SmartSense GPS Locator Operating instructions

How do I use my
What’s in my smart pack
Smartsense GPS locator
Battery recharge docking station
240v to 5v charger
USB cable
SIM card (internal) with phone number
Lanyard, key ring and pouch holder
Instructions
Smart
package inclusions
Charging the locator battery
Un-pack the docking station and USB cable. Plug the USB mini plug into the
docking station, plug the larger USB plug in to the 240v charger and plug the
charger into a power outlet.
The docking station will show a slight red glow to indicate that it is on.
Place the locator into the docking station making sure you seat it properly so that
it can’t move, if it moves around you need to push in down slightly. Once it is
seated the docking station will show a bright red glow to indicate it is charging.
When the locator shows a slight red glow again, the locator is fully charged usually
after three hours and can be removed from the docking station or left until required.
The green and blue lights on the locator will be on, indicating that the locator is
operating and will begin to send location positions to smart-tracking.com (Internet)
and mobile application
We have programed the locator to be in Smart Power Saving mode with 2 minute
location updates so the locator battery will last at least two days with re-charging
required on the second night
Turning on the locator
By placing the locator into the powered docking station, the locator will start up and
start to send position location messages to the Smart Online Tracking System
(Internet). When not in the docking station you can also press the on/off button on
the side for one second to turn it on. To turn the locator off, push the SOS and
side button together for one second. The locator can stay turned on at all times.
When the green locator light is flashing twice quickly every 3 seconds, you locator
is connected to the mobile network and to the Tracking System (Internet).
A single flashing green light indicates that the locator is only connected to the
mobile network for SOS SMS and calls. The blue locator light will flash
once quickly every 3 seconds when receiving GPS satellite positions. A slow
flashing blue light indicates no GPS connection, try outdoors or another position.
In the pre-set Smart Power Saving mode, when there is no movement, the GPS
will go to sleep to conserve battery life and the blue indicator will turn off. Every 10
minutes it will wake and send one message and then go back to sleep. If GPS can
not get a fix it will send the last known location after waking and no movement.
Once movement occurs the GPS will immediately awake, the blue light will come on
and a GPS fix position message will be sent to the Tracking System every two
minutes, or until it detects no movement after which it will go back to 10 minute
messages
When needing to locate a wearer, the time interval for location message delivery
can be increased from two minutes to every minute in the Tracking system
application (Internet) or by sending an SMS TI01M to the locator phone number. In
the mobile app, click on the ‘spanner’ icon to go to time interval settings. Move the
slide bar a little to change the interval setting.
NOTE: The battery will deplete quicker when time interval set to 1 minute so set
back to 2-5 minutes when less frequent location messages required
Locator'name:'
Locator'Phone'No:'
on/off & phone call button
Smartsense
GPS locator
SIM'card'recharge'Ac'No:'
SIM'card'recharge'Password:'

!!
* The fall sensor may not detect some falls, we do not promote this device as a ‘Fall Detector’
The SOS button should be used whenever possible in a fall or emergency event
SOS button
Sending an SOS from the locator
To activate an SOS alarm, push the SOS button for three seconds until you feel a vibration.
Immediately an SMS ‘Help’ text message will be sent to all authorised phone numbers. The
SMS text message contains a link to the Google maps application to show the latest locator
position. It will also dial each of the programed authorised phone numbers in succession
whether or not the calls are answered in person or by messagebank. You can then
commence a conversation. Up to five numbers can be programed.
The locator has a built in fall sensor that may detect a *fall. On detection of a *fall it may send
an SMS SOS FALL alarm and call the authorised programed phone numbers. When one
phone answers you can commence a conversation. The SOS button should be pushed any
time the wearer needs help especially in a fall.
Request the locator position by sending an
SMS text from your mobile phone
Creating a geo-fence zone
The Smart Online Tracking System (Internet) can be programed to
send SMS and email alerts when the Smartsense locator wearer
wanders out of or into an area that has been defined as a zone on
Google maps. Refer to Smartsence supplier for setup.
To fetch the latest location position from the locator, send loc from your
SMS texting application to the phone number of the locator. You will be
sent an SMS reply from the locator with a link to Google Maps
To get the latest location position by street address, send add
from your SMS texting application to the phone number of the
locator. You will be sent an SMS reply from the locator with the
address details
Any phone can call the locator and any phone can request an SMS location
message from the locator. Only alerts and alarms are sent to authorised
phones
The above pictures show the SMS text messages received on a phone (programed to receive alerts) The Google Map link
is shown in blue. By clicking on the blue link your phone should open the Google Map application and show the locator
position on the map as a red pointer. An alert will also appear on the Smart Online Tracking System (Internet) and can send
an audible alarm on the computer if turned on
Locator settings pre-set by us
Authorised phone numbers (at least one required) five slots available
Wearer’s name in SMS alerts and alarms
Locations sent to Tracking system every two minutes
Low battery warning - locator blue light will flash rapidly to indicate 2 or 3 hours battery left
Smart Power setting – GPS sleep no motion and wake every 10 minutes to send location
Geo-fence zones set to clients requirements in the Smart Online Tracking System
*Fall detection set to send SMS and call authorised phones FL2 or SMS only FL1
* The fall sensor may not detect some falls, we do not promote this device as a ‘Fall
Detector’. The SOS button should be used whenever possible in a fall or emergency
event
Phone'1:'
Phone'2:'
Phone'3:'
Phone'4:'
Phone'5:'
Authorised phone numbers
