Washing Machine
User’s Manual
WTE 11735 XCST
EN

Please read this user manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from your
product which has been manufactured with high quality and state-of-the-art technology.
Therefore, please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use. If you hand
over the product to someone else, give this user manual as well. Follow all warnings and
information in the user manual.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
Explanaton of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints
about usage.
A
Warning for hazardous situations with
regard to life and property.
B
Warning for electric shock.
Recyclable materials.
Do not dispose of the packaging materials together with domestic or other wastes. Take
them to the packaging material collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN
Washng Machne / User’s Manual
1 General safety instructions 5
1.1 Life and property safety ---------------------------------------------------------------------------5
1.2 Children's safety -----------------------------------------------------------------------------------6
1.3 Electrical safety------------------------------------------------------------------------------------7
1.4 Hot surface safety---------------------------------------------------------------------------------7
2 Important instructions for the environment 8
2.1 Compliance with WEEE Directive------------------------------------------------------------------8
2.2 Package information ------------------------------------------------------------------------------8
3 Intended use 8
4 Your product 9
4.1 Overview -------------------------------------------------------------------------------------------9
4.2 Package Contents ---------------------------------------------------------------------------------10
4.3 Technical specifications---------------------------------------------------------------------------11
4.4 Installation-----------------------------------------------------------------------------------------12
4.4.1 Approprate nstallaton locaton ------------------------------------------------------------------------12
4.4.2 Removng packagng renforcement --------------------------------------------------------------------12
4.4.3 Removng transportaton safety bolts ------------------------------------------------------------------13
4.4.4 Connectng water supply --------------------------------------------------------------------------------13
4.4.5 Connectng the dran hose to the dran -----------------------------------------------------------------14
4.4.6 Adjustng the feet----------------------------------------------------------------------------------------15
4.4.7 Electrcal connecton -------------------------------------------------------------------------------------15
4.4.8 Intal use -------------------------------------------------------------------------------------------------15
4.5 Preparation ----------------------------------------------------------------------------------------16
4.5.1 Sortng the laundry ---------------------------------------------------------------------------------------16
4.5.2 Preparng laundry for washng---------------------------------------------------------------------------17
4.5.3 Thngs to be done for energy savng --------------------------------------------------------------------17
4.5.4 Loadng the laundry --------------------------------------------------------------------------------------18
4.5.5 Correct load capacty -------------------------------------------------------------------------------------18
4.5.6 Usng detergent and softener ---------------------------------------------------------------------------18
4.5.7 Tps for effcent washng--------------------------------------------------------------------------------21
TABLE OF CONTENTS

4 / EN
Washng Machne / User’s Manual
4.6 Operating the product ----------------------------------------------------------------------------22
4.6.1 Control panel----------------------------------------------------------------------------------------------22
4.6.2 Dsplay symbols ------------------------------------------------------------------------------------------22
4.6.3 Programme and consumpton table---------------------------------------------------------------------23
4.6.4 Programme selecton ------------------------------------------------------------------------------------24
4.6.5 Programmes ----------------------------------------------------------------------------------------------25
4.6.6 Temperature selecton-----------------------------------------------------------------------------------27
4.6.7 Spn speed selecton -------------------------------------------------------------------------------------27
4.6.8 Auxlary functon selecton------------------------------------------------------------------------------29
4.6.9 End Tme--------------------------------------------------------------------------------------------------30
4.6.10 Startng the programme--------------------------------------------------------------------------------31
4.6.11 Loadng door lock----------------------------------------------------------------------------------------31
4.6.12 Changng the selectons after programme has started -----------------------------------------------31
4.6.13 Chld Lock ------------------------------------------------------------------------------------------------32
4.6.14 Cancellng the programme -----------------------------------------------------------------------------33
4.6.15 End of programme --------------------------------------------------------------------------------------33
4.6.16 Adjustng the VOLUME level----------------------------------------------------------------------------33
4.7 Maintenance and cleaning ------------------------------------------------------------------------34
4.7.1 Cleanng the detergent drawer --------------------------------------------------------------------------34
4.7.2 Cleanng the loadng door and the drum ----------------------------------------------------------------34
4.7.3 Cleanng the body and control panel --------------------------------------------------------------------35
4.7.4 Cleanng the water ntake flters ------------------------------------------------------------------------35
4.7.5 Dranng remanng water and cleanng the pump flter------------------------------------------------35
5 Troubleshooting 37
TABLE OF CONTENTS

5 / EN
Washng Machne / User’s Manual
1 General safety nstructons
This section includes security instructions which may help prevent
the injuries and material damage risks. All kinds of warranties shall
be invalid if these instructions are not observed.
1.1 Lfe and property safety
u
Never place the product on a carpet-covered floor. Electrcal parts
wll get overheated snce ar cannot crculate from under the devce.
Ths wll cause problems wth your product.
u
Unplug the product f t s not n use.
u
Always have the reparng procedures carred out by an Authorsed
Servce Agent. The manufacturer shall not be held lable for damages
that may arse from procedures carred out by unauthorsed persons.
u
The water supply and dranng hoses must be securely fastened and
reman undamaged. Otherwse a water leak may occur.
u
Whle there s water nsde the product, never open the loadng door
or remove the flter. Otherwse, rsk of floodng and njury from hot
water wll occur.
u
Do not force open the locked loadng door. The door can be opened
a few mnutes after the washng cycle ends. In the case of forcng
the loadng door to open, the door and the lock mechansm may get
damaged.
u
Use detergents, softeners and supplements sutable for automatc
washng machnes only.
u
Follow the nstructons on the label of textles and the detergent
package.

6 / EN
Washng Machne / User’s Manual
1.2 Chldren's safety
u
Ths product can be used by chldren who are at the age of 8 and over
and the people whose physcal, sensory or mental sklls are not fully
developed or who do not have necessary requred experence and
knowledge as long as they are supervsed or traned about the safe
use of the product and ts rsks. Chldren should not play wth the
devce. Cleanng and mantenance works should not be performed
by chldren unless they are supervsed by someone. Chldren of less
than 3 years should be kept away unless contnuously supervsed.
u
Packagng materals may be dangerous for chldren. Keep packagng
materals n a safe place away from reach of chldren.
u
Electrcal products are dangerous for chldren. Keep chldren away
from the product when t s n use. Do not allow them to play wth the
product. Use the chld lock to prevent chldren from nterferng wth
the product.
u
Do not forget to close the loadng door when leavng the room where
the product s located.
u
Store all detergents and addtves n a safe place away from the
reach of chldren and close the cover of the detergent contaner or
seal the detergent package.

7 / EN
Washng Machne / User’s Manual
1.3 Electrcal safety
u
If the product has a falure, t should not be operated unless t s
repared by an Authorsed Servce Agent. Rsk of electrc shock!
u
Ths product s desgned to resume operatng n the event of
powerng on after a power nterrupton. If you wsh to cancel the
programme, see "Cancellng the programme" secton.
u
Plug the product nto a grounded outlet protected by a 13 A fuse. Do
not neglect to have the groundng nstallaton made by a qualfed
electrcan. Our company shall not be lable for any damages that
wll arse when the product s used wthout groundng n accordance
wth the local regulatons.
u
Do not wash the product by sprayng or pourng water onto t! Rsk of
electrc shock!
u
Never touch the power cable plug wth wet hands! Do not grab the
power cord to unplug the machne, always unplug t by holdng the
socket wth one hand, and pullng the plug wth the other hand.
u
Product should be unplugged durng nstallaton, mantenance,
cleanng and repar procedures.
u
If the power cable s damaged, t must be replaced by the
manufacturer, after sales servce or a smlarly qualfed person
(preferably an electrcan) or someone desgnated by the mporter n
order to avod possble rsks.
1.4 Hot surface safety
While washing the laundry at high
temperatures, the loading door glass will
get hot. Considering this fact, during the
washing operation keep children away
from the loading door of the product to
prevent them touching it.

8 / EN
Washng Machne / User’s Manual
3 Intended use
• Thisproducthasbeendesignedfordomesticuse.Itisnotforcommercialpurposesorit
should not be used other than its intended use.
• Theproductmustonlybeusedforwashingandrinsingoflaundrythataremarked
accordingly.
• Themanufacturerwaivesanyresponsibilityarisingfromincorrectusageor
transportation.
• Theservicelifeofyourproductis10years.Duringthisperiod,originalsparepartswillbe
available to operate the appliance properly.
2 Important instructions for the environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Do not dispose of the
waste product with normal domestic and other wastes at the end of its service
life. Take it to the collection center for the recycling of electrical and electronic
equipment. Please consult your local authorities to learn about these collection centres.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.

9 / EN
Washng Machne / User’s Manual
4 Your product
4.1 Overview
1
2
3
4
5
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Drain hose
5- Loading door
6- Filter cap
7- Adjustable feet
8- Detergent drawer

10 / EN
Washng Machne / User’s Manual
4.2 Package Contents
9
10
11 12
13
14
15
16
abc
9- Power cable
10- Drain hose
11- Transportation safety bolts*
12- Mains water inlet hose (One of the following filter types is used for the mains hose
connection.)
a- Electronic water shut-off
b- Mechanical water shut-off
c- Standard
13- Liquid detergent container**
14- User Manual
15- Blind plug***
16- Plastic plug group
* Number of transportation safety bolts may change depending on the model of your product.
** This may be supplied with the machine depending on the model of your product.
*** It will be supplied if your product has double water inlet.
C
Figures in this manual are schematic and may not match the product exactly.
