smartmicro UMRR-0C Type 42 User manual

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 1 of 19 INovember 22, 2017
Project Documentation | UMRR-0C Type 42 User Manual
Project Number:
...
SMS Project Number:
Project Title:
UMRR-0C Type 42 User Manual
Keyword(s):
UMRR-0C Type 42 radar sensor
Date:
November 22, 2017
Document:
UMRR-0C Type 42 User Manual USA-Canada_100MHz
Version:
2

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 2 of 19 INovember 22, 2017
1Contents
1Contents.................................................................................................................... 2
2Abbreviations............................................................................................................. 3
3Introduction............................................................................................................... 4
4General description .................................................................................................... 5
4.1 Sensor description................................................................................................ 5
4.2 Transmit Signal.................................................................................................... 5
4.3 General Performance Data.................................................................................... 6
5Hardware .................................................................................................................. 7
5.1 UMRR sensor ....................................................................................................... 7
5.2 Sensor Dimensions............................................................................................... 9
6Cables and connectors.............................................................................................. 10
6.1 Sensor connector ............................................................................................... 10
7Data interfaces ........................................................................................................ 12
7.1 CAN data interface ............................................................................................. 12
7.2 CAN-Settings ..................................................................................................... 12
7.3 RS485 data interface.......................................................................................... 13
8Designated use ........................................................................................................ 16
9Compliance.............................................................................................................. 17
9.1 Declaration of Conformity for USA....................................................................... 17
9.1.1 FCC Label.................................................................................................... 17
9.2 Declaration of Conformity for CANADA ................................................................ 18
9.2.1 Declaration of Conformity in English.............................................................. 18
9.2.2 Déclaration de conformité en francais ........................................................... 18
9.2.3 Industry Canada (IC) Label........................................................................... 18
9.3 Declaration of Conformity for EUROPE................................................................. 19
9.4 Safety Instruction .............................................................................................. 19

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 3 of 19 INovember 22, 2017
2Abbreviations
ADC Analog-to-digital converter
CAN Controller area network
DAC Digital-to-analog converter
DSP Digital signal processing; digital signal processor
EEPROM Electrically erasable programmable read-only memory
FMCW Frequency modulated continuous wave
MMIC Monolithic microwave integrated circuit
RAM Random access memory
RS485 Physical communication layer standard EIA RS-485
SPI Serial peripheral interface
UMRR Universal medium-range radar

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 4 of 19 INovember 22, 2017
3Introduction
This document is a short documentation of the general purpose universal medium range radar
(UMRR) UMRR-0C Type 42 radar sensor with type 42 antenna.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 5 of 19 INovember 22, 2017
4General description
4.1 Sensor description
The main task of the UMRR is the detection of any reflectors in the field of view, to measure
the distance, the relative speed and the angle to the shortest reflector (and to other reflectors),
to detect motion and to track (filter) the results over time.
For this general purpose measurement application, range and relative radial speed and
the angle value of each reflector inside the antenna beam are measured and the results are
reported via the communication links cycle by cycle.
4.2 Transmit Signal
The UMRR transmit frequency is located in the 24 GHz ISM band (24000 MHz to 24250 MHz),
the used bandwidth is smaller than 100 MHz. The maximum transmit power is 20 dBm.
Antenna type 42 is used, consisting of one transmit and eight receive antennas, both linear
polarized. The 2 way 3 dB cut-off angle in az. +-25deg. and in el. +-5deg.
The antenna has two main lobes. The greater man lobe is at +17°, counting clockwise, the
second at -20°.
The device uses different FMCW transmit signal waveforms for distance and speed
measurement.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 6 of 19 INovember 22, 2017
4.3 General Performance Data
After power up or reset, the sensor readings are within specified performance within <30
seconds. In Table 1: General performance data are given.
Table 1: General performance data
Environmental
Ambient Temperature
-40 ... +74
degree C
Shock
100
grms
Vibration
14
grms
IP
67
Pressure / Transport altitude
0…10.000
m
Mechanical
Weight
1340
g
Dimensions
See 5.2
Housing Identification
07
Antenna Identification
2A
DSP Board Identification
0C
General
Power Supply
13 ... 32 I
11.8
V DC
W
Frequency Band
24.075…24.175
GHz
Bandwidth
< 100
MHz
Max. Transmit Power (EIRP)
20.0
dBm
Interfaces
CAN V2.0b (passive) II
RS485 half or full duplex
10/100 Ethernet
Connector
12 Pin plug Hirose LF10WBRB-
12PD
CAN, Power,
RS485, Eth.
Imeasured at connector
II Also available: Relay contacts, see interfaces. It is recommended to use an external surge protection for
power, CAN, RS485, Ethernet and other interface ports.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 7 of 19 INovember 22, 2017
5Hardware
5.1 UMRR sensor
An example picture of a UMRR (universal medium-range radar) sensor (housing type 070707)
is shown in the figures below.
Figure 1: UMRR sensor, housing type 070707, front

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 8 of 19 INovember 22, 2017
Figure 2: UMRR sensor housing 070707 rear

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 9 of 19 INovember 22, 2017
5.2 Sensor Dimensions
All values given in mm.
Figure 3: Housing 070707 Dimensions

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 10 of 19 INovember 22, 2017
6Cables and connectors
6.1 Sensor connector
The used sensor connector is a 12-pin male (plug) circular bayonet type connector (water
proof IP67, series LF10WBRB-12PD, manufacturer Hirose, Japan). A female counterpart
(socket)e.g. LF10WBP-12S has to be used to connect to the sensor. The pin numbering of the
socket is shown in Figure 4 together with the pin description is given in Table 2: Sensor
Connector pin out Model UMRR-0C
Figure 4: Sensor connector pin out Model UMRR-0C
Table 2: Sensor Connector pin out Model UMRR-0C
Pin
Signal name
Wire Pair
Function
1
Eth_Tx1_P
1
Ethernet –RJ45 Pin 1
2
Eth_Tx1_N
Ethernet –RJ45 Pin 2
3
RS485_IN_N
2
RS485 Input
4
RS485_IN_P
5
RS485_OUT_N
3
RS485 Output
6
RS485_OUT_P
7
GND
4
Ground
8
Vcc
13 .. 32 V DC Supply
9
Eth_Tx2_N
5
Ethernet –RJ45 Pin 6
10
Eth_Tx2_P
Ethernet –RJ45 Pin 3
11
CAN Hi
6
CAN Interface
12
CAN Lo

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 11 of 19 INovember 22, 2017
Please note that in the standard configuration the sensor has no 120Ohms resistor on board
(CAN bus termination between CAN_Lo and CAN_Hi and RS485 IN / OUT). The resistors are
nevertheless required at either end of a CAN / RS485 bus and is in most cases integrated in
the cable delivered along with the sensor (if cable is manufactured by Smartmicro).
For the RS485 data interface there is a 120Ohms resistor on board of the sensor.
A number of cable sets for initial operation and test purposes are offered by Smartmicro, to
deliver a fast set-up of a sensor system. Among those preconfigured ready-to-run cables as
well as cable stumps (pig tail cables or various lengths) which carry the connector on one side
and open wires on the other.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 12 of 19 INovember 22, 2017
7Data interfaces
7.1 CAN data interface
This specification gives a detailed description of the CAN data communication used in the UMRR
based systems on the sensor CAN. The UMRR is compliant with CAN 2.0B standard.
CAN is a very robust full duplex bidirectional interface.
7.2 CAN-Settings
Baud Rate: 500kBit/s or lower
Tseg1: 8
Tseg2: 7
Tsjw: 1 (SJW: synchronization jump width)
Above values for CAN bit timing are illustrated in Figure 5 used in the UMRR radar sensor
(note: the CAN module is integrated in the DSP). For comparison purposes, in Figure 6 the
CAN bit timing as defined by the CAN protocol is shown.
The CAN bit timing parts as defined by the CAN protocol (Figure 6) can be described as follows:
•Sync: This part of bit time is used to synchronize the various nodes on the bus. An
edge is expected to lie within this segment. For the UMRR sensor, this segment is
always 1 TIME QUANTUM (TQ).
•Prop: This part of the bit time is used to compensate for the physical delay times
within the network. It is twice the sum of the signal’s propagation time on the bus
line, the input comparator delay, and the output driver delay. For the UMRR sensor,
this segment is programmable from 1 to 8 TIME QUANTA (TQ.
•Phase 1: This phase is used to compensate for positive edge phase error. For the
UMRR sensor, this segment is programmable from 1 to 8 TIME QUANTA (TQ) and
can be lengthened by resynchronization.
•Phase 2: This phase is used to compensate for negative edge phase error. For the
UMRR sensor, this segment is programmable from 2 to 8 TIME QUANTA (TQ) and
can be shortened by resynchronization.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 13 of 19 INovember 22, 2017
Figure 5: CAN bit timing for UMRR sensor
Figure 6: CAN bit timing as defined by the CAN protocol
7.3 RS485 data interface
The RS485 interface from the UMRR sensor has a predefined speed of 230400 baud/s.
Typical other data rates are between 921.6kBit/s and 56.7kBit/s.
The RS485 message payload is identical to the CAN format. The data messages will be sent
in several packets of one byte.
Every cycle begins with a start sequence and ends with a calculated checksum and an end
sequence. The length of the data payload depends on the number of targets and tracked
objects.
Every cycle has one start sequence one end sequence and one checksum.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 14 of 19 INovember 22, 2017
Table 3: RS485 message structure
Byte\Bit
7
6
5
4
3
2
1
0
0
Start sequence (4 x UINT8)
0xCA
1
0xCB
2
0xCC
3
0xCD
x
Data payload (n x UINT8)
x
x
x
x
x
x
x
0
XOR Checksum (UINT8)
1
End sequence (4 x UINT8)
0xEA
2
0xEB
3
0xEC
4
0xED
Every data message consists of its own message ID, the number of used data bytes and the
data bytes itself.
The checksum is calculated on all data except the start sequence and the end sequence. The
Checksum is a simple XOR Assignment of all n data bytes.
Byte0 XOR Byte1 XOR Byte2 ... XOR Byte (n-1)

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 15 of 19 INovember 22, 2017
Table 4: Structure of a RS485 data payload block
Byte\Bit
7
6
5
4
3
2
1
0
0
CAN message ID (UINT16)
High
1
Low
2
CAN message length (UINT8)
3
CAN data payload (length x UINT8)
4
5
6
7
8
9
10
The sensor receives only one message per cycle. It is important to wait for the end sequence
to send an additional command.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 16 of 19 INovember 22, 2017
8Designated use
The UMRR general purpose medium range radar is suitable for any application where the
distance to and relative radial speed of large objects has to be measured.
Typical applications are:
Robotics: measure shortest distance to obstacle.
Security: detect motions and measure distance to moving object.
Traffic management: detect moving objects, count those, measure speed and measure
distance to moving object.
Cranes: measure distance to ground.
Aircraft: measure distance to ground.
The detection range depends on object size. Very large reflectors can be detected at a range
of more than 500 m.

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 17 of 19 INovember 22, 2017
9Compliance
9.1 Declaration of Conformity for USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Usually this is followed by the following FCC caution:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may case harmful interferences to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more following
measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
-Consult the dealer or an experienced radio/TV technician for help.
9.1.1 FCC Label
Figure 7: FCC ID

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 18 of 19 INovember 22, 2017
9.2 Declaration of Conformity for CANADA
9.2.1 Declaration of Conformity in English
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with the
minimum distance 20cm between the radiator & your body.
9.2.2 Déclaration de conformité en francais
Le present appareil est conforme aux CNR d’Industrie Canada applicables aus appareils radio
exempts de licence. Léxploitation est autorisée aux deux conditions suivantes: (1) l’appareil
ne doit pas produire de brouillage, et (2) l’utilisaeur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
DÉCLARATION D’EXPOSITION AUX RADIATIONS
Cet equipement est conforme aux limites d’exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cetéquipement doit être installé et utilisé avec un minimum de
20cm de distance entre la source de rayonnement et votre corps.
9.2.3 Industry Canada (IC) Label
Figure 8: Label including IC, HVIN, PMN, FVIN (Sample)

CONFIDENTIAL AND PROPRIETARY
The Information contained in this document shall remain the sole exclusive property of s.m.s, smart microwave sensors GmbH and shall not
be disclosed by the recipient to third parties without prior consent of s.m.s, smart microwave sensors GmbH in writing.
UMRR-0C Type 42 User Manual USA-Canada_100MHz.docx Version 2 IPage 19 of 19 INovember 22, 2017
9.3 Declaration of Conformity for EUROPE
The UMRR-0C Type 42 has been marked with the CE mark. This mark indicates the
compliance with the Directive 2014/53/EU. A full copy of the Declaration of Conformity can
be obtained from s.m.s, smart microwave sensors GmbH, 38108 Braunschweig, Germany or
via E-Mail. Please contact us at inf[email protected].
9.4 Safety Instruction
Note:
Parts of the UMRR-0C device may be hot. To ensure protection against accidental contact
and fire protection, operate this device only with observe safety instructions according
EN 60 950-1, corresponding UL Standard or national safety regulation.
