Smeg DWA6214X2 User manual

Contents
1
1. Safety and operating instructions ___________________________2
1. Installation and hook-up___________________________________7
2. Description of the controls ________________________________10
3. Operating instructions ___________________________________17
4. Cleaning and maintenance _______________________________29
5. Troubleshooting ________________________________________33
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use of
your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
Recommendations are given for the correct use of the baskets, spray
arms, containers, filters, washing programs, and for operating the controls.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
This user-friendly manual will provide answers to all your questions about
use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of the
appliance.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.

Installation instructions
2
1. Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE; IT MUST
ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER FOR FUTIRE
REFERENCE. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE
INSTRUCTIONS CONTAINED IN THIS MANUAL. THEY CONTAIN IMPORTANT
INFORMATION FOR THE INSTALLATION, USE AND MAINTENANCE OF THE
APPLIANCE. IN THE EVENT OF SALE OR TRANSFER, ENSURE THAT THE
MANUAL ALWAYS ACCOMPANIES THE APPLIANCE.
THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD AND SIMILAR
APPLICATIONS SUCH AS:
- STAFF KITCHEN AREAS IN SHOPS, OFFICES AND OTHER WORKING
ENVIRONMENTS;
- FARM HOUSES;
- BY CLIENTS IN HOTELS, MOTELS AND OTHER RESIDENTIAL TYPE
ENVIRONMENTS;
- BED AND BREAKFAST TYPE ENVIRONMENTS
THIS APPLIANCE IS DESIGNED TO BE USED ONLY IN STATIONARY
LOCATIONS.
THIS APPLIANCE COMPLIES WITH DIRECTIVES 2006/95/EC AND
2004/108/EC CURRENTLY IN FORCE, INCLUDING THE PREVENTION AND
ELIMINATION OF RADIO FREQUENCY INTERFERENCE AND IS DESIGNED
FOR THE FOLLOWING PURPOSE: WASHING AND DRYING OF DISHES; ANY
OTHER USE SHALL BE CONSIDERED IMPROPER. THE MANUFACTURER
DECLINES ALL RESPONSIBILITY FOR USES OTHER THAN THOSE
DESCRIBED ABOVE.
DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING TRANSIT!
IF IN DOUBT, CONSULT YOUR DEALER.
THE APPLIANCE MUST BE INSTALLED AND CONNECTED IN ACCORDANCE
WITH THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER.
INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN
COMPLIANCE WITH THE REGULATIONS IN FORCE.
DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED
WITHIN THE HOME. DO NOT ALLOW CHILDREN TO PLAY WITH PACKAGING
MATERIALS. SEPARATE THE VARIOUS MATERIALS WHICH MAKE UP THE
PACKAGING AND TAKE THEM TO THE NEAREST SORTED WASTE
COLLECTION CENTRE.
THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND
MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE DOOR.
THE NAME PLATE MUST NEVER BE REMOVED.

Installation instructions
3
THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN
ACCORDANCE WITH THE ELECTRICAL SAFETY REGULATIONS IN FORCE.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO
PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO EARTH THE
APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION.
DURING THE INSTALLATION THE APPLIANCE MUST BE DISCONNECTED
FROM THE NETWORK..
DO NOT INSTALL THE APPLIANCE IN A PLACE SUBJECT TO FREEZING.
IF THE APPLIANCE IS INSTALLED ON A CARPET FLOOR, TAKE CARE THAT
THE OPENINGS IN ITS BASE ARE NOT OBSTRUCTED.
DO NOT INSTALL THE APPLIANCE NEAR EQUIPMENT WITH HIGH
IRRADIATION TEMPERATURES (EG. GAS BURNERS, FIREPLACES, ETC.) AS
THEY MAY CAUSE DAMAGE.
IF THE APPLIANCE IS INSTALLED IN A COMPARTMENT ABOVE OR BELOW
ANOTHER EQUIPMENT (EG. GAS BURNERS, OVENS, ETC.), READ
CAREFULLY THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER OF
THE EQUIPMENT. IF THE INSTRUCTIONS OF THE EQUIPMENT DO NOT
CONTAIN INFORMATION, CONTACT THE MANUFACTURER OF THE
EQUIPMENT TO ENSURE THAT THE APPLIANCE CAN BE INSTALLED ABOVE
OR BELOW IT.
BUILDING-IN THE APPLIANCE UNDERNEATH A HOB IS ABSOLUTELY
FORBIDDEN.
INSTALL A HOB ON TOP OF A FREE-STANDING APPLIANCE IS ABSOLUTELY
FORBIDDEN.
TO ENSURE STABILITY, INSTALL THE APPLIANCE ONLY UNDER
CONTINUOUS WORKTOP, SECURELY FIXED TO ADJACENT CABINETS. IF
THE APPLIANCE IS INSTALLED IN A HIGH CABINET BOTH, THE APPLIANCE
AND THE CABINET, MUST BE ADEQUATELY FIXED.
IF THE APPLIANCE IS NOT BUILT-IN AND IS THEREFORE ACCESSIBLE ON
ONE SIDE, THE DOOR HINGE AREA MUST BE COVERED FOR SAFETY
REASON (INJURY HAZARD). THE COVERING FIXTURES ARE AVAILABLE AS
AN ACCESSORY FROM SPECIALIST DEALERS OR THE AFTER-SALES.
CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH
THE RATINGS ON THE NAME PLATE OF THE APPLIANCE.
THE PLUG ON THE SUPPLY CORD AND THE CORRESPONDING SOCKET
OUTLET MUST BE OF THE SAME TYPE AND MEET THE REGULATION IN
FORCE.
DO NOT USE ADAPTORS OR SHUNT CONNECTIONS IN ORDER TO AVOID
THE POSSIBILITY OF OVERHEATING OR BURNING.
THE PLUG OF THE APPLIANCE MUST BE ACCESSIBLE AFTER
INSTALLATION.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER CORD.

Installation instructions
4
IF THE APPLIANCE IS PROVIDED WITH A PLUGLESS SUPPLY CORD, A
CIRCUIT BREAKER PROVIDING A FULL DISCONNECTION IN OVERVOLTAGE
PROTECTION CLASS III MUST BE INSTALLED IN AN EASILY ACCESSIBLE
POSITION ON THE SUPPLY LINE.
THE DISHWASHER MUST ALWAYS BE CONNECTED TO THE WATER
SYSTEM USING NEW HOSE SETS.
IMMEDIATELY AFTER INSTALLING THE DISHWASHER, PERFORM A QUICK
TEST OF THE APPLIANCE. IF THE DISHWASHER FAILS TO OPERATE
CORRECTLY, DISCONNECT IT FROM THE ELECTRICAL POWER SUPPLY
AND CALL THE NEAREST TECHNICAL SERVICE CENTRE. DO NOT ATTEMPT
TO REPAIR THE APPLIANCE.
THE APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING
CHILDREN) WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY
HAVE BEEN GIVEN SUPERVISED OR INSTRUCTION CONCERNING USE OF
THE APPLIANCE BY A RESPONSIBLE PERSON FOR THEIR SAFETY.
YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO
NOT PLAY WITH THE APPLIANCE.
WARNING: SOME DISHWASHER DETERGENTS ARE STRONGLY ALKALINE.
THEY CAN BE EXTREMELY DANGEROUS IF SWALLOWED. AVOID CONTACT
WITH SKIN AND EYES AND KEEP CHILDREN AWAY FROM THE DISHWASHER
WHEN THE DOOR IS OPEN.
KEEP CHILDREN AWAY FROM THE DISHWASHER WHEN THE DOOR IS
OPEN. ALWAYS CHECK THAT THE DETERGENT RECEPTACLE IS EMPTY
AFTER COMPLETION OF THE WASH CYCLE.
DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE
THE DISHES OR APPLIANCE AT THE END OF THE WASHING PROGRAM.
DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE IN
THE APPLIANCE, AS THIS MAY CAUSE AN EXPLOSION.
DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINT.
PLEASE DO NOT LEAVE THE DOOR OPEN AS THIS WILL CAUSE A TRIPPING
HAZARD.
WARNING: KNIVES AND OTHER UTENSILS WITH SHARPS POINTS MUST BE
LOADED IN THE BASKET WITH THE POINTS DOWN OR PLACED IN A
HORIZONTAL POSITION.
THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE
REGULATIONS IN FORCE CONCERNING SAFETY AND ELECTRICAL
EQUIPMENT. ANY TECHNICAL CHECKS SHOULD BE CONDUCTED
EXCLUSIVELY BY TRAINED AND AUTHORISED TECHNICIANS: REPAIRS

Installation instructions
5
CARRIED OUT BY UNAUTHORISED PERSONS WILL INVALIDATE THE
WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE
ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE
MANUFACTURER OR ITS SERVICE AGENT OR A SIMILARLY QUALIFIED
PERSON IN ORDER TO AVOID HAZARD.
SOME COMPONENTS ARE LIVE EVEN WITH THE ON/OFF BUTTON IN THE
OFF POSITION. BEFORE MAINTENANCE WORK ON THE APPLIANCE,
DISCONNECT THE PLUG OR TURN OFF THE MAINS SWITCH IN THE FIXED
WIRING
CLEANING AND REGULAR MAINTENANCE OF THE APPLIANCE BY
CHILDREN IS ONLY PERMITTED UNDER THE SUPERVISION OF A PERSON
RESPONSIBLE FOR THEIR SAFETY.
DO NOT USE STEAM CLEANERS TO CLEAN THE DISHWASHER.
MODELS WITH “AQUASTOP” DEVICE
THE “AQUASTOP” DEVICE PREVENTS FLOODING IN THE EVENT OF A
WATER LEAK. WHEN THE “AQUASTOP” DEVICE IS TRIPPED, CALL IN A
QUALIFIED TECHNICIAN TO IDENTIFY AND REPAIR THE FAULT.
INSIDE THE “AQUASTOP” WATER INTAKE HOSE, THERE ARE ELECTRICAL
PARTS. DO NOT CUT THE HOSE AND DO NOT ALLOW THE “AQUASTOP”
DEVICE TO DROP INTO WATER. IN THE EVENT OF DAMAGE TO THE
“AQUASTOP” WATER INTAKE HOSE, DISCONNECT THE APPLIANCE FROM
THE ELECTRICAL SUPPLY AND FROM THE WATER SUPPLY.
MODELS WITH INTERNAL LIGHTING
THE LIGHTING SYSTEM OF THE APPLIANCE BELONGS TO RISK GROUP 1
UNDER THE IEC/EN 62471 STANDARD. THIS MEANS THAT THERE IS NO
PHOTOBIOLOGICAL RISK IN NORMAL CONDITIONS OF USE.
IN ACCORDANCE TO ART. 26 OF THE LEGISLATIVE DECREE 14 MARCH
2014, NR. 49 “IMPLEMENTATION OF THE DIRECTIVE 2012/19/EU ON WASTE
OF ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)”.
THE SYMBOL OF A CROSSED OUT WHEELIE BIN ON THE DEVICE OR
PACKAGE SHOWS THAT THE PRODUCT MUST BE COLLECTED SEPARATE
FROM OTHER WASTE, AT THE END OF ITS SERVICE LIFE. THEREFORE, THE
USER HAS TO TAKE ANY EQUIPMENT THAT HAS REACHED THE END OF ITS
SERVICE LIFE TO LOCAL WASTE DISPOSAL CENTRES FOR ELECTRICAL
AND ELECTRONIC EQUIPMENT WASTE.
AS AN ALTERNATIVE TO THE IDEPENDENT MANAGEMENT, IT IS POSSIBLE
TO DELIVER THE EQUIPMENT WHICH HAS TO BE DISPOSED OF TO THE
DEALER, AT THE MOMENT OF PURCHASING A NEW EQUIVALENT DEVICE
AT THE ELECTRONIC EQUIPMENT DEALERS WITH A SALES AREA OF AT

Installation instructions
6
LEAST OF 400 M2. ALSO, FOR DISUSED DEVICES WITH DIMENSIONS
INFERIOR TO 25 CM, FREE DELIVERY TO THE DEALERS IS POSSIBLE, WITH
NO PURCHASE OBLIGATION
A PROPER SEPARATE WASTE COLLECTION AND THE CONSEQUENT
HEADING OF THE DISUSED DEVICE TOWARDS ITS RECYCLING, TREATMENT
AND ENVIRONMENTALLY COMPATIBLE DISPOSAL, CONTRIBUTES IN
PREVENTING ANY POSSIBLE NEGATIVE EFFECTS ON ENVIRONMENT AND
HEALTH; ALSO, IT SUPPORTS THE REUSE AND/OR RECYCLE OF THE
MATERIALS WHICH COMPOSED THE DEVICE.
OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE
MAINS POWER CORD AFTER UNPLUGGING IT FROM THE WALL OUTLET,
AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS FOR
CHILDREN (LOCKS, DOORS, CABLES, HOSES, ETC.).
The manufacturer declines all responsibility for damage to persons or property
resulting from failure to observe the above precautions, from tampering with
even a single component of the appliance, or from the use of non original spare
parts.
TECHNICAL DATA
TECHNICAL DATA
Width
597  599 mm
Depth measured flush with the
outer edge of the control panel
Free standing: 600 mm
Semi-integrated: 570 mm
Height (depending on models)
Free standing: from 850 mm to 890 mm
from 890 mm to 930 mm
Semi-integrated: from 820 mm to 890 mm
from 860 mm to 930 mm
Capacity
14 Standard place settings
Water supply pressure
min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar)
Electrical characteristics
See rating plate

Installation instructions
7
2. Installation and hook-up
Remove the polystyrene basket retainers.
Position the appliance in the desired place of installation. The back or
sides of the dishwasher may be placed up against walls or other furniture
units. If the dishwasher is installed near a heat source, fit the special
insulating panel to prevent overheating and malfunction of the appliance.
To ensure stability, install integrated or built-under dishwashers only under
continuous worktops, and screw them to the adjacent units. To facilitate
the installation procedure, the intake and drain hoses can be positioned in
any direction; make sure that the hoses are not kinked, crushed or pulled
too tightly. Make sure to tighten the locking ring-nut once the pipes have
been placed in the direction required. A hole at least 8 cm in diameter is
required to allow the power supply cable and pipes to pass. Before putting
the dishwasher into its definitive position, turn on the water tap and check
that there are no leaks from the tap connection, the dishwasher
connection or the hose.
Level the appliance on the floor using its adjustable feet. This operation is
essential for ensuring correct operation of the dishwasher.
Some models are equipped with only one adjustable foot at the rear, which
can be adjusted by turning the screw on the lower front part of the
appliance.
Building-in a dishwasher underneath a hob is absolutely forbidden.
Moreover, dishwashers may not be installed directly touching appliances
which are not conventional built-in kitchen appliances (e.g. fireplaces,
stoves, etc.).
When installing the dishwasher in a compartment next to one or more other
appliances, it is essential to comply with all the recommendations provided
by the appliance’s manufacturer (minimum distances, installation
procedures, etc.).

Installation instructions
8
2.1 Water supply connection
Preventing the risk of clogging or damage: if the water pipe is new or
has not been used for a long time, before connecting to the water supply
check that the water is clear and free of impurities, to prevent damage to
the appliance.
The dishwasher must always be connected to the water system with
new hoses; old or used hoses must never be reused.
CONNECTING TO THE WATER SUPPLY
Connect the intake hose to a cold water supply with ¾” gas
thread, inserting the filter A supplied with the dishwasher.
Take care to screw the hose firmly into place with your
hands and then complete by tightening about ¼ of a
turn with pliers.
In dishwashers equipped with the ACQUASTOP device,
the filters is already fitted inside the threaded ring.
The dishwasher can also be connected to a hot water supply not exceeding
60°C. Supplying the appliance with hot water cuts down the washing time
by approximately 20 minutes, but slightly reduces its effectiveness. Make
the connection to the domestic hot water supply using the same procedure
described for connecting to the cold water supply.

Installation instructions
9
DRAIN CONNECTION
Insert the dishwasher’s drain hose
into a drain pipe having a diameter
of at least 4 cm, or alternatively,
place it inside the kitchen sink
using the plastic support provided,
taking care not to crush or
excessively bend the hose. It is
important to prevent the hose from
coming loose and falling. For this
purpose, the plastic support is
equipped with a hole for tying it to
the wall or water tap.
The free end should be positioned at a height of between 30 and 100 cm,
and should never be submerged in water. If a horizontal drain extension
hose is used (for a maximum of 3 m) the drain hose can be placed at a
maximum height of 85 cm from the ground.
Class of protection against moisture: IPX0

User instructions
10
3. Description of the controls
3.1 Front panel
All the dishwasher controls are grouped on the front panel. Programming
and option selection are only possible with the door closed.
1
ON/OFF BUTTON AND WARNING LIGHT
2
OPTION SELECTION BUTTONS AND WARNING LIGHTS
3
“CHILD LOCK” ACTIVATION BUTTONS
4
NO RINSE AID LIGHT (some models only)
5
WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT/
SALT WARNIN LIGHT (on some models only)
6
START/PAUSE BUTTON
7
PROGRAM SELECTION BUTTON
8
PROGRAM LIGHTS
9
HANDLE TO OPEN THE DOOR
N.B.: symbols and styling are guideline and may vary depending on
the model or version of the dishwasher purchased.

User instructions
11
PROGRAMS TABLE
PROGRAMME
NUMBER
& SYMBOL
LOAD CROCKERY AND
CUTLERY
PROGRAM
PROGRESS
DURATION
CONSUMPTION
MINUTES
(1)
WATER
LITRES
POWER
kWh (1)
1 SOAK
Pans and dishes awaiting
completion of the load
Cold prewash
15
3,5
0,02
2 NORMAL
ECO (*)
Crockery and cutlery
normally soiled
Cold prewash
Wash at 45°C
Rinse at 45°C
Dry
147
11,3
0,72
3 ECO
Dishes with normal dirt,
even with dried-on
residues.
Wash at 55°C
Cold rinse
Rinse at 70°C
Dry
100
11
1,30
4 NORMAL
Dishes with normal dirt,
even with dried-on
residues
Cold prewash
Wash at 65°C
Rinse at 70°C
Dry
105
13,5
1,35
5 ULTRA
CLEAN
Very dirty pans and
dishes, even with dried-on
residues.
Hot prewash
Wash at 70°C
Cold rinse
Rinse at 70°C
Dry
160
15,5
1,70
The ULTRA CLEAN program terminate with an extra anti-bacteria rinse that ensures a
further reduction in the bacteria level. If the temperature falls during this stage of the
program (e.g. because the door is opened or due to a power blackout), the program
lights flash to warn that the anti-bacteria effect is not guaranteed.
*
Reference program as per AS/NZS 2007.
During the comparative tests the dishwasher shall to be setted as follow:
- At the end of the cycle the door must be opened about 15 cm.
Only run the soak program with partial loads.
(1)
The cycle duration and power consumption may vary according to the water
and room temperatures, and the type and amount of dishes.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.

User instructions
12
3.2 Washing programs
The dishwasher is equipped with a control panel, described in chapter "3.
Description of the controls", from which it is possible to carry out all the
power switch-on, switch-off and programming operations.
Before starting a washing program make sure that:
 The water supply tap is open.
 The correct amount of detergent has been added to the
dispenser.
 The baskets have been correctly loaded.
 The spray arms are able to rotate freely and without
obstruction.
 The dishwasher door is securely closed.
Warning:
during the initial phase of the washing program, the operation of sprayers
is not perceived because they start rotating about 5 minutes after the start.
This is the normal operation of the washing cycle.
SWITCHING ON
When the ON/OFF button (1) is pressed, the dishwasher switches on.
The indicator lights will display the dishwasher's "status".
PROGRAMMING
Programming operations are only possible with the door closed.
As long as the door is open, the PROGRAMS (8) lights remain off.
PROGRAM SELECTION
Press the PROGRAM SELECTION button (7) several times until the light of
the program required comes on.
STARTING THE PROGRAM
To start the dishwasher, press the START/PAUSE button (6) for a few
seconds, until the light of the selected program starts to flash (confirmation
beep).
The light will flash as long as the program is in progress, to indicate that it
is being performed.

User instructions
13
END OF PROGRAM
At the end of the program the beeper sounds briefly and
the program lights 4 and 5 (marked "end") flash.
INTERRUPTION A PROGRAM
To interrupt a program in progress:
 press the START/PAUSE button (6); the light of the program in
progress remains on (confirmation beep);
 you may now restart the program by pressing button (6) again until it
restarts, or change or annul the program (see "CHANGING A PROGRAM",
or "ANNULLING A PROGRAM").
CHANGING A PROGRAM
To change the running program it is necessary:
 to interrupt the running program (see “INTERRUPTION A PROGRAM”);
 select the new program;
 start the program (see “STARTING THE PROGRAM”).
ANNULLING A PROGRAM
To annul the program, keep the START/PAUSE button (6) pressed until
the program is interrupted (light on and confirmation beep).
Press button (6) again and keep it pressed until the
program lights 4 and 5 (marked "end") come on.
The water in the tank will be pumped out and the program will end at the
point where it was interrupted.

User instructions
14
In case that the door is opened during the operation, to the next door
closing it is going to be necessary to start the program as shown in
paragraph “STARTING THE PROGRAM”. The program will resume from the
point in which it was interrupted.
In case that the tub temperature is higher than 50°C the program will
start about 30 seconds later.
OPTION SELECTION
Options are selected by pressing the relative button by the symbol of the
option required; the light comes on to confirm that the option has been
activated.
 It is not possible to select any options when the soak program
is being used.
 All options except "Flexi Tabs" are disabled at the end of the
wash cycle. To disable the “Flexi Tabs” option, press the
relative button (the light goes out).
 All options, including "Flexi Tabs" are disabled when a program
is CANCELLED after it has begun.
PROGRAM DELAY
The PROGRAM DELAY button can be pressed to delay the start of the
washing program by 3, 6 or 9 hours. This function allows you to set the
dishwasher to work at your preferred time of day.
After selecting the delay, start the program (see relative section).
The appliance will prewash the dishes, after which the “program delay” set
previously will come into effect (light indicating the time left before the start
of the program and light indicating the program set flash).
N.B.: It is not possible to select the PROGRAM DELAY option once the
cycle has begun.

User instructions
15
Flexi Tabs
Specifically for washing with combination detergents in tablets, which also
contain salt and rinse aid (3in1) or other agents such as glass protector,
steel rinse aids, etc. (4in1, 5in1…). When this option is selected, salt and
rinse aid will not be dispensed even if the relative compartments contain
them. If the containers are empty, the lights will remain on.
With short programs, because there is less time for them to dissolve,
tablets may fail to wash effectively and undissolved residues may be left.
Powder detergents are more suitable for these programs.
If the option is not provided, we recommend the use of conventional
products (separate detergent, salt and rinse aid), because with
conventional washing cycles, combined products might create problems
such as a white deposit, poor drying results and residues left on dishes.
For further information, refer to the detergent pack.
IMPORTANT:
when no longer required, the option must be deactivated by pressing the
relative button (the light goes out).
These products are not suitable for use with excessively “hard” water.
If the hardness level set is higher than H3, when the option is activated
the relative light flashes to indicate that the product is being used
incorrectly; the dishwasher will still work, but washing results may be
poor.
“CHILD LOCK” OPTION
By pressing the indicated buttons (3) at the same time, the controls are
locked, which is confirmed by the flashing ON/OFF (1) warning light. This
option stays active (and the warning light keeps flashing) until the buttons
(3) are pressed again.

User instructions
16
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
 Always try to run the dishwasher fully loaded.
 Do not wash the dishes in running water.
 Use the washing program that is most appropriate for each type of
load.
 Do not carry out any preliminary rinsing.
 If available, connect the dishwasher to a hot water supply up to 60°C.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to save
on electricity, observe the following:
 separate the more delicate items from dishes that are more resistant
to aggressive detergents and high temperatures;
 do not pour the detergent directly on the dishes.
ENERGY MANAGEMENT
At the end of the program, afterwards 5 minutes, the washing machine
switches off automatically in order to reduce standby power consumption.
In order to switch it on again, it is necessary to press the ON/OFF button.
REMOVING THE DISHES
At the end of the washing program, wait at least 20 minutes before
removing the dishes, to allow them to cool down. To prevent any water
droplets on the upper basket from falling on the dishes in the lower basket,
it is advisable to unload the lower basket first, and then the upper basket.

User instructions
17
4. Operating instructions
Once the dishwasher has been correctly installed, prepare for use as
follows:
 Adjust the water softening system (on some models only);
 Add the regenerating salt (on some models only);
 Add the rinse aid and detergent.
4.1 Using the water softening system
(on some models only)
The amount of scale contained in the water
(water hardness index) can cause whitish
staining on the dry dishes, which tend to
become dull over time. The dishwasher is
equipped with an automatic softening
system which uses a special regenerating
salt to reduce the hardness of the water.
The dishwasher is factory set for water
hardness level 3 (average hardness).
When using water of medium hardness, the regenerating salt container
should be refilled after approximately 20 washing cycles. The salt
container can hold approximately 1.7 Kg of salt in grains. The container is
situated at the bottom of the dishwasher. After removing the lower basket,
unscrew the salt container cap by turning it anticlockwise and pour in the
salt using the funnel supplied with the dishwasher. Before replacing the
cap, remove any salt residues from around the opening.
 When using the dishwasher for the first time, in addition to the salt it
is also necessary to add one litre of water to the container.
 Each time the salt container is refilled, make sure that the cap is
securely closed. The mixture of water and detergent must never
penetrate the salt container, as this would compromise the operation
of the regeneration system. In the event of this occurring, the warranty
will be invalidated.
 Only use regenerating salt specially formulated for domestic
dishwashers. If using salt tablets, do not fill the container
completely.
SALE
SALT

User instructions
18
 Do not use table salt as it contains insoluble substances which, over
time, may damage the water softening system.
 When necessary, refill the regenerating salt container before
starting the washing program. In this way, the excess saline
solution will be immediately removed by the water; the prolonged
presence of salt water inside the tank may lead to corrosion.
Be careful not to confuse the salt and detergent packages; adding
detergent to the salt container will damage the water softening system.
ADJUSTING THE WATER SOFTENING SYSTEM
The dishwasher is equipped with a device which allows the softener
setting to be varied to suit the hardness of the mains water. The hardness
is set using the PROGRAM SELECTION BUTTON (5).
To access the setting function, hold the button down for more than 15
seconds. The WATER HARDNESS ADJUSTMENT INDICATOR LIGHT
flashes, while the SELECTED PROGRAM INDICATOR LIGHTS (6)
show the current setting. Each pressure on the button changes the
setting following the sequence in the table below:
>

User instructions
19
WATER HARDNESS TABLE
WATER HARDNESS
SETTING
German
degrees (°dH)
French
Degrees (°dF)
0 - 6
0 - 11
All lights off
(no salt)
7 - 10
12 - 18
One light on
11 - 15
19 - 27
Two lights on
16 - 21
28 - 37
Three lights on
22 - 28
38 - 50
Four lights on
29 - 35
51 - 62
Five lights on
36 - 50
63 - 90
Two lights on
Contact your local water board for information on the hardness of your
water supply.
After adjustment or display of the current setting, simply do not touch the
button for a few seconds; the dishwasher will automatically return to
standard mode, quitting the adjustment mode.
4.2 Using the rinse aid and detergent dispensers
The detergent and rinse aid
dispensers are situated on the inner
part of the door: the detergent
dispenser is on the left, and the rinse
aid dispenser is on the right.
With the exception of the SOAK program, before every washing cycle it is
necessary to add the required amount of detergent to the detergent
dispenser. The rinse aid, on the other hand, should only be added as
required.

User instructions
20
ADDING THE RINSE AID
The rinse aid helps the dishes dry faster and
prevents the formation of scale deposits and
staining; it is automatically added to the water
during the final rinse cycle, from the container
situated on the inner side of the door.
To add rinse aid:
 Open the door.
 Rotate the container cap anticlockwise by ¼ of a turn and remove it.
 Add the rinse aid until the container is full (approximately 140 cc). The
optical level indicator on the side of the cap should be completely
obscured. Refill the rinse aid when the optical level indicator becomes
clear again, or when the rinse aid warning light illuminates.
 Replace the cover and turn it in a clockwise direction.
 Use a cloth to remove any spillage of rinse aid which might lead to
the formation of excess foam.
ADJUSTING THE RINSE AID DISPENSER SETTING
The dishwasher is factory set for medium water hardness. However it
possible to change the setting by turning the dispenser’s selector to the
desired position: the amount of rinse aid dispensed is proportional to the
selector position.
 To adjust the rinse aid setting, rotate the dispenser cap through a
quarter turn in an anticlockwise direction and remove it.
 Then use a screwdriver to rotate the rinse aid selector to the desired
position.
 Replace the cap, turning it clockwise.
 The amount of rinse aid must be increased if the washed dishes
appear dull or feature circular stains.
 If, on the other hand, the dishes are sticky or have white streaks, it is
necessary to reduce the rinse aid setting.
