Skyworth SKW-T21 User manual
Bedienungsanleitung
User Manual
Empfänger für hochauösendes
Antennenfernsehen
SKW-T21
05 Sep 2017 15:02
Geliefert von STRONG Austria
Vertreten durch
STRONG Ges.m.b.H.,
Franz-Josefs-Kai 1,
1010 Wien, Österreich
Email: [email protected]
Licenses
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC
VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
This product contains one or more programs protected under international and U.S. copyright
laws as unpublished works. They are confidential and proprietary to Dolby Laboratories. Their
reproduction or disclosure, in whole or in part, or the production of derivative works therefrom
without the express permission of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby
Laboratories. All rights reserved.
THIS PRODUCT IS SOLD WITH A LIMITED LICENSE AND IS AUTHORIZED TO BE USED ONLY
IN CONNECTION WITH HEVC CONTENT THAT MEETS EACH OF THE THREE FOLLOWING
QUALIFICATIONS: (1) HEVC CONTENT ONLY FOR PERSONAL USE; (2) HEVC CONTENT THAT IS NOT
OFFERED FOR SALE; AND (3) HEVC CONTENT THAT IS CREATED BY THE OWNER OF THE PRODUCT.
THIS PRODUCT MAY NOT BE USED IN CONNECTION WITH HEVC ENCODED CONTENT CREATED BY A
THIRD PARTY, WHICH THE USER HAS ORDERED OR PURCHASED FROM A THIRD PARTY, UNLESS THE
USER IS SEPARATELY GRANTED RIGHTS TO USE THE PRODUCT WITH SUCH CONTENT BY A LICENSED
SELLER OF THE CONTENT. YOUR USE OF THIS PRODUCT IN CONNECTION WITH HEVC ENCODED
CONTENT IS DEEMED ACCEPTANCE OF THE LIMITED AUTHORITY TO USE AS NOTED ABOVE.
05 Sep 2017 15:01
1
SKYWORTH declares that this item complies with the basic requirements and other relevant regulations of directives
EMC 2014/30/EU, LVD 2014/35/EU and RoHS 2011/65/EU.
Subject to alterations. In consequence of continuous research and development technical specifications, design and
appearance of products may change. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries. Manufactured under license from
Dolby Laboratories. Dolby Audio, Dolby Digital, Dolby Digital Plus and the double-D symbol are registered trademarks of
Dolby Laboratories. All other product names are trademarks or registered trademarks of their respective owners.
© SKYWORTH 2017. All rights reserved.
TABLE OF CONTENTS
1.0 INTRODUCTION 3
1.1 Safety Instructions 3
1.2 Storage 4
1.3 Equipment Set-up 4
1.4 Accessories 5
1.5 Usage of external USB devices 5
2.0 YOUR RECEIVER 5
2.1 DEFAULT PIN: 0000 5
2.2 Front Panel 5
2.3 Rear Panel 6
2.4 Remote control 6
2.5 Installing the batteries 7
2.6 Using the remote control 7
3.0 CONNECTION 7
3.1 Connecting to a terrestrial
antenna 7
3.2 Connecting to TV with HDMI
cable 8
3.3 Connecting to TV with SCART
cable 8
3.4 Connecting a USB storage
device 8
3.5 Connecting to Ethernet for RSS
feeds and weather forecasts 8
3.6 Extended connections for your
home entertainment 8
4.0 STARTING UP FOR THE FIRST TIME 9
4.1 Language selection 9
4.2 Region, Subtitles, Scan Mode
and screen settings 9
4.3 Aerial Adjustment 9
5.0 QUICK GUIDE TO USING YOUR RECEIVER
10
6.0 OPERATION 10
6.1 Changing channels 10
6.2 Info Banner 11
6.3 Selection of audio language 11
6.4 Teletext 11
6.5 Subtitles 11
6.6 EPG (Electronic Programme
Guide) 12
6.7 Record, Time shift and Format*
12
7.0 MAIN MENU 13
7.1 Installation of channels 13
7.2 Channels 15
7.3 Settings 16
7.4 Multimedia 20
7.5 Network 22
7.6 Software update 23
8.0 TROUBLESHOOTING 24
9.0 TECHNICAL SPECIFICATIONS 25
2
1.0 INTRODUCTION
1.1 Safety Instructions
Read all of the instructions before operating the device. Keep these instructions well for later use.
Only use attachments/accessories specified or provided by the manufacturer (such as the
exclusive supply adapter, battery etc.).
Please refer to the information on the product enclosure for electrical and safety information
before installing or operating the apparatus.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The ventilation should not be impeded by covering the ventilation openings with items, such
as newspaper, table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The mark indicates a risk of electric shock.
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with
the installation instructions.
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or
equivalent types.
The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Listening to music at high volume levels and for extended durations can damage one's hearing.
In order to reduce the risk of damage to hearing, one should lower the volume to a safe,
comfortable level, and reduce the amount of time listening at high levels.
The mains plug or appliance coupler is used as disconnect device, it shall remain readily
operable. When not in use and during movement, please take care of the power cord set, e.g.
tie up the power cord set with cable tie or something like that. It shall be free from sharp edges
or similar which can cause abrasion of the power cord set. When put into use again, please
make sure the power cord is not damaged. The absence of a light indication on the apparatus
does not mean that it is fully disconnected from the mains. To disconnect the apparatus
completely, the mains plug must be pulled out.
Attention should be drawn to environmental aspects of battery disposal.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
To prevent the spread of fire, keep candles or other open flames away from this product
at all times.
Equipment with this symbol is a Class II or double insulated electrical appliance. It has
been designed in such a way that it does not require a safety connection to electrical
earth.
Precautions
Never try to open the device. It is dangerous to touch the inside of the device due to high
voltages and possible electrical hazards. Opening the device will void the warranty of the
product. Refer all maintenance or servicing to suitably qualified personnel.
3
When you are connecting cables, be sure that the device is disconnected from the mains
supply voltage. Wait a few seconds after switching off the device before you move the device
or disconnect any equipment.
It is a necessity that you only use an approved extension and compatible wiring that is suitable
for the electrical power consumption of the installed equipment. Please ensure that the
electrical power supply corresponds with the voltage on the electrical identification plate at the
back of the device.
Operating Environment
Do not install this equipment in a confined space such as a bookcase or similar unit.
Do not use the set near damp, and cold areas, protect the set from overheating.
Keep away from direct sunlight.
Do not use the set near dust place.
Do not attach candle to accessible opening area, to avoid flammable foreign material from
entering the device.
WEEE Directive
Correct Disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased. They can
take this product for environmental safe recycling.
1.2 Storage
Your device has been carefully checked and packed before shipping. When unpacking it, make sure
that all the parts are included and keep the packaging away from children. We recommend that you
keep the carton during the warranty period, to keep your device perfectly protected in the event of
repair or warranty.
1.3 Equipment Set-up
We recommend you to consult a professional installer to set up your equipment. Otherwise, please
follow the instructions below:
Refer to the user manual of your TV and, if applicable, your antenna.
Make sure that the HDMI cable and, if applicable, outdoor components are in a good condition.
If you use the TV SCART connection, use a well shielded SCART cable.
This manual provides complete instructions for installing and using this receiver. The following
symbols will serve as follow.
WARNING: Indicates warning information.
NOTE Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver.
(Bold characters)
Move to Represents a menu item within a window.
(Italic characters)
4
1.4 Accessories
Installation instructions
1 remote control unit
2x batteries (AAA type)
1 HDMI cable
WARNING: The batteries should not be recharged, disassembled, electrically short-
circuited, be mixed or used with other types of batteries. If rechargeable
accumulators instead of batteries are going to be used (e.g. NiMH), we
recommend using types with low self-discharge to ensure long time
operation of your remote control.
1.5 Usage of external USB devices
It is recommended to use USB 2.0 storage devices or higher. If your device is not compatible
to USB 2.0 specifications, recording, playback and other multimedia functions of the receiver
might not work properly.*
To ensure best performance of your USB storage device please format it via your receiver
(through the menu “Multimedia”) to FAT32 system. Other file systems are not all supported by
the receiver. However, it is possible to use already NTFS formatted disks.
SKYWORTH cannot guarantee compatibility with all types of USB storage devices.
If you are going to use external USB HDDs (Hard Disk Drives), please consider that power
specifications may exceed the supported output of your receiver (max.5 V/800 mA). If so, please
connect your USB HDD to an according external power adapter.
Playback of files cannot be guaranteed although extensions are listed, as it depends on codec,
data bit rate and resolution used (all MPEG codec formats are supported).
It is advised not to store important information on USB storage devices used with the receiver.
Always make backups of data on your USB storage device before using it with this receiver.
SKYWORTH will not take responsibility for any loss of information or circumstances caused by
loss of information.
*This user manual describes the full functionality including the recording function and may not be applicable if the
software for recording via USB has not yet been installed (available in our web shop: www.strong.tv).
2.0 YOUR RECEIVER
2.1 DEFAULT PIN: 0000
2.2 Front Panel
Fig. 1
1. IR Sensor Receives commands from the remote control
2. LED Display Shows channel number and time in standby
5
3. Mode Indicator LED RED indicates that the receiver is in STANDBY mode. GREEN
indicates that the receiver is in OPERATING mode.
4. Standby/ON button Switches the receiver ON or into Standby
5. USB To connect your USB storage device.
2.3 Rear Panel
Fig. 2
1. ANT IN To connect to your antenna for reception of broadcast signals.
2. ETHERNET To connect to your Ethernet cable (RJ-45) for RSS feeds and
weather forecasts
3. HDMI To connect your receiver with your TV-set using an HDMI cable.
4. S/PDIF Coaxial To connect your receiver to a digital home cinema set, AV
receiver or digital audio amplifier.
5. TV SCART To connect your receiver with your TV-set using a SCART cable.
6. Power cord Your receiver requires a supply voltage of 220 – 240 V AC
(Auto-selectable), 50/60Hz +/-5%. Please ensure the local power
specification meets these requirements before connecting your
receiver to the wall outlet.
7. Power switch To power your receiver ON or OFF
2.4 Remote control
Fig. 3
1. qSwitches the receiver On/Standby.
Quick press: passive standby – enables quick start-up. Long press
(more than one second): active standby - longer start-up time.
2. !Mutes all audio outputs of the receiver
3. 0~9 Enter channel number in TV mode or value input in menu
4. TV/R Toggles between TV or RADIO mode.
5. No function
6. FAV Opens the favourite group selection.
7. 9One step back in menu or back to previous channel.
8. AUDIO Opens the audio* language selection
9. INFO Opens the current channel information; 2x opens the current
event information and 3x the next event information.*
10. EPG Opens the EPG* (Electronic Programme Guide) in TV mode.
11. pq Change channel to next/previous.
Menu: Moves the cursor up/down.
12. tuDecreases/increases the volume level.|
Menu: Change settings for specific menus.
13. OK Opens the current channel list in menu: for confirmation
14. MENU Opens the main menu, in a menu you will get one step back.
15. Exits from the menu or sub-menu.
16. VOL+/VOL- Increases/decreases the volume level.
17. P+/P- Page up/down in all list modes.
6
18. LIST Call the current channel list.
19. CH+/CH- Channel up/down.
20. OPT Opens quick menu to adjust screen settings
21. TEXT Opens the Teletext* if available
22. SUB Shows a list of subtitle* languages.
23. To read messages from your provider.
24. 2Hold play during playback/starting Timeshift mode**
25. 56Fast rewind/fast forward.
26. 4Starts recording of the currently watched programme**
27. uOpens the multimedia menu
28. 7 8 Jump function in multimedia playback
29. 3Stop playback.
30. COLOUR BUTTONS In different menus for specific functions
* Subtitles, Videotext, EPG (Electronic Programme Guide), and Audio languages are depending on availability in the
specific broadcast
** This user manual describes the full functionality including the recording function and may not be applicable if the
software for recording via USB has not yet been installed (available in our web shop: www.strong.tv).
2.5 Installing the batteries
Fig. 4
Open the cover on the remote control and insert 2x AAA type batteries into the compartment.
Observe correct polarity of the batteries when inserting. A terminal diagram is shown inside the
compartment.
1. Remove the cover.
2. Insert the batteries.
3. Place the cover.
2.6 Using the remote control
Fig. 5
To use the remote control, point it towards the front of your receiver. The remote control supports a
range of up to 5 meters distance to the receiver at an angle of up to approx. 30 degrees.
NOTE: Managing the receiver will be limited or not possible if there are obstacles
between the remote control sensor (at the front panel of the receiver)
and the remote control. Direct sunlight or very bright light can reduce or
disturb the reception of the remote control signals.
3.0 CONNECTION
3.1 Connecting to a terrestrial antenna
Fig. 6
7
To receive broadcast signals, your terrestrial indoor or outdoor antenna must be connected to the
ANT IN connector on the back of the receiver. Use a proper shielded antenna cable and suitable
connectors.
NOTE: If the signals at your location are too weak to receive proper signals with
an indoor antenna, we recommend using an outdoor antenna which
can be pointed towards the transmission tower. Ask your local dealer for
more information. If you are using an active antenna with built-in antenna
amplifier, switch the antenna power to ON in the menu Manual Search.
3.2 Connecting to TV with HDMI cable
Fig. 6
The TV set shall be connected to the receiver using a good quality HDMI cable. This connection gives
the highest possible picture quality.
3.3 Connecting to TV with SCART cable
Fig. 6
Your receiver is also equipped with a SCART connector; alternatively, the TV set can be connected to
the receiver using a good quality SCART cable.
3.4 Connecting a USB storage device
Fig. 6
This port can be used for USB storage devices such as USB pen drives or HDD with a maximum peak
current of 800 mA. It is recommended to use USB 2.0 storage devices (or higher) for playback of video
files or HD movies.
3.5 Connecting to Ethernet for RSS feeds and weather
forecasts
Fig. 7
To use this option of your receiver it must be connected to your router. Connect the Ethernet (RJ-45)
connector with a class CAT5E (or higher) cable to your router.
3.6 Extended connections for your home entertainment
Fig. 8.
Connecting to a Digital Audio Amplier with S/PDIF
By connecting your receiver to a digital amplifier or home cinema set, you can enjoy the best possible
sound quality and multi-channel audio (depending on broadcast). Connect your Digital Audio
Amplifier or home cinema set with a suitable cinch cable to the S/PDIF connector on the back of the
receiver. Alternatively, if you’re using an analogue amplifier, then connect the audio output jack for
stereo audio.
8
Connecting to a digital audio amplier and TV using HDMI
By connecting your receiver to an HDMI equipped digital amplifier or home cinema set you will
enjoy the best possible sound quality and multi-channel audio (depending on broadcast). Connect
the HDMI output of the unit to an input of your amplifier, and then connect the HDMI output of the
amplifier to your TV set. Select the correct input on your amplifier to watch and listen to programmes.
4.0 STARTING UP FOR THE FIRST TIME
Make sure that your receiver and antenna are connected/aligned correctly. If you have any related
questions accordingly, please contact your local service or retailer. Then switch your receiver “ON” by
using the power switch below the main power cord.
The first time installation will guide you through the required steps, after that you will be able to
enjoy your HD TV completely. If you already connected an Ethernet cable to your receiver, you can
access RSS feeds and weather forecasts. We wish you lots of fun with your new product.
4.1 Language selection
When you use your receiver for the first time, the “Bevorzugte Sprache” (Preferred Language) menu
appears. Use pq to select the desired language. Once you have selected your language, press the
GREEN Next button to go to the next page.
4.2 Region, Subtitles, Scan Mode and screen settings
The receiver will now show the “First Time Installation” screen where you can adapt some of the most
important settings. Use pq to move to the desired setting and use tuto change values. Press the
GREEN Next button to go to the next page or press the RED Back button to go one step back. The
following settings are available:
Region: The region is pre-set to Germany. The receiver can only be used in Germany.
Subtitle: Select On to display subtitles per default, select Off to hide subtitles per
default.*
Aspect Mode: Use this option to select the aspect ratio of the connected TV. The options
are: 4:3 for a 4:3 TV (black bars on top and bottom of picture) and 16:9 for 16:9
TV sets.
Scan mode: Select All to store scrambled and free-to-air channels or select Free to store
only free-to-air channels.
* Availability of DVB/HoH subtitles depends on the broadcast. If subtitles are not supported, they can be activated via
Teletext if available.
When all settings have been made, press the GREEN Next button to continue.
4.3 Aerial Adjustment
This part of the wizard is of great help when setting up your antenna system.
Use pq to move the highlight to the setting you wish to change and use tuto change values. The
following settings are available:
Antenna Power: Set to On if you use an active antenna (with built-in amplifier). When set to
On, 5 V will be present at the ANT IN connector of the receiver. Select Off for
passive antennas.
9
Channel No.: Select a channel that is known to carry a broadcast signal in your region.
The Signal Strength and Signal Quality bars give a visual indication of the
reception. Adjust your antenna to obtain maximum signal strength and
quality.
When all settings have been made, press the GREEN Next button to start scanning.
The receiver will search for all available channels. When the scan is finished, the receiver switches to
viewing mode. Now you can enjoy watching your favourite TV channels. If you get the message “No
channels found”, then check again the antenna, coaxial cable, connector and in menu if you have
reception. When this has been checked, reset the unit and follow the installation wizard again as
shown below.
NOTE: If the receiver won’t start after switching on the receiver for the first
time, reset the receiver to factory settings by pressing the MENU
button and selecting Load Factory Setting in the menu Installation.
(DEFAULT PIN: 0000).
5.0 QUICK GUIDE TO USING YOUR RECEIVER
We at SKYWORTH understand that you can’t wait to enjoy your new high definition digital terrestrial
receiver. The following quick guide will make you familiar with the basic operation of this device. We
do, however, advice you to read the full manual to get the best performance from your receiver.
Make sure the power switch on the back panel below the main power cord is turned ON. To turn your
receiver ON or to Standby, press qon the remote control or the button on the right hand side of the
front panel.
Choose the desired channel with pq. Alternatively, you can press the channel number with the 0~9
buttons on the remote control or press OK in viewing mode to display the channel list. The volume
can be adjusted with tu.
6.0 OPERATION
Your new receiver is equipped with several features to make watching TV a true pleasure. This
paragraph describes these features. Please do also read chapter 7.0 to get familiar with the menu of
your receiver.
6.1 Changing channels
Following ways are possible for changing channels with your new receiver:
Via direct access using the 0~9 buttons.
Via the channel list through OK and the PG+/PG- buttons.
Via the pq buttons.
6.1.1 Direct access via 0~9 buttons
To gain direct access to a certain channel, simply enter its number with the 0~9 buttons on the
remote control. Channel numbers can be up to four digits long. Entering a number with less than
10
four digits is possible. Just wait a few seconds and your receiver will switch to the selected channel or
press OK immediately after selecting the channel number.
6.1.2 Channel list
Press OK in viewing mode to display the current TV list. Use pq in the channel list to highlight your
channel of choice and press OK to switch. Press OK again to leave the channel list mode. Inside the
channel list it is possible to use the PG+/PG- buttons as well in order to scroll page-wise through the
list to speed up.
6.1.3 Using pq
pswitches to the next channel.
qswitches to the previous channel.
6.2 Info Banner
While watching TV, you can press INFO at any time to access information about the current channel
and event*. Press INFO twice for extended EPG details about the current channel. Press INFO three
times for EPG details of the next programme.
* Event information is displayed when available. Availability depends on broadcast.
6.3 Selection of audio language
Some channels support a choice of audio formats and/or languages.
To select another audio stream, press AUDIO in viewing mode. A list of available audio streams will
now be displayed. Use pq to select a stream and confirm with OK. The audio channel as stereo, mix,
left and right can be selected with tu.
6.4 Teletext
To access the available Videotext, press the TEXT button in viewing mode and use the 0~9 buttons
to enter the number of the page you wish to see. In case of availability you can also use the COLOUR
BUTTONS of the remote control for direct access, as indicated on the bottom of the screen.
Use pq to select one page up or down, use tuto select subpages. Press or TEXT to get back to
viewing mode. While in TEXT mode, use the OK button to select the level of the teletext transparency
(five steps possible).
6.5 Subtitles
Some channels support a choice of subtitle languages. Press SUB in viewing mode to display a list of
available subtitle languages. Select your subtitle of choice with pq and press OK to confirm. Press
to leave without making changes.*
* Availability of DVB/Hard of Hearing subtitles depends on the broadcast. If subtitles are not present, they can be activated
via Teletext (if available).
11
6.6 EPG (Electronic Programme Guide)
The Electronic Programme Guide is a very useful function that allows you to view event schedules
and programme information and to mark events/movies for wakeup of the receiver. To access the
EPG, press EPG in viewing mode. Use pq to select a channel and tuto select an event. Press OK
to display detailed information of the selected event. Use 9to quit the detailed information screen.
Press the RED or GREEN buttons to see and select another day. Press the YELLOW button to set a
timer for a selected event. Refer to section 7.3.4 for details of the timer function.
NOTE: Availability of EPG data depends on broadcast.
6.7 Record, Time shift and Format*
* This part of the user manual describes the full functionality including the recording function and may not be applicable
if the software for recording via USB has not yet been installed and activated. Please, visit our website www.strong.tv to
get more information.
To use these functions, you must connect a USB memory device to the USB port at the rear panel.
For best performance, especially of HD content, we advise to use Hard Disk Drives USB 2.0 or higher.
These must be formatted in FAT32 format otherwise Recording and Timeshift function will not work.
6.7.1 Instant recording*
To immediately record a programme, press 4to start the recording and press 3to quit.
6.7.2 Timeshift*
If you want to use the Timeshift function you only need to press 2in viewing mode. To resume
timeshifted content, press uor 2again. During the playback, you can use the 56or 2buttons. To
stop the Timeshift mode, press 3and it will jump to the actual time of the live signal. The function
will still be running in the background and as long you do not switch to another channel it is possible
to jump again to the beginning by pressing 2again. Also, with tuit is possible to jump in time
during Timeshift modes. Default is set to 20 seconds. Press the GREEN Jump Set button to change the
jump time.
If the channel is changed timeshifted content will only be accessible from the newly selected channel.
NOTE: To switch off the Timeshift function completely you need to change the
Timeshift status to disable in the Record setup menu.
6.7.3 Timer recording
There are 2 ways to set a timer:
Programming a record timer via the EPG
The easiest way to record an event is via the EPG. Press the EPG button to open the EPG, then use
pq to select a channel. After that, press tuand use pq to select an event. You can book a record
12
timer by pressing 4. If you press 4again on this event, the timer will be disabled. The set time of
timer is fixed and cannot be modified.
Programming a record timer via the Timer menu
If you want to programme a record timer via the timer menu, press the BLUE button from EPG to
open it. You can also select it via the MENU button on the remote control in viewing mode, option
Timer in the menu Settings. This way you are free to programme start and stop time. For further
details about this menu, please refer to chapter 7.3.6Timer in the user manual.
6.7.4 Playback
After a recording has been made you will find a new folder Records created on your external USB
storage device. By pressing uin viewing mode you can access this folder directly. Inside the Records
menu the following functions are supported:
pq To select a recorded event.
OK Starts playback in preview and again in full screen mode.
3Stops playback
RED Opens the option menu to select and deselect for deleting a recorded file(s).
This menu item opens only if you have selected first a file by using pq.
Marks a recording for deletion. When all recordings you want to delete are
marked, select Deleted Selected press OK. A message will appear to confirm
deleting. By pressing OK again the recordings will be permanently deleted
from your external USB storage device. Select Cancel if you don’t want to
delete them or select once more OK to definitely delete.
*This user manual describes the full functionality including the recording function and may not be applicable if the
software for recording via USB has not yet been installed (available in our web shop: www.strong.tv).
7.0 MAIN MENU
The main menu gives you access to Installation, Channels, Settings, Multimedia and Network functions.
To access the main menu, press MENU in viewing mode. Throughout the main menu, 9can be used
to get back to the previous screen and to quit.
7.1 Installation of channels
Use tuto select the main menu item Installation.
Use pq to highlight the submenu of choice and press OK to select. These submenus are available:
Manual Search, Auto Search, Information, Factory Settings and Freenet Menu
7.1.1 Manual Search
This menu allows you to search for channels at a specific Frequency or Channel number.
Use pq to select Scan mode, and select between Free which will only install Free-to-Air channels or
All. This means that channels that are Free-to-Air or scrambled will be searched and stored.
Use pq to select Channel No and select the channel number of the frequency you’d like to search.
Press OK to open a list to make selection faster.
The next option Modulation is to select between Only DVB-T or DVB-T+T2 modulation type.
13
When in doubt, use the DVB-T+T2 setting.
If you use an active antenna (with built-in amplifier), then switch the Antenna Power to On. If you use a
passive antenna (without built-in amplifier), then select Off.
Highlight Search and press OK to start scanning. New found channels will be added to the channel
list.
7.1.2 Auto Search
This menu allows you to search for channels from all available Frequencies or Channel numbers. Be
aware that all previous installed channels and favourite list(s) will be deleted. The new found channels
will be installed in the channel list and afterwards you can create a new favourite list if you like.
Select Scan mode, and select between Free which will only install Free-to-Air channels or All. Highlight
Search and press OK to start scanning.
7.1.3 Information
This submenu shows receiver specific information such as hardware and software version. It also
displays technical information from the currently selected channel and signal strength and quality.
Please have the Information screen on hand when you call our hotline. The person who answers your
call might ask for the information given in this screen.
7.1.4 Load Factory Settings
This option allows you to reset the receiver back to the factory settings, which also clears all stored
channels.
Use pq to select Load Factory Settings in the Installation menu and press OK. You are asked to
enter your PIN code. Enter the correct PIN code using the 0~9 buttons. (DEFAULT PIN: 0000). A
confirmation window is displayed. Select OK to load factory settings. Select Cancel to cancel. Press
to leave.
WARNING: By resetting your receiver to factory default, all your settings and stored
channels will be permanently deleted. Please use this option with care.
7.1.5 Freenet Menu
Read technical data about your subscription(s) and find messages from your provider. Moreover, you
can check the rights to watch certain programmes. A Software update is signalled here too. Follow
the instructions on screen. Some data given has no immediate meaning to a client, but is useful to
a service centre or provider itself. This menu gives access to the following submenus which can be
opened for detailed information about these items: Service Status, Loader Status, Product Status, Client
Status and Mailbox.
7.1.5.1 Mailbox
This menu allows access to provider mails. It is used for sending important information from
broadcaster/content provider to you. If you receive a mail you will get this message directly displayed
14
on screen. After the mail has been removed from the screen you can find the messages within the
menu and have the possibility to delete messages individually by pressing the BLUE Delete button or
to delete all of them by pressing the RED Delete ALL button.
7.2 Channels
Use tuto select Channels in the main menu.
Use pq to highlight the submenu of choice and press OK to select.
7.2.1 TV Manager
This menu allows you to create favourite lists, move channels in order, lock channels with PIN
protection and delete channels from the TV list.
7.2.1.1 Adding channels to favourite lists
Channels from the TV list can be added to up to 4 different favourite groups. Select Favourite and
press OK, select the wanted favourite group and press OK again. Use pq to select a channel you
wish to add to a favourite group. When the highlight is on the channel of your choice, press OK. At
the right hand side you will see your new created favourite list. If you like to remove a channel from a
favourite list, simply press uand select that channel and press OK to delete.
NOTE: It is recommended to start with the selection of the channel you’d like to
have at position 1 in the favourite list and then add others in the desired
order one by one. However, sorting of favourite channels afterwards is
possible by using the GREEN Move button, but only if the Logical Channel
Numbering function is switched Off. In the new software versions this
function is set to OFF by default (Menu Settings General settings), in case of
doubt please update your receiver with the latest software version.
If the Logical Channel Numbering function is switched On channels can’t be moved.
Press to finalize the process. A confirmation banner will pop up. Select OK to save the changes or
Cancel to discard.
7.2.1.2 Move channels in channel list
This receiver supports Logical Channel Numbering (LCN). This means that the channel numbers
are operator defined and automatically sorted into the main channel list. Sorting in the main list is
therefore not possible. In this case the Move function is marked grey and cannot be selected. The
default setting for this function is Off and you are free to sort the channels in the main channel list.
Further information about the functions Automatic channel update and Logical channel numbering,
which have influence on the functions of channel management, can be found in the chapters 7.3.3.3
and 7.3.3.4.
Sort the channel order from the main channel list
Select the option Move and press OK. Use pq to select the channel you wish to sort onto first
position. When the highlight is on the channel of your choice, press OK. This can be done with more
15
channels until you are happy with the sorted order. To remove one channel from selection list, press
tand select in the “Selected” list the channel. Press OK to remove it. To store the new channel order,
select in “Channel list” the position press the RED button Move. If you have only sorted a few channels
and want to store this between existing channels, select in “Channel list” the position where the
sorted channels need to be copied to.
7.2.1.3 Lock channels
Protect channels with a PIN code to prevent an unwanted watching of specific content/channels.
Select the option Lock and press OK. Use pq to select a channel you wish to protect. When
the highlight is on the channel of your choice, press OK. At the right hand side you will see your
protected channel list. If you like to remove a channel from this list, then simply press uand select
that channel and press OK to unselect.
7.2.1.4 Delete channels
Delete a channel or channels permanently from the main channel list (until you make a new search).
Select the option Delete and press OK. Use pq to select the channel you wish to delete. When the
highlight is on that channel, press OK. At the right hand side you will find the selection to delete from
channel list. When you are ready, press 9and confirm.
NOTE: If the function “Auto Channel Update” is set to On it is not possible to
delete channels This function can be found in the menu Settings in the
General Settings menu. See chapter 7.3.3.4.
7.2.2 Radio Manager
Create favourite lists, move channels in order, lock channels with PIN protection and delete channels
from the radio list. The functions of handling are the same as in the TV Manager as described above.
The only difference is that in the Radio manager there is no video information, so it will always display
the radio background on the preview screen.
7.2.3 EPG
This menu item opens the Electronic Programme Guide (EPG). For details, see chapter 6.6
7.3 Settings
Press MENU in the TV mode and use tuto select Settings. Use pq to highlight the submenu of
choice and press OK to select.
7.3.1 Language
This menu allows you to set up your language preferences.
OSD Language: Use tuto select the language for the On Screen Display.
1st Audio language: Use tuto select the audio language you like to hear as first priority, if
available.
16
Table of contents
