THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS
MANUAL. THIS IS A CLASS 3 BUILT-IN HOB.
INSTRUCTIONS FOR THE USER: these contain user advice, the description
of the controls and the correct procedures for cleaning and maintenance of
the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified
technician who must install the appliance, set it functioning and carry out
an inspection test.
1. INSTRUCTIONS FOR USE .............................................................. 26
2. SAFETY PRECAUTIONS ................................................................. 28
3. ENVIRONMENTAL RESPONSIBILITY............................................. 30
4. DESCRIPTION OF CONTROLS ...................................................... 31
5. USING THE HOB.............................................................................. 32
6. CLEANING AND MAINTENANCE.................................................... 36
7. POSITIONING IN THE COUNTER TOP .......................................... 38
8. ELECTRICAL CONNECTION........................................................... 40
9. GAS CONNECTION ......................................................................... 41
10. ADAPTATION TO DIFFERENT TYPES OF GAS ........................... 43

General instructions
26
1. INSTRUCTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS
ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF
THE HOB. WE ADVISE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT
CONTAINS CAREFULLY BEFORE USING THE HOB. ALSO KEEP THE SERIES OF
NOZZLES PROVIDED. INSTALLATION MUST BE CARRIED OUT BY QUALIFIED
PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE. THIS
APPLIANCE IS INTENDED FOR HOUSEHOLD USE AND COMPLIES WITH THE EEC
DIRECTIVES CURRENTLY IN FORCE. THE APPLIANCE HAS BEEN BUILT TO CARRY
OUT THE FOLLOWING FUNCTION: COOKING AND HEATING FOODS; ALL OTHER
USES ARE TO BE CONSIDERED IMPROPER.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR USE OTHER THAN AS
INDICATED.
IF THE APPLIANCE IS INSTALLED ON BOATS OR IN CARAVANS, DO NOT USE IT AS
A ROOM HEATER.
DO NOT USE THIS APPLIANCE FOR HEATING ROOMS.
THIS APPLIANCE IS MARKED ACCORDING TO EUROPEAN DIRECTIVE 2002/96/EC
ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS DIRECTIVE DETERMINES THE STANDARDS FOR THE COLLECTION AND
RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT APPLICABLE
THROUGHOUT THE EUROPEAN UNION.
BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL PROTECTIVE FILMS
MUST BE REMOVED.
SUITABLE HEAT-PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS.
DO NOT USE STEEL SPONGES AND SHARP SCRAPERS AS THEY WILL
DAMAGE THE SURFACE.
USE NORMAL NON-ABRASIVE PRODUCTS, INCLUDING WOODEN OR
PLASTIC UTENSILS IF NECESSARY. RINSE THOROUGHLY AND DRY
USING A SOFT CLOTH OR A MICROFIBRE CLOTH.
DO NOT LEAVE THE APPLIANCE UNATTENDED DURING COOKING OPERATIONS
WHERE FATS OR OILS COULD BE RELEASED.
FATS AND OILS MAY CATCH FIRE.

General instructions
27
ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE (OFF) POSITION
WHEN YOU FINISH USING THE HOB.
NEVER PLACE PANS WITH BOTTOMS WHICH ARE NOT PERFECTLY FLAT AND
SMOOTH ON THE COOKING HOB RACKS.
NEVER USE CONTAINERS WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE
HOB.

General instructions
28
2. SAFETY PRECAUTIONS
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS
FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS.
IN YOUR INTERESTS AND FOR YOUR SAFETY IT HAS BEEN ESTABLISHED BY LAW
THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS TO
BE CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE
REGULATIONS IN FORCE.
OUR APPROVED INSTALLERS GUARANTEE A SATISFACTORY JOB.
GAS OR ELECTRICAL APPLIANCES MUST ALWAYS BE DISCONNECTED BY
SUITABLY SKILLED PEOPLE.
BEFORE CONNECTING THE APPLIANCE TO THE POWER GRID, CHECK THE DATA
ON THE PLATE AGAINST THE DATA FOR THE GRID ITSELF.
THE IDENTIFICATION PLATE CONTAINING THE TECHNICAL DATA, SERIAL NUMBER
AND BRAND NAME IS IN A VISIBLE POSITION UNDER THE CASING.
DO NOT REMOVE THE PLATE ON THE CASING FOR ANY REASON.
BEFORE CONNECTING THE APPLIANCE, ENSURE THAT IT IS SET TO THE TYPE
OF GAS THAT IT WILL BE SUPPLIED WITH, CHECKING THE LABEL APPLIED UNDER
THE CASING.
BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT
THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY CABLE AND ITS SOCKET
MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN FORCE.
THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS BEEN BUILT IN.
NEVER DISCONNECT THE PLUG BY PULLING ON THE CABLE.
IF THE POWER SUPPLY CABLE IS DAMAGED, CONTACT THE TECHNICAL
SUPPORT SERVICE IMMEDIATELY AND THEY WILL REPLACE IT.
IT IS OBLIGATORY FOR ALL ELECTRICAL EQUIPMENT TO BE EARTHED
ACCORDING TO THE METHODS LAID DOWN BY SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A BRIEF INSPECTION TEST,
FOLLOWING THE INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT
FUNCTION, DISCONNECT IT FROM THE POWER SUPPLY AND CALL THE NEAREST
TECHNICAL SUPPORT CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH
THE HEATING ELEMENTS.
THE USE OF THIS APPLIANCE IS NOT PERMITTED TO PEOPLE (INCLUDING
CHILDREN) OF REDUCED PHYSICAL AND MENTAL ABILITY, OR LACKING IN
EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE
SUPERVISED OR INSTRUCTED BY ADULTS OR PEOPLE RESPONSIBLE FOR THEIR
SAFETY.

General instructions
29
DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR
PLAY WITH IT AT ANY TIME.
DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE
SLITS IN THE APPLIANCE.
DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.
THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING
SHORT-CIRCUITS.
DO NOT MODIFY THIS APPLIANCE.
DO NOT SPRAY ANY SPRAY PRODUCTS NEAR THE ELECTRICAL APPLIANCE
WHILE IT IS IN OPERATION.
DO NOT USE SPRAY PRODUCTS WHILE THE PRODUCT IS STILL HOT.
The manufacturer declines all responsibility for damage to persons or things
caused by non-observance of the above prescriptions or by interference with any
part of the appliance or by the use of non-original spare parts.

Instructions for disposal
30
3. ENVIRONMENTAL RESPONSIBILITY
3.1 Our environmental responsibility
Pursuant to Directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to
the reduction of the use of hazardous substances in electrical and electronic
appliances, as well as to the disposal of refuse, the crossed out bin symbol on
the appliance indicates that the product, at the end of its useful life, must be
collected separately from other refuse. Therefore, the user must consign the
product that has reached the end of its working life to the appropriate selective
collection centres for electrical and electronic refuse, or deliver it back to the
retailer when purchasing an equivalent product, on a one for one basis.
Adequate differentiated collection for the subsequent forwarding of the
decommissioned product to recycling, processing and ecologically compatible
disposal contributes to avoiding possible negative effects on the environment
and on health, and promotes recycling of the appliance's constituent materials.
The illicit disposal of the product by the user results in the application of
administrative sanctions.
The product does not contain substances in quantities sufficient to be
considered hazardous to health and the environment, in accordance with
current European directives.
3.2 Your environmental responsibility
Our product's packaging is made of non-polluting materials, therefore
compatible with the environment and recyclable. Please help by disposing of the
packaging correctly. You can obtain the addresses of collection, recycling and
disposal centres from your retailer or from the competent local organisations.
Do not discard the packaging or any part of it, or leave it unattended. It can
constitute a suffocation hazard for children, especially the plastic bags.
Your old appliance also needs to be disposed of correctly.
Important: hand over your appliance to the local agency authorised for the
collection of household appliances no longer in use. Correct disposal enables
intelligent recovery of valuable materials.
Before disposing of your appliance it is important to remove doors and leave
shelves in the same position as for use, to ensure that children cannot
accidentally become trapped inside during play. It is also necessary to cut the
connecting cable to the power supply, removing it along with the plug.

Instructions for the user
31
4. DESCRIPTION OF CONTROLS
4.1 Control zone
All the hob controls are grouped together at the centre front.
CONTROL ZONE
KNOB DESCRIPTION
To light the flame, press the knob and, at the same time, turn it
anticlockwise to the maximum flame symbol .
To adjust the flame, turn the knob to the zone between the
maximum and minimum settings.
To turn off the burner, turn the knob to the zero position to the
symbol.

Instructions for the user
32
5. USING THE HOB
Make sure that the burners, flame-spreader crowns and
racks are fitted correctly.
The notches Aof the flame-spreader crowns must be
inserted into the housings Bof the burner. The igniter
and thermocouple on the hob should fit into the 2 holes
on the burner.
5.1 Positioning the racks
The racks are provided unassembled on the hob. To position each rack correctly
on its burner, follow the instructions below:
Each rack must be positioned on the corresponding burner in order to guarantee
proper operation. Be very careful to match the different central diameters of the
racks to the flame-spreader crowns.

Instructions for the user
33
All the racks have two reference notches (A).
To position the racks correctly, align the reference notches (A) with the cavities
(B) on the hob.
After positioning, check that the rack feet are all resting on the same level.
Make sure that the racks are simply centred on their respective burners,
without forcing the burners to be raised or tilted. If they are, repeat the
positioning procedure.
INCORRECT INCORRECT CORRECT

Instructions for the user
34
5.2 Lighting the burners using a safety device
The appliance is equipped with electronic ignition. Simply press the knob and
simultaneously turn it anticlockwise to the minimum flame symbol , until it
lights. Hold down the knob for about 2 seconds to keep the flame lit and to
activate the safety device. The burner may go out when the knob is released. If
this happens, repeat the procedure, holding the knob down for longer.
If the burners should go out accidentally, after about 20 seconds a safety device
will be tripped, cutting off the gas supply, even if the gas tap is open.
5.3 Practical tips for using the burners
For better burner performance and minimum gas
consumption, pans with flat, even bases and with lids should
be used, and their size should be in proportion to the burner
(see “5.4 Pan diameters”).
During cooking, in order to avoid burns or damage to the hob
top, all pans or griddles must be positioned inside the outer
edge of the hob and at a minimum distance of 5-7 cm must be
maintained from the knobs.
If the burner flame accidentally goes out, turn off the control
knob and wait at least 1 minute before trying to re-light the
burner.

Instructions for the user
35
5.4 Pan diameters
BURNERS
1 Auxiliary
2. Semi-rapid
3 Medium Rapid
4 Large Rapid
min. and max. Ø (in cm)
7-18
10-24
18-24
20-26

Instructions for the user
36
6. CLEANING AND MAINTENANCE
Before performing any operations requiring access to powered parts, disconnect
the appliance from the power supply.
6.1 Cleaning the hob
To keep the hob in good condition it should be cleaned regularly after use.
Let it cool first.
6.1.1 Ordinary daily cleaning
To clean and preserve the stainless steel surfaces, always use only specific
products that do not contain abrasives or chlorine-based acids.
How to use: pour the product onto a damp cloth and wipe the surface, rinse
thoroughly and dry with a soft cloth or chamois leather.
6.1.2 Food stains or residues
Do not use metallic sponges or sharp scrapers: they will damage the
surface.
Use ordinary non-abrasive products for steel, together with anti-
scratch sponges and wooden or plastic utensils if necessary.
Rinse thoroughly and dry with a soft cloth or chamois leather.

Instructions for the user
37
6.2 Cleaning the components
6.2.1 Knobs
The knobs should be cleaned with a soft cloth dampened with lukewarm water,
then dried carefully. For easier cleaning they can be removed by pulling them
upwards.
Do not use aggressive products containing alcohol or products for cleaning steel
and glass when cleaning the knobs, as these products could cause permanent
damage.
6.2.2 Racks
Remove the racks and clean them with lukewarm water and non-
abrasive detergent, making sure to remove any encrustations.
Replace them on the cooking hob.
These components must not be washed in the dishwasher.
6.2.3 Flame-spreader crowns
The flame-spreader crowns are removable. Wash them with
lukewarm water and non-abrasive detergent, making sure to
remove any encrustations.
To remove burned on food residue, use Puliforno with a scourer
sponge.
For less stubborn residue and for polishing, use stainless steel
cream cleaner Crema Inox with a microfiber cloth.
After cleaning ensure they are perfectly dry and reposition them
correctly.
6.2.4 Igniters and thermocouples
For correct operation the igniters and thermocouples must always
be perfectly clean. Check them frequently and clean them with a
damp cloth if necessary. Remove any dry residues with a wooden
toothpick or a needle.

Instructions for the installer
38
7. POSITIONING IN THE COUNTER TOP
The following operation requires building and/or carpentry work so must be
carried out by a competent tradesman.
Installation can be carried out on various materials such as masonry, metal,
solid wood or plastic laminated wood as long as they are heat resistant (T 90°C).
7.1 Fixing to the supporting structure
Create an opening with the dimensions shown in the figure in the top surface of
the counter, keeping a minimum distance of 50 mm from the rear edge. This
appliance can be mounted against walls higher than the work surface on
condition that a distance of "X" be kept between the appliance and the wall as
shown in the figure so as to avoid damage from overheating. Make sure that
there is a minimum distance of 750 mm between the hob and any shelf that may
be installed directly above it.
Do not use aggressive products containing alcohol or products for cleaning steel
and glass when cleaning the knobs, as these products could cause permanent
damage.
If installing over an empty kitchen unit with doors, a separation panel must be
placed under the hob. Keep a minimum distance of 10 mm between the bottom
of the appliance and the surface of the panel, which must be easily extractable
to allow sufficient access for any technical assistance.

Instructions for the installer
39
Carefully position the supplied insulating seal on the outer perimeter of the hole
made in the counter top as shown in the figures below, trying to make it stick on
the entire surface by applying light pressure on it with your hands. Depending
on the hob model being installed refer to the dimensions in the figure, bearing in
mind that for both models the long front side must brush against the hole. Fix
the hob to the unit using the appropriate brackets Asupplied. Carefully trim the
surplus away from edge Bbeyond the seal. The dimensions given in the
following drawing refer from the hole to the inside of the seal.
The figure to the side shows the exact
holes to be used to correctly attach
the hob to the work surface with
brackets.
IMPORTANT: If installing the hob over an oven, ensure that the latter is
equipped with a cooling fan.

Instructions for the installer
40
8. ELECTRICAL CONNECTION
Make sure that the voltage and capacity of the power supply line conform to the
data shown on the plate located under the casing. Do not remove this plate
for any reason.
The plug at the end of the supply cable and the wall socket must be of the same
type and must conform to the applicable legislation on electrical installations.
Make sure that the supply line is suitably earthed.
Pass the power supply cable through the back of the unit, taking care that it
does not touch the bottom casing of the hob or the oven (if any) installed
underneath it.
Fit the power supply line with an omnipolar circuit breaker with a contact
opening gap equal to or greater than 3 mm in an easily accessible position close
to the appliance.
Avoid use of adapters and shunts.
If the power cable is replaced, the cross-
section of wires in the new cable must be
no less than 0.75 mm2(3 x 0.75 cable),
remembering that the end for connection to
the appliance must have an earth wire
(yellow/green) which is at least 20 mm
longer.
Only use a H05V2V2-F or similar cable resistant to the maximum temperature of
90°C. Its replacement must be carried out be a specialised technician who must
carry out the connection to the power grid following the diagram below.
L = brown
N = blue
= yellow/green
The power supply cable must be replaced by an authorised service centre to
prevent any risks.
The manufacturer declines all responsibility for damage to persons or things
caused by non-observance of the above prescriptions or by interference with
any part of the appliance.

Instructions for the installer
41
9. GAS CONNECTION
If the appliance is installed on an oven, you must avoid running the gas tube
round the back of the oven in order to avoid overheating.
Connection to the gas supply network can be made using a rigid copper hose or
a flexible steel hose with a continuous wall and in compliance with the
guidelines established by the applicable standard. To facilitate the connection,
connector Aon the back of the appliance can be orientated laterally; loosen
hexagonal nut B, twist connector Ainto the desired position then retighten
hexagonal nut B(it is sealed with a rubber gasket). Once the operation is
complete, check the hose fittings for leaks using a soapy solution; never use a
flame. The hob is preset for natural gas G20 (2H) at a pressure of 20 mbar. To
set it up for supply using other types of gas, see Chapter “10. ADAPTATION TO
DIFFERENT TYPES OF GAS”. The gas inlet connection is threaded ½” for
external gas (ISO 228-1).
Connection with a rigid copper hose: The
connection to the gas supply network must be made
in such a way that it does not cause stresses of any
type on the appliance. The connection can be made
using the adapter unit D with double cone, always
inserting gasket C(provided) in between.
Connection with a flexible steel hose: use only
continuous wall stainless steel hoses that comply
with the applicable standards, making sure to always
insert gasket C (provided) between connector A and
flexible hose B.
Installation with flexible hose must be carried out so that the length of the piping
does not exceed 2 metres when fully extended; make sure that the hoses do not
come into contact with moving parts and that they are not crushed in any way.

Instructions for the installer
42
9.1 Connection to liquid gas
Use a pressure regulator and make the connection on the gas cylinder following
the guidelines set out in the regulations in force.
Make sure that the supply pressure complies with the values indicated in the
paragraph “10.3 Burner and nozzle characteristics tables”.
9.2 Room ventilation
The room containing the appliance should have an air supply in accordance with
the standards in force. The room where the appliance is installed must have
enough air flow needed for the regular combustion of gas and the necessary air
change in the room itself. The air vents, protected by grills, must be the right
size to comply with current regulations and positioned so that no part of them is
obstructed, not even partially.
The room must be kept adequately ventilated in order to eliminate the heat and
humidity produced by cooking: in particular, after prolonged use, you are
recommended to open a window or to increase the speed of any fans.
9.3 Extraction of the combustion products
The combustion products may be extracted by means of hoods connected to a
natural draught chimney whose efficiency is certain or via forced extraction. An
efficient extraction system requires precision planning by a specialist qualified in
this area and must comply with the positions and distances indicated by the
regulations. When the job is complete, the installer must issue a certificate of
conformity.

Instructions for the installer
43
10. ADAPTATION TO DIFFERENT TYPES OF GAS
Before carrying out the following operations, disconnect the appliance from the
power supply.
The hob is preset for natural gas G20 (2H) at a pressure of 20 mbar. If other
types of gas are to be used, the nozzles must be replaced and the primary air
must be adjusted.
In order to replace the nozzles and adjust the burners, the hob top must be
removed as described below.
10.1 Removing the hob top
Remove all the burner components, following the numerical sequence in the
figures below:
• Take out all the knobs (1) by pulling them upwards;
• Remove the racks (2) by lifting them upwards;
• Lift all the burner components off the hob (3- 4);
• Unscrew the screws (5) that secure the burner supports;
• Having removed all the components described above, lift the hob top
upwards to access the burners and gas taps.
10.2 Replacement of the cooking hob nozzles
Unscrew screw Cand push air regulator Das far as
it will go. Using a 7-mm wrench, remove nozzle E
and replace it with the appropriate nozzle, following
the instructions in the tables for the type of gas to be
used. The nozzle tightening torque must be no more
than 3 Nm. Adjust the air by sliding regulator Duntil
distance “X” is reached, as indicated in the table in
paragraph “10.4 Primary air adjustment”.
Lock regulator Dby tightening screw C.

Instructions for the installer
44
10.3 Burner and nozzle characteristics tables
Burner
Rated
heating
capacity
(kW)
LPG – G30/G31 28/37 mbar
Nozzle
diameter
1/100 mm
Reduced
capacity
(W)
Capacity
g/h G30
Capacity
g/h G31
Auxiliary 1.05 48 400 76 75
Semi-rapid 1.65 62 500 120 118
Medium Rapid 2.5 76 750 182 179
Large Rapid 3.4 87 1050 247 243
Burner
Rated
heating
capacity
(kW)
Natural gas – G20 20 mbar
Nozzle diameter
1/100 mm
Reduced capacity
(W)
Auxiliary 1.05 76 400
Semi-rapid 1.7 95 500
Medium Rapid 2.6 117 750
Large Rapid 3.5 135 1050
