Smeg SI1M4954D User manual

Contents
41
EN
1Instructions 42
1.1 General safety instructions 42
1.2 Appliance purpose 46
1.6 Disposal 46
1.7 How to read the user manual 47
2 Description 48
2.1 General description 48
2.2 Control panel 49
3Use 51
3.1 Instructions 51
3.2 Preliminary operations 52
3.3 Using the hob 52
3.4 Additional functions 60
3.5 Special functions 63
3.6 Settings menu 64
3.7 User menu 66
3.8 Error codes 69
4 Cleaning and maintenance 70
4.1 Instructions 70
4.2 Cleaning the surfaces 70
4.3 Ordinary weekly cleaning 70
4.4 Food stains or residues 70
4.5 What to do if... 71
5Installation 72
5.1 Electrical connection 72
5.2 Instructions for the installer 73
5.3 Safety instructions 73
5.4 Power limitation 74
5.5 Section cut from the countertop 74
5.6 Mounting 75
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
These instructions apply only for the destination countries listed on the appliance's data
plate. This is a class 3 built-in hob.
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance’s aesthetic and functional qualities. For further information on the
product: www.smeg.com

Instructions
42
1 Instructions
1.1 General safety instructions
Risk of personal injury
• During use the appliance and its
accessible parts become very hot.
• Never touch the heating elements
during use.
• Protect your hands by wearing
heat-proof gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the flames
with a fire blanket or other
appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use of
electrical appliances, provided
that they are supervised or
instructed by adults who are
responsible for their safety.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of 8
away from the appliance when it
is in use.
• Cleaning and maintenance must
not be carried out by
unsupervised children.
• Be aware of how rapidly the
cooking zones heat up. Do not let
pans heat up when dry, as there is
a danger of them overheating.
• Fats and oils can catch fire if they
overheat. Do not leave the
appliance unattended while
preparing foods containing oils or
fats. If fats or oils catch fire, never
put water on them. Place the lid
on the pan and turn off the
relevant cooking zone.
• Do not use the Booster and
Double Booster functions to heat
fats or oils. Fire hazard.
• Place the cookware directly on
the glass ceramic. Do not put any
papers, cloths or trivets beyond
the pot. Risk of burning!
• The cooking process must always
be monitored. A short cooking
process must be continuously
monitored.
• Do not place metal objects, such
as dishes or cutlery, on the hob
surface during use as they may
overheat.
• Do not insert pointed metal
objects (cutlery or utensils) into the
slots in the appliance.
• Do not pour water directly onto
very hot trays.

Instructions
43
EN
• Do not use or store flammable
materials near the appliance or
directly underneath the hob.
• DO NOT USE AEROSOLS IN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• Switch off the appliance
immediately after use.
• DO NOT MODIFY THIS
APPLIANCE.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Before performing any work on
the appliance, switch off the
power supply.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• Do not try to repair the appliance
yourself or without the assistance
of a qualified technician.
• If the power supply cable is
damaged, contact technical
support immediately and they will
replace it.
Risk of damaging the appliance
• Do not use abrasive or corrosive
detergents (e.g. scouring
powders, stain removers and
metallic sponges) on glass parts.
• Use wooden or plastic utensils.
• Do not sit on the appliance.
• Do not use the hob as a support
surface.
• Do not obstruct ventilation
openings and heat dispersal slots.
• Do not use steam jets to clean the
appliance.
• The cookware’s bottom should be
as even as possible. An air gap
(e. g. stamped imprints with the
manufacturer’s logo in the center
point) may cause damages (e. g.
deformed bottom surfaces due to
overheating).
• Never leave the appliance
unattended during cooking
operations where fats or oils
could be released, as these could
then heat up and catch fire. Be
very careful.
• Fire hazard: Never leave objects
on the cooking surfaces.
• DO NOT FOR ANY REASON
USE THE APPLIANCE AS A
SPACE HEATER.
• Cooking vessels or griddle plates
should be placed inside the
perimeter of the hob.

Instructions
44
• All pans must have smooth, flat
bottoms.
• If any liquid does boil over or spill,
remove the excess from the hob.
• Take care not to spill acid
substances such as lemon juice or
vinegar on the hob.
• Do not spill sugar or sweet
mixtures on the hob during
cooking.
• Do not place materials or
substances that could melt or
catch fire (paper, plastic or
aluminium foil) on the appliance
while it is in use.
• Place the cookware directly on
the glass ceramic surface.
• Do not put empty pans or frying
pans on switched on cooking
zones.
• Do not use rough or abrasive
materials or sharp metal scrapers.
• Do not use cleaning products
containing chlorine, ammonia or
bleach on parts made of steel or
that have metallic surface finishes
(e.g. anodizing, nickel- or
chromium-plating).
Installation
• THIS APPLIANCE MUST NOT BE
INSTALLED IN BOATS OR
CARAVANS.
• Position the appliance into the
cabinet cut-out with the help of a
second person.
• Check that the carcase material is
heat resistant.
• Check that the carcase has the
required openings.
• To avoid potential overheating,
the appliance must not be
installed behind a decorative
door or a panel.
• Have the electrical connection
performed by authorised
technical personnel.
• Use a flexible and heat-resistant
connection cord. Apply wire end
ferrules to the cable ends before
connecting them to the generator.
• The appliance must be connected
to earth in compliance with
electrical system safety standards.
• Use cables that can withstand
temperatures of at least 90 °C.
• The tightening torque of the
screws of the terminal supply
wires must be 1.5 - 2 Nm.
• The power cable must only be
installed or replaced by a
qualified technician.

Instructions
45
EN
For this appliance
• If cracks or fissures form, or if the
glass ceramic cooking surface
breaks, turn off the appliance
immediately. Disconnect the
power supply and call Technical
Support.
• Avoid hard, solid objects falling
on the cooking surface.
• Do not use the hob if the pyrolytic
cycle is taking place inside any
oven installed below.
• Do not touch or clean the hob
surface during operation or when
the residual heat indicator lights
are still on.
• Activate the controls lock when
you have children or pets which
could reach the hob.
• After use the cooking zones
remain hot for a certain period of
time after they have been turned
off. Do not touch the hob surfaces.
• After use, switch off the plates.
Never rely solely on the
cookware detector.
• Do not use the glass ceramic
cooking surface as a support
surface.
• Remove any traces of liquid from
the cover (if fitted) before
opening.
• Supervise children carefully as
they cannot readily see the
residual heat indication. After use
the cooking zones remain hot for
a certain period of time even if
they have been turned off. Keep
children away from the cooking
zones.
• The glass ceramic surface is
highly resistant to impact.
However, prevent hard, solid
objects from falling on the
cooking surface as they may
cause it to break if they are sharp.
• Let the cooking surface cool
down before closing the cover.
• People who have pacemakers or
other similar devices fitted must
make sure that the operation of
these devices is not affected by
the induction field, the frequency
range of which is between 20
and 50 kHz.
• In conformity with the provisions
regarding electromagnetic
compatibility, the electromagnetic
induction cooking hob comes under
group 2 and class B (EN 55011).

Instructions
46
• This appliance complies with the
current standards and directives
regarding safety and
electromagnetic compatibility. It is
however recommended for
pacemaker wearers to maintain a
minimum distance of 20-30 cm
between the appliance when it is
operating and the pacemaker.
Consult the pacemaker
manufacturer for more information.
1.2 Appliance purpose
• This appliance is intended for
cooking food in the home
environment. Every other use is
considered improper.
• The appliance is not designed to
operate with external timers or
with remote-control systems.
1.3 Manufacturer’s liability
• The manufacturer declines all
liability for damage to persons or
property caused by:
• Use of the appliance other than
that specified
• Failure to comply with the
instructions in the user manual
• Tampering with any part of the
appliance
• The use of non-original spare
parts.
1.4 Identification plate
The identification plate bears the
technical data, serial number and
brand name of the appliance. Do not
remove the identification plate for
any reason.
1.5 This user manual
This user manual is an integral part of
the appliance and must therefore be
kept in its entirety and within the
user’s reach for the whole working
life of the appliance.
• Read this user manual carefully
before using the appliance.
1.6 Disposal
This appliance conforms to the
WEEE European directive
(2012/19/EU) and must be
disposed of separately from other
waste at the end of its service life.
The appliance does not contain
substances in quantities sufficient to
be considered hazardous to health
and the environment, in accordance
with current European directives.
To dispose of the appliance:
• Cut the power supply cable and
remove it along with the plug.
Power voltage
Danger of electrocution
• Disconnect the mains power
supply.
• Unplug the appliance.

Instructions
47
EN
• Deliver the appliance to the
appropriate recycling centre for
electrical and electronic
equipment waste, or return it to
the retailer when purchasing an
equivalent product, on a one for
one basis.
Our appliances are packaged in
non-polluting and recyclable
materials.
• Deliver the packing materials to
the appropriate recycling centre.
1.7 How to read the user manual
This user manual uses the following reading
conventions:
1. Sequence of instructions for use.
• Standalone instruction.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or
any part of it unattended.
• Do not let children play with the
plastic bags.
Instructions
General information on this user
manual, on safety and final
disposal.
Description
Description of the appliance and its
accessories.
Use
Information on the use of the
appliance and its accessories,
cooking advice.
Cleaning and maintenance
Information for proper cleaning and
maintenance of the appliance.
Installation
Information for the qualified
technician: Installation, operation
and inspection.
Safety instructions
Information
Advice

Description
48
2 Description
2.1 General description
80 cm (4 cooking zones)
80 cm (5 cooking zones)
90 cm

Description
49
EN
Maximum absorbed power table (Watt)
Power levels are approximate and may vary according to the pan used or the settings made
2.2 Control panel
1 On/Off button
2 Settings icons
3 Cooking zone display
4 Timer display
5 Settings menu button
6 Auto-Vent 2.0 function button
7 Grill function button
8 Scroll bar
Dimensions
H x L (mm) Level 9 Booster Double Booster
Zone 1/ 2: Single 180 x 218 2100 2500 3000
Zone 1/ 2:
Multizone 360 x 218 1500 1850 -
Zone 3 250 x 250 2300 3000 -
Zone 4 210 x 210 2300 3000 -
Zone 5 200 x 200 2300 3000 -
Zone 6 160 x 160 1400 2100 -

Description
50
Advantages of induction cooking
• Energy saving thanks to the direct
transmission of energy to the pan
(suitable magnetisable cookware is
required) compared to traditional
electric cooking.
• Improved safety as the energy is only
transmitted to the pan placed on the hob.
• High level of energy transmitted from the
induction cooking zone to the base of
the pan.
• Rapid heating speed.
• Reduced danger of burns as the cooking
surface is only heated under the base of
the pan; foods which overflow do not
stick.
Power control
The hob is fitted with a power control
module that optimises/limits consumption. If
the overall set power level exceeds the
maximum limit permitted, the electronic
circuit board will automatically manage the
power supplied by the hot plates. The
module tries to maintain the maximum
deliverable power levels. Levels set by the
automatic control will appear on the
display.
The appliance is equipped with an
induction generator for each
cooking zone. Each generator
located under the glass ceramic
cooking surface creates an
electromagnetic field which
induces a thermal current in the
base of the pan. This means the
heat is no longer transmitted from
the hob to the pan but created
directly inside the pan by the
inductive current.
• Priority is given to the last zone
that is set.
• The power control module does
not affect the total power
consumption of the appliance.

Use
51
EN
3 Use
3.1 Instructions
High temperature
Danger of burns
• Protect your hands by wearing heat-
proof gloves during use.
• Do not touch or clean the hob surface
during operation or when the residual
heat indicator lights are still on.
• Do not put empty pans or frying pans on
switched on cooking zones.
• Keep children under the age of 8 away
from the appliance when it is in use.
• Activate the controls lock when you
have children or pets which could reach
the hob.
• After use the cooking zones remain hot
for a certain period of time after they
have been turned off. Do not touch the
hob surfaces.
High temperature
Danger of fire or explosion
• Do not use or leave flammable materials
near the appliance or directly
underneath the hob.
• Do not cook in closed tins or containers,
plastic kitchenware or containers.
• Do not leave the appliance unattended
during cooking operations where fats or
oils could be released.
• In case you notice cracks or fissures or
you cannot turn off the appliance,
disconnect the power supply and
contact the Assistance Centre.
Improper use
Risk of damage to surfaces
• Do not use the hob if the pyrolytic cycle
is taking place inside any oven installed
below.
• Never place pans with bases which are
not perfectly flat and smooth.
• Avoid hard, solid objects falling on the
cooking surface.
• Do not use the hob as a support surface.

Use
52
3.2 Preliminary operations
In order to remove any moisture that could
have accumulated during the manufacturing
process and for the electronic circuits and
control keypad to work properly:
1. Remove the protective films from the
external surfaces of the appliance and
accessories.
2. Remove any labels (apart from the
technical data plate).
3.3 Using the hob
All the appliance’s control and monitoring
devices are located together on the front
panel. The induction hob is controlled by
means of the Touch control sensor buttons.
Lightly touch a symbol on the glass ceramic
surface. A beep will sound to confirm every
effective touch.
Switching on the hob for the first time
When the appliance is used for the first
time, after having been connected to the
mains the flashing symbol appears on
the display. It is used to access the
appliance’s technical menu and is intended
only for Technical Support personnel.
Once the appliance has been switched on,
the icon, the dimly lit button and
the text will appear on the timer
display.
List of icons
Warming function icon.
Timer icon.
Pause function icon.
Clean function icon.
Controls lock icon.
Automatic pan detection icon.
Button volume icon.
Display brightness icon.
Eco mode icon.
List of buttons
On/Off button: turns the hob on or off.
Settings menu button: allows you to
access the appliance’s settings.
Grill function button: activates the Grill
function
Auto-Vent 2.0 function button:
activates communication between the
hob and the extractor hood.
Scroll bar: increases or decreases the
power level of a cooking zone, allows you
to adjust settings and to select the user
menu options.
When the appliance is first
connected to the mains power
supply, an automatic check is
carried out that momentarily
switches on all the indicator lights.

Use
53
EN
Cooking zones display
The buttons for selecting the cooking zones
and the timer icons above each of them
and the Warming function icon are found in
this zone.
Timer display
The controls for setting the independent
timer and the timer for the cooking zones
are located in this area. The following text is
displayed when it is possible to set an
independent timer .
Pan diameters
Make sure that the minimum diameter of the
pans is that indicated in the following table:
*When using a pan with diameters smaller than
the smallest diameter shown in the “Ø minimum
(cm)” column, it may not be detected.
Bear in mind the following:
• Do not exceed the limits of the zones
printed on the hob.
• Do not cover the control panel.
• Do not place the pans next to the edges
of the glass.
• If you intend to use a griddle or a long
pan in zones 1and 2in Multizone
mode, it is recommended to use one with
a maximum size of 22 x 36 cm and a
minimum size of 19 x 19 cm.
Cookware suitable for use in induction
cooking
Cookware used on the induction cooking
surface must be made of metal, with
magnetic properties and a sufficiently large
base.
Suitable cookware:
• Enamelled steel cookware with thick
bases.
• Cast iron cookware with an enamelled
base.
• Cookware in multilayer stainless steel,
ferritic stainless steel and aluminium with
a special base.
Unsuitable cookware:
• Copper, stainless steel, aluminium,
fireproof glass, wood, ceramic and
terracotta cookware.
Zone
Ø
minimum (cm)
Ø
recommended
(cm)
Zone 1 and 2
(single zone) 9 - 11*18
Zone 1 and 2
(Multizone) 19 22
Zone 3 13 25
Zone 4 9 - 11*21
Zone 5 7 - 9*16

Use
54
To see whether the pan is suitable, bring a
magnet close to the bottom: if it is attracted,
the pan is suitable for induction cooking. If
you do not have a magnet, you can put a
small amount of water in the pan, place it
on a cooking zone and start the hot plate.
Limiting the cooking duration
The hob has an automatic device which
limits the duration of use.
If the cooking zone settings are not
changed, the maximum duration of
operation for each zone depends on the
power level selected.
When the device for limiting the duration of
use is activated, the cooking zone turns off,
a short alert sounds and, if the zone is hot,
the residual heat symbols appear on the
display.
Protection from overheating
If the hob is used on full power for a long
period, the electronics will have trouble
cooling down if the room temperature is
high.
If the temperature of the internal electronic
components exceeds the safety threshold,
the appliance will switch off automatically
and “ER21” will be displayed (see “Error
codes”).
Advice on energy-saving
• The diameter of the base of the pan must
not exceed the width of the silk-screened
cooking zone.
• Pans must not be placed outside the
perimeter of the hob or above the front
control panel.
• When buying a pan, check whether the
diameter indicated is that of the base or
the top of the pan, as the top is almost
always larger than the base.
• When preparing dishes with long
cooking times, you can save time and
energy by using a pressure cooker,
which also helps to retain vitamins
contained in the food.
• Make sure that the pressure cooker
contains enough liquid as, if there is not
enough and it overheats, this may cause
damage to both the pressure cooker and
the cooking zone.
Set power level Maximum cooking
duration in hours
18½
26½
35½
44½
53½
61½
71½
81½
91½

Use
55
EN
• If possible, always cover saucepans with
a suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
Power levels
The power in the cooking zone can be
adjusted to various levels. The table shows
the levels suitable for various types of
cooking.
* see Booster and Double Booster function
Switching the hob on and off
Keep the On/Off button pressed in
for at least 1 second to activate the hob.
Press it again for at least one second to
deactivate it.
• The text appears on the timer
display for a few seconds, during which
an independent timer can be set (see
“Independent timer”).
• If a power limitation has been set, the
number associated with the set power
will be displayed for a few seconds
instead of . In this case, you can
still set an independent timer by touching
the timer display.
Switching on the cooking zone
automatically
After switching on the hob:
• Position a pan (suitable for induction
cooking and not empty) on the cooking
zone you wish to use.
Under certain circumstances, if the
hob and the oven are being used
at the same time, the maximum
power limit that can be used by the
electrical system might be
exceeded.
Power level Suitable for:
0 OFF setting
1 - 2 Cooking small amounts of food
(minimum power)
3 - 4 Cooking
5 - 6 Cooking large quantities of food,
roasting larger portions
7 - 8 Roasting, slow frying with flour
9 Roasting
P / Roasting / Browning, cooking
(maximum power)*
If no power value is selected within
a few seconds, the hob is
automatically deactivated.
The hob is provided with an
automatic pan sensing system,
indicated by the icon. This
feature is active by default, but can
be disabled via the user menu.

Use
56
• The button corresponding to the zone on
which the pan has been placed turns on
automatically and displays . The
other zones cannot be activated.
If automatic pan detection is disabled,
when the appliance is switched on, the
symbol appears on the display of all the
cooking zones. To activate the zones, select
them via the relative display and then select
the required power level.
Pan detection indication
Once a zone has been activated /
selected, if the symbol appears on the
display, it means the pan is unsuitable.
The symbol also appears if there is no
pan or if the pan is removed.
Adjusting the cooking zone
After having selected/activated a cooking
zone:
1. Place a finger on the left-hand side of the
scroll bar of the cooking zone to be
used.
The power level is now .
2. Move your finger to the left or right on the
scroll bar to select the power level, from
to or activate the Booster
function (see “Booster Function”).
The display of the zone being used will
indicate the selected power level.
Switching off the cooking zone
1. Move your finger all the way to the left
on the scroll bar of the cooking zone you
wish to turn off.
Use only cookware with a
perfectly flat bottom which is
suitable for induction hot plates.
Using cookware with an irregular
bottom could jeopardise the
efficiency of the heating system
and prevent cookware from being
detected on the hot plate.
Make sure that the pans do not
cover the control panel.

Use
57
EN
The display of the zone being used
indicates .
Quick selection
After switching on the hob and having
selected a cooking zone:
1. Place a finger on the scroll bar at
approximately the required power level.
2. Move your finger to the left or right to
select the required cooking power.
Booster Function
After switching on the hob and having
selected a cooking zone:
1. Place a finger on the left-hand side of the
scroll bar.
The display of the cooking zone used will
turn on: the power value indicated is .
2. Move your finger to the far right on the
scroll bar to select power level 9.
3. Press the segment at the far right of the
scroll bar.
Hold the On/Off button
down for at least 2 seconds to
switch off all cooking zones at the
same time.
This function allows you to quickly
set the cooking zones to the
required power.
Improper use
Danger of burns
• Do not use the Booster and Double
Booster functions to heat fats or oils as
they could catch fire.
This function allows you to use the
maximum available power of the
cooking zone in order to bring a
large amount of water to the boil
rapidly.

Use
58
The display of the cooking zone used will
show . Select any other power level to
deactivate the Booster function.
The Booster function can be activated
quickly.
• After switching on the hob and having
selected a cooking zone, press the last
segment on the far right of the scroll bar
twice.
Double Booster Function
The Double Booster function allows more
power to be supplied compared to the
Booster function.
After having activated the Booster function
for a cooking zone, press the last segment
at the far right of the scroll bar. The symbols
, and will be displayed in
sequence.
Multizone function
After switching on the hob:
1. Place a finger on the front left and rear
left cooking zone buttons at the same
time.
After a short beep, the symbol will
appear next to the button of the rear zone.
The Multizone function is now active.
2. Use the left-hand scroll bar to set the
required cooking power.
The Booster function remains
active for a maximum of 5 minutes,
after which the power is reduced
automatically to level 9.
The Double Booster Function is
available only for zones 1and 2.
This function can be used to
operate two
cooking zones (front and
rear) when using pans like fish
kettles or rectangular pans.
The Multizone function can be
activated automatically by placing
a long pan on zones 1and 2.

Use
59
EN
The same power level will be set for both
cooking zones.
If a large, oval or oblong pan is being
used, make sure that it is placed in the
centre of the cooking zone.
Example of correct pan position
Example of incorrect pan position
Examples of griddle position
To deactivate the Multizone function:
Simultaneously press the buttons of the
cooking zones on which the Multizone
function is active. The symbol
disappears and the two zones can be
regulated separately.
It is only possible to activate the
Multizone function between zones
1and 2.
• This function automatically
divides the power equally
between both of the hot plates in
use.
• It is not possible to activate the
Double Booster function for the
cooking zones on which the
Multizone function is active.

Use
60
Cooking guidelines
The table below shows the power values
which can be set, together with the
corresponding type of food. Settings may
vary depending on the amount of food and
consumer taste.
Residual heat indication
After the cooking zone has been switched
off, each display shows a special symbol to
indicate whether the zone is still hot,
together with its indicative temperature:
1 if the temperature is between 60°C
and 79°C.
2 if the temperature is between 80°C
and 99°C.
3 if the temperature is 100°C or
higher.
3.4 Additional functions
Rapid heating
The rapid heating function heats one
cooking zone at maximum power for a
limited time, after which it continues cooking
at the set power level.
Power level Suitable for:
1 - 2
Reheating food, keeping small
amounts of water on the boil,
and whipping up sauces with
egg yolk or butter.
3 - 4
Cooking solid or liquid food,
keeping water on the boil,
defrosting deep-frozen food,
cooking 2- or 3-egg
omelettes, fruit and
vegetables, various cooking
processes.
5 - 7
Stewing meat, fish and
vegetables, simmering food,
making jams etc.
8-9
Cooking or frying meat, fish,
steaks and liver; browning
meat, fish, eggs, etc.
P - Double
Booster
Deep-frying potatoes, etc., or
bringing water to the boil
rapidly.
Improper use
Danger of burns
• Supervise children carefully as they
cannot easily see the residual heat
indicator. The cooking zones remain hot
for a certain period of time even after
they have been turned off. Make sure
that children never touch the hob.
This function is not available for
power level 9or the Booster and
Double Booster functions.
