Smeg SE332EB User manual

PRECAUTIONS - 2191477A870/A
e
PRECAUTIONS 21
General safety instructions 21
Installation 24
Appliance purpose 25
This user manual 25
Manufacturer’s liability 25
Identification plate 25
Disposal 25
To save energy 26
How to read the user manual 26
DESCRIPTION 26
General description 26
Control panel 28
USE 28
Preliminary operations 28
Basic functions 28
Using the hob 28
CLEANING AND MAINTENANCE 33
Cleaning the glass ceramic hob 33
What to do if... 33
INSTALLATION 34
Electrical connection 34
Section cut from the countertop 35
Mounting 36
Fixing to the built-in cabinet 37
Fixing brackets 37
Testing 37
Instructions for the installer 37
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• The appliance becomes very
hot during use. Take care never
to touch the heating elements.
• Protect your hands by using
oven gloves when handling hot
pans.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children below the age
of 8 away from the appliance
unless they are constantly
supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Be aware of how rapidly the

22 - PRECAUTIONS 91477A870/A
cooking zones heat up. Do not
place empty pans on the heat.
Danger of overheating.
• After use the cooking zones
remain hot for a certain period
of time after they have been
turned off. Do not touch the hob
surfaces.
• The cooking process must
always kept under control. A
short cooking process must be
continuously monitored.
• WARNING: Leaving food that
contains fat and/ oil
unattended when cooking can
be dangerous and can cause a
fire. DO NOT attempt to
extinguish a fire with water. Turn
off the appliance and smother
the flames, for example with a
lid or a blanket.
• Do not use the Booster and/or
the Double Booster functions (if
present) to heat fats or oils. Fire
hazard.
• Do not place metal objects,
such as dishes or cutlery, on the
surface of the hob during
cooking as they may overheat.
• Do not cook foods in closed
tins or containers or plastic
containers.
• Do not insert pointed metal
objects (cutlery or utensils) into
the slots in the appliance.
• Do not use or store flammable
materials near the appliance.
• Do not pour water directly onto
very hot trays.
• If you need to move food or at
the end of cooking, open the
door 5 cm for a few seconds,
let the steam come out, then
open it fully.
• Switch off the appliance
immediately after use.
• Do not pull the cable to unplug
the appliance (if present).
• DO NOT USE OR STORE
FLAMMABLE MATERIALS IN
THE STORAGE
COMPARTMENT (IF
AVAILABLE) OR NEAR THE
APPLIANCE.
•DONOTUSEAEROSOLSIN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Always wear personal
protective equipment (PPE)
before carrying out any work
on the appliance (installation,
maintenance, positioning or
moving).
• Do not clean the appliance if it
is still hot or in operation.
• Before performing any work on
the appliance, switch off the
power supply.
• WARNING: Make sure that
the appliance has been
switched off and disconnected
from the mains power supply or
that the mains power has been
switched off before replacing
the interior lighting bulbs.

PRECAUTIONS - 2391477A870/A
e
• The bulbs used in this
appliance are specific for
household appliances; do not
use them for home lighting.
• Do not try to repair the
appliance yourself or without
the assistance of a qualified
technician.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• If cracks or fissures form, or if
the glass ceramic cooking
surface breaks, turn off the
appliance immediately.
Disconnect the power supply
and call Technical Support.
• Do not touch or clean the hob
surface during operation or
when the residual heat
indicator lights are still on.
• Activate the controls lock when
you have children or pets that
could reach the hob.
• Supervise children carefully as
they cannot readily see the
indication of residual heat. After
use the cooking zones remain
hot for a certain period of time
even if they have been turned
off. Keep children away from
the cooking zones.
• The appliance is not intended
to operate with external timers
or remote-control systems.
• WARNING: Only use a
protective shield designed by
the manufacturer of the cooking
appliance. The use of
inadequate protective shields
can lead to accidents.
Risk of damaging the appliance
• Do not use harsh or abrasive
detergents or sharp metal
scrapers to clean the glass
door of the oven since they
may scratch the surface and
cause the glass to shatter.
• Use wooden or plastic utensils.
• Do not use steam jets to clean
the appliance.
• Do not use the appliance as a
support surface.
• Do not obstruct ventilation
openings and heat dispersal
slots.
• Do not sit on the appliance.
• Never leave the appliance
unattended during cooking
operations that could lead to
oils and fats overheating and
catching fire. Be very careful
• Risk of fire: Do not store objects
on the cooking surfaces.
• Do not spray any product near
the appliance.
• DO NOT FOR ANY REASON
USE THE APPLIANCE AS A
SPACE HEATER.
• Do not use plastic kitchenware
or containers for cooking.

24 - PRECAUTIONS 91477A870/A
• Cooking vessels or griddle
plates should be placed inside
the perimeter of the hob.
• All pans must have smooth, flat
bottoms.
• If any liquid does boil over or
spill, remove the excess from
the hob.
• Take care not to spill acid
substances such as lemon juice
or vinegar on the hob.
• Do not spill sugar or sweet
mixtures on the hob during
cooking.
• Do not place materials or
substances that could melt or
catch fire (paper, plastic or
aluminium foil) on the
appliance while it is in use.
• Do not use steam jets to clean
the appliance.
• Place the cookware directly on
the glass ceramic surface.
• Do not put empty pans or frying
pans on switched on cooking
zones.
• Do not use rough or abrasive
materials or sharp metal
scrapers.
• Do not use cleaning products
containing chlorine, ammonia
or bleach on parts made of
steel or that have metallic
surface finishes (e.g. anodizing,
nickel- or chromium-plating).
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges) on glass parts.
• The glass ceramic surface is
highly resistant to impacts.
However, avoid hard, solid
objects falling on the cooking
surface as they may cause it to
break.
• Keep sensor buttons clean at
all times and do not place any
object on them.
Installation
• THIS APPLIANCE MUST NOT
BE INSTALLED IN A BOAT OR
CARAVAN.
• This appliance must not be
installed on a pedestal.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Check that the cabinet has the
required slots.
• Check that the cabinet material
is heat resistant.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• Have the electrical connection
performed by authorised
technical personnel.
• The appliance must be
connected to earth in
compliance with electrical
system safety standards.
• Use cables withstanding a

PRECAUTIONS - 2591477A870/A
e
temperature of at least 90 °C.
• The tightening torque of the
screws of the terminal supply
wires must be 1.5 - 2 Nm.
• Be careful when connecting
additional electrical
appliances. Connection cables
must not come into contact with
hot cooking zones.
• The power cable must only be
installed or replaced by a
qualified technician.
• Allow the appliance to be
disconnected after installation,
via an accessible plug or a
switch in the case of a fixed
connection.
• Fit the power line with an all-
pole circuit breaker with a
contact separation distance
sufficient to provide complete
disconnection in category III
overvoltage conditions,
pursuant to installation
regulations.
• This appliance can be used up
to a maximum altitude of 2,000
metres above sea level.
Appliance purpose
This appliance is intended for
cooking food in the home
environment. Every other use is
considered inappropriate. It
cannot be used:
• in employee kitchens, shops,
offices and other working
environments.
• in farms/farmhouses.
• by guests in hotels, motels and
residential environments.
• In bed and breakfast
accommodation.
This user manual
• This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user's reach for the
whole working life of the appliance.
• Read this user manual carefully before using
the appliance.
• The explanations in this manual include
images, which describe all that regularly
appears on the display. However, it should
be kept in mind that the appliance may be
equipped with an updated version of the
system, and as such, all that appears on the
display may differ from those in the manual.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
specified;
• failure to comply with the instructions in the
user manual;
• tampering with any part of the appliance;
• use of non-original spare parts.
Identification plate
The identification plate bears the technical data,
serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances in
quantities sufficient to be considered hazardous
to health and the environment, in accordance
with current European directives.
To dispose of the appliance:
• Cut the power cable and remove it.
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.

26 - DESCRIPTION 91477A870/A
• Deliver the appliance to the appropriate
recycling centre for electrical and electronic
equipment waste, or return it to the retailer
when purchasing an equivalent product, on
a one for one basis.
Our appliances are packaged in non-polluting
and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
To save energy
• The diameter of the base of the pan must not
extend beyond the lines printed on the glass
ceramic surface.
• Pans must not be placed outside the
perimeter of the hob or on the display.
• When buying a pan, check whether the
diameter indicated is that of the base or the
top of the pan, as the top is almost always
larger than the base.
• When preparing dishes with long cooking
times, you can save time and energy by
using a pressure cooker, which also helps to
retain vitamins contained in the food.
• Make sure that the pressure cooker contains
enough liquid as, if there is not enough and
it overheats, this may cause damage to both
the pressure cooker and the cooking zone.
• If possible, always cover pans with a
suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
How to read the user manual
This user manual uses the following reading
conventions:
DESCRIPTION
General description
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part of it
unattended.
• Do not let children play with the plastic
bags.
Under certain circumstances, if the hob
and the oven are used at the same time,
the maximum power limit of the
electrical system might be exceeded.
Warning/Caution
Information/Advice
30

DESCRIPTION - 2791477A870/A
e
60
77
90
Zone Outer diameter
(mm)
Maximum
power draw
(W)*
Inside diameter
(mm)
Maximum
power draw
(W)*
Middle
diameter (mm)
Maximum
power draw
(W)*
1 148 1200 - - - -
2 184 2000 124 800 - -
3 184 1800 - - - -
4 288 2700 150 1950 216 1050

28 - USE 91477A870/A
*Power levels are approximate and may vary according to the settings made and the mains voltage.
Control panel
Symbols
Cooking zones
USE
Preliminary operations
• Remove any protective film from the outside
or inside of the appliance, including any
accessories (if present).
• Remove any labels (apart from the technical
data plate).
Basic functions
First power connection
When connected to the power supply for the
first time, or after power has been switched
back on after a power failure, an automatic
check is carried out that control turns on the
indicator lights and the displays for a few
seconds. Afterwards, the appliance can be
used normally.
Switching on and off
To switch on the hob, hold down the ON/OFF
key for 1 second.
If no cooking zone is activated within 5 seconds
of switching on, the hob switches off
automatically.
Using the hob
Switching on a single cooking zone
1. After switching on the hob, use the Increase
button to activate the required cooking
zone. The symbol appears on the
display.
5 214 2200 148 1000 - -
6 oval plate 2200 170 1400 - -
71992000----
8 184 1700 124 700 - -
9 oval plate 2000 148 1100 - -
Zone Outer diameter
(mm)
Maximum
power draw
(W)*
Inside diameter
(mm)
Maximum
power draw
(W)*
Middle
diameter (mm)
Maximum
power draw
(W)*
ON/OFF button
Turns the hob on or off.
Control lock button
Activates or deactivates the controls lock
if pressed for 3 seconds.
Increase button
Increases the power level or cooking
time.
Decrease button
Reduces the power level or cooking
time.
Timer button
Activates the timer for the automatic
shutdown/minute minder function.
Front left
Rear left
Central
Rear right
Front right
Central right
Front (30 cm model only)
Rear (30 cm model only)
See General safety instructions.

USE - 2991477A870/A
e
2. Press the Increase button again .
The or symbol appears on the
display to indicate that the cooking zone is
on at maximum power.
3. Press the Increase or Decrease
buttons to increase or decrease the power
level.
Switching on the double / triple cooking
zone
1. After setting the maximum power
or , press the Increase buttons. An
illuminated dot appears on the display next
to the power setting to indicate that the
internal cooking zone or is on.
For a triple cooking zone (if present)
2. Press the Increase button again to
completely activate the cooking zone. The
illuminated dot flashes on the display next to
the power setting to indicate that the entire
cooking zone or is on.
To modify the power level (both zones)
3. Use the Increase and Decrease
buttons to increase or decrease the power
level.
Melting function
To activate the Melting function, first turn on the
hob, then:
1. After having set the power to press the
Increase button . appears on the
display.
2. Press the increase button again .
appears on the display.
Residual heat
If the cooking zone is still hot after being
switched off, the symbol will be displayed
on the display.
Accelerator
This function can be used to reach the selected
heating level more quickly. The cooking zones
will start at maximum power. Once the selected
power level is reached, power is reduced.
1. Use the Increase and Decrease
buttons to select a power level ranging
between 1 and 9 (also in double or triple
mode).
2. Press the Increase and Decrease
buttons simultaneously for the cooking zone
on which you wish to activate the
accelerator function. The display alternately
shows and the power level that has just
been selected.
Controls lock
The controls lock is a device that protects the
appliance from accidental or inappropriate use.
Useful for preventing accidental changes to set
cooking values, the lock can be activated while
the hob is on or off.
When the cooking zone is off ( ), it
cannot be activated by pressing the
Decrease button.
If the Increase button is pressed when
the cooking zone is on maximum
power, the cooking
zone switches off.
If the Increase button is pressed when
the cooking zone is on maximum
power, the cooking
zone switches off.
This function can be used to melt food
such as butter and chocolate.
Power level Heating times with the
function activated (min)
12
23
34
45
56
67
78
810
912

30 - USE 91477A870/A
1. After switching on the hob, press the
Controls lock button for at least 2
seconds. An illuminated dot appears on the
button to indicate that the controls are
locked. Pressing any button will
cause or to be
displayed (depending on the model).
2. Press the Controls lock button for at
least 2 seconds. The lighted dot above the
symbol switches off to indicate that the
controls have been unlocked and any
button can be pressed.
Minute minder timer (on some models only)
This function allows you to set a minute minder
timer, which will sound a buzzer at the end of
the pre-set time (from 1 to 99 minutes).
1. Press the Timer button when the
appliance is off. appears on the
display to indicate that the timer can be
modified.
2. Use the and buttons to set the
required minute minder time (press and hold
to set the time more quickly).
3. At the end of the set time, the hob will warn
the user with a series of buzzers. To stop this
buzzer, press the Timer button .
4. To deactivate the minute minder timer
during the countdown, zero its value using
the Decrease button . When
appears on the display, the timer is
deactivated.
Automatic shut-down timer (on some models
only)
This function allows you to set a minute minder
timer, which will sound a buzzer at the end of
the pre-set time (from 1 to 99 minutes).
1. Press the Timer button when the
appliance is off. The display shows
to indicate that the timer can be modified.
2. Press the Timer button again. If at least
one cooking zone is active a lighted dot
comes on under the controls of the first
active zone (from left to right).
3. Use the Increase and Decrease
buttons to set the required automatic shut-
down time (hold the buttons down to
advance more quickly), or select an
additional cooking zone using the
Timer button.
4. To modify the set time, press the Timer
button until an illuminated dot appears
under the controls of the cooking zone for
which you wish to make the modification.
5. At the end of the previously set time, the hob
deactivates the cooking zone and warns the
user with a series of buzzes. Press any
button to stop the indication.
Secondary menu
The hob has a secondary menu for activating or
deactivating certain parameters:
1 = Automatic controls lock: activating this mode
will cause the controls lock to activate
automatically one minute after the last operation
by the user.
2 = Showroom: activating this mode will cause
the appliance to deactivate all the heating
elements, while keeping the control panel active
(useful for in-store demonstration purposes).
Every minute, appears for one
second on the display. To use the hob normally,
set this mode to .
3 = ECO-Logic (on some models only):
when activating this mode, the hob electronics
will automatically adjust the power levels to stay
within the set maximum power draw: 3 or 4 kW.
To use the hob at maximum power, this mode
has to be set to .
When installing for the first time, within two
minutes of turning powering on to the hob, hold
down the Increase and Decrease
buttons for the first cooking zone (the one near
For safety reasons the ON/OFF
button remains active with at least
one cooking zone switched on. The
entire hob can be switched off at any
time, even if the controls lock is active.
If the automatic shut-down timer is
activated and no cooking zone is active
it functions like a minute minder timer.

USE - 3191477A870/A
e
the symbol).
The cooking zone display shows the number of
the setting currently being modified (1 =
Automatic controls lock, 2 = Showroom, 3 =
ECO-logic) with its setting at the side ( :
activated, : deactivated).
For example, indicates that the
automatic controls Lock is deactivated.
Press the Increase or Decrease buttons
to change the settings to or . If the
ECO-logic parameter is modified you can
select the following values (3 kW), (4
kW), (maximum power draw).
To change the subsequent settings, press the
Controls lock button .
Advice on energy-saving
The diameter of the base of the pan must
correspond to the diameter of the cooking zone.
• When buying a pot, check whether the
diameter indicated is that of the base or the
top,
as the top is almost always larger than the base.
• The base of the cookware must be thick and
completely flat. In addition, the hob should
be clean and dry as well.
• When preparing dishes with long cooking
times, you can save time and energy by
using a pressure cooker, which also makes it
possible to preserve the vitamins in the food.
• Make sure that the pressure cooker contains
enough liquid as, if there is not enough and
it overheats, this may cause damage to both
the pressure cooker and the cooking zone.
• If possible, always cover the pans with a
suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
• Do not use cast-iron cookware or cookware
with a rough base.
If the hob is already installed and in use,
cut the power supply to the hob. Switch
the power back on and proceed as
indicated above within two minutes.
If hob and oven are being used at the
same time, under certain conditions the
maximum power limit that can be used
by your electrical system might be
exceeded.

32 - USE 91477A870/A
Cooking information table
Limiting the cooking duration
The hob has an automatic device which limits
the duration of use.
If the cooking zone settings are not changed,
the maximum duration of operation for each
zone depends on the power level selected.
When the device for limiting the duration of use
is activated, the cooking zone turns off, a short
beep will be emitted and, if the zone is hot,
the symbol appears on the display.
Protection from overheating
If you are using the hob at full power for a long
time, for the electronics it could be difficult to
cool down, especially if the room temperature is
high.
In this case, a device activates to disconnect the
power to the front cooking zones,
and flash on the display.
If the temperature of the electronic circuit board
does not decrease, the device will disconnect
power to all the cooking zones
and will appear on the display
(on some models only).
Cooking can be resumed once the temperature
returns below alarm levels.
Other functions
If you press three or more controls at the same
time or for a long period, (e.g. due to
accidentally placing a saucepan on them or
due to an overflow of liquid), an automatic
device deactivates all the cooking zones, if they
are on, and the display will show error .
Power lev-
el Cooking mode Suitable for...
0 OFF setting Off
U Dishwarming Warming up dishes
1Cooking small amounts of food (mini-
mum power) Melting butter, chocolate or similar products.
2 Cooking small amounts of food Keeping small amounts of water on the boil, whisk
egg yolk sauces or butter
3-4 Normal cooking
Heating solid or liquid food, keeping water on the
boil, defrosting deep-frozen food, cooking 2 or 3 egg
omelettes, fruit and vegetable dishes, various cook-
ing processes
5 Cooking large amounts of food
Keeping water on the boil, cooking 4 or 6 egg
omelettes, fruit and vegetable dishes, various cooking
processes
6 Cooking large amounts of food, roast Stewing meat, fish and vegetables, simmering food,
making jams, etc.
7-8 Roasting larger pieces, frying with flour Roasting meat, fish, steaks and liver; sautéing meat, fish,
eggs, etc.
9-P Roasting, browning, cooking (maximum
power)
Deep-frying potatoes, etc., or bringing water to the boil
rapidly.
Power level Maximum cooking time (min)
U 600
1 600
2 360
3 300
4 240
5 180
6 120
7 120
8 120
970
P70

CLEANING AND MAINTENANCE - 3391477A870/A
e
CLEANING AND MAINTENANCE
Cleaning the glass ceramic hob
Cleaning the surfaces
To keep the surfaces in good condition, they
should be cleaned regularly after use. Let them
cool first.
Ordinary daily cleaning
Always and only use specific products that do
not contain abrasives or chlorine-based acids.
Pour the product onto a damp cloth and wipe
the surface, rinse thoroughly and dry with a soft
cloth or a microfibre cloth.
Weekly cleaning
Clean and maintain the hob once a week using
an ordinary glass ceramic cleaning product.
Always follow the manufacturer’s instructions.
The silicon in these products creates a
protective, water-repellent membrane which
also resists dirt. All marks stay on the membrane
and can therefore be removed easily. After
cleaning, dry the surface with a clean cloth.
Make sure that there is no detergent left on the
cooking surface as it might undergo an
aggressive reaction when heated up and could
modify the structure of the cooking surface.
Food stains or residues
Light coloured marks from pans with aluminium
bases can be easily cleaned off with a cloth
moistened in vinegar. Remove any burnt-on
residues after cooking; then rinse with water and
dry thoroughly with a clean cloth. Dirt, which
may have fallen on the hob while cleaning
lettuce or potatoes, can scratch the hob when
moving pans. Consequently, remove any dirt
from the cooking surface immediately. Changes
in colour do not affect the operation and
stability of the glass. These are not alterations to
the material of the hob but just residues which
have not been removed and have then
carbonised. Shiny surfaces can form due to the
bases of pans, especially aluminium ones,
rubbing on the surface, and due to the use of
unsuitable detergents. They are difficult to
remove using conventional cleaning products. It
may be necessary to repeat the cleaning
process several times. Use of corrosive
detergents or rubbing of pan bases can wear
away the decoration on the hob over time and
contribute to the formation of stains.
What to do if...
The hob does not work:
• Make sure that the hob is connected and
that the main switch is turned on.
• Make sure that there is no power failure.
• Make sure that the fuse has not blown. In
this case replace the fuse.
• Make sure that the circuit breaker of the
residential electrical system has not tripped.
In this case, reset the circuit breaker.
The cooking results are unsatisfactory:
• Make sure that the cooking temperature is
not too high or too low.
• Make sure that the hob has proper
ventilation and that the air intakes are
completely free.
The hob smokes:
• Let the hob cool down and clean it once
cooking is complete.
• Make sure that the food has not spilled out
of the pan and use a larger cooking vessel,
if needed.
The fuses blow or the circuit breaker of the
residential electrical system trips repeatedly.
• Call Technical Support or an electrician.
There are cracks or fissures in the hob:
• Turn off the appliance immediately,
disconnect the power supply and contact
Technical Support.
See General safety instructions.
In case of stubborn dirt, clean when
cold using a damp kitchen sponge and
neutral detergent; then dry with a
microfibre cloth.
We recommend the use of cleaning
products distributed by the
manufacturer.
After cleaning, dry the appliance
thoroughly to prevent any water or
detergent from interfering with its
operation or creating unsightly marks.

34 - INSTALLATION 91477A870/A
INSTALLATION
Electrical connection
General information
Check the mains characteristics against the data
indicated on the plate.
The identification plate bearing the technical
data, serial number and brand name is visibly
positioned on the appliance.
Do not remove this plate for any reason.
The appliance must be connected to ground
using a wire that is at least 20 mm longer than
the other wires.
Terminal block connection
Arrange the cables in an orderly manner to
avoid overlapping or contact with any jumpers.
The cables must be of the correct length to
avoid build-up/twisting inside the terminal box.
The appliance can work in the following modes:
30 cm models:
60 cm models:
See General safety instructions.
220-240 V 1N~
3 x 1.5 mm ²
three-core cable
220-240 V 1N~
5 x 2.5 mm ²
five-core cable
220-240 V 2~
5 x 2.5 mm ²
five-core cable
220-240 V 3~
5 x 2.5 mm ²
five-core cable
380-415 V 2N~
5 x 2.5 mm ²
five-core cable
The aforementioned power cables are
sized taking into account the
coincidence factor (in compliance with
standard EN 60335-2-6).
Always use the jumper provided, if any,
for each connection; terminals 2 and 3,
4 and 5 must always be connected.

INSTALLATION - 3591477A870/A
e
60 - 77 - 90 cm models:
60 - 90 cm models (limited to 3 kW)
Section cut from the countertop
Safety instructions for positioning and
installation
• Installation can be carried out on various
materials such as masonry, metal, solid
wood or plastic laminated wood as long as
they are heat resistant (>90°C).
• Veneers, adhesives or plastic coatings on
adjacent furniture should be temperature-
resistant (>90°C), otherwise they might
warp over time.
• If the piece of furniture does not have the
required recess opening, either it will have
to be cut or masonry work carried out by a
competent technician.
• The minimum clearance between exhaust
hoods and the cooking surface must be at
least the distance indicated in the exhaust
hood installation instructions.
• The minimum clearances must also be
respected for the edges of the hob on the
back as indicated in the assembly
instructions.
• If the appliance is to be installed above an
oven, the oven must be fitted with a cooling
fan.
Appliance overall dimensions (mm)
with frame:
with bevelled edge:
with straight edge:
For this kind of hobs additional milling is needed
in the recessed hole if you wish to install the hob
flush with the work surface.
220-240 V 1N~
3 x 6 mm ²
three-core cable
220-240 V 2~
3 x 6 mm ²
three-core cable
380-415 V 2N~
4 x 4 mm ²
four-core cable
220-240 V 3~
4 x 4 mm ²
four-core cable
380-415 V 3N~
5 x 2.5 mm ²
five-core cable
Always use the jumper provided, if any,
for each connection; terminals 4 and 5
must always be connected.
220-240 V 1N~
3 x 1.5 mm ²
three-core cable
See General safety instructions.
A B C D E
min. 50 min. 460 min. 750 20÷60 min. 50
L X Y
570 560 500
760 750 500
L X Y
300 270 490
600 565 490
770 745 490
900 850 490
L X Y G H
600 565 490 604 514
770 745 490 774 514
900 865 490 904 514

36 - INSTALLATION 91477A870/A
Hob seal
To prevent leakage of liquid between the frame
of the hob and the countertop, place the
adhesive seal provided along the entire outer
edge of the hob before assembly.
In the case of flush mounting, after placing the
adhesive seal (A) on the glass surface and after
positioning and securing the hob, fill the edges
with insulating silicone (B) and wipe off any
excess. If for any reason the hob needs to be
removed, cut the silicone using a cutter before
attempting to remove it (C).
Mounting
On top of oven built-in unit
The clearance between the hob and the kitchen
furniture or other installed appliances must be
enough to ensure sufficient ventilation and air
discharge. If installed above an oven, a space
must be left between the bottom of the hob and
the top of the appliance installed below.
On top of empty kitchen unit or drawers
If there are other pieces of furniture (lateral
walls,
drawers, etc.), dishwashers or fridges under the
hob, a double-layer wooden base must be
installed at least 20 mm from the bottom of the
hob to avoid any accidental contact. It must
only be possible to remove the double-layer
base using suitable equipment.
opens on bottom:
Do not use silicone to secure the hob.
This would make it impossible to remove
the hob without damaging it.

INSTALLATION - 3791477A870/A
e
opens on rear:
Fixing to the built-in cabinet
To ensure the hob is fixed and centred as
accurately as possible, the clips provided must
be positioned as described below:
1. Fit the clips by gently pressing them
horizontally into the appropriate space.
2. Then turn them upwards to fix them in place.
Fixing brackets
Screw the mounting brackets into the holes on
the sides of the bottom casing to fasten the hob
correctly to the structure.
Fixed connection
Fit the power line with an all-pole circuit breaker
with a contact separation distance sufficient to
provide complete disconnection in category III
overvoltage conditions, pursuant to installation
regulations.
For the Australian/New Zealand market:
The circuit breaker incorporated in the fixed
connection must comply with AS/NZS 3000.
Testing
At the end of installation, carry out a brief
inspection test. If it fails to work, after making
sure that you have carried out the instructions
correctly, contact Technical Support.
Instructions for the installer
• If you use a plug (if present) to connect to
the power supply, the plug must be
accessible after installation.
• Do not bend or trap the power cable.
• The appliance must be installed according
to the installation diagrams.
• If the appliance does not work correctly
after having carried out all the checks,
contact your local Authorised Service
Centre.
• Once the appliance has been installed,
please explain to the user how to use it
correctly.
Failure to install the double-layer
wooden base exposes the user to
possible accidental contact with sharp
or hot parts.
If installed on top of an oven, the latter
must be equipped with a cooling fan.
The clips should not be installed at the
front of the appliance.
If tightened too much the glass may be
strained and crack.
