Smeg STFABUBL-1 User manual

Contents
1
1. Safety and operating instructions __________________________ 2
2. Installation and hook-up _________________________________ 7
3. Description of the controls ______________________________ 11
4. Operating instructions __________________________________ 20
5. Cleaning and maintenance ______________________________ 37
6. Troubleshooting ______________________________________ 43
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use of
your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
Recommendations are given for the correct use of the baskets, spray
arms, containers, filters, washing programs, and for operating the controls.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
This user-friendly manual will provide answers to all your questions about
use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified
technician who must carry out the installation, hook-up and testing of the
appliance.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.

User instructions
2
1. Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE; IT MUST
ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER FOR FUTIRE
REFERENCE. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE
INSTRUCTIONS CONTAINED IN THIS MANUAL. THEY CONTAIN IMPORTANT
INFORMATION FOR THE INSTALLATION, USE AND MAINTENANCE OF THE
APPLIANCE. IN THE EVENT OF SALE OR TRANSFER, ENSURE THAT THE
MANUAL ALWAYS ACCOMPANIES THE APPLIANCE.
THIS APPLIANCE IS INTENDED FOR INDOOR USE IN A HOUSEHOLD
ENVIRONMENT AND SIMILAR SUCH AS STAFF KITCHENS OF SHOPS,
OFFICES AND OTHER WORKPLACES, INSTITUTIONS, AND FOR THE USE BY
GUESTS AT HOTELS, HOSTELS, BED AND BREAKFAST AND OTHER
RESIDENTIAL FACILITIES.
THIS APPLIANCE MUST NOT BE INSTALLED AND USED IN NON-STATIONARY
PLACES (FOR EXAMPLE ON SHIPS, MOTOR CARAVANS, CARAVANS……
.).
THIS APPLIANCE COMPLIES WITH DIRECTIVES 2006/95/EC AND
2004/108/EC CURRENTLY IN FORCE, INCLUDING THE PREVENTION AND
ELIMINATION OF RADIO FREQUENCY INTERFERENCE AND IS DESIGNED
FOR THE FOLLOWING PURPOSE: WASHING AND DRYING OF DISHES; ANY
OTHER USE SHALL BE CONSIDERED IMPROPER. THE MANUFACTURER
DECLINES ALL RESPONSIBILITY FOR USES OTHER THAN THOSE
DESCRIBED ABOVE.
DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING TRANSIT!
IF IN DOUBT, CONSULT YOUR DEALER.
THE APPLIANCE MUST BE INSTALLED AND CONNECTED IN ACCORDANCE
WITH THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER.
INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN
COMPLIANCE WITH THE REGULATIONS IN FORCE.
DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED
WITHIN THE HOME. DO NOT ALLOW CHILDREN TO PLAY WITH PACKAGING
MATERIALS. SEPARATE THE VARIOUS MATERIALS WHICH MAKE UP THE
PACKAGING AND TAKE THEM TO THE NEAREST SORTED WASTE
COLLECTION CENTRE.
THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND
MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE DOOR.
THE NAME PLATE MUST NEVER BE REMOVED.
THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN
ACCORDANCE WITH THE ELECTRICAL SAFETY REGULATIONS IN FORCE.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO
PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO EARTH THE
APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION.

User instructions
3
DURING THE INSTALLATION THE APPLIANCE MUST BE DISCONNECTED
FROM THE
NETWORK..
DO NOT INSTALL THE APPLIANCE IN A PLACE SUBJ
ECT TO FREEZING.
IF THE APPLIANCE IS INSTALLED ON A CARPETED OR COVERED FLOOR,
ENSURE THAT THE OPENINGS ON ITS UNDERSIDE ARE NOT OBSTRUCTED.
DO NOT INSTALL THE APPLIANCE NEAR EQUIPMENT WITH HIGH
IRRADIATION TEMPERATURES (EG. GAS BURNERS, FIREPLACES, ETC.) AS
THEY MAY CAUSE DAMAGE.
IF THE APPLIANCE IS INSTALLED IN A COMPARTMENT ABOVE OR BELOW
ANOTHER EQUIPMENT (EG. GAS BURNERS, OVENS, ETC.), READ
CAREFULLY THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER OF
THE EQUIPMENT. IF THE INSTRUCTIONS OF THE EQUIPMENT DO NOT
CONTAIN INFORMATION, CONTACT THE MANUFACTURER OF THE
EQUIPMENT TO ENSURE THAT THE APPLIANCE CAN BE INSTALLED ABOVE
OR BELOW IT.
BUILDING-IN THE APPLIANCE UNDERNEATH A HOB IS ABSOLUTELY
FORBIDDEN.
INSTALL A HOB ON TOP OF A FREE-STANDING APPLIANCE IS ABSOLUTELY
FORBIDDEN.
TO ENSURE STABILITY, INSTALL THE APPLIANCE ONLY UNDER
CONTINUOUS WORKTOP, SECURELY FIXED TO ADJACENT CABINETS. IF
THE APPLIANCE IS INSTALLED IN A HIGH CABINET BOTH, THE APPLIANCE
AND THE CABINET, MUST BE ADEQUATELY FIX
ED.
IF THE APPLIANCE IS NOT BUILT-IN AND IS THEREFORE ACCESSIBLE ON
ONE SIDE, THE DOOR HINGE AREA MUST BE COVERED FOR SAFETY
REASON (INJURY HAZARD). THE COVERING FIXTURES ARE AVAILABLE AS
AN ACCESSORY FROM SPECIALIST DEALERS OR THE AFTER
-
SALES.
CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH
THE RATINGS ON THE NAME PLATE OF THE APPLIANCE.
THE PLUG ON THE SUPPLY CORD AND THE CORRESPONDING SOCKET
OUTLET MUST BE OF THE SAME TYPE AND MEET THE REGULATION IN
FORCE.
DO NOT USE ADAPTORS OR SHUNT CONNECTIONS IN ORDER TO AVOID
THE POSSIBILITY OF OVERHEATING OR BURNING.
THE PLUG OF THE APPLIANCE MUST BE ACCESSIBLE AFTER
INSTALLATION.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER CORD.
IF THE APPLIANCE IS PROVIDED WITH A PLUGLESS SUPPLY CORD, A
CIRCUIT BREAKER PROVIDING A FULL DISCONNECTION IN OVERVOLTAGE
PROTECTION CLASS III MUST BE INSTALLED IN AN EASILY ACCESSIBLE
POSITION ON THE SUPPLY LINE.

User instructions
4
THE APPLIANCE MUST BE CONNECTED TO THE WATER SUPPLY BY NEW
HOSES; OLD HOSES MUST NEVER
BE REUSED.
IMMEDIATELY AFTER INSTALLING THE DISHWASHER, PERFORM A QUICK
TEST OF THE APPLIANCE. IF THE DISHWASHER FAILS TO OPERATE
CORRECTLY, DISCONNECT IT FROM THE ELECTRICAL POWER SUPPLY
AND CALL THE NEAREST TECHNICAL SERVICE CENTRE. DO NOT ATTEMPT
TO
REPAIR THE APPLIANCE.
THIS DISHWASHER MUST BE USED BY ADULTS. USE OF THE APPLIANCE
BY CHILDREN AGED FROM EIGHT YEARS AND PERSONS WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IS ONLY PERMITTED UNDER THE SUPERVISION OF A
PERSON RESPONSIBLE FOR THEIR SAFETY.
DO NOT ALLOW CHILDREN TO PLAY
WITH THE APPLIANCE.
SOME DETERGENTS ARE STRONGLY ALKALINE. AVOID CONTACT WITH
THE SKIN AND EYES. DETERGENTS CAN BE EXTREMELY DANGEROUS IF
SWALLOWED. THEY CONTAIN SUBSTANCES CAPABLE OF CAUSING
PERMANENT DAMAGE TO THE MOUTH AND THROAT, AND EVEN LEADING
TO SUFFOCATION. OBSERVE ALL THE SAFETY INSTRUCTIONS ON THE
PACKAGING OF THESE PRODUCTS.
KEEP CHILDREN AWAY FROM THE DISHWASHER WHEN THE DOOR IS
OPEN. ALWAYS CHECK THAT THE DETERGENT RECEPTACLE IS EMPTY
AFTER COMPLETION OF THE WASH CYCLE.
DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE
THE DISHES OR APPLIANCE AT THE END OF THE WASHING PROGRAM.
DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE IN
THE APPLIANCE, AS THIS MAY CAUSE AN EXPLOSION.
DO NOT LOAD DISHES
THAT ARE SOILED WITH ASH, WAX OR PAINT.
NEVER LEAVE THE DISHWASHER DOOR OPEN; PEOPLE MIGHT TRIP OVER
IT.
LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY
CAUSE THE APPLIANCE TO OV
ERTURN.
DO NOT INTRODUCE ANIMALS INTO THE DISHWASHER
KNIVES OR OTHER SHARP-ENDED COOKING TOOLS MUST BE PLACED IN
THE CUTLERY BASKET BLADE-DOWN, OR LAID HORIZONTAL IN THE TOP
BASKET. TAKE CARE NOT TO CUT YOURSELF AND ENSURE THAT THEY DO
NOT PROJECT
FROM THE BASKET.

User instructions
5
THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE
REGULATIONS IN FORCE CONCERNING SAFETY AND ELECTRICAL
EQUIPMENT. ANY TECHNICAL CHECKS SHOULD BE CONDUCTED
EXCLUSIVELY BY TRAINED AND AUTHORISED TECHNICIANS: REPAIRS
CARRIED OUT BY UNAUTHORISED PERSONS WILL INVALIDATE THE
WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE
ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP.
IN THE EVENT OF DAMAGE TO THE SUPPLY CORD, HAVE IT REPLACED BY
THE MANUFACTURER OR AN AUTHORIZED TECHNICAL SERVICE CENTRE.
IN CERTAIN SITUATIONS, HYDROGEN MAY BE GENERATED INSIDE A HOT
WATER SYSTEM THAT HAS NOT BEEN USED FOR TWO WEEKS. HYDROGEN
IS AN EXPLOSIVE GAS. IF THE HOT WATER SYSTEM HAS NOT BEEN USED
FOR TWO WEEKS OR MORE, OPEN ALL THE HOT WATER TAPS AND ALLOW
THE WATER TO RUN FOR A FEW MINUTES BEFORE USING THE
DISHWASHER. THIS WILL DISCHARGE ANY HYDROGEN BUILDUPS. AS THIS
GAS IS FLAMMABLE, DO NOT SMOKE OR USE NAKED FLAMES WHILE
PE
RFORMING THIS OPERATION.
TWO PEOPLE WEARING SAFETY GLOVES ARE REQUIRED TO MOVE THE
DISHWASHER
DURING INSTALLATION, TAKE CARE NOT TO INJURE YOURSELF ON THE
SHARP EDGES OF THE APPLIANCE; WEAR SAFETY GLOVES
SOME COMPONENTS ARE LIVE EVEN WITH THE ON/OFF BUTTON IN THE
OFF POSITION. BEFORE MAINTENANCE WORK ON THE APPLIANCE,
DISCONNECT THE PLUG OR TURN OFF THE MAINS SWITCH IN THE FIXED
WIRING
CLEANING AND REGULAR MAINTENANCE OF THE APPLIANCE BY
CHILDREN IS ONLY PERMITTED UNDER THE SUPERVISION OF A PERSON
RESPONSIBLE FOR THEIR SAFETY.
DO NOT USE STEAM CLEANERS TO
CLEAN THE DISHWASHER.
MODELS WITH “AQUASTOP” DEVICE
THE “AQUASTOP” DEVICE PREVENTS FLOODING IN THE EVENT OF A
WATER LEAK. WHEN THE “AQUASTOP” DEVICE IS TRIPPED, CALL IN A
QUALIFIED TECHNICIAN TO IDENTIFY AND REPAIR THE FAULT.
INSIDE THE “AQUASTOP” WATER INTAKE HOSE, THERE ARE ELECTRICAL
PARTS. DO NOT CUT THE HOSE AND DO NOT ALLOW THE “AQUASTOP”
DEVICE TO DROP INTO WATER. IN THE EVENT OF DAMAGE TO THE
“AQUASTOP” WATER INTAKE HOSE, DISCONNECT THE APPLIANCE FROM
THE ELECTRICAL SUPPLY AND FROM THE WATER SUPPLY.
WARNING:
THE DEVICE ONLY WORKS IF THE DISHWASHER IS CONNECTED TO THE
MAINS POWER SUPPLY
.

User instructions
6
MODELS WITH INTERNAL LIGHTING
THE LIGHTING SYSTEM OF THE APPLIANCE BELONGS TO RISK GROUP 1
UNDER THE IEC/EN 62471 STANDARD. THIS MEANS THAT THERE IS NO
PHOTOBIOLOGICAL RISK IN NORMAL CONDITIONS OF USE.
OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE
MAINS POWER CORD AFTER UNPLUGGING IT FROM THE WALL OUTLET,
AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS FOR
CHILDREN (LOCKS, DOORS, CABLES, HOSES, ETC.).
The manufacturer declines all responsibility for damage to persons or property
resulting from failure to observe the above precautions, from tampering with
even a single component of the appliance, or from the use of non original spare
parts.
TECHNICAL DATA
Width 597

599 mm
Depth
5
8
5
-
630
mm
Height
from 8
18
mm to 8
88
mm
Capacity 13 Standard place settings
Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar)
Electrical characteristics
See rating plate

User instructions
7
2. Installation and hook-up
Remove the polystyrene basket retainers.
Position the appliance in the desired place of installation. The back or
sides of the dishwasher may be placed up against walls or other furniture
units. If the dishwasher is installed near a heat source, fit the special
insulating panel to prevent overheating and malfunction of the appliance.
To ensure stability, install integrated or built-under dishwashers only under
continuous worktops, and screw them to the adjacent units. To facilitate
the installation procedure, the intake and drain hoses can be positioned in
any direction; make sure that the hoses are not kinked, crushed or pulled
too tightly. Make sure to tighten the locking ring-nut once the pipes have
been placed in the direction required. A hole at least 8 cm in diameter is
required to allow the power supply cable and pipes to pass. Before putting
the dishwasher into its definitive position, turn on the water tap and check
that there are no leaks from the tap connection, the dishwasher
connection or the hose.
Level the appliance on the floor using the appropriate Allen key to regulate
the adjustable feet. This operation is essential for ensuring correct
operation of the dishwasher.
Some models are equipped with only one adjustable foot at the rear, which
can be adjusted by turning the screw on the lower front part of the
appliance.
Building-in a dishwasher underneath a hob is absolutely forbidden.
Moreover, dishwashers may not be installed directly touching appliances
which are not conventional built-in kitchen appliances (e.g. fireplaces,
stoves, etc.).
When installing the dishwasher in a compartment next to one or more other
appliances, it is essential to comply with all the recommendations provided
by the appliance’s manufacturer (minimum distances, installation
procedures, etc.).
For free-standing models only:
- Installing a hob on top of a free-standing dishwasher is absolutely
forbidden.
- To build in the dishwasher, the special kit must be purchased from
authorised dealers or the After-Sales Service.
- The tops of free-standing dishwashers can be removed to allow them to
be installed underneath a worktop. This procedure must be carried
ou
t by authorised staff.

User instructions
8
2.1 Water supply connection
Preventing the risk of clogging or damage: if the water pipe is new or
has not been used for a long time, before connecting to the water supply
check that the water is clear and free of impurities, to prevent damage to
the appliance.
The dishwasher must always be connected to the water system with
new hoses; old or used hoses must never be reused.
CONNECTING TO THE WATER SUPPLY
Connect the intake hose to a cold water supply with ¾” gas
thread, inserting the filter A supplied with the dishwasher.
Take care to screw the hose firmly into place with your
hands and then complete by tightening about ¼ of
a
turn with pliers.
In dishwashers equipped with the ACQUASTOP device,
the filters is already fitted inside the threaded ring.
The dishwasher can also be connected to a hot water supply not exceeding
60°C. Supplying the appliance with hot water cuts down the washing time
by approximately 20 minutes, but slightly reduces its effectiveness. Make
the connection to the domestic hot water supply using the same procedure
described for connecting to the cold water supply.

User instructions
9
DRAIN CONNECTION
Insert the dishwasher’s drain hose
into a drain pipe having a diameter
of at least 4 cm, or alternatively,
place it inside the kitchen sink
using the plastic support provided,
taking care not to crush or
excessively bend the hose. It is
important to prevent the hose from
coming loose and falling. For this
purpose, the plastic support is
equipped with a hole for tying it to
the wall or water tap.
The free end should be positioned at a height of between 30 and 100 cm,
and should never be submerged in water. If a horizontal drain extension
hose is used (for a maximum of 3 m) the drain hose can be placed at a
maximum height of
85 cm
from the ground.
Class of protection against moisture: IPX0

User instructions
10
2.2 Electrical connection and precautions
CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH
THE RATINGS ON THE NAME PLATE OF THE APPLIANCE POSITIONED ON
THE INNER EDGE OF THE DOOR.
THE PLUG ON THE SUPPLY CORD AND THE CORRESPONDING SOCKET
OUTLET MUST BE OF THE SAME TYPE AND MEET THE REGULATIONS IN
FORCE.
THE PLUG MUST BE ACCESSIBLE AFTER INSTALLATION.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER SUPPLY
LEAD.
AFTER CHANGING THE SUPPLY CORD, MAKE SURE THAT THE BRACKET
WHICH SECURES THE CORD IS FIXED SECURELY IN PLACE.
DO NOT USE ADAPTORS OR SHUNT CONNECTIONS IN ORDER TO AVOID
THE POSSIBILITY OF OVERHEATING OR BURNING.
In the event of damage to the supply cord, have it replaced by the
manufacturer or an Authorized Technical Service Centre in order to
avoid any risk.
Some components are live even with the ON/OFF button in the OFF position.
Before maintenance work on the appliance, remove the plug or turn off the
power supply at the wall switch.

User instructions
11
3. Description of the controls
3.1 Upper panel
All the dishwasher controls are grouped on the upper panel. Switch-on,
programming, switch-off, etc. procedures are only possible when the door
is open.
1 ON/OFF BUTTON
Press this button to switch the dishwasher on/off.
2
SELECTED PROGRAM INDICATOR LIGHTS
Illumination of this light denotes the program selected and the
occurrence of a fault (troubleshooting).
3 PROGRAM SELECTION BUTTON
Press this button to select the required washing program.
4 SALT INDICATOR LIGHT
When lit, it indicates that the salt container is empty.
5 RINSE AID INDICATOR LIGHT
When lit, it indicates that the rinse aid dispenser is empty.
6 PROGRAM DELAY BUTTON
Press this button to delay the start of the program.
7 INFORMATION DISPLAY
8 OPTIONS
9 SANITATION INDICATOR LIGHT
Shows that sanitation has been completed.

User instructions
12
Information displayed
Scheduled program duration no
Remaining program time no
Delayed start 1 - 9 hours
Error message
E
SETTING THE WASHING PROGRAM AND SWITCHING ON
After identifying the most suitable program with the aid of the programs
table:
 Press the ON/OFF button (1) and wait for the PROGRAM
INDICATOR LIGHT (2) to illuminate;
 Keep pressing the PROGRAM SELECTION button (3) until the
indicator light corresponding to the desired program illuminates;
 select the option required (if any and if the model provides options);
 close the door; after about 2" the program will start LIGHT will
flashing (indicating that the program is being executed).

User instructions
13
PROGRAMS TABLE
PROGRAMME
NUMBER
& SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
DURATION
CONSUMPTION
MINUTES
(1)
WATER
POWER
KWh (1)
1 RAPID 27’
Dishes with light dirt,
washed immediately
after use
Wash at 38°C (100°F)
Rinse at 50°C (122°F) 27 7.5l
1.98gal.
0,40
2 CRYSTAL
Glass, china and
mixed dishes with light
dirt.
Wash at 45°C (113°F)
Cold rinse
Rinse at 70°C (158°F)
Dry
70 12l
3.17gal.
0.5
2 AUTO
DELICATE (2)
Normally soiled dishes
including dried-on
residues, for daily use.
Wash at 45°C (113°F)
Cold rinse
Rinse at 64°C (147°F)
Dry
130-150 10.6l
2.8gal. 0.5-0.6
4 WASH PLUS
Mixed dishes very
dirty, including dried-
on residues.
Cold prewash
Wash at 65°C (149°F)
Cold rinse
Rinse at 70°C (158°F)
Dry
110 15l
3.96gal.
1.00
5 EXTREME
WASH
ETL
SANITATION
LISTED
Mixed dishes very dirty
and pans dirty,
including dried-on
residues.
Cold prewash
Wash at 70°C (149°F)
2 cold rinses
Rinse at 70°C (158°F)
Dry
110 16l
4.23gal.
1.2
1 – The cycle times and electrical energy listed use and care manual are based on
normal soil loads and 120°F (49°C) incoming water and will vary based on your actual
conditions.
2 – Program for energy star.
Only “EXTREME WASH” program conforms to NSF std 184 and is certified by
INTERTEK with the ETL SANITATION LISTED.
When the “Sanitized” light shine it means that the dishwasher and its contents have
been sanitized according to the requirements of the National Sanitation
Foundation (NSF).
If the dishwasher door is open or not properly closed, the washing cycle
will not start.

User instructions
14
QUICK TIME PROGRAMS
(see relevant section for explanation of functioning modes)
PROGRAMME
NUMBER E
SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
DURATION CONSUMPTION
MINUTI
(1)
WATER
LITRES POWER
KWh (1)
6 RINSE’
+
Pans and dishes
awaiting completion
of the load
Cold prewash 15 3.5l
0.95gal.
0,02
7 DELICATE
QUICK
+
Dishes with light dirt.
Cold prewash
Wash at 50°C (122°F)
Cold rinse
Rinse at 70°C (158°F)
60 15l
3.96gal.
1.00
8 ECO QUICK
+
Dishes with normal
dirt, washed
immediately after
use.
Cold prewash
Wash at 60°C (140°F)
Cold rinse
Rinse at 70°C (158°F)
80 15l
3.96gal.
1.20
9 NORMAL
QUICK
+
Dishes with normal
dirt, washed
immediately after
use.
Cold prewash
Wash at 70°C (158°F)
Cold rinse
Rinse at 70°C (158°F)
75 15l
3.96gal.
1.30
10 STRONG
and FAST
+
Mixed dishes with
normal dirt without
dried-on residues.
Wash at 65°C (149°F)
Cold rinse
Rinse at 70°C (158°F)
50 12l
3.17gal.
1,12
1 – The cycle times and electrical energy listed use and care manual are based on
normal soil loads and 120°F (49°C) incoming water and will vary based on your actual
conditions.
If the dishwasher door is open or not properly closed, the washing cycle
will not start.

User instructions
15
3.2 Washing programs
Before starting a washing program make sure that:
 The water supply tap is open.
 The softener container contains regenerating salt.
 The correct amount of detergent has been added to the
dispenser.
 The baskets have been correctly loaded.
 The spray arms are able to rotate freely and without
obstruction.
 The dishwasher door is securely closed.
Warning:
during the initial phase of the washing program, the operation of sprayers
is not perceived because they start rotating about 5 minutes after the start.
This is the normal operation of the washing cycle.
3.3 Switching on
Press the on/off button to start the dishwasher. Then wait for one of the
program indicator light to turn on.
IMPORTANT
The door of the dishwasher must ble closed within 4 seconds after use
of the program selection button for all functions (e.g. program selection,
change, delection, etc.). If the door is not closed within 4 seconds, one or
more program lights (depending on the current opertaion) will flash at
high speed to indicate that the operation must be confirmed before the
door is closed.
To confirm, simply press the program selection button once and the
flashes will slow down; close the door an once to start/restart the
dishwasher.
The same applies if the dishwasher is opened with the program delay
option set and the cycle not started (e.g. to add more dishes): the
program selection button must be pressed before the door is closed,
restarting the program delay countdown.
If the door of the diishwashehas not been closed or has been incorrectly
closed, the washing cycle will not begin.

User instructions
16
OPTION SELECTION
Options are selected by pressing the relative button by the symbol of the
option required; the light comes on to confirm that the option has been
activated.
 It is not possible to select any options when the soak program
is being used.
 All options except "Flexi Tabs" are disabled at the end of the
wash cycle.
 To disable the “Flexi Tabs” option, press the relative button
(the light goes out).
 All options, including "Flexi Tabs" are disabled when a program
is
CANCELLED
after it has begun.
QUICK TIME OPTION
Select this option together with any washing program (except the soak
program) to SHORTEN the cycle. To activate this option, press button (light
comes on) after selecting the program required.
The option is automatically deactivated at the end of the program.
1/2 LOAD FLEXI ZONE
Ideal if just a few dishes need to be washed, allowing energy savings. The
dishes should be placed in both baskets and less detergent should be
placed in the detergent dispenser compared to the amount used for a full
load.
DELAYED START
The start of the washing program can be delayed to program the dishwasher
to operate at the preferred time of day (e.g. overnight). Press the
PROGRAM DELAY button to activate the option and display a 1 hour
delay. Keep pressing to select the delay required, which may be up to 9, 12
or 24 hours depending on the model.
When the door is closed, the appliance will prewash the dishes, after
which the "program delay" set will come into effect.

User instructions
17
Flexi Tabs
Specifically for washing with combination detergents in tablets, which also
contain salt and rinse aid (3in1) or other agents such as glass protector,
steel rinse aids, etc. (4in1, 5in1…). When this option is selected, salt and
rinse aid will not be dispensed even if the relative compartments contain
them. If the containers are empty, the lights will remain on.
If the option is not provided, we recommend the use of conventional
products (separate detergent, salt and rinse aid), because with
conventional washing cycles, combined products might create problems
such as a white deposit, poor drying results and residues left on dishes.
For further information, refer to the detergent pack.
IMPORTANT:
when no longer required, the option must be deactivated by pressing the
relative
button
(the light goes out).
These products are not suitable for use with excessively “hard” water.
If the hardness level set is higher than H3, when the option is activated
the relative light flashes to indicate that the product is being used
incorrectly; the dishwasher will still work, but washing results may be
poor
.
CANCELLING THE CURRENT PROGRAM
 To cancel the currently selected program open the door and hold
down the PROGRAM SELECTION (3) button for a few seconds until
the indicator lights for programs 4 and 5 illuminate simultaneously
(marked "end").
 Close the door.
 After approximately 1 minute the dishwasher will advance to the end
of cycle.
CHANGING THE PROGRAM
To change the program in progress, simply open the door and select a
new program. When the door is closed the dishwasher will automatically
select the new program.

User instructions
18
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
 Always use the dishwasher with a full load.
 Do not wash the dishes in running water.
 Use the washing program that is most appropriate for each type of
load.
 Do not carry out any preliminary rinsing.
 If available, connect the dishwasher to a hot water supply up to 60°C.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to save
on electricity, observe the following:
 separate the more delicate items from dishes that are more resistant
to aggressive detergents and high temperatures;
 do not pour the detergent directly on the dishes.
If the door has to be opened while washing is in progress, the program will
be interrupted. The relative light will keep flashing and a beeper will signal
that the cycle has not been completed. You must wait about 1 minute
before closing the door to restart the program. When the door is closed
the program will continue from where it was interrupted. This operation
should only be carried out if strictly necessary, because it might cause
problems in execution of the program.

User instructions
19
SWITCHING OFF
At the end of the program the beeper sounds
briefly and the lights of programs no. 4 and 5
(marked "end") flash.
To switch off the dishwasher, open the door and press the ON/OFF button
(1)
.
ENERGY MANAGEMENT
After 5 minutes of waiting (washing cycle completed, stopped or set but
not started) the dishwasher switches to a standby state to reduce energy
consumption.
In this state, the dishwasher indicator panel (lights or display depending
on model) functions more slowly (
switch
-
on once
every
5 seconds
).
REMOVING THE DISHES
At the end of the washing program, wait at least 20 minutes before
removing the dishes, to allow them to cool. To ensure that any drops of
water left in the top basket cannot drip onto the dishes still in the bottom
basket, you are advised always to
empty the bottom basket first
.

User instructions
20
4. Operating instructions
Once the dishwasher has been correctly installed, prepare for use as
follows:
 Adjust the water softening system;
 Add the regenerating salt;
 Add the rinse aid and detergent.
4.1 Using the water softening system
The amount of scale contained in the water
(water hardness index) can cause whitish
staining on the dry dishes, which tend to
become dull over time. The dishwasher is
equipped with an automatic softening
system which uses a special regenerating
salt to reduce the hardness of the water.
When using water of medium hardness, the regenerating salt container
should be refilled after approximately 20 washing cycles. The salt
container can hold approximately 1 Kg of salt in grains. Some models are
equipped with an optical no-salt indicator. In these models, the cap of the
salt container contains a green float which descends as the salt
concentration in the water drops. When the green float can no longer be
seen through the transparent cap, the container must be topped up with
regenerating salt. The container is situated at the bottom of the
dishwasher. After removing the lower basket, unscrew the salt container
cap by turning it anticlockwise and pour in the salt using the funnel
supplied with the dishwasher. Before replacing the cap, remove any salt
residues from around the opening.
 When using the dishwasher for the first time, in addition to the salt it
is also necessary to add one litre of water to the container.
 Each time the salt container is refilled, make sure that the cap is
securely closed. The mixture of water and detergent must never
penetrate the salt container, as this would compromise the operation
of the regeneration system. In the event of this occurring, the warranty
will be invalidated.
 Only use regenerating salt specially formulated for domestic
dishwashers. If using salt tablets, do not fill the container
completely.
SALT
