Smart Cabling & Transmission HW02 User manual

V1.0
HDMI Extender Series
User Manual
Model : HW02
Wall Plate HDMI & IR Repeater CAT5e Extender

1
User Manual
HW02
Introduction
HW02 is an HDMI wall plate (UK Standard) extender that can use two cost-effective Ethernet cables to
send HDMI and IR signals, with a resolution of 1080p@60Hz and a transmission distance up to 60M.
Besides, the IR transmission allows you to conveniently control the remote HDMI source device, such as
Blu-ray player.
Features
Resolution up to 1080p@60Hz.
Signal extension up to 60M over two CAT5e (or greater) cables.
UK standard (86 x 86mm) housing design.
Power input at either the terminal on the PCB or the external DC jack.
Supports auto detection for different distance.
Supports DDC, EDID, CEC, Hot Plug Detection.
Managed via IR remote.
Installation View
Resolution
Transmission Range (Max.)
480i / 576i / 480p / 576p
60M
720p / 1080i
CAT5e:50M CAT6:60M
1080p
CAT5e:30M, CAT6:40M

2
User Manual
HW02
Panel View
HW02T HW02R
Cable
Video Link cable using hi quality CAT5E UTP or CAT6 UTP cable, CAT6 cable enhances transmission range
and signal stability.
Data Link cable using CAT5E UTP/STP cable,
It is not hi speed signal transmission, so using regular CAT5E UTP cable will be ok.
RJ45 pin Define
Video Link (TIA/EIA-568-B)
1. Orange-white TMDS Data2 +
2. Orange TMDS Data2 -
3. Green-white TMDS Clock +
4. Blue TMDS Data1 +
5. Blue-white TMDS Data1 -
6. Green TMDS Clock -
7. Brown-white TMDS Data0 +
8. Brown TMDS Data0 -
Data Link (TIA/EIA-568-B)
1. Orange-white CEC
2. Orange HPD
3. Green-white SCL
4. Blue HW01R POWER
5. Blue-white IR
6. Green GND
7. Brown-white SDA
8. Brown HW01T POWER

3
User Manual
HW02
LED Indication
HW02T Status
Blue normal.
Red abnormal ( HDMI equipment power off or cable not have properly connection)
Flash = IR emitting.
Off No Power (HDMI Source power off and no connect with HW01R)
HW02R Status
Blue normal.
Red abnormal ( HDMI equipment power off or cable not have properly connection)
Off = No power or power source is too low
Caution
1. The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, radio
equipment, high voltage.
2. HW01 Data Rate support up to 2.25Gbps, but not support 1080p Deep Color signal.
3. IR receiving angle is ±45° with maximum distance 5 meters.
IR emitting angle is ±30° with maximum distance 3 meters.

4
User Manual
HW02
Specification
ITEM NO.
HW02T
HW02R
Support
Compliance
HDMI 1.3a, HDCP 1.1
Max. Video Resolution
1080p
Video Bandwidth
2.25Gbps
Max. Transmission Distance
40M at 1080p
IR Support
38Khz
Ports & Interfaces
Video Input
1 x HDMI Type A
1 x RJ45
Video Output
1 x RJ45
1 x HDMI Type A
IR Receiver
1 x (3.5mm) Phone Jack
IR Emitter
1 x (3.5mm) Phone Jack
Power
Power Supply
DC 5V 1A
DC 5V 1A
Power Consumption
500mA
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
86 x 50 x 86mm
86 x 50 x 86mm
Weight
125g
130g
