USER GUIDE
WiShare
Wireless TV Adapter
SMCWTVA100

No. 1, Creation Road III,
Hsinchu Science Park,
30077, Taiwan, R.O.C.
TEL: [phone]
Fax: [phone]
Wireless TV Adapter
User Guide
June 2014
E062014-AP-R03

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.
However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or
other rights of third parties which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications
at any time without notice.
Copyright © 2014 by
SMC Networks, Inc.
No. 1 Creation Road III,
Hsinchu Science Park,
30077, Taiwan, R.O.C.
All rights reserved
Trademar ks:
SMC is a registered trademark; and Barricade, EZ Switch, TigerStack, TigerSwitch, and TigerAccess
are trademarks of SMC Networks, Inc. Other product and company names are trademarks or
registered trademarks of their respective holders.

– 4 –
WARRANTY AND PRODUCT REGISTRATION
To register SMC products and to review the detailed warranty statement,
please refer to the Support Section of the SMC Website at http://
www.smc.com.

– 5 –
COMPLIANCES
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
◆Reorient or relocate the receiving antenna
◆Increase the separation between the equipment and receiver
◆Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
◆Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
N OTE : The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user’s authority to operate the equipment.
CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)
Declaration of Conformity (DoC) can be obtained from
www.smc.com-> support -> download -> declarations &
certifications

– 6 –
This information technology equipment complies with the requirements of
the Council Directive 89/336/EEC on the Approximation of the laws of the
Member States relating to Electromagnetic Compatibility and 73/23/EEC
for electrical equipment used within certain voltage limits and the
Amendment Directive 93/68/EEC. For the evaluation of the compliance
with these Directives, the following standards were applied:
◆Health (Article 3.1(a) of the R&TTE Directive)
■RF exposure related standards use ERC REC 519/EC
◆Safety (Article 3.1(a) of the R&TTE Directive)
■LVD: EN60950-1:2006+A11:2009+A1:2010
◆Electromagnetic compatibility (Article 3.1 (b) of the R&TTE Directive)
■EN 301 489-1 V.1.8.1
■EN 301-489-17 V2.1.1
◆Radio frequency spectrum usage (Article 3.2 of the R&TTE Directive)
■EN 300 328 V1.7.1
■EN 301 893 V1.6.1

– 7 –
ABOUT THIS GUIDE
PURPOSE This guide details the hardware features of the wireless TV adapter,
including its physical and performance-related characteristics, and how to
install the device and use its configuration software.
AUDIENCE This guide is for Smart Phone and PC users with a working knowledge of
computers. You should be familiar with Windows and Android operating
system concepts.
CONVENTIONS The following conventions are used throughout this guide to show
information:
N OTE : Emphasizes important information or calls your attention to related
features or instructions.
C AUTION : Alerts you to a potential hazard that could cause loss of data, or
damage the system or equipment.
W ARNING : Alerts you to a potential hazard that could cause personal injury.
RELATED PUBLICATIONS The following publication gives basic information on how to install and use
the wireless TV adapter.
Quick Installation Guide
Also, as part of the wireless TV adapter’s software, there is online help that
describes all configuration related features.
REVISION HISTORY This section summarizes the changes in each revision of this guide.
JUNE 2014 REVISION
Updates new features released for the second firmware version.

C HAPTER |
– 8 –
JULY 2013 REVISION
Adds new features released for the second firmware version.
OCTOBER 2012 REVISION
This is the first revision of this guide.

– 9 –
CONTENTS
WARRANTY AND PRODUCT REGISTRATION 4
COMPLIANCES 5
ABOUT THIS GUIDE 7
CONTENTS 9
FIGURES 11
TABLES 13
1I
NTRODUCTION 14
Overview of the Wireless TV Adapter 14
Main Features 14
Package Contents 15
Key Hardware Features 15
2SYSTEM REQUIREMENTS AND CONNECTIONS 17
System Requirements for Mirror Mode 17
System Requirements for PC to TV Mode 17
System Requirements for Mediashare Mode (DLNA) 18
3INSTALLATION GUIDE 19
How to Connect the TV Adapter 19
Install Screencasting Software 20
Hardware Reset to Factory Default Settings 21
4OPERATION MODES 22
Mirror Mode (Android Users) 22
Mirror Mode Local Sharing 22
Mirror Mode Internet Sharing 25
PC to TV Mode (Windows Users) 26
Install PC to TV Client 26
PC to TV Mode (Local Sharing) 29
PC to TV (Internet Sharing-Wired Connection) 31

C ONTENTS
– 10 –
PC to TV (Internet Sharing-Wireless Connection) 32
Mediashare Mode (Android and iOS Users) 37
Install DLNA App (Android System) 37
Install DLNA App (iOS System) 40
Mediashare Mode Using AirFun 44
USB Mode 46
Using USB Mode 46
Firmware Upgrade 47
Setup Using the OSD Menu 48
Network 49
Audio 49
Video 49
System 50
5SPECIFICATIONS 51

– 11 –
FIGURES
Figure 1: Rear View 15
Figure 2: Side View 16
Figure 3: Connection Diagram 19
Figure 4: Standby Mode 20
Figure 5: Reset Button 21
Figure 6: Mirror Mode (Local Sharing) 23
Figure 7: Mirror Mode—Accessing Miracast Within Android 23
Figure 8: Media Output 24
Figure 9: Select Miracast Device 24
Figure 10: Connect to a Miracast Device 25
Figure 11: Mirror Mode (Internet Sharing) 26
Figure 12: Install PC to TV Client 27
Figure 13: Choose the Language 27
Figure 14: Select Installation location 27
Figure 15: Select Installation location 28
Figure 16: Select Installation location 28
Figure 17: PC to TV Icon 29
Figure 18: PC to TV Mode (Local Sharing) 29
Figure 19: Connect to the Device 29
Figure 20: PC to TV Login Window 30
Figure 21: PC to TV Controller 30
Figure 22: PC to TV Mode (Wired/Wireless Connection) 31
Figure 23: Wired Connection 32
Figure 24: WirelessConnection 32
Figure 25: PC to TV Remote Control 33
Figure 26: Virtual Remote 33
Figure 27: Virtual Remote Setup 34
Figure 28: Setup Main Page 34
Figure 29: WiFi Connection 35
Figure 30: Switch the WiFi Connection to On 35
Figure 31: Connecting to a Home Router 36

C ONTENTS
– 12 –
Figure 32: Enter the Home Router’s Password 36
Figure 33: AirFun App QR Code 37
Figure 34: Google Play Store 37
Figure 35: Search DLNA Software App - Android Users 38
Figure 36: Install AirFun App - Android Users 38
Figure 37: Download AirFun App - Android Users 39
Figure 38: AirFun App is Installed - Android Users 39
Figure 39: Activate AirFun App -Android Users 40
Figure 40: AirFun App QR Code 40
Figure 41: App Store 41
Figure 42: Search DLNA Software App - iOS Users 41
Figure 43: Install AirFun App - iOS Users 42
Figure 44: AirFun App Install Complete - iOS Users 42
Figure 45: AirFun App is Installed - iOS Users 43
Figure 46: Activate AirFun App - iOS Users 43
Figure 47: Connect to SMCWTVA100 44
Figure 48: Search and Connect to Device 44
Figure 49: AirFun Setup Screen 45
Figure 50: AirFun Activate 45
Figure 51: USB source 46
Figure 52: Upgrade Firmware 47
Figure 53: Upgrade Firmware Completed 47
Figure 54: Setup Main Page 48

– 13 –
TABLES
Table 1: System Requirements (PC to TV Mode) 17
Table 2: System Requirements (Mediashare Mode) 18
Table 3: Additional PC to TV Controller Menu Items 30

– 14 –
1INTRODUCTION
This chapter includes these sections:
◆Overview of the Wireless TV Adapter
◆Package Contents
◆Key Hardware Features
OVERVIEW OF THE WIRELESS TV ADAPTER
Enjoy all of your personal and online content on a big screen with a simple
wireless connection. The SMCWTVA100 can use Mirror, PC to TV,
Mediashare (DLNA or Digital Living Network Alliance) to transfer
technology to share your mobile device or laptop content through a Wi-Fi
link to your TV or room projector. You can sit back on a couch and enjoy
your favorite movies, videos, photos, online shows and more, all in full HD.
You can also make business presentations or play music, photos or video
directly from your smartphone or tablet by Wi-Fi. The SMCWTVA100 can be
used with Windows, Android, and Apple iOS systems to share your
happiness.
MAIN FEATURES ◆Mirror—Android smartphone screen and sound is “screencast” and
displayed on your TV.
◆PC to TV—All PC video and audio output is “screencast” and displayed
on your TV.
◆Mediashare—DLNA technology displays selected video, image, and
sound files from tablets, and smartphones onto your TV.
◆USB interface—USB thumb media files are displayed on your TV.
◆Dual-band Wi-Fi connectivity (2.4G or 5G Band 2T2R 300 Mbps)
◆HDMI/CVBS support—To support both new and previous generation
televisions, monitors, and projectors.
◆Micro-USB DC in port—Any convenient USB power source can be
used.

C HAPTER 1 | Introduction
Package Contents
– 15 –
PACKAGE CONTENTS
The packaging should contain the following items:
◆SMCWTVA100
◆HDMI cable
◆AV Cable
◆Power adapter
◆Resource CD — including this User Guide and PC TO TV Client Software
◆Warranty Card
N OTE : Make sure that the package contains the above items. If any of the
listed items are damaged or missing, please contact your distributor.
KEY HARDWARE FEATURES
Figure 1: Rear View
The following items are located on the rear panel (from left to right).
1. AV
This CVBS port connects the TV adapter output signal to a TV or projector.
2. HDMI
This port connects the TV adapter output signal to a TV or projector.
12 345

C HAPTER 1 | Introduction
Key Hardware Features
– 16 –
3. ETHERNET LAN PORT
This port connects the TV adapter to a LAN over Ethernet. For example,
you can connect it to a spare port on your home WI-FI router.
4. POWER BUTTON
When the DC power adapter is attached and connected to a power source,
the power button must be depressed to power on the unit.
5. DC 5V
The micro-USB power socket is where you connect the power adapter. Use
the power adapter provided with the TV adapter or any suitable device
which can supply DC voltage over a USB connection.
Figure 2: Side View
The following items are located on the side panel (from left to right).
6. USB PORT
This port is for upgrading firmware only. Connect an external USB storage
device, such as a thumb drive, to this port.
6

– 17 –
2SYSTEM REQUIREMENTS AND
CONNECTIONS
This chapter includes these sections:
◆System Requirements for Mirror Mode
◆System Requirements for PC to TV Mode
◆System Requirements for Mediashare Mode (DLNA)
SYSTEM REQUIREMENTS FOR MIRROR MODE
Mirror mode is supported by a limited number of Android 4.2+ release
devices. Please check the SMC website (http://www.smc.com/en-global/
products/product/19) for a compatibility list of currently supported devices
or check with your device’s manufacturer.
SYSTEM REQUIREMENTS FOR PC TO TV MODE
PC to TV software uses a proprietary protocol similar to Wi-Di however,
instead of being limited to the few models that support Wi-Di, you can use
it on any Windows 7 or Windows 8 OS computer.
Table 1: System Requirements (PC to TV Mode)
System Component Requirement
PC or Laptop CPU: 1.6 GHz or better
Memory: 1.0 GB or better
Network: 802.11g/n Wi-Fi and/or 100/1000 Mbps Ethernet

C HAPTER 2 | System Requirements and Connections
System Requirements for Mediashare Mode (DLNA)
– 18 –
SYSTEM REQUIREMENTS FOR MEDIASHARE MODE (DLNA)
The SMCWTVA100 is designed to be a DLNA-DMR (digital media renderer)
device, which means you are able to stream video, music, and photo
content from a PC (Windows 7 or Windows 8 OS), smartphone, or tablet-
PC to your TV.
Table 2: System Requirements (Mediashare Mode)
System Component Requirement
PC or Laptop CPU: 1.6 GHz or better
Memory: 1.0 GB or better
Network: 802.11g/n Wi-Fi and/or 100/1000 Mbps Ethernet
Smartphone CPU: 800 MHz or better
Memory: 256 MB or better
Network: 802.11g/n Wi-Fi or better
Tablet CPU: 600 MHz or better
Memory: 256 MB or better
Network: 802.11g/n Wi-Fi or better

– 19 –
3INSTALLATION GUIDE
The sections that follow describe the hardware and software installation
procedures and some additional configuration required to connect your
SMCWTVA100 into your existing LAN or WLAN. The following sections are
included:
◆How to Connect the TV Adapter
◆Install Screencasting Software
◆Hardware Reset to Factory Default Settings
HOW TO CONNECT THE TV ADAPTER
For a basic “stand-alone” hardware install of the TV adapter, perform the
following steps:
N OTE : If Internet is required for your display function, before installing the
TV adapter, make sure your PC, smartphone or tablet-PC is successfully
connected to the Internet through a broadband service. If there are any
problems, first contact your ISP to resolve them.
1. Plug in the power cord.
2. Connect the HDMI cable to the HDMI output of the SMCWTVA100 and
to the HDMI input of your TV, projector or monitor.
3. To turn on the SMCWTVA100, push in the power button until it clicks in
the depressed position.
Figure 3: Connection Diagram

C HAPTER 3 | Installation Guide
Install Screencasting Software
– 20 –
4. When you see the following screen, the device is ready to use.
Figure 4: Standby Mode
INSTALL SCREENCASTING SOFTWARE
Whether you want to use a PC, tablet or smartphone with the
SMCWTVA100, your devices will need screencasting software to be able to
display and play your device contents.
1. Download and install the required software on your PC, smartphone, or
tablet.
■For Windows 7 and 8 users, install the PC to TV client software. See
“Install PC to TV Client” on page 26.
■For Android and Apple iOS users, install a DLNA software app, which
can be downloaded from Google Play (formerly Android Market). or
Apple App Store. Supported DLNA App: AirFun. See “Install DLNA
App (Android System)” on page 37 or “Install DLNA App (iOS
System)” on page 40.
