SMC Networks SMCRPUPOE User manual

Power Unit SMCRPUPOE
44PPoorrttRReedduunnddaannttPPoowweerrUUnniitt
www.smc.com
Redundant power units provide an easy to
install and use method of giving you the peace
of mind required when managing safety tolerant
systems.
This Redundant Power Unit (SMCRPUPOE) can
supply 200W of primary power and up to 360W
for PoE devices in the event of AC loss or failure
of the internal power supply of the 1st attached
device to fail. It ships with four DC Backup
Power Cords included (IEC connectors). Thermal
overload protection prevents the RPU from
overheating if a thermal overload occurs. Over-
voltage protection shuts down an output channel
if the voltage exceeds a preset threshold where
as over-current protection shuts down the RPU
if the output load exceeds a preset threshold.
Short-circuit protection prevents the RPU from
being damaged from a short circuit on any out-
put channel. Four status indicators for Link,
Activity, Fan, Thermal, and Power are located on
the RPUs front panel. While the AC supply and
DC backup sockets are located on the RPUs rear
panel. The SMCRPUPOE can be mounted in a
standard 19-inch equipment rack(brackets
included) or on a flat surface.
FEATURES
OVERVIEW
Connects to up to four switches with cables included
Thermal overload protection
Supplies both the switch and PoE devices with power up to 560W.
Over-voltage protection for each output channel
Over-current protection
Short-circuit protection against output channels

TECHNICAL SPECIFICATIONS SMCRPUPOE
PORTS
4 RPU DC power outlets (IEC socket 216C743-07)
LEDS
Port: Link, Activity
System: Power, Fan, Thermal
WEIGHT
5Kg (11lbs)
DIMENSIONS
44.0 x 32.3 x 4.3 cm (17.34 x 12.6 x 1.69 in.)
TEMPERATURE
Operating: 0 to 45 °C (32 to 113°F)
Storage: -40 to 70 °C (-40 to 158 °F)
HUMIDITY
Operating: 5% to 95%
AC INPUT
100 to 240 V, 50 to 60 Hz
DC POWER CABLE CONNECTOR
18-pin P-Type connector
EIA RATINGS
10 A @ 125 VAC
10 A @ 250 VAC
DC Power Cable Connector
14-pin P-Type connector
POWER SUPPLY
Internal, auto-ranging transformer:
100 to 240 VAC, 50 to 60 Hz
Output 12 VDC, -50 VDC
POWER CONSUMPTION
570W (Maximum)
161 W (Maximum per port)
MAXIMUM CURRENT
7A @ 110 VAC
3A @ 220 VAC
OVERLOAD PROTECTION
Ports are shutdown when output exceeds
200 W @ 12 V or 360 W @ -50 V
POWER SUPPLY
+12 VDC
Initial accuracy: +/- 1%
Current: 2 A (minimum), 10 A (maximum)
Line regulation: +/- 1%
Load regulation: +/- 10%
Overshoot and undershoot: 5%
COMPLIANCES
CE Mark
EMISSIONS
AS/NZS 3548 (1995) Class B
EN 50081/2-1
EN 55022 (CISPR 22) Class B
EN 60555-2 Class B
EN 60555-3
EN 61000-3-2/3/4/6
FCC Class B
Industry Canada Class B
VCCI Class B
IMMUNITY
EN 55024
SAFETY
CSA/ C US (CSA22.2 No.60950-1 & UL60950-1)
CB: IE 60950-1
TÜV/GS (EN 60950-1)
IMMUNITY
EN 55024
Safety
CSA/ C US (CSA 60950-00 & UL60950)
CB: IEC 60950
EN 60950 (TÜV/GS)
