CAUTION! Wear appropriate PPE when working with chemicals. Backow prevenon required.
!
Venturi Sanitize Foam
Quick Start Guide
M2444 - SLX-MS2-VS-VF Quick Start Guide
Last Updated: 01/20/2023
A. Take hold of spray wand for either system
B. Open discharge ball valve
C. Open water supply valve - unit will spray
D. Verify water pressure is at least 35 PSI
E. [Foamers] Open air supply valve - unit will foam
F. [Foamers] Adjust air pressure to alter foam quality
G. Foam equipment, from boom to top, and rinse
before it dries
H. Sanize from top to boom
I. When complete, turn o supply valves
J. Store hose depressurized, with discharge valve
open, and coiled properly to prevent kinks
3Operaon
WATER SUPPLY (35 - 125psi)
3/4" NPT CONNECTION
AIR SUPPLY
AIR PRESSURE GAUGE
AIR REGULATOR
AIR SUPPLY BALL VALVE
FOAMER SUPPLY BALL VALVE
SANITIZER SUPPLY BALL VALVE FOAMER WATER PRESSURE GAUGE
SANITIZER WATER PRESSURE GAUGE
DOOR LOCK
SANITIZER CHEMICAL INLET
SANITIZER SOLUTION LINE WITH
STRAINER & CERAMIC WEIGHT
FOAMER SOLUTION LINE WITH
STRAINER & CERAMIC WEIGHT
FOAMER
SANITIZER
FOAMER DISCHARGE HOSE (BLUE)
SANITIZER DISCHARGE HOSE (RED)
FOAMER DISCHARGE BALL VALVE
SANITIZER DISCHARGE BALL VALVE
FOAMER CHEMICAL INLET
Example Installaon
A. Select a metering p for desired diluon rao
B. Install the metering p by screwing it onto the hose
barb for each chemical inlet
C. Install chemical sucon lines to hose barbs
D. Connect sucon lines to chemical soluons
2Diluon
Metering Tip Calculator
Mobile App:
A. Mount SLX enclosure
to wall
B. Flush supply lines
C. Install backow
prevenon per local
guidelines
D. Connect supply lines:
• Compressed air
(1/4” FNPT)
• Water (3/4” FNPT)
E. Connect discharge
hoses
F. Place chemical
containers below unit
1Install and
Connect

CAUTION! Wear appropriate PPE when working with chemicals. Backow prevenon required.
!
Venturi Sanitize Foam
Quick Start Guide
M2444 - SLX-MS2-VS-VF Quick Start Guide
Last Updated: 01/20/2023
Purchase Replacement Parts:
View User Manual for
More Details:
Mul Staon
Le Staon Right Staon
(1)
Insert
(2)
Wand Assembly (3)
Insert
(4)
Barb
(5)
Hose
(6)
Wand Assembly
Poly Stainless Poly Stainless
SLX-MS2-VS54-VF14 M2331 M2336 M2337 M2325 M2425 M2273 M2340 M2341
SLX-MS2-VS107-VF14 M2332 M2340 M2341 M2325 M2425 M2273 M2340 M2341
SLX-MS2-VS107-VF42 M2332 M2340 M2341 M2330 M2426 M2277 M2342 M2343
P2466
P2484
P2292
P2464
P2455
P2467
M2239
M2440
(x2)
M2419
M2427
(x2)
(22 PACK)
Poly: M2252
Stainless: M2219
(x2)
Poly: M2421
Stainless: M2420
Slotted Thumb: M2259
Socket Head: M2435
(x3)
M2258 (x2)
(Poly Bodied
Units Only)
2
6
5
4
3
M2430
WARNING:
A backflow preventer is required and must be
supplied by the end user. Follow all local codes.
M2244
M2442
P2450
(x2)
(x2)
(x2)
(x3)
(x2)
(x3)
M2224
Poly: M2256
Stainless: M2223
P2269
M2418
1
P2456
(x2)
M2425
M2274
Unit Part No.
Left Station Right Station
1 - Insert
2 - Wand Assembly
3 - Insert 4 - Barb 5 - Hose
6 - Wand Assembly
Poly Stainless Poly Stainless
SLX-MS2-VS54_-VF14_ M2331 M2336 M2337 M2325 M2425 M2273 M2340 M2341
SLX-MS2-VS107_-VF14_ M2332 M2340 M2341 M2325 M2425 M2273 M2340 M2341
SLX-MS2-VS107_-VF42_ M2332 M2340 M2341 M2330 M2426 M2277 M2342 M2343
M2427
SHEET 3 OF 3
DATE CREATED:
1/21/2022
DRAWN BY:
A. ZIEGER
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:1
0.017
TITLE: SLX METERING TIP FULL KIT REV101
Material <not specified>
FINISH
MATERIAL
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
1/16"
ANGULAR: MACH
.5 BEND 2
TWO PLACE DECIMAL .015"
THREE PLACE DECIMAL
.005"
PROPRIETARY AND CONFIDENTIAL!
THE INFORMATION CONTAINED
IN THIS DRAWING IS THE SOLE
PROPERTY OF CLEAN-LOGIX.
ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF
CLEAN-LOGIX IS PROHIBITED.
5
4
3
2
1
ITEM NUMBER:
M2427
WEIGHT (LB.)
NOTE: DEBURR AND BREAK ALL
SHARP EDGES!
LAST SAVED:
2/17/2022
