into
the receiver.
5. Make sure the wall transmitter is within the 15 to 20-feet range of the receiver.
6. Positioning of the receiver is important. If the receiver is “enclosed” in a metal surround, the operation of the
receiver may be affected as noted below. Reposition the receiver to improve operating range. It is suggested that a
heat shield be installed to protect the receiver from extreme heat. If the receiver is “enclosed” in a metal surround,
this can:
-Cause the RF signal to get lost and not communicate with the receiver.
-Cause the working distance to be shorter than normal.
NOTE: A receiver located in an area, where the ambient temperature inside the case exceeds 130°F, will cause
THERMO-SAFETY feature to cut in, requiring you to reposition the receiver to stop the warning beeps, and to “reset” the
receiver’s operation.
SPECIFICATIONS
BATTERIES: Wall Transmitter 6V – 2ea. (CR2032) 3.0 volt lithium button cell batteries
Remote Receiver 6V – 4ea. AA 1.5 Alkaline
FCC ID No.’s: transmitter –(K9L TS-R-2A); receiver – (K9L 3301RX) Operating Frequency: 303.8MHZ
Canadian IC ID No.’s: transmitter – (2439A-TSR2A) receiver – 2439A-3301RX
FCC REQUIREMENTS
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED
BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE
USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
