Slingshot PHANTASM KITE 633 User manual

PHANTASM
KITE 633

PHANTASM KITE 633 PACKAGE
After two years of meticulous and extensive research and
development, we are proud to introduce the ALL NEW
Phantasm 633. The Phantasm 633 is a high-performance
carbon freeride foil with tons of versatility in a lightweight
premium carbon construction. The Phantasm 633 is made
from super light, stiff and efficient high-modulus carbon,
with a larger, lower aspect front wing that gives it tons of
lift, stability and dynamic performance at lower speeds. At
higher speeds, the Phantasm 633 will track and retain its
stability which aids in setting up for jibes and tacks, but
also will prevent over-foiling. The larger surface area of the
PFI 633 front wing, combined with the efficiency of carbon
means it has a huge wind and speed range. The wing’s
unique inverted gull shape provides a crazy level of dynamic
carving control and a self-centering flight you have to feel
to believe. The Phantasm 633 package was built to provide
you with maximum free ride performance. Equal parts:
Speed, Stability, Lift, and Maneuverability, makes it the most
predictable and user friendly foil on the market.

SKU: 121237003
SKU: 121237006
SKU: 121237007
SKU: 121237005
SKU: 121237008
*SKU: 121237008
PFI 633
PFI 633 FRONT WING
NEOPRENE COVER
PHANTASM 400 STABILIZER
NEOPRENE COVER
PHANTASM 633 FOIL
PACKAGE CARRING CASE
FRONT WING
*COMPLETE HARDWARE
PACKAGE
T30 TORX WRENCH
710 FUSELAGE
SKU: 121237002
MAST 92 cm
SKU: 121237001
M6 X 37mm
FLATHEAD SCREW
M6 X 40mm
FLATHEAD SCREW
M6 X 30mm
FLATHEAD
SCREW
M6 X 25mm
SOCKET HEAD
SCREWS
M6 X 18mm
FLATHEAD
SCREWS
PS 400
STABILIZER
BARREL NUT M6
THREAD
*SKU: 121237008
*SKU: 121237008 *SKU: 121237008
*SKU: 121237008 *SKU: 121237008
SKU: 121237004
*SKU: 121237008
COMPLETE FOIL SETUP

FOIL ASSEMBLY
1. Coat all bolt hardware with Lanolin oil or a marine-grade
grease and wrap with Teflon tape before assembling your foil.
(see maintenance section for details)
2. Connect the front wing to the fuselage using the M6x37mm
flathead screw for the forward hole, the M6x40mm screw for
the center hole and the M6x30mm screw for the third hole.
3. Connect the rear wing to the fuselage using the two M6 x
18mm flathead screws.
4. Position the mast so that it is vertical. Be careful of knocking
the mast over, attaching the pedestal to an upside down board
can help with stability.
5. Insert the mast foot into the fuselage slot so that the 3 holes
align and fasten with the three M6x25mm socket head screws.
It may be necessary to use a rubber mallet to fit the fuselage
on and off the mast for the first few sessions.
Coat all hardware
5

1. To attach your fully assembled foil to your board, place your
board upside down and slide the four female pieces of your
mounting hardware into slots in the tracks of your board,
two on each side.
Note: Mounting hardware comes packaged with Slingshot
foil boards, and is not included in the foil package.
2. Carefully place your foil over the mounting track so
the front hole pattern in the pedestal line up with the
mounting hardware. Be extra cautious with your foil in this
position; components are fragile and can damage easily if
it gets knocked down or blown over.
3. Bolt your foil to your board, tightening each bolt bit by bit
until all four are equally tight.
ATTACHING FOIL TO BOARD
s. Thi
will be a little tricky with the bolts covered in a layer of
Lanolin oil/ or marine-grade grease, but it acts as a second
SKU: 19236110
SKU: 120711033
PFI 633
NEOPRENE COVER
NEOPRENE COVER
(FRONT WING)
(FRONT WING)
(REAR WING)
GREASE KIT
T30 TORX WRENCH
M6 X 40mm M6 X 25mm
SOCKETHEAD M6 X 16mm
PS 400
STABILIZER
0012 Ti
BARRELNUT M6
THREAD
COMPLETE FOIL SETUP
SKU: 120711033
SKU: 120711033
SKU: 120711033
SKU: 120711033
710 FUSELAGE
SKU: 19711015
MAST 92 cm
SKU: 18711010
SKU: 18711010
PANTASM
KITE 633
PHANTASM KITE 633 PACKAGE
After two years of meticulous and extensive research and
development, we are proud to introduce the ALL NEW
Phantasm 633. The Phantasm 633 is a high-performance
carbon freeride foil with tons of versatility in a lightweight
premium carbon construction. The Phantasm 633 is made
from super light, stiff and effcient high-modulus carbon,
but with a larger, lower aspect front wing that gives it tons
of lift, stability and dynamic performance at lower speeds.
At higher speeds, the Phantasm 633 will track and retain
its stability which aids in setting up for jibes and tacks, but
also will prevent over-foiling. The larger surface area of the
PFI 633 front wing, combined with the effciency of carbon
means it has a huge wind and speed range. The wing’s
unique inverted gull shape provides a crazy level of dynamic
carving control and a self-centering fight you have to feel
to believe. The Phantasm 633 package was built to provide
you with maximum free ride performance. With equal parts:
Speed, Stability, Lift, and Maneuverability, this is the most
predictable and user friendly foil on the market.
WRAPWITH TEFLON TAPE:
Wrap all bolt hardware in athin layer of Tefon Tape
layer of protection to prevent your bolts from corroding
and fusing with other components of your foil. Wrap
the tape tight so it feeds through the threads of the foil
properly without peeling off.
and fusing together. Don’t forget the inside of your front
wing. A cotton swab works well for this. Lanolin, or wool’s
wax, is a natural oil that acts as a lubricant and water
repellent. If you have an allergy to wool, be sure to take
precautions or use a different oil.
WWW.SLINGSHOTSPORTS.COM
CONTACT:
[email protected]
RIDER SERVICE IN THE US:
877.775.4832
INTERNATIONAL PHONE:
509.427.4950
SHIPPING ADDRESS:
390 EVERGREEN DRIVE, SUITE NORTH F
NORTH BONNEVILLE, WA USA 98639

Foiling comes with a unique set of challenges, risks and
dangers. Know your limits, know your gear, know the
conditions and use extra caution to keep yourselves
and others safe in the water. Here are a few basic safety
precautions we recommend taking.
1. The use of a helmet, wetsuit, neoprene booties, and
impact vest are highly recommended, especially when
learning, to help protect yourself from impacts with
your board and foil.
2. Check all foil screws and components before every
session to ensure all connections are tight, and
components are in proper working order.
3. Use extreme caution when foiling near other people or
objects. Give yourself and others a wide berth.
4. Do not foil in shallow water.
5. Pay extra attention to wind and water conditions; always
air on the side of caution.
6. Be aware that your foil will carry speed and drift on its
own faster and farther than a regular board.
SAFETY MAINTENANCE
It is imperative to clean and lubricate your foil regularly,
especially after use in salt water. This is true for all of your
gear, but especially for your foil. Following these simple
steps on a regular basis will minimize corrosion and
prevent the components of your foil from fusing together.
1. Coat all bolt hardware with Lanolin oil or a marine-
grade grease and wrap with Teflon tape before
assembling your foil.
2. Rinse your foil well after EVERY exposure to
salt water.
3. Regularly disassemble, clean and inspect
all components.
4. Regularly lubricate foil components and hardware
at all connection points. Use a general marine-grade
grease or Lanolin oil. Lubricate where components
come together to help prevent wear and corrosion.
5. Ensure all hardware is screwed firmly in place before
each use.
6. Be careful when handling your foil and use your
protective neoprene covers whenever possible.

WRAP WITH TEFLON TAPE:
Wrap all bolt hardware in a thin layer of Teflon Tape. This
will be a little tricky with the bolts covered in a layer of
Lanolin oil/ or marine-grade grease, but it acts as a second
layer of protection to prevent your bolts from corroding
and fusing with other components of your foil. Wrap
the tape tight so it feeds through the threads of the foil
properly without peeling off.
LUBRICATE HARDWARE:
In a clean, sand-free area, carefully coat all bolt hardware,
bolt holes and ALL connection points with a layer of
Lanolin oil or marine-grade grease. Coat anywhere that
parts touch each other to prevent them from corroding
and fusing together. Don’t forget the inside of your
fuselage to mast slot. A cotton swab works well for
this. Lanolin, or wool’s wax, is a natural oil that acts as a
lubricant and water repellent. If you have an allergy to
wool, be sure to take precautions or use a different oil.
