Smeg LBS65-9 User manual

Washing Machine
Lavatrice
LBS85-9
LBS65-9

2 - EN
1 Warnings
General Safety
• Neverplaceyourmachineonacarpet
coveredfloor.Otherwise,lackofairflow
frombelowofyourmachinemaycause
electricalpartstooverheat.Thismaycause
problemswithyourwashingmachine.
• Ifthepowercableormainsplugis
damagedyoumustcallAuthorizedService
forrepair.
• Fitthedrainhoseintothedischarge
housingsecurelytopreventanywater
leakageandtoallowmachinetotakein
anddischargewaterasrequired.Itisvery
importantthatthewaterintakeanddrain
hosesarenotfolded,squeezed,orbroken
whentheapplianceispushedintoplace
afteritisinstalledorcleaned.
• Yourwashingmachineisdesignedto
continueoperatingwhenthepower
restoresafterapowerinterruption.The
machinewillresumeitsprogramwhenthe
powerrestores.Pressthe“Start/Pause/
Cancel”buttonfor3secondstocancelthe
program(See,CancelingaProgram)
• Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.Itisnot
harmfultoyourmachine.
• Someproblemsyoumayencountermay
becausedbytheinfrastructure.Press
“Start/Pause/Cancel”buttonfor3seconds
tocanceltheprogramsetinyourmachine
beforecallingtheauthorizedservice.
First Use
• Carryoutyourfirstwashingprocess
withoutloadingyourmachineandwith
detergentunder“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingyourmachine.
• Ifthecurrentfuseorcircuitbreakerisless
than16Amperes,pleasehaveaqualified
electricianinstalla16Amperefuseor
circuitbreaker.
• Whileusingwithorwithoutatransformer,
donotneglecttohavethegrounding
installationlaidbyaqualifiedelectrician.
Ourcompanyshallnotbeliableforany
damagesthatmayarisewhenthemachine
isusedonalinewithoutgrounding.
• Keepthepackagingmaterialsoutofreach
ofchildrenordisposethembyclassifying
accordingtowastedirectives.
Intended use
• Thisproducthasbeendesignedforhome
use.
• Theappliancemayonlybeusedfor
washingandrinsingoftextilesthatare
markedaccordingly.
Safety instructions
• Thisappliancemustbeconnectedto
anearthedoutletprotectedbyafuseof
suitablecapacity.
• Thesupplyanddraininghosesmust
alwaysbesecurelyfastenedandremainin
anundamagedstate.
• Fitthedraininghosetoawashbasinor
bathtubsecurelybeforestartingupyour
machine.Theremaybeariskofbeing
scaldedduetohighwashingtemperatures!
• Neveropentheloadingdoororremovethe
filterwhilethereisstillwaterinthedrum.
• Unplugthemachinewhenitisnotinuse.
• Neverwashdowntheappliancewitha
waterhose!Thereistheriskofelectric
shock!
• Nevertouchtheplugwithwethands.Do
notoperatethemachineifthepowercord
orplugisdamaged.
• Formalfunctionsthatcannotbesolvedby
informationintheoperatingmanual:
• Turnoffthemachine,unplugit,turnoff
thewatertapandcontactanauthorized
serviceagent.Youmayrefertoyourlocal
agentorsolidwastecollectioncenterin
yourmunicipalitytolearnhowtodisposeof
yourmachine.
If there are children in your
house...
• Keepchildrenawayfromthemachine
whenitisoperating.Donotletthem
tamperwiththemachine.
• Closetheloadingdoorwhenyouleavethe
areawherethemachineislocated.

3- EN
2 Installation
Removing packaging
reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
ATransportationsafetyboltsmustbe
removedbeforeoperatingthewashing
machine!Otherwise,themachinewillbe
damaged!
1. Loosenalltheboltswithaspanneruntil
theyrotatefreely(“C”)
2. Removetransportationsafetyboltsby
turningthemgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesonthe
rearpanel.(“P”)
C
Keepthetransportationsafetyboltsin
asafeplacetoreusewhenthewashing
machineneedstobemovedagaininthe
future.
C
Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
ADonotuseanytoolstoloosenthelock
nuts.Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutson
thefeet.
2. Adjustthemuntilthemachinestandslevel
andfirmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorun
themachinemustbe1-10bar(0,1–1
MPa).
• Connectthespecialhosessuppliedwith
themachinetothewaterintakevalveson
themachine.
• Ifyouaregoingtouseyourdoublewater-
inletmachineasasingle(cold)water-inlet
unit,youmustinstallthestopper*,supplied
withyourmachinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwater
hoseafterremovingthestopperand
gasketgroupfromthehotwatervalve.
*Appliesfortheproductssuppliedwithablind
stoppergroup.
• Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.
Whenreturningtheappliancetoitsplaceafter
maintenanceorcleaning,careshouldbetaken
nottofold,squeezeorblockthehoses.
Connecting to the drain
Thewaterdischargehosecanbeattachedto
theedgeofawashbasinorbathtub.Thedrain
hoseshouldbefirmlyfittedintothedrainasto
notgetoutofitshousing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainorto
thewashbasin.
• Thehoseshouldbeattachedtoaheightof
atleast40cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingit
onthefloorlevelorclosetotheground
(lessthan40cmabovetheground),water
dischargebecomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothe
drainageformorethan15cm.Ifitistoo
longyoumayhaveitshortened.

4- EN
• Themaximumlengthofthecombined
hosesmustnotbelongerthan3.2m.
Electrical connection
Connectthemachinetoanearthedoutlet
protectedbyafuseofsuitablecapacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuse
protectionarespecifiedinthesection
“TechnicalSpecifications”.
• Thespecifiedvoltagemustbeequalto
yourmainsvoltage.
• Connectionviaextensioncordsormulti-
plugsshouldnotbemade.
BAdamagedpowercablemustbereplaced
byaqualifiedelectrician.
BTheappliancemustnotbeoperatedunless
itisrepaired!Thereistheriskofelectric
shock!
3 Initial preparations for
washing
Preparing clothes for washing
Laundryitemswithmetalattachmentssuch
as,bras,beltbucklesandmetalbuttons
willdamagethemachine.Removemetal
attachmentsorplacetheitemsinaclothing
bag,pillowcase,orsomethingsimilar.
• Sortthelaundryaccordingtotypeoffabric,
color,anddegreeofsoilingandpermissible
watertemperature.Alwaysfollowthe
adviceonthegarmentlabels.
• Placesmallitemslikeinfants’socksand
nylonstockings,etc.inalaundrybag,
pillowcaseorsomethingsimilar.Thiswill
alsosaveyourlaundryfromgettinglost.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriateprogram.
• Donotwashcolorsandwhitestogether.
New,darkcoloredcottonsmayreleasea
lotofdye.Washthemseparately.
• Useonlydyes/colorchangersandlime
removerssuitableformachinewash.
Alwaysfollowtheinstructionsonthe
packaging.
• Washtrousersanddelicateclothesturned
insideout.
Correct load capacity
CPleasefollowtheinformationinthe
"ProgramSelectionTable".Washing
resultswilldegradewhenthemachineis
overloaded.
Loading door
Thedoorlocksduringprogramoperationand
theDoorLockedSymbollightsup.Thedoor
canbeopenedwhenthesymbolfadesout.
Detergents and softeners
Detergent Drawer
Thedetergentdraweriscomposedofthree
compartments:
Thedetergentdispensermaybeintwo
differenttypesaccordingtothemodelofyour
machine.
–(I)forprewash
–(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other cleaning
agents
Adddetergentandsoftenerbeforestartingthe
washingprogram.
Neveropenthedetergentdispenserdrawer
whilethewashingprogramisrunning!
Whenusingaprogramwithoutpre-wash,no
detergentshouldbeputintothepre-wash
compartment(Compartmentno.I).
Detergent quantity
Theamountofwashingdetergenttobeused
dependsontheamountoflaundry,thedegree
ofsoilingandwaterhardness.
• Donotuseamountsexceedingthe
quantitiesrecommendedonthepackage
toavoidproblemsofexcessivefoam,
poorrinsing,financialsavingsandfinally,
environmentalprotection.
• Neverexceedthe(>max<)levelmarking;
otherwise,thesoftenerwillbewasted
withoutbeingused.
• Donotuseliquiddetergentifyouwantto
washusingthetimedelayfeature.

5- EN
4 Selecting a program and operating your machine
Control panel
1-SpinSpeedAdjustmentKnob*
2-TemperatureAdjustmentKnob*
3-Start/Pause/CancelButton
4-AuxiliaryFunctionButtons
5-ProgramSelectionKnob
Turning the machine on
Youcanpreparethemachineforprogram
selectionbypressingthe“On/Off”button.
Whenthe“On/Off”buttonispressed,the
“Ready”lightilluminatesindicatingthatthe
doorisulocked.Pressthe“On/Off”button
againtoshutdownthemachine.
Program selection
Selecttheappropriateprogramfromthe
programtableandthefollowingwashing
temperaturetableaccordingtotype,amount
anddegreeofsoilingofthelaundry.Selectthe
desiredprogramwiththeprogramselection
button.
CEachoftheseprogramsconsistofa
completewashingprocess,including
wash,rinseand,ifrequired,spincycles.
90˚C Normallysoiled,whitecottons
andlinens.
60˚C Normallysoiled,fadeproof
coloredlinens,cottonsor
syntheticclothesandlightly
soiledwhitelinens
40˚C
30°C
Cold
Blendedclothesincluding
syntheticsandwoolensaswell
asdelicateclothes.
CProgramsarelimitedwiththehighestspin
speedappropriateforthatparticulartype
ofcloth.
Main programs
Dependingonthetypeoftextile,thefollowing
mainprogramsareavailable:
• Cotone (Cottons)
Youcanwashyourdurableclotheswiththis
program.Yourlaundrywillbewashedwith
6-On/OffButton
7-ProgramFollow-upIndicators
8-Child-proofLockIndicator*
*Accordingtoyourmachine’smodel
643
7
5
2

6- EN
vigorouswashingmovementsduringalonger
washingcycle.
• Sintetici (Synthetics)
Youcanwashyourlessdurableclotheson
thisprogram.Gentlerwashingmovements
andashorterwashingcycleisusedcompared
tothe“Cottons”program.Itisrecommended
foryoursyntheticclothes(suchasshirts,
blouses,synthetic/cottonblendedgarments,
etc.).Forcurtainsandlace,the“Synthetic
40”programwithpre-washandanti-creasing
functionsselectedisrecommended.
• Lana (Woollens)
Youcanwashyourmachine-washablewoolen
garmentsonthisprogram.Washbyselecting
thepropertemperatureaccordingtothelabels
ofyourclothes.Itisrecommendedtouse
appropriatedetergentsforwoolens.
Additional programs
Forspecialcases,therearealsoextra
programsavailable:
CAdditionalprogramsmaydifferaccording
tothemodelofyourmachine.
• Delicati (Delicate)
Youcanwashyourdelicateclothesonthis
program.Ithasmoresensitivewashing
movementsanddoesnotmakeintermediate
spinningcomparedto“Synthetic”program.
• Lavaggio a Mano (Hand wash)
Youcanwashyourwoolen/delicateclothes
thatbear“notmachine-washable”labelsfor
whichhandwashisrecommendedonthis
program.Itwashesthelaundrywithvery
tenderwashingmovementswithoutdamaging
yourclothes.
• Quotidiano
Thisprogramisusedtoquicklywash(30
minutes)asmallamountoflightlysoiledcotton
garments.
• Super
Thisprogramwashesforalongerperiod
at40°Candgivesthesameresultasthe
“Cottons60°C”program,thusitsavesenergy.
Itissuitableforclothesforwhichyoucannot
usethe“Cotton60°C”program.
Special programs
Forspecificapplications,youcanselectanyof
thefollowingprograms:
• Risciaquo (Rinse)
Thisprogramisusedwhenyouwanttorinse
orstarchseparately.
• Centrifuga+Scarico (Spin + Drain)
Thisprogramspinswithmaximumpossible
rpminthedefaultsettingafterthewaterdrains
fromthemachine.
CYoushouldusealowerspinspeedfor
delicatelaundries.
Spin Speed selection
Youcanhaveyourclothesspunatthe
maximumrpmselectiononyourmachineby
usingtheselectionknobinmodelsequipped
withanrpmselectionknob.Inordertoprotect
yourclothes,yourmachinewillnotspinabove
800rpmonsyntheticprogramsand600rpm
onwoolensprogram.Furthermore,ifyouwant
toskipthespincycleandtakeyourclothes
out,turntherpmselectionknobto“nospin”
position.
Inmachinesnotequippedwithaspinspeed
selectionknob,themachinewillspininthe
maximumpossiblerpminthedefaultsettingof
theselectedprogram.

7 - EN
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Waterandpowerconsumptionandprogrammedurationmaydifferfromthetableshown,
subjecttochangesinwaterpressure,waterhardnessandtemperature,ambienttemperature,
typeandamountoflaundry,selectionofauxiliaryfunctions,andfluctuationsinthesupply
voltage.
C Theauxiliaryfunctionsinthetablemaydifferaccordingtothemodelofyourmachine.
EN 2Auxiliaryfunctions
Programme
Max.Load(kg) ProgrammeDuration (~min) WaterConsumption(l) EnergyConsumption (kWh) Prelavaggio RisciaquoAggiuntivo Antipiega Spinspeedreduction EsclusioneCentrifuga NoHeat
Cotone 90 5 155 45 1.70 • • • • • •
Cotone 60** 5 145 49 0.95 • • • • • •
Cotone 40 5 150 49 0.65 • • • • • •
Sintetici 60 2.5 120 55 0.90 • • • • • •
Sintetici 40 2.5 125 55 0.55 • • • • • •
Delicati 30 285 60 0.40 • • • • •
Lana 40 1.5 75 60 0.40 • • • • •
LavaggioaMano 30 1 55 50 0.21 • • •
Quotidiano 30 2.5 30 40 0.16 • • •

8 - EN
Auxiliary functions
Auxiliary function selection keys
Selecttherequiredauxiliaryfunctionsbefore
startingtheprogram.
CAuxiliaryfunctionbuttonsmaydiffer
accordingtothemodelofyourmachine.
Auxiliary function selection
Ifanauxiliaryfunctionthatshouldnotbe
selectedtogetherwithapreviouslyselected
functionischosen,thefirstselectedfunction
willbecancelledandthelastauxiliaryfunction
selectionwillremainactive.
Forexample:Ifyouwanttoselectpre-wash
firstandthenquickwash,pre-washwillbe
cancelledandquickwashwillremainactive.
Auxiliaryfunctionthatisnotcompatible
withtheprogramcannotbeselected.(see
“ProgramSelectionTable”)
• Prelavaggio (Prewash)
Apre-washisonlyworthwhileforheavily
soiledlaundry.Withoutpre-washyousave
energy,water,detergentandtime.Pre-wash
withoutdetergentisrecommendedforlace
andcurtains.
• Risciaquo Aggiuntivo (Rinse Plus)
Withthisfunction,youcanincreasethe
numberofcurrentrinsingsteps.Thus,
sensitiveskins’riskofbeingaffectedbythe
remainderdetergentontheclotheswillbe
decreased.
• Antipiega (Rinse Hold)
Ifyoudonotwanttounloadyourclothes
immediatelyafterthecotton,synthetics,
woolenanddelicatefabricsprogram,you
mayreleaseyourclothesinsidethemachine
inthelastrinsingwaterbypressingtherinse
holdbuttoninordertopreventyourclothes
becomewrinkled.Afterthisprocessyoumay
spinyourlaundrybypressing“Start/Pause/
Cancel”buttonoryoumayendtheprogram
bypressing“Start/Pause/Cancel”buttonfor
3sec.
• Inthemachinesequippedwithspinspeed
selectionknoborbutton,youcanspinby
selectingthedesiredspinspeedandpress
“Start/Pause/Cancel”button.
• Asformachinesnotequippedwithaspin
speedselectionknob,youcanendthe
programwithoutaspincyclebypressing
the“Start/Pause/Cancel”buttonand
drainingthewater.Ifyouwishyourclothes
bespun,youcanspinthembyselecting
“pump+spin”program.
• No Heat
Ifyouwishtowashyourclothesincoldwater,
youcanusethisprogram.
• Esclusione Centrifuga (No Spin)
Youmayusethisprogramifyoudonotwant
tospinyourclothesattheendofcottons,
synthetics,woolenordelicateprograms.
• Spin speed reduction
Youmayusethespeedreductionbutton
wheneveryouwishtospinyourclothes
belowthemaximumspinspeed.Whenspeed
reductionbuttonispressed,spinspeedwillbe
attheminimumrpmgivenonthepanel.
Starting the Program
Press“Start/Pause/Cancel”buttontostart
theprogram.“Start/Pause/Cancel”button
willlightuptoindicatethattheprogramhas
started.Thedoorislockedandthe“Lid”light
fades.
Progressing a program
Progressofarunningprogramisshown
throughtheprogramfollow-upindicator.At
thebeginningofeveryprogramstep,the
relevantindicatorlampwilllightupandlightof
thecompletedstepwillturnoff.
CIfthemachineisnotspinning,the
programmaybeinrinseholdmodeorthe
automaticspincorrectionsystemhasbeen
activatedbecauseofexcessiveunbalanced
distributionoflaundryinthemachine.
Changing the selections after the
program has started
Youcanusethisfeatureafteryourmachine
hasstartedtowashdifferenttextilegroups
inthesamebatchofclothesunderhigher
orlowertemperatures.Youmustcancel
theongoingprograminordertochangethe
washingprogram.
Forexample,pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsto“Cancel”
theprograminordertoselect“Cottons40”
programinsteadof“Cottons60”program.
Selectthe“Cottons40”programbyrotating
theprogramknob.Press“Start/Pause/Cancel”
buttontostarttheprogram.
Switching the machine to standby
mode
Press“Start/Pause/Cancel”button
momentarilytoswitchyourmachinetothe
standbymode.Auxiliaryfunctionscanbe
cancelledorselectedinaccordancewith
thesteptheprogramisat.Thedoorcanbe
openedifthewaterlevelissuitable.Laundry
maybeadded/takenoutbyopeningthe
door.
Child-proof lock
Youcanprotecttheappliancefrombeing
tamperedbychildrenbymeansofthechild-
prooflock.Inthiscase,nochangecanbe
madeintherunningprogram.

9- EN
Thisfunctionprotectstheappliancefrom
beingtamperedbychildren.Inthiscase,allof
thebuttonsareinactiveexceptOn/Offbutton;
byOn/Offbuttonyoucanwhetherstopor
resume(whilechild-lockon)theprogramof
yourmachine.
Themachineisswitchedtochild-lockby
pressingthe1stand2ndauxiliaryfunctions
fromtheleftfor3sec.1stauxiliaryfunction
lightwillflashcontinuously.Todeactivatethe
child-prooflock,pressthesamebuttonsfor
3sec.
Ending the program through
canceling
Inordertocanceltheselectedprogram,
pressthe“Start/Pause/Cancel”buttonfor3
seconds.Themachinestartstodischargethe
water.“Wash”and“ProgramFinished”lights
willlightup.“Start/Pause/Cancel”and“Wash”
lightswillgooffafterdischargingprocessis
overandthe“Lid”lightwillstartflashing.“Lid”
lampwilllightupcontinuouslywhenthedoor
isunlocked.
Iftheprogramiscancelledinthemiddleof
theprocess,“Wash”and“ProgramFinished”
lightswilllightup.Themachinecandrainall
thewaterorcantakeinwaterfor3timesat
mosttocooldowntheclothesandcomplete
drainingprocess.Whenthewaterdischarging
processiscompleted,the“Wash”lightwillgo
off,the“ProgramFinished”lightwilllightup
andthe“Lid”lightwillcontinuouslyflashuntil
thedoorisunlocked.
End of program
The“ProgramFinished”lampontheprogram
follow-upindicatorwilllightupwhenthe
programcomestoanend.Thelidisunlocked
2minuteslater,the“ProgramFinished”and
“Lid”lampswilllightupcontinuously.The
machineisnowreadyforasecondcycle.
Ifanykeyispressedwhenthemachineisat
theendoftheprogramorifthepositionof
theselectionknobischanged,the“Program
Finished”lightwillgooffandonlythe“Lid”
lampwillremainaslit.Ifthedoorisstilllocked,
the“Lid”lightwillcontinueflashinguntilthe
doorisunlocked.
Pressthe“On/Off”buttontoshutdownthe
machine.
5 Maintenance and cleaning
Detergent Drawer
Removeanypowderresiduebuildupinthe
drawer.Todothis;
1. Pressthedottedpointonthesiphoninthe
softenercompartmentandpulltowards
youuntilthecompartmentisremovedfrom
themachine.
C Ifmorethananormalamountofwater
andsoftenermixturestartstogatherinthe
softenercompartment,thesiphonmustbe
cleaned.
2. Washthedispenserdrawerandthe
siphonwithplentyoflukewarmwaterina
washbasin.
3. Replacethedrawerintoitshousingafter
cleaning.Checkifthesiphonisinits
originallocation.
Inlet water filters
Thereisafilterattheendofeachwaterintake
valveatthebacksideofthemachineandalso
attheendofeachwaterintakehosewhere
theyareconnectedtothetap.Thesefilters
preventtheforeignsubstancesanddirtinthe
watertoenterintothemachine.Filtersshould
becleanedastheygetdirty.
• Closethetaps.
• Removethenutsofthewaterintakehoses
tocleanthesurfacesofthefiltersonthe
waterintakevalveswithanappropriate
brush.
• Ifthefiltersareverydirty,youcanpullthem
outbymeansofpliersandcleanthem.
• Takeoutthefiltersontheflatendsof
thewaterintakehosestogetherwith
thegasketsandcleanthoroughlyunder
streamingwater.
• Replacethegasketsandfilterscarefullyto
theirplacesandtightenthehosenutsby
hand.

10 - EN
hose.Drainthewateroffintothecontainer
bypullingouttheplugattheendofthe
hose.Iftheamountofwatertobedrained
offisgreaterthanthevolumeofthe
container,replacetheplug,pourthewater
out,thenresumethedrainingprocess.
• Afterdrainingprocessiscompleted,
replacetheplugintotheendofthehose
andfitthehosebackintoitsplace.
Ifyourproductisnotsuppliedwithan
emergencydrainhose,dothefollowingas
showninthefigurebelow:
• Placealargecontainerinfrontofthefilter
toreceivewaterflowingfromthefilter.
• Loosenpumpfilter(anticlockwise)until
waterstartstoflowoutofit.Directthe
flowingwaterintothecontaineryouhave
placedinfrontofthefilter.Youcanusea
pieceofclothtoabsorbanyspilledwater.
• Whenthereisnowaterleft,turnthepump
filteruntilitiscompletelylooseandremove
it.
• Cleananyresiduesinsidethefilteras
wellasfibers,ifany,aroundthepropeller
region.
• Ifyourproducthasawaterjetfeature,be
suretofitthefilterintoitshousinginthe
pump.Neverforcethefilterwhilereplacing
itintoitshousing.Fitthefilterfullyintoits
housing;otherwise,watermayleakfrom
thefiltercap.
4-Closethefiltercap.
Closethetwo-piecefiltercapofyourproduct
bypushingthetabonit.
Closetheone-piecefiltercapofyourproduct
byfittingthetabsonthebottomintotheir
positionsandpushingtheupperpartofit.
Draining any remaining water and
cleaning the pump filter
Yourproductisequippedwithafiltersystem
whichensuresacleanerwaterdischargethat
extendspumplifebypreventingsoliditems
suchasbuttons,coinsandfabricfibersfrom
cloggingthepumppropellerduringdischarge
ofthewashingwater.
• Ifyourmachinefailstodrainthewater,
thepumpfiltermaybeclogged.Youmay
havetocleanitevery2yearsorwhenever
itisplugged.Watermustbedrainedoffto
cleanthepumpfilter.
Inaddition,watermayhavetobedrainedoff
completelyinthefollowingcases:
• beforetransportingthemachine(e.g.when
movinghouse)
• whenthereisthedangeroffrost
Inordertocleanthedirtyfilteranddischarge
thewater;
1-Unplugthemachinetocutoffthesupply
power.
ATheremaybewaterat90°Cinthe
machine.Therefore,thefiltermustbe
cleanedonlyaftertheinsidewateris
cooleddowntoavoidhazardofscalding.
2-Openthefiltercap.Thefiltercapmaybe
composedofoneortwopiecesaccordingto
themodelofyourmachine.
Ifitiscomposedoftwopieces,pressthetab
onthefiltercapdownwardsandpullthepiece
outtowardsyourself.
Ifitiscomposedofonepiece,holditfrom
bothsidesandopenitbypullingout.
3-Anemergencydrainhoseissuppliedwith
someofourmodels.Othersarenotsupplied
withthisitem.
Ifyourproductissuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Pulloutthepumpoutlethosefromits
housing.
• Placealargecontainerattheendofthe

11 - EN
6 Solution suggestions for problems
Problem Cause Explanation / Suggestion
Programcannot
bestartedor
selected.
Machinemayhave
switchedtoself
protectionmodedueto
aninfrastructureproblem
(suchaslinevoltage,water
pressure,etc.).
Resetyourmachinebypressing“Start/Pause/
Cancel”buttonfor3seconds.(see,Canceling
aProgram)
Thereiswater
comingfrom
thebottomof
themachine.
Theremightbeproblems
withhosesorthepump
filter.
Besurethesealsofthewaterinlethosesare
securelyfitted.
Tightlyattachthedrainhosetothetap.
Makesurethatthepumpfilteriscompletely
closed.
Machine
stopped
shortlyafter
theprogram
started.
Machinecanstop
temporarilyduetolow
voltage.
Itwillresumeoperatingwhenthevoltageis
backtothenormallevel.
Itcontinuously
spins.
Remainingtime
doesnotcount
down.
(Formodels
withadisplay)
Theremaybeanimbalance
oflaundryinthemachine.
Theautomaticspincorrectionsystemmight
havebeenactivatedduetotheunbalanced
distributionofthelaundryinthedrum.
Thelaundryinthedrummaybeclustered
(bundledlaundryinabag).Laundryshouldbe
rearrangedandre-spun.
Nospinningisperformedwhenthelaundryis
notevenlydistributedinthedrumtoprevent
anydamagetothemachineandtoits
environment.
Itcontinuously
washes.
Remainingtime
doesnotcount
down.
(Formodels
withadisplay)
Inthecaseofapaused
countdownwhiletakingin
water:
Timerwillnotcountdown
untilthemachineisfilled
withthecorrectamountof
water.
Themachinewillwaituntilthereisasufficient
amountofwatertoavoidpoorwashingresults
duetolackofwater.Thenthetimerwillstartto
countdown.
Inthecaseofapaused
countdownattheheating
step:
Timewillnotcount
downuntiltheselected
temperatureforthe
programisreached
Inthecaseofapaused
countdownatthespinning
step:
Theremaybeanimbalance
oflaundryinthemachine.
Theautomaticspincorrectionsystemmight
havebeenactivatedduetotheunbalanced
distributionofthelaundryinthedrum.
Thelaundryinthedrummaybeclustered
(bundledlaundryinabag).Laundryshouldbe
rearrangedandre-spun.
Nospinningisperformedwhenthelaundryis
notevenlydistributedinthedrumtoprevent
anydamagetothemachineandtoits
environment.

12 - EN
LBS85-9 LBS65-9
5 5
84 84
60 60
54 54
61 61
230V/50Hz
10 10
2300
800 600
7 Specifications
Specificationsofthisappliancemaychangewithoutnoticetoimprovethequalityoftheproduct.
Figuresinthismanualareschematicandmaynotmatchyourproductexactly.
Valuesstatedonthemachinelabelsorinthedocumentationaccompanyingitareobtained
inlaboratoryinaccordancewiththerelevantstandards.Dependingonoperationaland
environmentalconditionsoftheappliance,valuesmayvary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
Thisappliance’spackagingmaterialisrecyclable.Helprecycleitandprotectthe
environmentbydroppingitoffinthemunicipalreceptaclesprovidedforthispurpose.
Yourappliancealsocontainsagreatamountofrecyclablematerial.Itismarkedwith
thislabeltoindicatetheusedappliancesthatshouldnotbemixedwithotherwaste.
Thisway,theappliancerecyclingorganisedbyyourmanufacturerwillbedoneunder
thebestpossibleconditions,incompliancewithEuropeanDirective2002/96/ECon
WasteElectricalandElectronicEquipment.Contactyourtownhalloryourretailerforthe
usedappliancecollectionpointsclosesttoyourhome.Wethankyoudoingyourpartto
protecttheenvironment.
