Smeg LBS 126 User manual

Washing Machine
Lavatrice
LBS 126

2 - EN
1 Warnings
General Safety
• Neverplaceyourmachineonacarpet
coveredfloor.Otherwise,lackofairflow
frombelowofyourmachinemaycause
electricalpartstooverheat.Thismaycause
problemswithyourwashingmachine.
• Ifthepowercableormainsplugis
damagedyoumustcallAuthorizedService
forrepair.
• Fitthedrainhoseintothedischarge
housingsecurelytopreventanywater
leakageandtoallowmachinetotakein
anddischargewaterasrequired.Itisvery
importantthatthewaterintakeanddrain
hosesarenotfolded,squeezed,orbroken
whentheapplianceispushedintoplace
afteritisinstalledorcleaned.
• Yourwashingmachineisdesignedto
continueoperatingwhenthepower
restoresafterapowerinterruption.The
machinewillresumeitsprogramwhenthe
powerrestores.Pressthe“Start/Pause/
Cancel”buttonfor3secondstocancelthe
program(See,CancelingaProgram)
• Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.Itisnot
harmfultoyourmachine.
• Someproblemsyoumayencountermay
becausedbytheinfrastructure.Press
“Start/Pause/Cancel”buttonfor3seconds
tocanceltheprogramsetinyourmachine
beforecallingtheauthorizedservice.
First Use
• Carryoutyourfirstwashingprocess
withoutloadingyourmachineandwith
detergentunder“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingyourmachine.
• Ifthecurrentfuseorcircuitbreakerisless
than16Amperes,pleasehaveaqualified
electricianinstalla16Amperefuseor
circuitbreaker.
• Whileusingwithorwithoutatransformer,
donotneglecttohavethegrounding
installationlaidbyaqualifiedelectrician.
Ourcompanyshallnotbeliableforany
damagesthatmayarisewhenthemachine
isusedonalinewithoutgrounding.
• Keepthepackagingmaterialsoutofreach
ofchildrenordisposethembyclassifying
accordingtowastedirectives.
Intended use
• Thisproducthasbeendesignedforhome
use.
• Theappliancemayonlybeusedfor
washingandrinsingoftextilesthatare
markedaccordingly.
Safety instructions
• Thisappliancemustbeconnectedto
anearthedoutletprotectedbyafuseof
suitablecapacity.
• Thesupplyanddraininghosesmust
alwaysbesecurelyfastenedandremainin
anundamagedstate.
• Fitthedraininghosetoawashbasinor
bathtubsecurelybeforestartingupyour
machine.Theremaybeariskofbeing
scaldedduetohighwashingtemperatures!
• Neveropentheloadingdoororremovethe
filterwhilethereisstillwaterinthedrum.
• Unplugthemachinewhenitisnotinuse.
• Neverwashdowntheappliancewitha
waterhose!Thereistheriskofelectric
shock!
• Nevertouchtheplugwithwethands.Do
notoperatethemachineifthepowercord
orplugisdamaged.
• Formalfunctionsthatcannotbesolvedby
informationintheoperatingmanual:
• Turnoffthemachine,unplugit,turnoff
thewatertapandcontactanauthorized
serviceagent.Youmayrefertoyourlocal
agentorsolidwastecollectioncenterin
yourmunicipalitytolearnhowtodisposeof
yourmachine.
If there are children in your
house...
• Keepchildrenawayfromthemachine
whenitisoperating.Donotletthem
tamperwiththemachine.
• Closetheloadingdoorwhenyouleavethe
areawherethemachineislocated.

3- EN
2 Installation
Removing packaging
reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
ATransportationsafetyboltsmustbe
removedbeforeoperatingthewashing
machine!Otherwise,themachinewillbe
damaged!
1. Loosenalltheboltswithaspanneruntil
theyrotatefreely(“C”)
2. Removetransportationsafetyboltsby
turningthemgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesonthe
rearpanel.(“P”)
C Keepthetransportationsafetyboltsin
asafeplacetoreusewhenthewashing
machineneedstobemovedagaininthe
future.
C Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
ADonotuseanytoolstoloosenthelock
nuts.Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutson
thefeet.
2. Adjustthemuntilthemachinestandslevel
andfirmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorun
themachinemustbe1-10bar(0,1–1
MPa).
• Connectthespecialhosessuppliedwith
themachinetothewaterintakevalveson
themachine.
• Ifyouaregoingtouseyourdoublewater-
inletmachineasasingle(cold)water-inlet
unit,youmustinstallthestopper*,supplied
withyourmachinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwater
hoseafterremovingthestopperand
gasketgroupfromthehotwatervalve.
*Appliesfortheproductssuppliedwithablind
stoppergroup.
• Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.
Whenreturningtheappliancetoitsplaceafter
maintenanceorcleaning,careshouldbetaken
nottofold,squeezeorblockthehoses.
Connecting to the drain
Thewaterdischargehosecanbeattachedto
theedgeofawashbasinorbathtub.Thedrain
hoseshouldbefirmlyfittedintothedrainasto
notgetoutofitshousing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainorto
thewashbasin.
• Thehoseshouldbeattachedtoaheightof
atleast40cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingit
onthefloorlevelorclosetotheground
(lessthan40cmabovetheground),water
dischargebecomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothe
drainageformorethan15cm.Ifitistoo
longyoumayhaveitshortened.
• Themaximumlengthofthecombined
hosesmustnotbelongerthan3.2m.

4- EN
Electrical connection
Connectthemachinetoanearthedoutlet
protectedbyafuseofsuitablecapacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuse
protectionarespecifiedinthesection
“TechnicalSpecifications”.
• Thespecifiedvoltagemustbeequalto
yourmainsvoltage.
• Connectionviaextensioncordsormulti-
plugsshouldnotbemade.
BAdamagedpowercablemustbereplaced
byaqualifiedelectrician.
BTheappliancemustnotbeoperatedunless
itisrepaired!Thereistheriskofelectric
shock!
3 Initial preparations for
washing
Preparing clothes for washing
Laundryitemswithmetalattachmentssuch
as,bras,beltbucklesandmetalbuttons
willdamagethemachine.Removemetal
attachmentsorplacetheitemsinaclothing
bag,pillowcase,orsomethingsimilar.
• Sortthelaundryaccordingtotypeoffabric,
color,anddegreeofsoilingandpermissible
watertemperature.Alwaysfollowthe
adviceonthegarmentlabels.
• Placesmallitemslikeinfants’socksand
nylonstockings,etc.inalaundrybag,
pillowcaseorsomethingsimilar.Thiswill
alsosaveyourlaundryfromgettinglost.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriateprogram.
• Donotwashcolorsandwhitestogether.
New,darkcoloredcottonsmayreleasea
lotofdye.Washthemseparately.
• Useonlydyes/colorchangersandlime
removerssuitableformachinewash.
Alwaysfollowtheinstructionsonthe
packaging.
• Washtrousersanddelicateclothesturned
insideout.
Correct load capacity
CPleasefollowtheinformationinthe
"ProgramSelectionTable".Washing
resultswilldegradewhenthemachineis
overloaded.
Loading door
Thedoorlocksduringprogramoperationand
theDoorLockedSymbollightsup.Thedoor
canbeopenedwhenthesymbolfadesout.
Detergents and softeners
Detergent Drawer
Thedetergentdraweriscomposedofthree
compartments:
Thedetergentdispensermaybeintwo
differenttypesaccordingtothemodelofyour
machine.
–(I)forprewash
–(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other cleaning
agents
Adddetergentandsoftenerbeforestartingthe
washingprogram.
Neveropenthedetergentdispenserdrawer
whilethewashingprogramisrunning!
Whenusingaprogramwithoutpre-wash,no
detergentshouldbeputintothepre-wash
compartment(Compartmentno.I).
Detergent quantity
Theamountofwashingdetergenttobeused
dependsontheamountoflaundry,thedegree
ofsoilingandwaterhardness.
• Donotuseamountsexceedingthe
quantitiesrecommendedonthepackage
toavoidproblemsofexcessivefoam,
poorrinsing,financialsavingsandfinally,
environmentalprotection.
• Neverexceedthe(>max<)levelmarking;
otherwise,thesoftenerwillbewasted
withoutbeingused.
• Donotuseliquiddetergentifyouwantto
washusingthetimedelayfeature.

5- EN
4 Selecting a Program and Operating Your Machine
Control panel
1- SpinSpeedAdjustmentKnob*
2- TimeDelayButton*
3- TemperatureAdjustmentKnob*
4- Start/Pause/CancelButton
5- AuxiliaryFunctionKeys
6- ProgramSelectionKnob
7- On/OffButton
8- ProgramFollow-upIndicators*
9- Child-proofLockIndicator*
*Accordingtoyourmachine’smodel
Turning the machine on
Youcanpreparethemachineforprogram
selectionbypressingthe“On/Off”button.
Whenthe“On/Off”buttonispressed,the
“Ready”lightilluminatesindicatingthatthe
doorisulocked.Pressthe“On/Off”button
againtoshutdownthemachine.
Program selection
Selecttheappropriateprogramfromthe
programtableandthefollowingwashing
temperaturetableaccordingtotype,amount
anddegreeofsoilingofthelaundry.Selectthe
desiredprogramwiththeprogramselection
button.
CEachoftheseprogramsconsistofa
completewashingprocess,including
wash,rinseand,ifrequired,spincycles.
90˚C Normallysoiled,whitecottons
andlinens.
60˚C
Normallysoiled,fadeproof
coloredlinens,cottonsor
syntheticclothesandlightly
soiledwhitelinens
40˚C-
30°C-
Cold
Blendedclothesincluding
syntheticsandwoolensaswell
asdelicates.
C Programsarelimitedwiththehighestspin
speedappropriateforthatparticulartype
ofcloth.
Main programs
Dependingonthetypeoftextile,thefollowing
mainprogramsareavailable:
•Cottons
Youcanwashyourdurableclotheswiththis
program.Yourlaundrywillbewashedwith
vigorouswashingmovementsduringalonger
washingcycle.
•Synthetics
Youcanwashyourlessdurableclotheson
thisprogram.Gentlerwashingmovements
8
124 5
67

6- EN
andashorterwashingcycleisusedcompared
tothe“Cottons”program.Itisrecommended
foryoursyntheticclothes(suchasshirts,
blouses,synthetic/cottonblendedgarments,
etc.).Forcurtainsandlace,the“Synthetic
40”programwithpre-washandanti-creasing
functionsselectedisrecommended.
•Delicates
Youcanwashyourdelicateclothesonthis
program.Ithasmoresensitivewashing
movementsanddoesnotmakeintermediate
spinningcomparedto“Synthetic”program.
•Woolens
Youcanwashyourmachine-washablewoolen
garmentsonthisprogram.Washbyselecting
thepropertemperatureaccordingtothelabels
ofyourclothes.Itisrecommendedtouse
appropriatedetergentsforwoolens.
•Hand Wash
Youcanwashyourwoolen/delicateclothes
thatbear“notmachine-washable”labelsfor
whichhandwashisrecommendedonthis
program.Itwashesthelaundrywithvery
tenderwashingmovementswithoutdamaging
yourclothes.
Additional programs
Forspecialcases,therearealsoextra
programsavailable:
CAdditionalprogramsmaydifferaccording
tothemodelofyourmachine.
• Baby
Increasedhygieneisprovidedbyalonger
heatingperiodandanadditionalrinsecycle.It
isrecommendedforbabyclothesandclothes
wornbyallergicpeople.
• Intensive
Youcanwashyourdurableandheavilysoiled
clothesonthisprogram.Thisprogramwashes
foralongertimeandanextrarinsecyclewill
bemadecomparedtothe“Cottons”program.
Youcanuseitforyourheavilysoiledclothes
thatyouwishtoberinsedgently.
• Mix
Youcanusethisprogramtowashcottons
andsyntheticstogetherwithoutneedingto
sortthem.
• Mini
Thisprogramisusedtoquicklywash(30
minutes)asmallamountoflightlysoiledcotton
garments.
Special programs
Forspecificapplications,youcanselectanyof
thefollowingprograms:
• Rinse
Thisprogramisusedwhenyouwanttorinse
orstarchseparately.
• Spin
Thisprogramspinswithmaximumpossible
rpminthedefaultsetting.
CYoushouldusealowerspinspeedfor
delicatelaundries.
• Pump
Thisprogramisusedtodischargethewaterof
theclothessoakedintowaterinthemachine.
Spin Speed selection
Youcanhaveyourclothesspunatthe
maximumrpmselectiononyourmachineby
usingtheselectionknobinmodelsequipped
withanrpmselectionknob.Inordertoprotect
yourclothes,yourmachinewillnotspinabove
800rpmonsyntheticprogramsand600rpm
onwoolensprogram.Furthermore,ifyouwant
toskipthespincycleandtakeyourclothes
out,turntherpmselectionknobto“nospin”
position.
Inmachinesnotequippedwithaspinspeed
selectionknob,themachinewillspininthe
maximumpossiblerpminthedefaultsettingof
theselectedprogram.

7 - EN
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Waterandpowerconsumptionandprogrammedurationmaydifferfromthetableshown,
subjecttochangesinwaterpressure,waterhardnessandtemperature,ambienttemperature,
typeandamountoflaundry,selectionofauxiliaryfunctions,andfluctuationsinthesupply
voltage.
CTheauxiliaryfunctionsinthetablemaydifferaccordingtothemodelofyourmachine.
Programme
Max.Load(kg) ProgrammeDuration(~min) WaterConsumption(l) EnergyConsumption(kWh) Prewash QuickWash RinsePlus Anti-Creasing RinseHold Spinspeedreduction NoSpin
Cottons 90 6 150 55 2.00 • • • • • • •
Cottons 60** 6 140 49 1.14 • • • • • • •
Cottons 40 6 125 49 0.70 • • • • • • •
Intensive 60 6 160 65 1.30 • • • •
Synthetics 60 3 115 55 0.90 • • • • • • •
Synthetics 40 3 105 55 0.50 • • • • • • •
Delicate 40 270 60 0.35 • • • • •
Woollens 40 1.5 55 55 0.3 • • • •
Handwash 30 1 40 35 0.15 • •

8 - EN
Auxiliary functions
Auxiliary function selection keys
Selecttherequiredauxiliaryfunctionsbefore
startingtheprogram.
CAuxiliaryfunctionbuttonsmaydiffer
accordingtothemodelofyourmachine.
Auxiliary function selection
Ifanauxiliaryfunctionthatshouldnotbe
selectedtogetherwithapreviouslyselected
functionischosen,thefirstselectedfunction
willbecancelledandthelastauxiliaryfunction
selectionwillremainactive.
Auxiliaryfunctionthatisnotcompatible
withtheprogramcannotbeselected.(see
“ProgramSelectionTable”)
Pre-wash
Apre-washisonlyworthwhileforheavily
soiledlaundry.Withoutpre-washyousave
energy,water,detergentandtime.Pre-wash
withoutdetergentisrecommendedforlace
andcurtains.
Quick wash
Thisfunctioncanbeusedforcottonsand
syntheticsprograms.Itdecreasesthewashing
timesforlightlysoiledlaundriesandalsothe
numberofrinsingsteps.Shortenstheprogram
timeapproximately45minutes.
Rinse plus
Withthisfunction,youcanincreasethe
numberofcurrentrinsingsteps.Thus,
sensitiveskins’riskofbeingaffectedbythe
remainderdetergentontheclotheswillbe
decreased.
Rinse hold
Ifyoudonotwanttounloadyourclothes
immediatelyafterthecotton,synthetics,
woolenanddelicatefabricsprogram,you
mayreleaseyourclothesinsidethemachine
inthelastrinsingwaterbypressingtherinse
holdbuttoninordertopreventyourclothes
becomewrinkled.Youcanspinbypressing
“Start/Pause/Cancel”buttonafterthis
process.
Anti-creasing
Thisfunctionreducesdrummovementand
limitsthespinningspeedtopreventcreasing.
Inaddition,washingiscarriedoutatahigher
waterlevel.
CUsethisfunctionfordelicatelaundriesthat
creaseeasily.
CWheneveryouselectthisauxiliaryfunction,
loadyourmachinewithhalfofthe
maximumlaundryspecifiedintheprogram
table.
Spin speed reduction
Youmayusethespeedreductionbutton
wheneveryouwishtospinyourclothes
belowthemaximumspinspeed.Whenspeed
reductionbuttonispressed,spinspeedwillbe
attheminimumrpmgivenonthepanel.
No spin
Youmayusethisprogramifyoudonotwant
tospinyourclothesattheendofcottons,
synthetics,woolenordelicateprograms.
Time delay
Ifyouwishtowashyourclothesatalater
timeinmachinesequippedwithatimedelay
button,thetimedelayfunctionallowsyou
todelaytheprogramstarttimefor3,6or9
hours.
Whenthetimedelayingbuttonispressed
once,a3hoursdelayisselected.Whenthe
samebuttonispressedagain,6hours;and
ifpressedoncemore,a9hoursdelaywill
beselected.Ifthetimedelayingbuttonis
pressedonemoretime,timedelayingfunction
willbecancelled.Timedelayfunctionstarts
countdownaftersettingthedesiredtimedelay
andpressingthe“Start/Pause/Cancel”button.
CMorelaundrymaybeloadedduringthe
timedelayperiod.
Changing and canceling the time delay.
Pressthe“Start/Pause/Cancel”buttonto
switchthemachineto“Pause”mode.Press
“Start/Pause/Cancel”buttontostartthe
programaftermakingthenewtimedelay
selection.
Starting the Program
Press“Start/Pause/Cancel”buttontostart
theprogram.“Start/Pause/Cancel”button
willlightuptoindicatethattheprogramhas
started.Thedoorislockedandthe“Ready”
lightfades.
Progressing a program
Progressofarunningprogramisshown
throughtheprogramfollow-upindicator.At
thebeginningofeveryprogramstep,the
relevantindicatorlampwilllightupandlightof
thecompletedstepwillturnoff.
CIfthemachineisnotspinning,theprogram
maybeinrinseholdmodeortheautomatic
spincorrectionsystemmighthavebeen
activatedbecauseofexcessiveunbalanced
distributionoflaundryinthemachine.
Changing the program after the
program has started
Youcanusethisfeatureafteryourmachine
hasstartedtowashdifferenttextilegroups
inthesamebatchofclothesunderhigher
orlowertemperatures.Youmustcancel
theongoingprograminordertochangethe
washingprogram.
Forexample,pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsinordertoselect

9- EN
“Cottons40”programinsteadof“Cottons60”
program.Selectthe“Cottons40”program.
Starttheprogram.
Switching the machine to standby
mode
Press“Start/Pause/Cancel”button
momentarilytoswitchyourmachinetothe
standbymode.Auxiliaryfunctionscanbe
cancelledorselectedinaccordancewith
thesteptheprogramisat.Thedoorcanbe
openedifthewaterlevelissuitable.Laundry
maybeadded/takenoutbyopeningthe
door.
Child-proof lock
Youcanprotecttheappliancefrombeing
tamperedbychildrenbymeansofthechild-
prooflock.Inthiscase,nochangecanbe
madeintherunningprogram.
Themachineisswitchedtochild-lockby
pressingthe1stand2ndauxiliaryfunctions
fromtheleftfor3sec.Child-prooflocklamp
ontheprogramfollow-upindicatorwilllight
upwhenthechild-prooflockisactivated.
Todeactivatethechild-prooflock,pressthe
samebuttonsfor3sec.
Ending the program through
canceling
Inordertocanceltheselectedprogram,
pressthe“Start/Pause/Cancel”buttonfor
3seconds.Youcanselectandstartanew
programwhenthe“Ready”lightislit.
The“Spin”lightilluminatesifthecancellation
processisactivatedinthemiddleofthe
programandthemachinecaneitherdrainall
thewaterorcantakeinwater3timesatmost
tocooldowntheclothesandperformthe
drainingprocess.
Theprogramwhichisselectedfirstwillkeep
ongoingevenifthepositionoftheprogram
selectionbuttonischanged.Anewprogram
canbeselectedorstartedafter“Programis
cancelled”inordertochangethewashing
program.
End of program
The“Ready”lampontheprogramfollow-up
indicatorwilllightupwhentheprogramcomes
toanend.Thedoorcanbeopenedandthe
machineisreadyforasecondcyclenow.
Pressthe“On/Off”buttontoshutdownthe
machine.
5 Maintenance and cleaning
Detergent Drawer
Removeanypowderresiduebuildupinthe
drawer.Todothis;
1. Pressthedottedpointonthesiphoninthe
softenercompartmentandpulltowards
youuntilthecompartmentisremovedfrom
themachine.
C Ifmorethananormalamountofwater
andsoftenermixturestartstogatherinthe
softenercompartment,thesiphonmustbe
cleaned.
2. Washthedispenserdrawerandthe
siphonwithplentyoflukewarmwaterina
washbasin.
3. Replacethedrawerintoitshousingafter
cleaning.Checkifthesiphonisinits
originallocation.
Inlet water filters
Thereisafilterattheendofeachwaterintake
valveatthebacksideofthemachineandalso
attheendofeachwaterintakehosewhere
theyareconnectedtothetap.Thesefilters
preventtheforeignsubstancesanddirtinthe
watertoenterintothemachine.Filtersshould
becleanedastheygetdirty.
• Closethetaps.
• Removethenutsofthewaterintakehoses
tocleanthesurfacesofthefiltersonthe
waterintakevalveswithanappropriate
brush.
• Ifthefiltersareverydirty,youcanpullthem
outbymeansofpliersandcleanthem.
• Takeoutthefiltersontheflatendsof
thewaterintakehosestogetherwith
thegasketsandcleanthoroughlyunder
streamingwater.
• Replacethegasketsandfilterscarefullyto
theirplacesandtightenthehosenutsby
hand.

10 - EN
bypullingouttheplugattheendofthe
hose.Iftheamountofwatertobedrained
offisgreaterthanthevolumeofthe
container,replacetheplug,pourthewater
out,thenresumethedrainingprocess.
• Afterdrainingprocessiscompleted,
replacetheplugintotheendofthehose
andfitthehosebackintoitsplace.
Ifyourproductisnotsuppliedwithan
emergencydrainhose,dothefollowingas
showninthefigurebelow:
• Placealargecontainerinfrontofthefilter
toreceivewaterflowingfromthefilter.
• Loosenpumpfilter(anticlockwise)until
waterstartstoflowoutofit.Directthe
flowingwaterintothecontaineryouhave
placedinfrontofthefilter.Youcanusea
pieceofclothtoabsorbanyspilledwater.
• Whenthereisnowaterleft,turnthepump
filteruntilitiscompletelylooseandremove
it.
• Cleananyresiduesinsidethefilteras
wellasfibers,ifany,aroundthepropeller
region.
• Ifyourproducthasawaterjetfeature,be
suretofitthefilterintoitshousinginthe
pump.Neverforcethefilterwhilereplacing
itintoitshousing.Fitthefilterfullyintoits
housing;otherwise,watermayleakfrom
thefiltercap.
4-Closethefiltercap.
Closethetwo-piecefiltercapofyourproduct
bypushingthetabonit.
Closetheone-piecefiltercapofyourproduct
byfittingthetabsonthebottomintotheir
positionsandpushingtheupperpartofit.
Draining any remaining water and
cleaning the pump filter
Yourproductisequippedwithafiltersystem
whichensuresacleanerwaterdischargethat
extendspumplifebypreventingsoliditems
suchasbuttons,coinsandfabricfibersfrom
cloggingthepumppropellerduringdischarge
ofthewashingwater.
• Ifyourmachinefailstodrainthewater,
thepumpfiltermaybeclogged.Youmay
havetocleanitevery2yearsorwhenever
itisplugged.Watermustbedrainedoffto
cleanthepumpfilter.
Inaddition,watermayhavetobedrainedoff
completelyinthefollowingcases:
• beforetransportingthemachine(e.g.when
movinghouse)
• whenthereisthedangeroffrost
Inordertocleanthedirtyfilteranddischarge
thewater;
1-Unplugthemachinetocutoffthesupply
power.
ATheremaybewaterat90°Cinthe
machine.Therefore,thefiltermustbe
cleanedonlyaftertheinsidewateris
cooleddowntoavoidhazardofscalding.
2-Openthefiltercap.Thefiltercapmaybe
composedofoneortwopiecesaccordingto
themodelofyourmachine.
Ifitiscomposedoftwopieces,pressthetab
onthefiltercapdownwardsandpullthepiece
outtowardsyourself.
Ifitiscomposedofonepiece,holditfrom
bothsidesandopenitbypullingout.
3-Anemergencydrainhoseissuppliedwith
someofourmodels.Othersarenotsupplied
withthisitem.
Ifyourproductissuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Pulloutthepumpoutlethosefromits
housing.
• Placealargecontainerattheendofthe
hose.Drainthewateroffintothecontainer

11 - EN
6 Solution suggestions for problems
Problem Cause Explanation / Suggestion
Programcannot
bestartedor
selected.
Machinemayhave
switchedtoself
protectionmodedueto
aninfrastructureproblem
(suchaslinevoltage,water
pressure,etc.).
Resetyourmachinebypressing“Start/Pause/
Cancel”buttonfor3seconds.(see,Canceling
aProgram)
Thereiswater
comingfrom
thebottomof
themachine.
Theremightbeproblems
withhosesorthepump
filter.
Besurethesealsofthewaterinlethosesare
securelyfitted.
Tightlyattachthedrainhosetothetap.
Makesurethatthepumpfilteriscompletely
closed.
Machine
stopped
shortlyafter
theprogram
started.
Machinecanstop
temporarilyduetolow
voltage.
Itwillresumeoperatingwhenthevoltageis
backtothenormallevel.
Itcontinuously
spins.
Remainingtime
doesnotcount
down.
Theremaybeanimbalance
oflaundryinthemachine.
Theautomaticspincorrectionsystemmight
havebeenactivatedduetotheunbalanced
distributionofthelaundryinthedrum.
Thelaundryinthedrummaybeclustered
(bundledlaundryinabag).Laundryshouldbe
rearrangedandre-spun.
Nospinningisperformedwhenthelaundryis
notevenlydistributedinthedrumtoprevent
anydamagetothemachineandtoits
environment.
Itcontinuously
washes.
Remainingtime
doesnotcount
down.
Inthecaseofapaused
countdownwhiletakingin
water:
Timerwillnotcountdown
untilthemachineisfilled
withthecorrectamountof
water.
Themachinewillwaituntilthereisasufficient
amountofwatertoavoidpoorwashingresults
duetolackofwater.Thenthetimerwillstartto
countdown.
Inthecaseofapaused
countdownattheheating
step:
Timewillnotcount
downuntiltheselected
temperatureforthe
programisreached
Inthecaseofapaused
countdownatthespinning
step:
Theremaybeanimbalance
oflaundryinthemachine.
Theautomaticspincorrectionsystemmight
havebeenactivatedduetotheunbalanced
distributionofthelaundryinthedrum.
Thelaundryinthedrummaybeclustered
(bundledlaundryinabag).Laundryshouldbe
rearrangedandre-spun.
Nospinningisperformedwhenthelaundryis
notevenlydistributedinthedrumtoprevent
anydamagetothemachineandtoits
environment.

12 - EN
LBS126
6
84
60
54
70
230V/50hz
10
2200
1200
7 Specifications
Specificationsofthisappliancemaychangewithoutnoticetoimprovethequalityoftheproduct.
Figuresinthismanualareschematicandmaynotmatchyourproductexactly.
Valuesstatedonthemachinelabelsorinthedocumentationaccompanyingitareobtained
inlaboratoryinaccordancewiththerelevantstandards.Dependingonoperationaland
environmentalconditionsoftheappliance,valuesmayvary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
Thisappliance’spackagingmaterialisrecyclable.Helprecycleitandprotectthe
environmentbydroppingitoffinthemunicipalreceptaclesprovidedforthispurpose.
Yourappliancealsocontainsagreatamountofrecyclablematerial.Itismarkedwith
thislabeltoindicatetheusedappliancesthatshouldnotbemixedwithotherwaste.
Thisway,theappliancerecyclingorganisedbyyourmanufacturerwillbedoneunder
thebestpossibleconditions,incompliancewithEuropeanDirective2002/96/ECon
WasteElectricalandElectronicEquipment.Contactyourtownhalloryourretailerfor
theusedappliancecollectionpointsclosesttoyourhome.Wethankyoudoingyour
parttoprotecttheenvironment.
