SR4 Diagnostic Mode Fault Codes
What is Diagnostic Mode?
Diagnostic Mode is an environment that runs a set of tests on the SmartRecorder™ 4 (SR4) in
order to identify any faults that may be occurring. Diagnostic Mode utilizesthe SR4 Keypad and
Sensor Bar to specify those faults.
It takes approximately 4 minutes for the SR4 to run a self-diagnosticcheck and up to 12 minutes
to completely reboot the system. Please note that events will not be recorded while the system
is inDiagnostic Mode.
Diagnostic Mode should be ran after every installation or repair.
How to Initiate Diagnostic Mode?
With the Ignition ON and the vehicle safely parked – press the Panic button on the Keypad
(large green button) 5 times within 10 seconds.This will initiate DiagnosticMode. After15
seconds, the Keypad will display “TEST” which confirms Diagnostic Mode is in progress.
Diagnostic Mode will displayany appropriate fault codes on the keypad, along with their
corresponding LED marker code on the Sensor Bar.
Fault codes appearing on the keypad are cumulative (i.e. Sensor Bar not found (020000) + No
GPS Signal (000100) = (020100).
How to Exit Diagnostic Mode?
To exit DiagnosticMode, turn Ignition OFF and wait 15 seconds. The target icon
on the Sensor Bar should display solid green once the SmartRecorder is ready to record.
Code
Description
Target
Icon
Gear
Icon
Keypad
Code Action Sensor Bar Lights
Diagnostic Mode
has initiated
Blue
Blink
Blue
Blink

© 2017 SmartDrive Systems, Inc. All rights reserved. SmartDrive, the SmartDrive logo, and Measured Safety Program are registered trademarks of SmartDrive Systems, Inc. SmartDrive SmartIQ is a trademark of SmartDrive Systems,
Inc. All other marks are the property of their respective owners.
Diagnostic Mode
has completed
with no faults
Green
Solid
Green
Solid 000000 N/A
Cellular Modem
Fault Red Solid Red
Solid 400000 Replace
Controller
Extended Storage
Media Fault Red Solid Red
Solid 000400 Replace
Controller
Audio Fault Red Solid Red
Solid 000004 Replace
Controller
Bluetooth Fault Red Solid Red
Solid 000040 Replace
Controller
Analog Camera
Capture Circuit Red Solid Red
Solid 000002 Replace
Controller
Wi-Fi Modem
Fault Red Solid Red
Solid 000020 Replace
Controller
Sensor Bar fault Blue
Solid
Red
Solid 040000 Replace Sensor
Bar
External GPS Green
Solid
Red
Solid 000200 Replace GPS
Puck
Forward-Facing
Camera enabled
not working
Blue
solid
Blue
Blink 004000
Troubleshoot
camera
connectivity

© 2017 SmartDrive Systems, Inc. All rights reserved. SmartDrive, the SmartDrive logo, and Measured Safety Program are registered trademarks of SmartDrive Systems, Inc. SmartDrive SmartIQ is a trademark of SmartDrive Systems,
Inc. All other marks are the property of their respective owners.
Interior- Facing
Camera enabled
but not working
Blue
solid
Blue
Solid 002000
Troubleshoot
camera
connectivity
Analog camera
enabled and not
detected
Blue
Solid N/A 000001
Check analog
camera
connections
Wi-Fi Wireless
signal found, but
unable to connect
to SmartDrive
Green
Blink
Red
Blink 000010
Verify in
coverage and
proper Wi-Fi
setup
Cellular
Wireless Signal
not found
Green
Solid
Red
Blink 200000 Verify in
coverage
No GPS Signal Blue
Solid
Red
Blink 000100
Verify vehicle is
out doors with
good line of
sight to the sky
Sensor Bar not
found N/A N/A 020000
Troubleshoot
Sensor Bar
connectivity, if
connected
replace Sensor
bar
Ignition currently
off
Green
Blink
Green
Blink 010000
Verify ignition is
turned on. If it is
verify proper
wiring
