SmartSense Temp/Humidity Installation and operation manual

THV001.0914
Meet the
SmartSense™
Temp/Humidity
Extreme temperatures and humidity
can cause serious damage to your
home and property. The
SmartSense Temperature/Humidity
sensor will send you instant alerts as
soon as they detect dangerous
temperatures or high
humidity levels.

V001.0914
How to Connect a
SmartSense
Temp/Humidity
You can connect devices at any time
by following these two steps:
Tap ‘+’ in the SmartThings
mobile app to add things.
Follow the on-screen prompts
to connect your device and
set up top alerts and/or
actions.
1
2
THV001.0914
www.SmartThings.com
REMOVE
TO PAIR

How to Reset and
Reconnect a
SmartSense
Temp/Humidity
To reset, press and hold the Connect
button while inserting the battery.
Release the button when the LED is
lit. The LED will blink blue while
attempting to connect. See How to
Connect for more.
Connect Button LED Light
Battery
www.SmartThings.com
+
THV001.0914

Replacing Battery (CR2)
Bottom
Top
CR2 Battery
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
ATTENTION. RISQUE D'EXPLOSION SI LA BATTERIE EST
REMPLACÉE PAR UN MODÈLE INCORRECT. JETEZ LES
BATTERIES USAGÉES SELON LES INSTRUCTIONS S’Y
RÉFÉRANT.
WARNING: No user-serviceable parts inside.
Refer all servicing to qualified service personnel.
ATTENTION: l’équipement SmartThings ne doit
être en aucun cas ouvert par l’utilisateur
luimême. Pour l’entretien et/ou la maintenance,
contacter le personnel qualifié.
www.SmartThings.com
THV001.0914

www.SmartThings.com
Example Mounting
Configuration for
SmartSense™
Temp/Humidity
THV001.0914

Safety Instructions
• Read, keep, and follow these instructions.
• Heed all warnings.
• Clean only with a dry cloth.
• Do not install near any heat sources such as
radiators, heat registers, stoves or other apparatus
(including amplifiers) that produce heat.
• Only use attachments and accessories specified by
the manufacturer.
• Read our Product Usage Guidelines at:
http://SmartThings.com/guidelines
Règles de sécurité:
• Lire, conserver et suivre ces instructions
• Respecter toutes les consignes de sécurité
• Nettoyer l'appareil uniquement avec un chiffon sec
• Ne pas installer a proximité d une source de chaleur
telle que radiateur, poêle ou autres appareils
(incluant les amplificateurs) qui produisent de la
chaleur
• Utiliser uniquement des accessoires recommandées
par le fabricant
www.SmartThings.com
THV001.0914

Certifications
SmartSense™ Temp/Humidity
Contains FCC ID: W7Z-ZICM357SP2
Conforms to FCC Part 15B
FCC Statement
Operation of this device is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
Information to the User
Changes or modifications not expressly approved by Physical Graph Corporation could void
your authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician
for help.
www.SmartThings.com
THV001.0914

One (1) Year Limited Warranty
Physical Graph Corporation (“SmartThings”) warrants this product (the “Product”) against
defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from
the date of purchase by the original purchaser (“Warranty Period”). If a defect arises and a
valid claim is received within the Warranty Period, then as your sole remedy (and SmartThings’
sole liability), SmartThings will at its option either 1) repair the defect at no charge, using new or
refurbished replacement parts, or 2) replace the Product with a new product that is functionally
equivalent to the original, in each case within 30 days following receipt of the returned Product.
A replacement product or part, assumes the remaining warranty of the original Product. When
a Product or part is exchanged, any replacement item becomes your property and the
replaced Product or part becomes SmartThings’ property.
Obtaining Service: To obtain warranty service, visit support.smartthings.com to speak with a
service agent or open a service request. Please be prepared to describe the Product that
needs service and the nature of the problem. A purchase receipt is required. The Product must
be insured, and shipped freight prepaid and securely packaged. You must contact support for
a Return Material Authorization Number (“RMA Number”) before shipping any Product, and
include the RMA Number, a copy of your purchase receipt and a description of the problem
you are experiencing with the Product. Any claim under this Limited Warranty must be
submitted to SmartThings before the end of the Warranty Period.
Exclusions: This warranty does not apply to: a) damage caused by failure to follow instructions
relating to the Product’s use or the installation of components; b) damage caused by accident,
abuse, misuse, transport, neglect, fire, floods, earthquake or other external causes; c) damage
caused by service performed by anyone who is not an authorized representative of
SmartThings; d) accessories used in conjunction with a covered Product; e) a Product or part
that has been modified to alter functionality or capability; f) items intended to be periodically
replaced by the purchaser during the normal life of the Product, including, without limitation,
batteries, bulbs or cables; g) a Product that is used commercially or for a commercial purpose,
in each case as determined by SmartThings.
EXCEPT FOR BODILY INJURY, SMARTTHINGS SHALL NOT BE LIABLE FOR (I) ANY LOST
PROFITS, COST OF PROCUREMENT OF SUBSTITUTE PRODUCTS, OR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR (II) ANY AMOUNTS IN EXCESS OF THE PURCHASE PRICE
FOR THE PRODUCT, IN EACH CASE WHETHER RESULTING FROM THE USE OF OR
INABILITY TO USE THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY, EVEN IF COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION AND
EXCLUSIONS MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, SMARTTHINGS DISCLAIMS ANY AND
ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. IF SMARTTHINGS CANNOT
LAWFULLY DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT
PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE
WARRANTY PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights and you may also have other rights, which vary
from state to state. To exercise your rights under this warranty, please follow the instructions
above under the heading “Obtaining Service”, or contact SmartThings at Physical Graph
Corporation, 1000 Potomac St NW #120, Washington,
DC 20007.
www.SmartThings.com
THV001.0914

1
2
Snap Lock
Mounting
Cleat
You can Mount the
SmartSense
Temp/Humidity using the
Optional Wall Bracket:
Affix wall bracket into desired
surface then slide sensor onto
wall plate mounting cleat.
Slide sensor down to engage
snap lock.
www.SmartThings.com
THV001.0914

Wall Bracket
Without Wall
Bracket
Template for Wall
Mounting:
1in
2.4in
6.09cm
Print without document scaling.
