Smeg SAWS 8160 User manual

SAWS 8160
Lav atrice
Manuale utente
Washing Machine
User’s Manual
Document Number 282052Smeg/ 10-02-15.(13:24)

C
A
Please read this user manual first!
Dear Customer ,
Thank you for prefering a Smeg product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep
it as a reference for future use. If you handover the product to someone else, give the user manual as
well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful hints
about usa ge.
Warning for hazardous situations with
regard to life and property .
B
Warning for electric shock.
Packaging materials of the product
are manufactured from recycla ble
materials in accordance with our
National Environment Regula tions.
Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local authorities.

TABLE OF CONTENTS
1 Important instructions for safety and
environment 4
1.1 General safety ........ ........ ...... . 4
1.2 Intended use ............. .......... . 5
1.3 Children's safety. ........ ........... . . 6
1.4 Package information. ....... .... ...... . 6
1.5 Disposing of the waste product .......... . 6
1.6 Compliance with WEEE Directive ......... . 7
2 Y our washing machine 8
2.1 Overview ... ........ ........... .... . 8
2.2 Package Contents ................... . 9
2.3 Technical specifications ........... ... . 10
3 Installation 11
3.1 Appropriate installation location. ........ . 11
3.2 Removing packaging reinforcement ..... . 11
3.3 Removing the transportation locks. ...... . 11
3.4 Connecting water supply. ............. . 12
3.5 Connecting to the drain. ........... ... . 13
3.6 Adjusting the feet ..... ........... ... . 13
3.7 Electrical connection. ... ........ ..... . 14
4 Preparation 15
4.1 Sorting the laundr y ...... ... ......... . 15
4.2 Preparing laundry for washing. ......... . 16
4.3 Things to be done for energy saving ..... . 16
4.4 Initial use ... ........ ........... ... . 17
4.5 Correct load capacity ................ . 17
4.6 Loading the laundry ................. . 17
4.7 Using detergent and softener .......... . 17
4.8 Tips for efficient washing ............. . 20
5 Operating the product 21
5.1 Control panel .......... ... ......... . 21
5.2 Displaysymbols 22
5.3 Preparing the machine ............... . 23
5.4 Programme selection ................ . 23
5.5 Programmes ........ .............. . 23
5.8 Temperature selection. ............... . 27
5.9 Spin speed selection. ................ . 27
5.10 Programme and consumption table. .... . 29
5.11 Auxiliary function selection ........... . 30
5.12 End Time ... ........ ........ ..... . 31
5.13 Starting the programme ........ ..... . 31
5.14 Loading door lock. ..... ... ......... . 32
5.15 Changing the selections after the
programme has started ........ ..... . 32
5.16 Child Lock ....................... . 32
5.17 Canceling the programme. ........... . 33
5.18 End of programme ........ ......... . 33
5.19 Adjusting the VOLUME level .......... . 33
6 Maintenance and cleaning 34
6.1 Cleaning the detergent drawer ......... . 34
6.2 Cleaning the loading door and the drum .. . 34
6.3 Cleaning the body and control panel ... .. . 35
6.4 Cleaning the water intake filters ........ . 35
6.5 Draining remaining water and cleaning the
pump filter. ........ ........ ...... . 35
7 Troubleshooting 37

3 / EN

4 / EN
Washing Machine /User’s Manual
4 / EN
Washing Machine /User’s Manual
1
Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty .
1.1 General safety
• This product can be used by children at and above 8 years old and by persons
whose physical, sensory or mental capabilities were not fully developed or
who lack experience and knowledge provided that they are supervised or
trained on the safe usage of the product and the risks it brings out. Children
must not play with the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by someone. Children of
less than 3 years should be kept away unless continuously supervised.
• Never place the product on a carpet-covered floor. Otherwise, lack of airflow
beneath the machine will cause electrical parts to overheat. This will cause
problems with your product.
• If the product has a failure, it should not be operated unless it is repaired b y
the Authorized Service Agent. There is the risk of electric shock!
• This product is designed to resume operating in the event of powering on after
a power interruption. If you wish to cancel the programme, see "Cancelling
the programme" section.
• Connect the product to a grounded outlet protected by a 16 A fuse. Do not
neglect to have the grounding installation made by a qualified electrician. Our
company shall not be liable for any damages that will arise when the product
is used without grounding in accordance with the local regula tions.
• The water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, there is the risk of water leakage.
• Never open the loading door or remove the filter while there is still water in the
drum. Otherwise, risk of flooding and injury from hot water will occur .
• Do not force open the locked loading door. The loading door will be ready to
open just a few minutes after the washing cycle comes to an end. In case of
forcing the loading door to open, the door and the lock mechanism may get
damaged.
• Unplug the product when not in use.

5 / EN
Washing Machine /User’s Manual
5 / EN
Washing Machine /User’s Manual
• Never wash the product by spreading or pouring water onto it! There is the
risk of electric shock!

6 / EN
Washing Machine /User’s Manual
6 / EN
Washing Machine /User’s Manual
Important instructions for safety and environment
• Never touch the plug with wet hands! Never unplug by pulling on the ca ble,
always pull out by grabbing the plug.
• Use detergents, softeners and supplements suitable for automatic washing
machines onl y .
• Follow the instructions on the textile tags and on the detergent package.
• The product must be unplugged during installation, maintenance, cleaning
and repairing procedures.
• Always have the installation and repairing procedures carried out by the
Authorized Service Agent Manufacturer shall not be held liable
for damages that may arise from procedures carried out by unauthorized
persons.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similary qualified persons in order to avoid a hazard.
• If the power cable is damaged, it must be replaced by the manufacturer ,
after sales service or a similarly qualified person (preferably an electrician) or
someone designated by the importer in order to avoid possible risks.
• Place the product on a rigid, flat and level surface.
• Do not place it on a long-pile rug or similar surfaces.
• Do not place the product on a high platform or near the edge on a cascaded
surface.
• Do not place the product on the power ca ble.
• Never use sponge or scrub materials. These will damage the painted, chrome
plated and plastic surfaces.
1.2 Intended use
• This product has been designed for domestic use. It is not suitable f or
commercial use and it must not be used out of its intended use.
• The product must only be used for washing and rinsing of laundry that are
marked accordingl y .
• The manufacturer waives any responsibility arisen from incorrect usage or
transporta tion.

7 / EN
Washing Machine /User’s Manual
7 / EN
Washing Machine /User’s Manual
Important instructions for safety and environment
Important instructions for safety and environment
1.3 Children's safety
• Packaging materials are dangerous to children. Keep packaging materials in a
safe place away from reach of the children.
• Electrical products are dangerous for the children. Keep children away from
the product when it is in use. Do not let them to tamper with the product. Use
child lock to prevent children from intervening with the product.
• Do not forget to close the loading door when leaving the room where the
product is loca ted.
• Store all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
While washing the laundry at high temperatures, the loading
door glass becomes hot. Therefore, keep especially the
children away from the loading door of the machine while the
washing operation is in progress.
1.4 Package information
• Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated b y
the local authorities.
1.5 Disposing of the waste product
• This product has been manufactured with high quality parts and ma terials
which can be reused and are suitable for recycling. Therefore, do not dispose
the product with normal domestic waste at the end of its service life. Take it
to a collection point for the recycling of electrical and electronic equipment.
Please consult your local authorities to learn the nearest collection point. Help
protect the environment and natural resources by recycling used products. For

8 / EN
Washing Machine /User’s Manual
8 / EN
Washing Machine /User’s Manual
Important instructions for safety and environment
children's safety, cut the power cable and break the locking mechanism of the
loading door so that it will be non-functional before disposing of the product.

9 / EN
Washing Machine /User’s Manual
9 / EN
Washing Machine /User’s Manual
Important instructions for safety and environment
1.6 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU).
This product bears a classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with high quality pa rts
and materials which can be reused and are suitable f or
recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. T ake
it to the collection center for the recycling of electrical and
electronic equipment. Please consult your local authorities to
learn about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/
EU). It does not contain harmful and prohibited materials specified in the
Directive.

10 / EN
Washing Machine /User’s Manual
10 / EN
Washing Machine /User’s Manual
Your washing machine
2
Your washing machine
2.1 Over view
1
2
8
3
4
5
6
7
1- Power ca ble
2- Top panel
3- Control panel
4- Drain hose
5- Loading door
6- Filter ca p
7- Adjustable feet
8- Detergent drawer

11 / EN
Washing Machine /User’s Manual
11 / EN
Washing Machine /User’s Manual
Your washing machine
2.2 Package Contents
3 4
2
1
a b
c
6 8
7
5
1- Power ca ble
2- Drain hose
3- Transportation safety bolts *
4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.)
a- Electronic water shut-of f
b- Mechanical water shut-of f
c- Standard
5- Liquid detergent container**
6- User Manual
7- Blind plug***
8- Plastic plug assembl y
* Number of transportation safety bolts may change depending on the model of your machine.

12 / EN
Washing Machine /User’s Manual
12 / EN
Washing Machine /User’s Manual
Your washing machine
** This may be supplied with the machine depending on the model of your machine.
*** This is supplied if your machine is equipped with double water inlet.

13 / EN
Washing Machine /User’s Manual
13 / EN
Washing Machine /User’s Manual
Your washing machine
2.3 Technical specifications
Models (EN)
SAWS 8160
Maximum dry laundry capacity (kg)
8
Height (cm)
84
Width (cm)
60
Depth (cm)
60
Net weight (±4 kg.)
77
Electrical input (V/Hz)
220-240 V / 50Hz
Total current (A)
10
Total power (W)
2000-2350
Spin speed (rpm/ min., max.)
1600
Stand-by mode power (W)
0.64
Off-mode power (W)
0.44
Main model code
978
Single Water inlet / Double Water inlet
- / •
Woolmark No:
M1403
• A vaila ble
“The wool wash cycle of this machine has been approved by The W oolmark
Company for the washing of machine washable wool products provided that the
products are washed according to the instructions on the garment label and those
issued by the manufacturer of this washing machine. M1403.”
“In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certification trade
mark.”
C
Technical specifications may be changed without prior notice to improve the quality of the product.
C
Figures in this manual are schematic and may not match the product exactl y .

14 / EN
Washing Machine /User’s Manual
14 / EN
Washing Machine /User’s Manual
Your washing machine
C
Values stated on the product labels or in the documentation accompanying it are obtained in labora tor y
conditions in accordance with the relevant standards. Depending on operational and environmental
conditions of the product, these values may var y .

15 / EN
Washing Machine /User’s Manual
15 / EN
Washing Machine /User’s Manual
Your washing machine
C
Preparation of the location and electrical,
tap water and waste water installations
at the place of installation is under
customer's responsibility .
B
WARNING: Installation and electrical
connections of the product must be
carried out by the Authorized Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorized
persons.
A
WARNING: Prior to installation, visuall y
check if the product has any defects on
it. If so, do not have it installed. Damaged
products cause risks for your safety .
C
Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3 Installation
Refer to the nearest Authorised Service Agent f or
installation of the product. To make the product
ready for use, review the information in the user
manual and make sure that the electricity, tap
water supply and water drainage systems are
appropriate before calling the Authorized Service
Agent. If they are not, call a qualified technician
and plumber to have any necessary arrangements
carried out.
3.2 Removing packaging
reinforcement
Tilt the machine backwards to remove the
packaging reinforcement. Remove the packaging
reinforcement by pulling the ribbon.
3.3 Removing the
transportation locks
A
WARNING: Do not remove the
transportation locks before taking out the
packaging reinforcement.
A
safety bolts before operating the washing
WARNING: Remove the transportation
machine! Otherwise, the product will be
damaged.
3.1 Appropriate installation location
• Place the machine on a rigid floor. Do not place
it on a long pile rug or similar surfaces.
• Total weight of the washing machine and the
dryer -with full load- when they are placed
on top of each other reaches to approx. 180
kilograms. Place the product on a solid and f la t
floor that has sufficient load carrying ca pacity!
• Do not place the product on the power ca ble.
• Do not install the product at places where
temperature may fall below 0ºC.
• Place the product at least 1 cm away from the
edges of other furniture.
1. Loosen all the bolts with a suitable spanner until
they rotate freely (C) .
2. Remove transportation safety bolts by turning
them gentl y .

16 / EN
Washing Machine /User’s Manual
16 / EN
Washing Machine /User’s Manual
Installation
C
Keep the transportation safety bolts in
a safe place to reuse when the washing
machine needs to be moved again in the
future.
C
Never move the product without the
transportation safety bolts properly fixed
in place!
C
The water supply pressure required to run
the product is between 1 to 10 bars (0.1
– 1 MPa). It is necessary to have 10 –80
liters of water flowing from the fully open
tap in one minute to have your machine
run smoothly. Attach a pressure reducing
valve if water pressure is higher .
C
If you are going to use the double water -
inlet product as a single (cold) water -inlet
unit, you must install the supplied stopper
to the hot water valve before operating the
product. (Applies for the products supplied
with a blind stopper g roup.)
A
WARNING: Models with a single water
inlet should not be connected to the hot
water tap. In such a case the laundry will
get damaged or the product will switch to
protection mode and will not opera te.
A
WARNING: Do not use old or used water
inlet hoses on the new product. It ma y
cause stains on your laundr y .
A
3. Attach the plastic covers supplied in the User
Manual bag into the holes on the rear panel. (P)
hose (left) (max. 90 ºC) is for hot water inlet,
blue hose (right) (max. 25 ºC) is for cold water
inlet.
3.4 Connecting water supply
WARNING: Ensure that the cold and
hot water connections are made correctl y
when installing the product. Otherwise,
your laundry will come out hot at the end
of the washing process and wear out.
2. Tighten all hose nuts by hand. Never use a tool
when tightening the nuts.
3. Open the taps completely after making the
hose connection to check for water leaks a t
the connection points. If any leaks occur, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. To prevent
water leakages and damages caused by them,
keep the taps closed when the machine is not
in use.
1. Connect the special hoses supplied with the
product to the water inlets on the product. Red

17 / EN
Washing Machine /User’s Manual
17 / EN
Washing Machine /User’s Manual
Installation
A
A
Installation
3.5 Connecting to the drain
• The end of the drain hose must be directl y
connected to the wastewater drain or to the
washbasin.
WARNING: Your house will be flooded if
the hose comes out of its housing during
water discharge. Moreover, there is risk
of scalding due to high washing
temperatures! To prevent such situations
and to ensure smooth water intake and
discharge of the machine, fix the end
of the discharge hose tightly so that it
cannot come out.
• The hose should be attached to a height of a t
least 60 cm, and 90 cm at most.
• In case the hose is elevated after laying it on
the floor level or close to the ground (less than
60 cm above the ground), water discharge
becomes more difficult and the laundry ma y
come out excessively wet. Therefore, follow the
heights described in the figure.
• To prevent flowing of dirty water back into the
machine and to allow for easy discharge, do not
immerse the hose end into the dirty water or do
not drive it in the drain more than 15 cm. If it is
too long, cut it short.
• The end of the hose should not be bent, it
should not be stepped on and the hose must
not be pinched between the drain and the
machine.
• If the length of the hose is too short, use it b y
adding an original extension hose. Length of the
hose may not be longer than 3.2 m. To avoid
water leak failures, the connection between
the extension hose and the drain hose of the product
must be fitted well with an a ppropriate clamp as not
to come off and leak.

18 / EN
Washing Machine /User’s Manual
18 / EN
Washing Machine /User’s Manual
Installation
A
3.6 Adjusting the feet
WARNING: In order to ensure
tha t the product operates more
silentl y and vibration-free, it
must stand level and balanced
on its feet. Balance the
machine by adjusting the feet.
Otherwise, the product may move
from its place and cause crushing
and vibration problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product
stands level and balanced.
3. Tighten all lock nuts again by hand.
WARNING: Do not use any tools to
loosen the lock nuts. Otherwise, they will
get damaged.

19 / EN
Washing Machine /User’s Manual
19 / EN
Washing Machine /User’s Manual
Installation
B
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall not
be liable for any damages that will arise when the
product is used without grounding in accordance
with the local regulations.
• Connection must comply with na tional
regulations.
• Power cable plug must be within easy reach
after installation.
• If the current value of the fuse or breaker in the
house is less than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
• The voltage specified in the "T echnical
specifications" section must be equal to your
mains volta ge.
• Do not make connections via extension cables
or multi-plugs.
WARNING: Damaged power cables
must be replaced by the Authorized
Service Agents.
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water suppl y
connections.
3. Drain all water that has remained in the
product. See 6.5
4. Install transportation safety bolts in the reverse
order of removal procedure; see 3.3.
C
Never move the product without the
transportation safety bolts properly fixed
in place!
A
WARNING: Packaging materials are
dangerous to children. Keep packaging
materials in a safe place away from
reach of the children.
