SMC Networks HAW7 User manual

Doc.no. ATX-OM-F003E-C
PRODUCT NAME
Water Cooled Aftercooler
MODEL / SERIES
HAW2
HAW7
HAW22
HAW37
HAW55
HAW75
HAW110
© 2020 SMC CORPORATION All Rights Reserved
.
This manual is intended to explain the installation and operation of the product. Only
people who understand the basic operation of the product, or have basic knowledge
and ability to handle industrial machinery, are allowed to work on the product.

To Customers
Thank you for selecting SMC Water Cooled Aftercooler.
For safety and long life of the product, be sure to read this Operation Manual (hereinafter
referred to as the “manual”) and clearly understand the contents.
●The instructions described in this manual must be followed in addition to ISO 4414*1) and
JIS B 8370*2) and other safety regulations.
*1) ISO4414: Pneumatic fluid power – Recommendations for the application of equipment to
transmission and control systems.
*2) JIS B 8370: General rules for pneumatic equipment.
●This manual is intended to explain the installation and operation of the product. Only people
who understand the basic operation of the product through this manual, or who install and
operate industrial machinery and have basic knowledge and ability to handle such equipment,
are allowed to work on the product.
●This manual and other documents attached to the product do not constitute a contract, and
will not affect any existing agreements or commitments.
●It is strictly prohibited to copy this manual entirely or partially for use by a third party without
prior permission from SMC.
Note: This manual is subject to change without prior notice.

Table of Contents
i. Safety Instructions··············································································1
1. Specifications ··················································································· 4
2. Model No. identification mark·······························································5
3. Construction Principle ········································································5
4. Outer dimensions and descriptions of each part ······································6
5. Installation ······················································································· 9
6. Cautions··························································································10
7. Maintenance ····················································································11
8. Water quality standard of cooling water ················································· 13

Water Cooled Aftercooler
HAW
Series - 1 - i-1 Warning: Before using this product
i Safety Instructions
Before using the product be sure to read and understand all the
important actions highlighted in this manual.
i - 1 Warning: Before using this product
This chapter is intended to specifically describe the safety related issues for handling the product.
Read this before handling the product.
- The water cooled aftercooler is a product that cools the hot and humid air discharged from the compressor with
cooling water, and condenses and separates the contained water.SMC does not take any responsibility for any
problems that may arise from using the product for other purposes.
- Not only people handle the water cooled aftercooler but every people who perform maintenance on or do works related to it
should read safety instructions on this operation manual before handling.
- This manual is not a comprehensive manual covering safety and health related issues. This should be handled by
a person in charge of safety training.
- All personnel who work with or around the product should have sufficient knowledge about the dangers inherent
to the product and be trained in safety measures.
- The safety manager is responsible for strictly observing safety standards, but responsibility in respect to safety
standards during daily work resides with each individual operator and maintenance personnel.
- The operator and maintenance personnel should consider work places and environments for each task with due
consideration of safety issues.
- It is necessary to undergo appropriate general safety training before being trained about this product. Training
without having sufficient knowledge about safety is very dangerous. Training must not be conducted without
consideration to safety.
- This manual must be kept available to the operator whenever necessary.
i - 2 Danger, Warning and Caution
The instructions given in this manual aim to assure the safe and correct operation of the product, and to prevent
injury of operators or damage to the product. These instructions are grouped into three categories, "Danger",
"Warning" and "Caution", which indicate the level of hazard, damage and also the degree of emergency. All safety
critical information should be carefully observed at all times.
DANGER, WARNING and CAUTION signs are in order according to severity (DANGER> WARNING> CAUTION).
The signs are explained on the following page.
Danger
"Danger" indicates a hazard with a high level of risk which will result in death or serious
injury if an operator performs incorrect handling during the operation and maintenance of
the product or does not follow the instructions necessary to avoid it.
Warning
“Warning” indicates a hazard with a medium level of risk which will result in death or
serious injury if an operator does not follow the specified procedures during the operation
or maintenance of the product or does not follow the instructions necessary to avoid it.
Caution
“Caution” indicates a hazard of a low level of risk which will result in minor and moderate
injury or damage to product and equipment if an operator does not follow the specified
procedures during the operation and maintenance of the product or does not follow the
instructions to avoid it.
ATX-OM-F003E
i Safety Instructions

Water Cooled Aftercooler
HAW
Series - 2 -
i - 3 Hazards related to high temperatures
Warning
- Since this product has parts that become hot during operation, there is a danger of burns
resulting from contact with these parts. There is also a danger of burns due to residual
heat after the power supply is cut. Therefore, wait until the temperature of hot parts has
fallen below 50oC.
- Excessive or insufficient cooling water will damage the heat transfer tubes, so design within the
rated water volume range. (Refer to product specifications)
i - 4 Hazards related to pneumatic circuit
Warning
- Be sure to check air pressure is zero before replacing the element or performing the
maintenance of the auto drain.
- When parts are loosened, there is a possibility of becoming rapid part unexpected accident such
as shooting out and it is very dangerous when the compressed air pressure remains in the
product.
ATX-OM-F003E
i Safety Instructions
i-3 Hazards related to high temperatures

Water Cooled Aftercooler
HAW
Series - 3 -
i - 5 Limited warranty and Disclaimer / Compliance Requirements
The product used subject to the following “Limited warranty and Disclaimer “and “Compliance
Requirements.
Read and accept them before using the product.
『Limited warranty and Disclaimer』
(1) The warranty period of the product is 1 year in service or 1.5 years after the product is delivered.
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
(2) For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
(3) Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
『Compliance Requirements』
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are govemed by the
relevant security laws and regulation of the countries involved in the transaction. Prior to the
shipment of a SMC product of a SMC product to another country, assure that all local rules
goveming that export are known and followed.
Caution
The Product is provided use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contact if necessary.
If anything is unclear, contact your nearest sales branch.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country. Therefore, SMC products cannot
be used for business or certification ordained by the metrology (measurement) laws of each country.
ATX-OM-F003E
i Safety Instructions
i
-
5
Limited warranty and Disclaimer
/ Compliance Requirements

Water Cooled Aftercooler
HAW
Series - 4 -
1. Specifications
ATX-OM-F003E
1. Specifications
1. Specifications

Water Cooled Aftercooler
HAW
Series - 5 -
2．Model No. Identification Mark
3．Construction Principle
ATX-OM-F003E
2. Model No. Identification Mark
2. Model No. Identification Mark

Water Cooled Aftercooler
HAW
Series - 6 -
4．Outer dimensions and descriptions of each part
1) Outer dimensions
HAW2/7
HAW22 to 110
(mm)
Model A B C D E F ΦG H J K L M N P Q R S T ΦU V W Y Z ZA
HAW2-04 360 190 83 35 270 35 130 203 159 159 182 209 60 - 60 - 94 4.5 10 1/2 1/2 1/2 - -
HAW7-06 570 390 83 35 480 35 130 203 159 159 182 209 60 - 60 - 94 4.5 10 3/4 1/2 1/2 - -
HAW22-14 948 575 212 37 704 138 165 257 245 215 206 254 90 120 60 120 150 4.5 12 1 1/2 3/4 3/4 359 371
HAW37-14 1354 893 258 80 1056 170 216 315 264 219 234 305 100 140 66 140 139 6.0 18 1 1/2 3/4 1 380 431
HAW55-20 1612 1038 366 150 1203 276 216 315 264 219 234 305 100 140 66 140 139 6.0 18 2 3/4 1 375 426
HAW75-20 2112 1538 366 150 1703 276 216 315 264 219 234 305 100 140 66 140 139 6.0 18 2 3/4 1 375 426
HAW110-30 1724 950 500 72 1210 365 267 -- - 303 356 200
Note 1
70
Note 1
195 8.0 18 3 1 1 1/4 395 459
Note 1) HAW110-30 is Φ220
2×V（HAW110-30）
Flange
ATX-OM-F003E
4. Outer dimensions and descriptions of each part
4 1) Outer dimensions

Water Cooled Aftercooler
HAW
Series - 7 -
2) Descriptions of each part
HAW2/7
ATX-OM-F003E
4. Outer dimensions and descriptions of each part
part
4 2) Descriptions of each part
Component parts (HAW2/7)
No.
1
2
3
4
Replacement parts
No. Description Material
2Flower fin tube
assembly
Aluminum,
Copper,
Carbon steel
5 Seal Non-asbestos
6 Seal Non-asbestos
Water chamber cover FC200
Flower fin tube assembly C1220T
Housing AC2A-F
Description Material
Outside tube AC2A-F
Note
-
Flower fin
-
-
HAW2 HAW7
42012
(1 pc.)
42013
(2 pcs.)
42022
(1 pc.)
42013
(2 pcs.)
42015
(1 pc.)
42015
(1 pc.)

Water Cooled Aftercooler
HAW
Series - 8 -
HAW22 to 110
4 2) Descriptions of each part
ATX-OM-F003E
4. Outer dimensions and descriptions of each part
part
Component parts (HAW22 to 110)
No.
1
2
3
4
5
Replacement parts
No. Description Material HAW22 HAW37 HAW55 HAW75 HAW110
4Flower fin tube
assembly
Aluminum,
Copper,
Carbon steel
42036
(1 pc.)
42046
(1 pc.)
42054
(1 pc.)
42062
(1 pc.)
42073
(1 pc.)
6 Seal Non-asbestos 42032#1
(2 pcs.)
42042#1
(2 pcs.)
42042#1
(2 pcs.)
42042#1
(2 pcs.) -
7 Seal Non-asbestos 42035#1
(1 pc.)
42045#1
(1 pc.)
42045#1
(1 pc.)
42045#1
(1 pc.)
42072#1
(1 pc.)
8 Seal Non-asbestos 42037#1
(1 pc.)
42047#1
(1 pc.)
42047#1
(1 pc.)
42047#1
(1 pc.)
42074#1
(1 pc.)
Housing
Outside tube
Body
FC200Water chamber cover
Note
-
-
-
Flower fin
-
Flower fin tube assembly
Description Material
SGP，SS400
STK
FC200
C1220T

Water Cooled Aftercooler
HAW
Series - 9 -
5．Installation
(1)Installation Location
1) Install the after-Cooler in level.
2) Make sure to correctly connect the compressed air inlet/outlet and the cooling water inlet/outlet.
3) Use union joints to connect the cooling water pipes so that they can be easily removed during
maintenance.
4) Connect a drain pipe because a large amount of drainage is generated when the compressed air is
cooled.
The drain pipe must have a minimum pipe bore of 10 mm, and a maximum length of 5 m (when
installing an optional auto drain).
5) Auto-drain is available on request.
6) For applications where the use of extremely contaminated cooling water is unavoidable, install a filter in
the inlet line. (Nominal filtration rating approx.100μm)
7) After installing this water-cooled after-cooler, hot air will flow in, so first check for air leaks.
8) Select the diameters of water and air piping’s large enough to eliminate pressure drops.
Diameters larger than the connection ports provided on this unit are sufficient.
9) Inspect the quality of the cooling water and replace the circulating water on a regular basis. If the
cooling water is cooled in a cooling tower, it is susceptible to the adhesion of water scale.
10) If there is a likelihood that the cooling water will be frozen, drain the cooling water to prevent damage.
Also, drain the cooling water when the equipment will not be used
11) If the cooling performance has been reduced, clean the inside of the cooling water pipes. (Refer to the
cleaning method, refer to 7. Maintenance.)
ATX-OM-F003E
5. Installation
5. 1) Installation Location

Water Cooled Aftercooler
HAW
Series - 10 -
(2) Air Piping
1) When the compressed air from a compressor is cooled down, a lot of condensed water will be
generated. Do not forget to conduct drain piping at the outlet of the drain valve.
It is recommended to use an automatic drain system for savings in labor.
We recommend our auto drain in the table below.
Product part number Auto drain number
Normally closed Normally open
HAW2-04C/D AD402-04C-6-A AD402-04D-6-A
HAW7-06D ―AD402-04D-6-A
HAW22/37-14D ―AD600-06
HAW55/75-20D ―AD600-06
HAW110-30D ―AD600-10
2) The drain piping, if conducted, should have an inside diameter of at least 10mm and a maximum
length of 5m. Improper piping will cause the back pressure to excessively increase at the time of
draining, resulting in unstable function of the auto drain.
Warning
- When draining, follow the user’s own procedure to keep operators safe. (E.g. Wearprotective
goggles, apron and gloves to prevent contact with the drained condensate.)
- When oils can enter the drained condensate, waste water treatment is necessary.
Follow the bylaws or rules of the local municipality.
6．Cautions
1) Use city water or industrial water as the cooling water. Never use sea water.
2) The unit cannot be used for the purpose of cooling chemicals and food.
3) Mount water suspension relay to prevent overheating without cooling water in case.
ATX-OM-F003E
5. Installation
6 2) Air Piping

Water Cooled Aftercooler
HAW
Series - 11 -
7．Maintenance
To hold the excellent cooling capacity for a long period of time and make more effective use of the unit, the
following inspection and maintenance operations must be made.
1) Open the drain valve and remove the drainage once and a while.
2) When an automatic drain system is used, check once and a while to see that drainage is discharged.
When the humidity is low or the compressor is run for a short time period, drain may not be produced.
3) Carry out inspection once or twice a year, depending on the degree of contamination of the fluid used.
4) In applications where the cooling water is cooled by a cooling tower the inside of the cooling water pipes in
liable to collect fur, with possible decrease in flow rater of the cooling water.
The use of the same cooling water for longer period is also liable to generate deposit of fur on the inside of
the pipes. Replace the circulating water periodically.
Furthermore, carry out back washing with opposite connection of inlet and outlet for cooling water.
5) For the use in a cold district where freezing of the cooling water is possible during the winter, drain the
water after use. The water should also be drained when the unit is kept shut down for longer period. (This
will prevent fur from deposition.)
6) Decrease in cooling performance usually results from extremely contaminated cooling water. When the unit
exhibits the decrease in cooling performance (a reading on the provided thermometer exceeds 40℃),
perform mechanical cleaning (such as cleaning by a jet cleaner or a bar with cloth, or brushing) inside of
the cooling water piping first, and then chemical cleaning inside the cooling water system after
re-assembling.
7) Being larger in cross-sectional area, the pass for air is considered being rarely blocked unless it is badly
contaminated. Should the greater pressure loss be encountered, the principal cause may be accumulation
of sludge (deteriorated oil). In such a case, remove the unit from the piping, disassemble and clean the
unit with alcohol.
8) In cleaning the finned tubes for the air and brushing the copper tubes for the water, disassemble the unit in
the following order referring to Construction Drawings.
[Disassembling Models HAW2/7]
(1) Remove the water chamber cover and housing.
(2) Push the heat transfer assembly from the housing side, and then the assembly will come out of the
shell.
[Disassembling Models HAW22 to 110]
(1) Remove the water chamber cover.
(2) Remove the hex cap bolts on the plate of the heat transfer assembly and install a M8 eye bolt.
(3) Thread a rope through the eye bolts, and pull it.
When sticking of the plate to the body makes pulling the plate difficult, pull in by the aid of a
lever-operated jack.
ATX-OM-F003E
7. Maintenance
7. Maintenance

Water Cooled Aftercooler
HAW
Series - 12 -
Note:
1. Great care should be paid not to damage the cooper tubes of the pulled out heat transfer assembly.
2. Disassembling job requires spare packing; contact our dealers for the spare pickings. (For the number of
the packing, refer to the Spare Parts list on page 7 to 8.)
3. Assembling may be performed in the reverse order. In assembling, push the heat transfer assembly into
the shell in such a condition that two bolts are vertically symmetric as shown in the Figure 1.
Danger
・During drainage work, follow your own procedure to ensure the safety of operators
(e.g.wear protective goggles, apron and gloves).
Danger
・There is a risk of touching drained waste liquid during replacement.
When draining, follow the user’s own procedure to keep operators safe.
(E.g. Wear protective goggles, apron and gloves to prevent contact with the drained
condensate.)
Danger
・If the drained fluid contains oil, waste liquid treatment is necessary according to local
laws orregulations.
Danger
・Be sure to check air pressure is zero before replacing the element or performing the
maintenance of the auto drain.
ATX-OM-F003E
7. Maintenance
7. Maintenance
Figure 1

Water Cooled Aftercooler
HAW
Series - 13 -
8．Water quality standard of cooling water
Various kinds of water, such as potable water, ground water, industrial water, river water etc. would be
used as cooling water, and they may cause the following troubles that deteriorate the performance of
After cooler when they are contaminated.
(1) Heat transfer piping’s burst out due to corrosion.
(2) The performance to transfer heat decreases due to formed coating caused by fur (the generic term
including scale, rust, slime etc.)
(3) The amount of cooling water decreases due to the blocked flow caused by fur accumulation, and
that leads the decrease of cooling performance. In the worst case, it would be blocked completely.
If water is used as the facility water, please refer to JRA-GL-02-1994 [water quality guidelines for
refrigeration and air-conditioning equipment] prepared by Japan Refrigeration and Air Conditioning
Industry Association as a reference for the water quality level to prevent excessive corrosion and
scale-related problems. The values are shown in Table 2.
Table 2
Item
Facility water system
Circulating type Transient type
Circulating fluid
Filling of
circulating fluid
Transient fluid
Standard items
pH [25°C] 6.5 to 8.2 6.0 to 8.0 6.8 to8.0
Electrical conductivity
(mS/m) [25°C] 80 or less 30 or less 40 or less
Chloride ions (mg/L) 200 or less 50 or less 50 or less
Sulfuric acid ions (mg/L) 200 or less 50 or less 50 or less
Acid consumption
[pH4.8](mgCaCO
3
/L) 100 or less 50 or less 50 or less
Total hardness (mgCaCO3/L) 200 or less 70 or less 70 or less
Calcium hardness (mgCaCO3/L) 150 or less 50 or less 50 or less
Ionic state silica (mgSiO2/L) 50 or less 30 or less 30 or less
Reference items
Iron (mg/L) 1.0 or less 0.3 or less 1.0 or less
Copper (mg/L) 0.3 or less 0.1 or less 1.0 or less
Sulfide ions (mg/L) Shall not be
detected.
Shall not be
detected.
Shall not be
detected.
Ammonium ions (mg/L) 1.0 or less 0.1 or less 1.0 or less
Residual chloride (mg/L) 0.3 or less 0.3 or less 0.3 or less
Free carbon dioxide (mg/L) 4.0 or less 4.0 or less 4.0 or less
Stability index 6.0 to 7.0 or
less －－
8. Water quality standard of cooling water
ATX-OM-F003E
8. Water quality standard of cooling water

Water Cooled Aftercooler
HAW
Series - 14 -
- Water quality inspection (Once a month)
If tap water or ground water (well water) is used as the facility water for the water-cooled condenser,
test the items shown in Table 2 using JIS K 0101 (Test methods for industrial water) or methods
based on these methods, and determine the applicability of the water based on the criteria shown in
Table 2.
If the values are outside of the criteria, the following measures shall be taken before using it.
a) Change of the water source (e.g. Change ground water to tap water.)
b) Consult a water treatment consultant about how to treat the water.
c) Change the cooling method from transient type to circulating type, and use applicable facility
water.
If the facility water in a cooling tower is used, the water quality standard will be satisfied at the
initial stage, however, if it is used in an air contaminated environment, sulfurous acid gas in the air
may dissolve into the facility water, forming sulfuric acid which may corrode the electro-thermal
surface. Therefore, control the water quality regularly by inspecting and replacing the facility water
regularly.
-Cleaning of the facility water equipment (once every three months)
•Clean the facility water equipment and replace the facility water.
•The supplied facility water should be within the range shown in Table 2.
8. Water quality standard of cooling water
ATX-OM-F003E
8. Water quality standard of cooling water

Revision
Rev. B：October 2020
Rev. C：December 2021
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN
Tel: + 81 3 5207 8249 Fax: [phone]
URL http://www.smcworld.com
Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
© 2020 SMC Corporation All Rights Reserved
