Smart+ Products SPP-PP1800-6WCH User manual

1
INFRARED ZONE HEATING SYSTEM
OWNER’S MANUAL
Model No. SPP-PP1800-6WCH
WARNING: READ THIS ENTIRE OWNER’S MANUAL CAREFULLY BEFORE USE.

2
Thank you for choosing a SMART+ PRODUCTS Infrared Zone Heating System. This owner’s
manual will provide you with valuable information necessary for the proper care and maintenance
of your new product. Please take a few moments to thoroughly read the instructions and
familiarize yourself with all the operational aspects of your new heater.
PLEASE SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS

3
READ AND UNDERSTAND ALL INSTRUCTIONS, SAFETY WARNINGS,
AND FAQ’s BEFORE USING THE HEATER
WARNING!
! POTENTIAL FOR ELECTRICAL HAZARD IF NOT ADHERED TO!
When using electrical appliances, basic precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons, including the following:
1. This heater must be plugged into a 120V, 15 amp (or more) circuit of its own. Nothing
else can be plugged into the same circuit. If unsure if your home meets this
specification, consult a certified electrician prior to use. Risk of fire, overheat,
malfunction, property damage, injury, or even death may result if not adhered
to!
2. Connect to a properly grounded, 3-prong outlet only. Do not connect the heater to
extension cords, surge protectors, timers, direct breakers, or an outlet with other
appliances connected to the same outlet. Risk of fire, overheat, malfunction,
property damage, injury, or even death may result if not adhered to!
3. This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. Use handles (certain models) or wheels to move this heater.
4. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and
curtains at least 3 feet (0.9m) from the front of the heater and keep them away from
the sides and rear of the heater.
5. Extreme caution is necessary when any heater is used by or near children, invalids,
pets, or when the heater is left operating unattended.
6. Always unplug the heater when not in use.
7. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped, or damaged in any manner. Contact the
manufacturer for resolution options.
8. Do not use outdoors. Exposure to outdoor elements such as rain, snow, sun, wind or
extreme temperatures may cause the heater to become a safety hazard.
9. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations, nor any locations that use GFCI outlets.

4
10.Never place heater where it may fall into a bathtub or other water receptacles.
11.Do not run cord under carpet. Do not cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.
12.The heater must be plugged into a wall outlet that is a DEDICATED CIRCUIT, with a
minimum 15 amp rating on that individual circuit.
13.To disconnect the heater: FIRST, turn the power button to the “off” position, then
remove plug from the wall outlet.
14.Do not allow foreign objects to enter or block any ventilation or exhaust opening as
this may cause an electric shock or fire, or damage the heater.
15.Allow at least 3 feet of unobstructed space to the front and rear of the heater to allow
for maximum heat, air, and ventilation flow.
16.A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored, nor use flammable solvents
to clean the heater. Also, make sure to keep heater dry at all times.
17.Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
18.Do not use abrasive solvents to clean the heater as it may cause damage to the finish
or casing.
PLEASE REVIEW FREQUENTLY ASKED QUESTIONS ON THE NEXT
FEW PAGES PRIOR TO USING YOUR HEATER.

5
FREQUENTLY ASKED QUESTIONS (FAQ’S)
My heater emits a “strange” odor when I first open the box/when I turn the heater on for the first time.
Why?
These are both normal. This heater is treated with a special heat safe/resistant coating. This
odor will sometimes be present when the box is opened, and may be compared to a heaters
version of “new car smell.” Also, similar to all hearth appliances (woodstoves, etc.), the coating,
exposed to heat, will produce this particular odor during the first few hours of operation. This will
dissipate after the break-in period. If you are sensitive to odors, you may want to pre-burn the
unit in a garage with the door open until the initial odor dissipates.
If my heater runs on approximately 1500 watts, how many BTU’s is that? Is that a lot of heat?
At 1500 Watts, your heater will use approximately 5100 BTUs. 5100 BTUs, compared to your
home furnace, is a very small amount of heat. It may take several minutes, to several hours to heat
your area, depending on various factors (see Heater Placement).
Can my heater really operate on less money per day? What are my operating costs?
Most Definitely. If the heater is used as it is intended (as supplement/assist heat), it should cycle
on and off, allowing for it to heat a total of approximately 8 out of the 24 hours of the day. Using the
national average of approximately 10¢ per kWh (look at your bill for exact cost per kWh--will vary
per state), your average heating cost per hour (add a few cents just for having it plugged in) should
be less per day compared to your main furnace. The costs will increase if it is used as the single
source of heat, or if heat somehow escapes the room being heated, since the “on” cycle will run
longer.
The Formula: To determine the cost of this or ANY 1500 watt appliance, multiply 1.5 X your cost
per Kilowatt Hour. You can find the cost per KWH for your state at:
http://www.eia.doe.gov/fuelelectric.html
What is the life expectancy for the Heating Elements? Can the heating elements be replaced?
The life expectancy of the heating elements is typically 25,000 hours. Heating elements may be
replaced by obtaining parts from SMART+ PRODUCTS Products, although it is not recommended
(unless you are a certified heater technician or authorized directly by SMART+ PRODUCTS). All
parts may be purchased through SMART+ PRODUCTS PRODUCTS if your product is out of
warranty. Note: If you feel that the elements are definitely faulty right out of the box, contact
SMART+ PRODUCTS Products Tech Support first (for troubleshooting). Contact your place of
purchase second.
Once I plug the unit in and turn it on, how long will it take to heat my room?
Typically it takes about ½ hour to feel a temperature change. Please remember that with any type
of heating process, there are many variables: Location (in the home), floor plan and size of the
room, how well the room is insulated, how many doors/windows, how much bare concrete (acts as
a heat sink with any type of heating), the opening and closing of an exterior door, long hallways,
high ceilings, etc. Customers with smaller rooms experience quick heat changes. Others with
larger and open floor plans can expect up to 24 hours to heat up.
I don’t have a grounded outlet; can I use adapters, a 2-prong power strip, or remove the ground
prong from the cord?

6
Definitely NOT! If you don’t have a grounded outlet, contact a certified electrician for advice.
Removing or altering any part of the heater’s original design or intent (including the power cord) will
not only void the warranty, but will make you liable for any unexpected or hazardous results.
Why doesn’t the temperature on my heater match the temperature display on my wall, or external
thermostat?
This is completely normal. The temperature display on your heater may vary from the
temperature display on another thermostat (like the one mounted to your wall or a purchased
external thermostat). The temperature sensor on your heater reads the temperature in, and
around, the heater. The unit is near the cold floor (and heat rises), which in turn, will display a
cooler temperature than elevated or external thermostats. The best way to operate your heater is
just to set the unit on “High” and dial up to a temperature that feels comfortable to you. Then, leave
it at that temperature, regardless of the mismatch. The heater will cycle off when the set
temperature is met or exceeded slightly.
My home is not insulated very well, will this heater help me? Can I use the heater if I have vaulted or
cathedral ceilings? I live in a structure that is more than 1800 square feet. Will this heater help me? Can I
use the heater to heat multiple rooms at the same time? Will I be able to use the heater in a basement or
garage?
The answer to these is the same. Yes. You will be able to use it, but keep in mind that
rooms/structures with open floor plans, minimal insulation, adjacent rooms, or high ceilings will not
retain the heat as efficiently, and may not feel pronounced heat changes. Also, the heater will stay
on longer (delays the “off” cycle), and may increase your electric costs. Note that if you do use it in
a garage or basement, the moisture levels must be very low and they must have dedicated circuits
(15 amps minimum) with no GFCI outlets. If unsure what a GFCI outlet is, contact a certified
electrician.
Can I use more than one heater at a time? Can I use the heater and another appliance at the same time?
Yes. But make sure they are not plugged into the same circuit. Each heater (heaters are
considered appliances) requires its own minimum15 amp circuit (with no other items plugged
into that circuit). If unsure your circuit meets these requirements, verify with a certified electrician.
Risk of fire, damage to property, or injury may result if requirements are not met.
Why does my heater’s fan continue to run even after the set temperature is reached or the power is turned
off?
This is normal. The heater’s fan will continue to run, even after the heater automatically cycles
down. The fan continues to run so that every last bit of heat is blown out of the heat chamber, while
allowing the unit to continue filtering your air. Once the internal box/components cool completely,
the fan should then shut off on its own. In this case, allow up to ½ hour after the heat cycles off
(with power on). The fan will shut off faster when the power is turned off.
My fan seems to run at all times, even when the heat has cycled off. Why?
This is normal. Although the heat cycles off, the fan stays on until the chamber is cool. If the
temperature falls below the desired set temperature during the time the fan is cooling, the heating
elements will cycle back on. This will not allow for the fan to completely cool off the chamber, and
shut down. The fan seems to run continuously. It is a safety mechanism to prevent overheating. If
you run into this issue, the solution is to simply increase the set temperature at least 5 degrees
higher that the ambient temperature to make sure the temperature holds during the cool off period.

7
Why doesn’t the fan speed increase when I change the setting from LO to HI?
This is normal. The heater’s fan’s speed is not affected by the HI/LO settings. The fan is designed
to vent the heat at one soft, comfortable, and energy efficient speed. What is affected by the HI
setting is the heat output. In essence, in the HI mode, the heater produces “more” heat, rather than
“faster” heat.
My heater does not perform as well as another brand heater that I purchased. Why Not?
There are many brands of heaters on the market. Each brand is designed with different heat
specifications, fan speeds, colors, material types, displays, and electrical components. They are
manufactured this way for you, as the consumer to have choices, selection, and preferences. As
long as the unit functions as specifications indicate, comparison to other brands will ultimately
depend on individual consumer perception.
I purchased my heater so that it could cut my heating costs, but my electric bill has gone up. Why?
The compact SMART+ PRODUCTS heater can definitely save you on heating costs, when
compared to the existing central heating system in place in your home, and when used as directed.
Your heater is designed to give your main heat source a supplement “boost,” or allow for you to
have extra heat (in the form of soft infrared waves) in locations where you would otherwise be
short. It is meant to cycle on and off, and not specifically designed to be used as a single heat
source, especially in larger homes. If you intend on using it as a single heat source (which you
may), expect the heater to 1) take as much as 24 hours to heat the area, 2) stay on for longer
periods of time (without cycling off) due to heat loss, and 3) increased use time, and electric costs.
My heater’s display shows my ambient temperature to be in the 20’s, when I know it is warmer than that.
Why?
The heater’s display is defaulted to read the temperature as Fahrenheit. If your heater is definitely
heating, but shows it is in the 20’s, you probably have the setting to read your temperature in
Celsius, rather than Fahrenheit. See Users Guide to change.
I don’t see my heater’s bulbs/elements light up when the heat is on. Why is that?
If you feel heat coming from the heater, the elements are lit up. The reason you can not see
them, is because they not only have a protective shield around each one of them (for safety
reasons), they are also strategically placed within the heat chamber in the middle of the heater
(also for safety reasons). They are not visible when looking at/through the grill.

8
SPECIFICATIONS
Voltage Rating
120 V (60Hz)
Power Consumption
1000W/ 1500W
Unit Size
12 3/5 in. (W) x 20 in. (D) x 17 4/5 in. (H)
Unit Weight
40 lbs
SAFETY FEATURES
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal switch
will automatically shut the heater off. Once the heater is restored to the upright position, the heater will
reset. To continue operation, turn on the heater using the supplied remote control or the control panel
on the heater.
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the heaters internal components reach a
certain temperature that could cause overheat and possible fire, the heater will automatically shut off.
WARNING: It is normal for the power cord to feel warm to the touch; however, a loose fit between the
outlet and the plug may cause overheating of the plug. If this occurs, try inserting the plug into a different
outlet. Contact a qualified electrician to inspect the original outlet for damage.
IN THE BOX
INFRARED ZONE HEATING
SYSTEM INSTRUCTION BOOKLET
REMOTE CONTROL (2 AAA Batteries
Not Included)

9
PRODUCT DIAGRAM
1、Signal-receiving window: For receiving remote control signal.
2、Digital display：Indicate set room temperature or time value according to the timer.
3、Power indication Light：Indicate when the unit connects to power supply.
4、ON/OFF switch button: For power-on or off.
5、Energy-saving mode：The light ‘s on when energy-saving mode goes.
6、Mode button：For select running mode.
7、Heat-down mode indication light: The light ‘s on when heat-down mode goes.
8、Temp up button: For setting temp upward.
9、Heat-up mode indication light: The light ‘s on when heat-up mode goes.
10、Temp down button: For setting temp downward.
11、Timer indication light：The light’s on when timer functions.
12、Timer button：Used for setting the timer and adjust time value for the timer.
13、Fahrenheit indicating light
14、℃/℉Button : Button for alternating between Fahrenheit and Celsius.
15、Celsius indicating light
Remote Control
Air Outlet
Wooden Cabinet
Temp. Down
Temp. Up
Mode
Power
Timer
Temp. Down
Temp. Up
Mode
Power
Timer
Control Panel
Wheel
Air Intake
Cord Clamp
Control Panel (Ref Fig. 1 next page)

10
Timer
Temp./Time
High Low ECO Power
RCIN
ON/OFF
Timer Mode
¡æ
¨H 77
1
6
2
3
4
5
8
7
10
9
12
11
13
14
15
Fig.1
Mode button: Used for mode selection
ON/OFF button: Used for power-on or power-off
Temp up button: To make set temperature rise
Temp down button: To make set temperature decline
Timer button: Used for setting timer and adjust time value of timing
℃/℉button : Button for alternating between Fahrenheit and Celsius.
Remote Control

11
PREPARATION
Place the heater on a firm, level surface and plug into a grounded 120V 60Hz power outlet. Only operate
heater in upright position with caster wheels attached.
Insert 2 AAA batteries into the remote control before using (Batteries Not Included)

12
OPERATING INSTRUCTIONS
1. Power the Display On/Off and Select Desired Mode
Or
Turn the heater on by pressing the ON/OFF button on the
control panel or by pressing the Power button on the
supplied remote control.
Turn the heater off by pressing the ON/OFF button on the
control panel or by pressing the Power button on the
supplied remote control.
Note: Powering off the heater will stop the heating process
only. The fan will continue to blow for approximately 3
more minutes to allow for the interior components to cool.
The fan will then turn off automatically.
Or
Select a heat Mode.
Press the MODE button to toggle between the three heat
settings.
High Mode uses 1500W; Low Mode uses 1000W. ECO
mode is an Economic Energy Saving Function. When ECO
mode is chosen, the heater will set the temperature
automatically to 68℉(20℃) under this mode
2. Setting Desired Temperature
Or Or
Or
Adjust the desired temperature by pressing the Up/Down
arrows on the control panel or remote control.
Or
Desired temperature options vary from 59℉to 86℉, or
from 15℃to 30℃. Once you have chosen the desired
temperature, the heater will remain on until the room
temperature increases to that temperature on the digital
display. The heater will cycle on and off to maintain that
desired room temperature.
Or
Press ℃/℉button to change the display temperature
between Fahrenheit and Celsius.

13
The Fahrenheit indicator LED will light, when the
temperature is displayed in Fahrenheit.
The Celsius LED will light, when the temperature is
displayed in Celsius.
3. Setting the POWER-OFF TIMER Function
Note: The Power-Off-Timer Function will allow for the heater to power OFF after a certain set time, and can
only be set while the heater’s display is in the “On” position.
Or
Turn the heater to the “On” position. Press the Timer
button on the heater’s control panel or the remote.
The digital display changes from the “temperature” to the
“hours” option for the timer. Continue to press the timer
button to change the number of hours you would like the
heater to run before powering itself off. The hour options
for the timer are from 0 to 12 hrs. (in 1 hr increments).
The selected hour increments will flash for a few seconds,
then revert back to the set desired temperature. The Timer
indicator light will remain lit as long as the Timer is set.
The heater will power OFF when the internal heater clock
counts down the hour increments you set.
4. Setting the POWER-ON TIMER Function
Note: The Power-ON-Timer Function will allow for the heater to power ON after a certain set time, and can
only be set while the heater’s display is in the “Off” position.
Or
Turn the heater to the “OFF” position. Press the Timer
button on the heater’s control panel or the remote.
The digital display shows the “hours” option for the timer.
Continue to press the timer button to change the number of
hours you would like the heater’s internal clock to count
down before powering itself on. The hour options for the
timer are from 0 to 12 hrs. (in 1 hr increments).
The Timer indicator light will remain lit as long as the
Timer is set. The heater will power itself ON when the
internal heater clock counts down the hour increments you
set.

14
5. Setting Electro Lock
The Electro Lock can help avoid the heater from being accidentally engaged by children. The locking
mechanism can be set in both the ON and OFF modes.
And
Press Temp Up and Temp Down buttons at the same time
for 3 seconds. Locking is complete when you hear a beep.
When locked, the functions of the control panel and remote
will be locked for use.
And
When you need to unlock it, press Temp Up and Temp
Down buttons at the same time for 3 seconds. You will hear
a beep. The control panel and remote control will become
functional again.
MAINTENANCE
1. Unplug the unit and let it cool completely.
2. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You may use a
mild detergent if necessary. After cleaning, dry the unit with a soft cloth. CAUTION: DO NOT
let liquid enter the heater.
3. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to clean the
heater. This may cause damage or deterioration to the surface of the heater.
4. DO NOT immerse the heater in water.
5. Wait until the unit is completely dry before use.
6. Air filter needs cleaning after used 3 months. Please take down the filter as following steps. Flush
and clean the taken –down filter with water, then dry it out and re-assemble.

15
7. If won’t use the unit for a long time, please take batteries out of the remote control according to
following steps, then store remote in a safe place.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the original
packaging to repack the unit.
BASIC TROUBLESHOOTING
If the heater will not operate, please check the following before seeking repair advice:
1. Check if the power cord is plugged into an electrical outlet, if not, plug in.
2. Check if power to the main power switch (in the back) is working.
3. Check to see if the battery on the remote is placed correctly, undamaged, and if the insulating film
is pulled out.
NOTE: For the heater to function properly, the desired temperature on the heater must be set a few
The unit
PULL
Air filter
Air intake grille
PUSH
lid
Battery

16
degrees higher than the temperature in the room. If it seems to not be heating, increase the desired
temperature on the heater to engage the heat elements.
