SMC Sierra Monitor FieldServer FS-QS-1 0 Series User guide

Document Revision: 2.J
T18600
FieldServer
QuickServer Start-up Guide
FS-QS-1011/12X0/12X1/1X50/1X51
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after July 2020.

QuickServer Start-Up Guide
Contact Information
Technical Support
Please call us for any technical support needs related to the FieldServer product.
MSA Safety
1991 Tarob Court
Milpitas, CA 95035
Website: www.sierramonitor.com
U.S. Support Information:
[phone]
[phone]
Email: [email protected]
EMEA Support Information:
[phone]
Email: [email protected]

QuickServer Start-Up Guide
Table of Contents
TABLE OF CONTENTS
1QuickServer Description.....................................................................................................................7
2Supplied Equipment............................................................................................................................7
3Certifications........................................................................................................................................8
3.1 BTL Mark –BACnet Testing Laboratory ........................................................................................8
3.2 LonMark Certification......................................................................................................................8
4QuickServer Setup...............................................................................................................................9
4.1 Mounting.........................................................................................................................................9
4.2 Dimensions...................................................................................................................................10
4.2.1 Dimension Drawing FS-QS-1X10-XXXX...............................................................................10
4.2.2 Dimension Drawing FS-QS-1XX1-XXXX..............................................................................11
4.2.3 Dimension Drawing FS-QS-123X Models with RS-422........................................................12
4.3 R2 Port Jumper Settings ..............................................................................................................13
4.3.1 RS-485 Port...........................................................................................................................13
4.3.1.1 Bias Resistors................................................................................................................13
4.3.1.2 Termination Resistor......................................................................................................14
4.3.1.3 Power Jumper Settings..................................................................................................15
4.3.2 M-Bus Port: Master/Slave Jumper ........................................................................................16
4.4 R1 Port Small DIP Switches.........................................................................................................17
4.4.1 RS-485 Port...........................................................................................................................17
5Installing the QuickServer ................................................................................................................18
5.1 RS-485..........................................................................................................................................18
5.1.1 RS-485 Connection R2 Port..................................................................................................18
5.1.2 RS-485 Connection R1 Port..................................................................................................18
5.2 QuickServer LonWorks (FS-QS-1XX1-XXXX).............................................................................19
5.3 QuickServer KNX (FS-QS-124X-XXXX).......................................................................................19
5.4 RS-232 Connection R2 Port (only available on FS-QS-122X Models)........................................20
6Operation............................................................................................................................................21
6.1 Power Up the Device....................................................................................................................21
6.2 Connect the PC to the QuickServer Over the Ethernet Port........................................................21
6.3 Connecting to the QuickServer.....................................................................................................22
6.3.1 Using the FieldServer Toolbox to Discover and Connect to the QuickServer......................22
6.3.2 Using a Web Browser to Connect to the QuickServer..........................................................22
7Setup Web Server Security...............................................................................................................23
7.1 Login to the FieldServer ...............................................................................................................23
7.2 Select the Security Mode..............................................................................................................25
7.2.1 HTTPS with Own Trusted TLS Certificate.............................................................................26
7.2.2 HTTPS with Default Untrusted Self-Signed TLS Certificate or HTTP with Built-in Payload
Encryption............................................................................................................................................26
8Configuring the QuickServer............................................................................................................27
8.1 Set IP Address of the QuickServer Using FS-GUI.......................................................................28
8.2 Retrieve the Sample Configuration File........................................................................................29
8.3 Change the Configuration File to Meet the Application................................................................29
8.4 Load the Updated Configuration File............................................................................................30
8.4.1 Using the FS-GUI to Load a Configuration File.....................................................................30
8.4.2 Retrieve the Configuation File for Modification or Backup....................................................31
8.5 Test and Commission the QuickServer........................................................................................32
8.5.1 Accessing SMC Cloud...........................................................................................................32
Appendix A Useful Features....................................................................................................................33
Appendix A.1. RS-422 Connection R2 Port............................................................................................33
Appendix A.1.1. Connection and Operation via the RS-422 Port........................................................34
Appendix A.2. KNX Connection R2 Port.................................................................................................35
Appendix A.3. M-Bus Connection R2 Port..............................................................................................36

QuickServer Start-Up Guide
Table of Contents
Appendix A.4. SSL/TLS for Secure Connection......................................................................................37
Appendix A.4.1. Configuring FieldServer as a SSL/TLS Server .........................................................37
Appendix A.4.1.1. Simple Secure Server Configuration.................................................................37
Appendix A.4.1.2. Limiting Client Access .......................................................................................38
Appendix A.4.1.3. To Upload the Authority File to the FieldServer ................................................38
Appendix A.4.1.4. Certificate Validation Options............................................................................39
Appendix A.4.1.5. Set up Server Certificate ...................................................................................39
Appendix A.4.2. Configuring FieldServer as SSL/TLS Client..............................................................40
Appendix A.4.2.1. Simple Secure Client Configuration ..................................................................40
Appendix A.4.2.2. Limit Server Access...........................................................................................40
Appendix A.4.2.3. Certificate Validation Options............................................................................40
Appendix A.4.2.4. Set up Client Certificate.....................................................................................40
Appendix B Vendor Information –M-Bus Data Profiles........................................................................41
Appendix B.1. Aquametro Calec ST Mappings to BACnet and Modbus ................................................41
Appendix B.2. Comet XRM-50 Mappings to BACnet and Modbus.........................................................41
Appendix B.3. Elvaco CMa20 Mappings to BACnet and Modbus ..........................................................41
Appendix B.4. EMU 3PH Power 3-85 Mappings to BACnet and Modbus ..............................................41
Appendix B.5. Kamstrup 601 Mappings to BACnet and Modbus ...........................................................41
Appendix B.6. Kamstrup 602 Mappings to BACnet and Modbus ...........................................................42
Appendix B.7. Sontay Zenner Multidata Mappings to BACnet and Modbus...........................................42
Appendix B.8. Sontex SuperCal 531 Mappings to BACnet and Modbus................................................42
Appendix B.9. Siemens WFH21 Mappings to BACnet and Modbus.......................................................43
Appendix B.10. Siemens FUE950 Energy Mappings to BACnet and Modbus.......................................43
Appendix B.11. QS All Data Profile Mappings to BACnet and Modbus..................................................43
Appendix B.12. Kamstrup 66 Mappings to BACnet and Modbus ...........................................................46
Appendix B.13. Amtron Sonic D Mappings to BACnet and Modbus.......................................................46
Appendix B.14. Shenitech STUF-280T Mappings to BACnet and Modbus............................................46
Appendix B.15. SensusHRI-B1-8Profile Mappings to BACnet and Modbus...........................................47
Appendix B.16. KromSchroderTRZ2S1 Mappings to BACnet and Modbus...........................................47
Appendix B.17. KromSchroderDE10R25-40B Mappings to BACnet and Modbus.................................47
Appendix B.18. RelayPadPulsM1 Mappings to BACnet and Modbus....................................................50
Appendix B.19. AILA AUF200 Meter Data Profile Mappings to BACnet and Modbus............................50
Appendix B.20. Siemens WFN21 Mappings to BACnet and Modbus.....................................................50
Appendix B.21. Siemens UH50 Mappings to BACnet and Modbus........................................................50
Appendix B.22. Siemens T230 Mappings to BACnet and Modbus.........................................................50
Appendix B.23. Kamstrup Multical Mappings to BACnet and Modbus...................................................51
Appendix B.24. Siemens UH50 Combined Mappings to BACnet and Modbus......................................51
Appendix B.25. Sensostar 2C Mappings to BACnet and Modbus..........................................................52
Appendix B.26. Axis SKU-03 Mappings to BACnet and Modbus ...........................................................52
Appendix B.27. ECS Elec Mtr Mappings to BACnet and Modbus..........................................................52
Appendix B.28. Diehl Hydrus Mappings to BACnet and Modbus...........................................................53
Appendix B.29. Diehl Sharky 775 Mappings to BACnet and Modbus ....................................................53
Appendix B.30. Metz T M4 Mappings to BACnet and Modbus...............................................................53
Appendix B.31. Hydrometer Mappings to BACnet and Modbus.............................................................53
Appendix B.32. Kamstrup 402 Mappings to BACnet and Modbus .........................................................54
Appendix C Troubleshooting Tips ..........................................................................................................55
Appendix C.1. Communicating with the QuickServer Over the Network................................................55
Appendix C.2. Take a FieldServer Diagnostic Capture...........................................................................56
Appendix C.2.1. Taking a Capture with Older Firmware.....................................................................57
Appendix C.3. Internet Browser Software Support .................................................................................59
Appendix C.4. Change Web Server Security Settings After Initial Setup ...............................................59
Appendix C.4.1. Change Security Mode .............................................................................................60
Appendix C.4.2. Edit the Certificate Loaded onto the FieldServer......................................................61
Appendix C.5. Change User Management Settings ...............................................................................62
Appendix C.5.1. User Management.....................................................................................................62
Appendix C.5.1.1. Create Users .....................................................................................................63
Appendix C.5.1.2. Edit Users..........................................................................................................64

QuickServer Start-Up Guide
Table of Contents
Appendix C.5.1.3. Delete Users......................................................................................................65
Appendix C.5.2. Change FieldServer Password.................................................................................66
Appendix D Reference..............................................................................................................................67
Appendix D.1. LED Functions.................................................................................................................67
Appendix D.2. QuickServer FS-QS-101X DCC ......................................................................................68
Appendix D.3. QuickServer 1XXX Part Numbers ...................................................................................68
Appendix D.4. Compliance with UL Regulations.....................................................................................69
Appendix D.5. Specifications...................................................................................................................70
Appendix E Limited 2 Year Warranty......................................................................................................71

QuickServer Start-Up Guide
List of Figures
LIST OF FIGURES
Figure 1: DIN Rail..........................................................................................................................................9
Figure 2: FS-QS-1X10-XXXX......................................................................................................................10
Figure 3: FS-QS-1XX1-XXXX.....................................................................................................................11
Figure 4: FS-QS-123X models with RS-422...............................................................................................12
Figure 5: Bias Resistor Jumper...................................................................................................................13
Figure 6: Termination Resistor Jumper.......................................................................................................14
Figure 7: Power Jumper Switch..................................................................................................................15
Figure 8: Setting Master/Slave Jumper.......................................................................................................16
Figure 9: Bias Resistor DIP Switches & EOL..............................................................................................17
Figure 10: RS-485 R2 Connection Port......................................................................................................18
Figure 11: RS-485 R1 Connection Port......................................................................................................18
Figure 12: LonWorks Commissioning and Port..........................................................................................19
Figure 13: KNX Commissioning..................................................................................................................19
Figure 14: RS-232 R2 Connection Port......................................................................................................20
Figure 15: Connecting Power .....................................................................................................................21
Figure 16: Ethernet Port..............................................................................................................................21
Figure 17: Web Server Security Unconfigured Window .............................................................................23
Figure 18: Connection Not Private Warning ...............................................................................................23
Figure 19: Warning Expanded Text............................................................................................................24
Figure 20: FieldServer Login.......................................................................................................................24
Figure 21: Security Mode Selection Screen................................................................................................25
Figure 22: Security Mode Selection Screen................................................................................................26
Figure 23: FS-GUI Landing Page ...............................................................................................................27
Figure 24: FS-GUI Network Settings ..........................................................................................................28
Figure 25: FS-GUI File Transfer .................................................................................................................29
Figure 26: FS-GUI Loading Files................................................................................................................30
Figure 27: Retrieve Configuration File........................................................................................................31
Figure 28: FS-GUI Connections Page........................................................................................................32
Figure 29: RS-422 Unit ...............................................................................................................................33
Figure 30: RS-422 Connectors...................................................................................................................34
Figure 31: KNX Unit....................................................................................................................................35
Figure 32: M-Bus R2 Port...........................................................................................................................36
Figure 33: Ethernet Port Location...............................................................................................................57
Figure 34: FS-GUI Landing Screen ............................................................................................................59
Figure 35: FS-GUI Security Setup..............................................................................................................60
Figure 36: FS-GUI Security Setup –Certificate Loaded.............................................................................61
Figure 37: FS-GUI User Management........................................................................................................62
Figure 38: Create User Window..................................................................................................................63
Figure 39: Setup Users...............................................................................................................................64
Figure 40: Edit User Window ......................................................................................................................64
Figure 41: Setup Users...............................................................................................................................65
Figure 42: User Delete Warning .................................................................................................................65
Figure 43: FieldServer Password Update via FS-GUI................................................................................66
Figure 44: FS-QS-1XXX LEDs....................................................................................................................67
Figure 45: Specifications.............................................................................................................................70

QuickServer Start-Up Guide
Page 7 of 71
1 QUICKSERVER DESCRIPTION
QuickServer is a high performance, cost effective Building and Industrial Automation multi-protocol
gateway providing protocol translation between serial, Ethernet, and LonWorks
1
devices and networks.
NOTE: For troubleshooting assistance refer to Appendix B, or any of the troubleshooting
appendices in the related driver supplements. Check the Sierra Monitor website for
technical support resources and documentation that may be of assistance.
The QuickServer is cloud ready and connects with MSA Safety’s SMC Cloud. See Section 8.5.1 for
further information.
2 SUPPLIED EQUIPMENT
QuickServer Gateway
•Preloaded with two selected drivers (on the FS-QS-1X11 and FS-QS-12X1 one of those drivers is
LonWorks). A sample configuration file is also pre-loaded onto the QuickServer.
•All instruction manuals, driver manuals, support utilities are available on the USB drive provided
in the optional accessory kit, or on the Sierra Monitor website.
Accessory kit (optional) (Part # FS-8915-36-QS) includes:
•7-ft Cat-5 cable with RJ45 connectors at both ends
•Power Supply -110/220V (p/n 69196)
•DIN rail mounting bracket
•Screwdriver for connecting to terminals
•USB Flash drive loaded with:
oQuickServer Start-up Guide
oFieldServer Configuration Manual
oAll FieldServer Driver Manuals
oSupport Utilities
oAny additional folders related to special files
configured for a specific QuickServer
oAdditional components as required –see Driver Manual Supplement for details
1
LonWorks is a registered trademark of Echelon Corporation.

QuickServer Start-Up Guide
Page 8 of 71
3 CERTIFICATIONS
3.1 BTL Mark –BACnet
2
Testing Laboratory
3.2 LonMark Certification
2
BACnet is a registered trademark of ASHRAE.
The BTL Mark is a symbol that indicates that a product has passed a series of
rigorous tests conducted by an independent laboratory which verifies that the
product correctly implements the BACnet features claimed in the listing. The
mark is a symbol of a high-quality BACnet product.
Go to www.BACnetInternational.net for more information about the BACnet
Testing Laboratory. Click here for the BACnet PIC Statement.
LonMark International is the recognized authority for certification, education,
and promotion of interoperability standards for the benefit of manufacturers,
integrators and end users. LonMark International has developed extensive
product certification standards and tests to provide the integrator and user with
confidence that products from multiple manufacturers utilizing LonMark
devices work together. MSA Safety has more LonMark Certified gateways
than any other gateway manufacturer, including the QuickServer,
ProtoCessor, ProtoCarrier and ProtoNode for OEM applications and the full
featured, configurable gateways.

QuickServer Start-Up Guide
Page 9 of 71
4 QUICKSERVER SETUP
4.1 Mounting
The following mounting options are available:
•Product comes with tabs for wall or surface mount. These can be snapped off if not required.
•DIN rail mounting bracket –Included in the accessory kit or ordered separately
(part # FS-8915-35-QS).
WARNING: Install only as instructed, failure to follow the installation guidelines or using screws
without the DIN rail mounting bracket could result in permanent damage to the product. If the
FieldServer is removed from the DIN rail, use the original screws to reattach. Only screws
supplied by MSA Safety should be used in the holes found on the back of the unit when
attaching the optional DIN Rail bracket. USE OF ANY OTHER SCREWS MAY DAMAGE THE
UNIT.
Tab
Din Rail
Figure 1: DIN Rail

QuickServer Start-Up Guide
Page 10 of 71
4.2 Dimensions
4.2.1 Dimension Drawing FS-QS-1X10-XXXX
R1 Port
R2 Port
Figure 2: FS-QS-1X10-XXXX

QuickServer Start-Up Guide
Page 11 of 71
4.2.2 Dimension Drawing FS-QS-1XX1-XXXX
LonWorks Port
R2 Port
Figure 3: FS-QS-1XX1-XXXX

QuickServer Start-Up Guide
Page 12 of 71
4.2.3 Dimension Drawing FS-QS-123X Models with RS-422
R1 Port
R2 Port
Figure 4: FS-QS-123X models with RS-422

QuickServer Start-Up Guide
Page 13 of 71
4.3 R2 Port Jumper Settings
Gently remove the QuickServer enclosure to access the jumpers on the unit.
4.3.1 RS-485 Port
NOTE: The following Sections only apply to QuickServer models: FS-QS-1011 and FS-QS-1211.
4.3.1.1 Bias Resistors
The QuickServer bias resistors are used to keep the RS-485 bus to a known state, when there is no
transmission on the line (bus is idling), to help prevent false bits of data from being detected. The bias
resistors typically pull one line high and the other low - far away from the decision point of the logic.
In the RS-485 carrier, the bias resistor is 510 ohms which is in line with the BACnet spec. It should only
be enabled at one point on the bus (on the field port were there are very weak bias resistors of 100k).
Since there are no jumpers, many FieldServers can be put on network without running into the bias
resistor limit which is < 500 ohms.
NOTE: See www.ni.com/support/serial/resinfo.htm for additional pictures and notes.
Bias Resistor Jumper
Figure 5: Bias Resistor Jumper

QuickServer Start-Up Guide
Page 14 of 71
4.3.1.2 Termination Resistor
Termination resistors are also used to reduce noise. These pull the two lines of an idle bus together.
However, they would override the effect of any bias resistors, if connected.
Termination Resistor
Jumper
Figure 6: Termination Resistor Jumper

QuickServer Start-Up Guide
Page 15 of 71
4.3.1.3 Power Jumper Settings
The QuickServer Carrier Board power jumper is set to position A by default but can be changed to
position B for other power supply requirements.
Position A: The Carrier makes use of a full-wave rectifying bridge. Can be used for 12-24VAC input or
9 –30VDC input. At 9VDC this becomes marginal.
Position B: The Carrier makes use of a half-wave rectifying bridge. Best position for grounded AC
transformers and for using DC voltage down to 9VDC.
Power Jumper Switch
in position “A”
Figure 7: Power Jumper Switch

QuickServer Start-Up Guide
Page 16 of 71
4.3.2 M-Bus Port: Master/Slave Jumper
NOTE: The following only applies to models: FS-QS-1A50, FS-QS-1A51, FS-QS-1B51, FS-QS-1B51,
FS-QS-1C51 and FS-QS-1C51.
The Master/Slave jumper is used to set the M-Bus hardware as a Master or Slave device (indicated by
the labels on the board).
Figure 8: Setting Master/Slave Jumper

QuickServer Start-Up Guide
Page 17 of 71
4.4 R1 Port Small DIP Switches
Gently remove the QuickServer enclosure to access the small DIP switches for the R1 Port.
4.4.1 RS-485 Port
NOTE: The following only applies to QuickServer models FS-QS-1XX0 or all non-LonWorks
models.
•If more than one RS-485 device is connected to the network, then the field bias resistor switch
needs to be enabled to ensure proper communication. See Figure 9 for the orientation of
switch positions referenced below.
oThe default factory setting is OFF (switch position = right side)
oTo enable biasing, turn the bias switch ON (switch position = left side)
NOTE: Biasing only needs to be enabled on one device. The QuickServer has 510-ohm resistors
that are used to set the biasing.
•If the FieldServer is the last device on the trunk, then the end of line (EOL) termination switch
needs to be enabled. See Figure 9 for the orientation of switch positions referenced below.
oThe default factory setting is OFF (switch position = right side)
oTo enable the EOL termination, turn the EOL switch ON (switch position = left side)
Figure 9: Bias Resistor DIP Switches & EOL
Bias Resistor Switch
End of Line Switch

QuickServer Start-Up Guide
Page 18 of 71
5 INSTALLING THE QUICKSERVER
5.1 RS-485
5.1.1 RS-485 Connection R2 Port
Connect to the 3 pins on the left-hand-side of the 6-pin connector as shown.
The following Baud Rates are supported on the R2 Port:
4800, 9600, 19200, 38400, 57600, 115200
For connection details to RS-232 or RS-422, refer to Appendix A.1.
5.1.2 RS-485 Connection R1 Port
NOTE: The following only applies to non-LonWorks QuickServers with an RS-435 R1 port.
Connect to the 3-pin connector as shown.
The following Baud Rates are supported on the R1 Port:
110, 300, 600, 1200, 2400, 4800, 9600, 19200, 20833, 28800, 38400, 57600, 76800, 115200
Figure 10: RS-485 R2 Connection Port
Figure 11: RS-485 R1 Connection Port
+ - GND
B+ A- SG

QuickServer Start-Up Guide
Page 19 of 71
LonWorks Service Pin
5.2 QuickServer LonWorks (FS-QS-1XX1-XXXX)
Connect the QuickServer to the LonWorks terminal using a twisted pair non-shielded cable.
To commission the QuickServer LonWorks port, insert a small screwdriver in the commissioning hole on
the face of the QuickServer’s enclosure to access the Service Pin. See the instructions on the
QuickServer as to which way to toggle the screwdriver during commissioning.
5.3 QuickServer KNX (FS-QS-124X-XXXX)
Connect the QuickServer to the KNX bus using the standard KNX twisted pair cable.
To commission the QuickServer as a KNX device in ETS Software, insert a small pin into the KNX
commissioning hole on the face of the QuickServer to access the button.
LonWorks Terminal
Figure 13: KNX Commissioning
Figure 12: LonWorks Commissioning and Port
KNX Programming Button

QuickServer Start-Up Guide
Page 20 of 71
5.4 RS-232 Connection R2 Port (only available on FS-QS-122X Models)
Refer to Appendix A2 for further hardware connection options.
The following Baud Rates are supported on the R2 Port:
4800, 9600, 19200, 38400, 57600, 115200
Figure 14: RS-232 R2 Connection Port
TX RX SG
