Smeg WHT1114LSIN-1 User manual

2820527852_EN/ 29-11-19.(10:06)
WHT1114LSIN-1
Document Number
Washing Machine
User’s Manual
Lavatrice
Manuale utente

2 / EN Washing Machine / User’s Manual
1 General safety instructions
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 Life and property safety
uNever place the product on a carpet-covered floor. Otherwise, lack of airflow
beneath the machine will cause electrical parts to overheat. This will cause
problems with your product.
uUnplug the product if it is not in use.
u
Always have the installation and repairing procedures carried out by the
Authorised Service Agent. The manufacturer shall not be held liable for
damages that may arise from procedures carried out by unauthorised persons.
uThe water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, there is the risk of water leakage.
u
While there is still water inside the product, never open the loading door or
remove the filter. Otherwise, risk of flooding and injury from hot water will occur.
uDo not force open the locked loading door. The door will open immediately
after the washing cycle has ended. If the door does not open, apply the
solutions provided for "Loading door cannot be opened." error in the
Troubleshooting section. In case of forcing the loading door to open, the
door and the lock mechanism may get damaged.
uUse detergents, softeners and supplements suitable for automatic washing
machines only.
u
Follow the instructions on the label of textile products and the detergent package.
u
The water supply pressure required to run the product is between 1 to 10 bars
(0.1 – 1 MPa).
u
Do not use old or used water inlet hoses on the new product. It may cause stains
on your laundry.
1.2 Children's safety
u
This product can be used by children at and above 8 years old and by persons
whose physical, sensory or mental capabilities were not fully developed or
who lack experience and knowledge provided that they are supervised or
trained on the safe usage of the product and the risks it brings out. Children
should not play with the product.Cleaning and maintenance works should not
be performed by children unless they are supervised by someone. Children
under the age of 3 should be kept away unless continuously supervised.

3 / EN
Washing Machine / User’s Manual
uPackaging materials are dangerous for the children. Keep packaging
materials in a safe place away from reach of the children.
uElectrical products are dangerous for the children. Keep children away from
the product when it is in use. Do not allow them to play with the product.
Use child lock to prevent children from intervening with the product.
uDo not forget to close the loading door when leaving the room where the
product is located.
uStore all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
1.3 Electrical safety
uIf the product has a failure, it should not be operated unless it is repaired by
the Authorised Service Agent! There is the risk of electric shock!
uThis product is designed to resume operating in the event of powering
on after a power interruption. If you wish to cancel the programme, see
"Cancelling the programme" section.
uPlug the product into a grounded outlet protected by a 16 A fuse. Do not
neglect to have the grounding installation made by a qualified electrician.
Our company shall not be liable for any damages that will arise when the
product is used without grounding in accordance with the local regulations.
uDo not wash the product by spraying or pouring water onto it! There is the
risk of electric shock!
uNever touch the power cable plug with wet hands! Never unplug by pulling
on the cable. Always press on the plug with one hand and pull out the plug
by grabbing with the other hand.
uProduct should be unplugged during installation, maintenance, cleaning
and repair procedures.
u
If the power cable is damaged, it must be replaced by the manufacturer,
authorized service or a similarly qualified person (preferably an electrician)
or someone designated by the importer in order to avoid possible risks.
1.4 Hot surface safety
The glass of the loading door gets too hot while
washing at higher temperatures. Therefore,
especially do not allow children touch the
loading door glass while washing.

4 / EN Washing Machine / User’s Manual
2Important instructions for environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which can be reused
and are suitable for recycling. Do not dispose of the waste product with normal domestic and
other wastes at the end of its service life. Take it to the collection center for the recycling of
electrical and electronic equipment. Please consult your local authorities to learn about these
collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful
and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance with our
National Environment Regulations. Do not dispose of the packaging materials together with the domestic or
other wastes. Take them to the packaging material collection points designated by the local authorities.
3Intended use
• This product has been designed for domestic use. It is not for commercial purposes or it should not be used
out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked accordingly.
• This appliance is intended to be used in household and similar applications such as:
– staff kitchen areas in shops, offices and other working environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of flats or in launderettes.

5 / EN
Washing Machine / User’s Manual
4Technical specifications
Height (cm) 84
Width (cm) 60
Depth (cm) 65
Net weight (±4 kg.) 81
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 9715
Complying Commission Delegated Regulation (EU) No 1061/2010
Supplier name or trademark SMEG
Model name WHT1114LSIN-1
Rated capacity (kg) 11
Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++
Annual Energy Consumption (kWh) (1) 233
Energy consumption of the standard 60°C cotton programme at full load (kWh) 1,270
Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0,880
Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0,860
Power consumption in ‘off-mode’ (W) 0,440
Power consumption in ‘left-on mode’ (W) 0,640
Annual Water Consumption (l) (2) 13199
Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B
Maximum spin speed (rpm) 1400
Remaining moisture Content (%) 53
Standard cotton programme (3) Cotton Eco 60°C and 40°C
Programme time of the standard 60°C cotton programme at full load (min) 230
Programme time of the standard 60°C cotton programme at partial load (min) 190
Programme time of the standard 40°C cotton programme at partial load (min) 185
Duration of the left-on mode (min) N/A
Airborne acoustical noise emissions washing/spinning (dB) 59/76
Built-in No
(1) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the
consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.
(2) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water
consumption will depend on how the appliance is used.
(3) “Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information
in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient
programmes in terms of combined energy and water consumption.

6 / EN Washing Machine / User’s Manual
4.1 Installation
• Apply to the nearest authorised service agent for the installation of your product.
• Preparation of the location and electrical, tap water and waste water installations at the place of installation
is under customer's responsibility.
• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after installation or cleaning procedures.
• Make sure that the installation and electrical connections of the product are performed by authorised
service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by
unauthorised persons.
• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar
surfaces.
• When the washing machine and dryer are placed on top of each other, their total weight –when loaded–
amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying
capacity!
• Do not place the product on the power cable.
• Do not install the product in the environments where the temperature falls below 0 ºC.
• Leaving a gap at the sides of the machine is suggested to reduce vibration and noise
• On a graduated floor, do not place the product next to the edge or on a platform.
• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them
on the product.
4.1.2 Removing packaging reinforcement (If the product has)
Tilt the machine backwards to remove the packaging reinforcement.
Remove the packaging reinforcement by pulling the ribbon. Do not make
this operation alone by yourself.
4.1.3 Removing the transportation locks
1 Loosen all bolts with an appropriate wrench until they turn freely.
2 Remove the transport safety bolts by turning them slightly.
3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.
ACAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be
damaged.
CKeep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the
future.
Install the transport safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!

7 / EN
Washing Machine / User’s Manual
4.1.4 Connecting water supply
C
It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run
smoothly. Attach a pressure reducing valve if water pressure is higher.
ACAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will
get damaged or the product will switch to protection mode and will not operate.
1 Tighten the nuts of the hose by hand. Never use a tool when
tightening the nuts.
2 When hose connection is completed, check whether there is leak
problems at the connection points by opening the taps fully. If any
leaks occur, turn off the tap and remove the nut. Retighten the nut
carefully after checking the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed when you do not use
the product.
4.1.5 Connecting the drain hose to the drain
• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.
ACAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine
performs water intake and discharge processes without any problem, fix the drain hose securely.
40 cm
100 cm
• Connect the drain hose to a minimum height of 40 cm
and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on the
floor level or close to the ground (less than 40 cm above
the ground), water discharge becomes more difficult and
the laundry may come out excessively wet. Therefore,
follow the heights described in the figure.
• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the
drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

8 / EN Washing Machine / User’s Manual
4.1.6 Adjusting the feet
ACAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced
on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing
and vibration problems.
CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands in a stable and balanced way.
3. Tighten all lock nuts by hand again.
4.1.7 Electrical connection
Connect the product to a grounded outlet protected by a 16 A fuse. The Manufacturer shall not be liable for any
damages that will arise when the product is used without grounding in accordance with the local regulations.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. Use of a
Groud Fault Circuit Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician
install a 16 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs.
BCAUTION: Damaged power cables must be replaced by the Authorised Service Agents.
4.1.8 Initial use
Before starting to use the product make sure that the preparations are
made which are in line with the “Important Safety and Environment
Instructions” and the instructions in the “Installation” section.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
machine, apply the method which is described in the section 4.4.2.
CUse an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to the quality control processes in the production. It is not harmful for
the product.

9 / EN
Washing Machine / User’s Manual
4.2 Preparation
4.2.1 Sorting the laundry
• Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature.
• Always observe the instructions given on the garment care labels.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the
machine. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “Machine washable” or “Hand washable” labeled products only with an appropriate programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them
separately.
• Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.
• Only use the dyes / color changers and descaling agents which are appropriate for machine wash. Always
follow the instructions on the package.
• Wash trousers and delicate laundry turned inside out.
• Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce
piling.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken
off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts
of the product in time and can cause damage.
4.2.3 Tips for energy saving
Following information will help you use the product in an ecological and energy-efficient manner.
• Operate the product in the highest load capacity allowed for the programme you have selected, but do not
overload. See, "Programme and consumption table".
• Observe the temperature instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing
process.
• Do not use more detergent than the recommended on the detergent packaging.
4.2.4 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the product in a loose manner.
3 Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.
The loading door is locked while a programme is running. The door lock will open immediately after the
washing programme has ended. Then you can open the loading door. If the door does not open, apply the
solutions provided for "Loading door cannot be opened." error in the Troubleshooting section.
4.2.5 Correct load capacity
The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing
programme.
The machine automatically adjusts the water amount according to the weight of the laundry put inside it.
AWARNING: Comply with the information in the section "Programme and consumption table". When overloaded,
product's washing performance will drop. Moreover, noise and vibration problems may occur.

10 / EN Washing Machine / User’s Manual
4.2.6 Using detergent and softener
C
When using detergent, softener, starch, fabric dye, bleach and descaling agents; read the manufacturer's instructions written
on the package and follow the dosages specified. Use measuring cup if available.
1
3
2
The detergent drawer is composed of three compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there is a siphon piece in the softener compartment.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing programme.
• While the washing cycle is in progress, do not leave the detergent drawer open!
• When using a programme without prewash, do not put any detergent into the prewash compartment
(compartment no. "1").
• In a programme with prewash, do not put liquid detergent into the prewash compartment (compartment no.
"1").
• Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place the
detergent bag or the dispensing ball directly among the laundry in the product.
• If you are using liquid detergent, do not forget to place the liquid detergent container into the main wash
compartment (compartment no. “2”).
Choosing the detergent type
Detergent type to be used depends on the fabric type and color.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) intended
solely for delicate clothes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woolens with special detergent made specifically for woolens.
AWARNING: Use only detergents manufactured specifically for washing machines.
WARNING: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and
water hardness.
• Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid
problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.
• Use lesser detergent for small amounts or lightly soiled clothes.
Using softeners
Pour the softener into the softener compartment of the detergent drawer.
• Do not exceed the (>max<) level sign on the softener compartment.
• If the softener has lost its fluidity, dilute it with water before adding it in the detergent compartment.
AWARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing
machines to soften the clothes.
Using liquid detergents
If the product contains a liquid detergent cup:
• Put the liquid detergent container into the compartment no “2”.
• If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.

11 / EN
Washing Machine / User’s Manual
2
2
If the product is equipped with a liquid detergent part:
• When you want to use liquid detergent, pull the apparatus towards yourself. The part that falls down will
serve as a barrier for the liquid detergent. If required, clean the apparatus with water when it is in place
or by removing it. If you will use powder detergent, the apparatus must be secured at top position.
If the product does not contain a liquid detergent cup:
• Do not use liquid detergent for the prewash in a programme with prewash.
• Liquid detergent stains your clothes when used with "End Time" function to started delayed. If you are going
to use the End Time function, do not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and your product does not contain a special liquid detergent container,
put the gel detergent into the main wash detergent compartment during first water intake. If your product
contains a liquid detergent container, fill the detergent into this container before starting the programme.
• If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly into the
drum before washing.
• Put tablet detergents into the main wash compartment (compartment no. "2") or directly into the drum
before washing.
Using starch
• Add liquid starch, powder starch or the dyestuff into the softener compartment.
• Do not use softener and starch together in a washing cycle.
• Wipe the inside of the product with a damp and clean cloth after using starch.
Using limescale remover
• When required, use limescale removers manufactured specifically for washing machines only.
Using bleaches
• Select a programme with prewash and add the bleach at the beginning of the prewash. Do not put detergent
in the prewash compartment. As an alternative application, select a programme with extra rinse and add the
bleach while the product is taking water from the detergent compartment during first rinsing step.
• Do not use bleach and detergent by mixing them.
• Use just a little amount (approx. 50 ml) of bleach and rinse the clothes very well as it causes skin irritation.
• Do not pour the bleach onto the laundry.
• Do not use it with the colored items.
• When using an oxygen-based bleach, select a program which washes the laundry at a low temperature.
• Oxygen-based bleach can be used together with the detergent. However, if its thickness is not the same
with the detergent, put the detergent first into the compartment no. "2" in the detergent drawer and wait
until the detergent flows while the product is taking in water. While the product continues taking in water,
add bleach in the same compartment.

12 / EN Washing Machine / User’s Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woolens/Silks
(Recommended temperature
range based on soiling level:
40-90°C)
(Recommended temperature
range based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold-30°C)
Soiling Level
Heavily Soiled
(difficult stains such
as grass, coffee, fruits
and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to clean
clay and soil stains and the
stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Normally Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for lightly soiled
clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
4.2.8 Displayed Program Time
You can see the programme duration on the display of your machine while selecting a programme. Depending
on the amount of laundry you have loaded into your machine, foaming, unbalanced load conditions,
fluctuations in power supply, water pressure and program settings, the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE: At programme start of Cottons and Cotton Eco programmes, display shows the duration
of half load, which is the most common use case. After programme starts, in 20-25 minutes actual load is
detected by the machine. And if the detected load is higher than half load; washing program will be adjusted
accordingly and program duration increased automatically. You may follow this change on the display.
Temperature Spin Pre-wash Quick wash Extra rinse
(Rinse Plus)
Steam Anti-creasing Start/Pause Wash Rinse Rinse hold
AntiCrease+
No spin Cold Time delay Child-proof
lock Finished Night
Mode
STOP
END

13 / EN
Washing Machine / User’s Manual
4.3 Operating the product
4.3.1 Control panel
1. Programme selection knob
2 - Spin Speed Adjustment button
3 - Temperature adjustment button
4 - Display
5 - Programme follow-up indicator
6 - On / Off button
7 - Start / Pause button
8 - End Time Adjustment button
9 - Auxiliary Function button 4
10 - Auxiliary Function button 3
11 - Auxiliary Function button 2
12 - Auxiliary Function button 1
13 - Programme Selection LEDs
4.3.2 Display symbols
1888
88:88
88
C
0
a b c d e f g
h
ijklm
a - Temperature indicator
b - Electrical connection
c - Steam indicator
d - Audio Warning indicator
e - No Water indicator
f - Detergent indicator
g - Start / Pause indicator
h - Program Follow-up indicator
i - End Time indicator
j - Duration Information Line
k - Auxiliary Function indicators
l - Lock indicator
m - Spin Speed indicator
CThe visuals used for machine description in this section are schematic and may not match exactly will the features of your
machine.
END
Auto Program
Steam Refresh
Wool
Stain
Shirts
Sports
Rinse
Duvet Delicate
Dark Wash
14 Minutes
Baby Cycle Synthetics
Spin+Drain
Cottons
Cotton Eco
Self Clean 3 sec. 3 sec.
ON/OFF
123 4 5
6
7
891011
12
13

14 / EN Washing Machine / User’s Manual
4.3.3 Programme and consumption table
• : Selectable.
* : Automatically selected, no canceling.
** : Energy Label programme (EN 60456 Ed.3)
*** : If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.
**** : Programme detects the type and quantity of the laundry to automatically adjust water and energy consumption and
programme time.
- : See the programme description for maximum load.
** "Cotton eco 40°C and Cotton eco 60°C are standard programmes." These programmes are known as '40°C cotton standard
programme' and '60°C cotton standard programme' and indicated with the symbols on the panel.
CThe auxiliary functions in the table may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry
you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the
actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.
"Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or removed."
"The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your machine."
EN 2Auxiliary functions
Programme
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed*** Prewash Quick Wash Extra Rinse Night Mode AntiCrease+
Selectable temperature
range °C
Cottons
90 11 110 2,25 1400 • • • • • Cold-90
60 11 110 1,40 1400 • • • • • Cold-90
40 11 72 1,10 1400 • • • • • Cold-90
Cotton Eco
60** 11 62,0 1,270 1400 Cold-60
60** 5,5 58,5 0,880 1400 Cold-60
40** 5,5 58,5 0,860 1400 Cold-60
Synthetics 60 5 84 1,50 1200 • • • • • Cold-60
40 5 84 0,95 1200 • • • • • Cold-60
14 Minutes
90 11 85 2,20 1400 • •• • Cold-90
60 11 85 1,20 1400 • •• • Cold-90
30 11 83 0,20 1400 • •• • Cold-90
14 Minutes + Quick Wash 30 2 48 0,20 1400 • •• • Cold-90
Wool 40 2,5 59 0,55 1200 •• Cold-40
Delicate 40 5 58 0,60 1200 •• Cold-40
Duvet 60 - 105 1,10 1000 •• Cold-60
Sports 40 5,5 66 0,50 1200 • Cold-40
Dark Wash 40 6 99 1,05 1200 • * • • Cold-40
Stain 60 5,5 100 0,90 1400 • • • 30-60
Shirts 60 5 85 1,50 800 • • • • Cold-60
Baby Cycle 90 9 120 2,15 1400 *20-90
Steam Refresh - 1 1 0,17 - -
Auto Program 60 11 **** **** 1400 • • • • • Cold-60
Self Clean 70 - 85 2,30 700 *70

15 / EN
Washing Machine / User’s Manual
4.3.4 Programme selection
1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with
"Programme and consumption table".
CProgrammes are limited with the highest spin speed appropriate for that particular type of fabric.
When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
Always select the lowest appropriate temperature. Higher temperature means higher electricity consumption.
2 Select the desired programme with the Programme Selection knob.
1888
88:88
88
C
0
4.3.5 Programmes
•Cotton Eco
Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other
programmes, it provides high energy and water savings. Actual water temperature may be different from the
stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in
programme stages may automatically get shorter. In this case, energy and water consumption will decrease
more, providing a more economic wash.
•Cottons
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this
programme. When the quick wash function key is pressed, programme duration becomes notably shorter but
effective washing performance is ensured with intense washing movements. If the quick wash function is not
selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
•Synthetics
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.
The programme duration gets notable shorter and washing with high performance is ensured. If the quick wash
function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
•Wool
Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with the tag of your
clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.
"Woolens programme of this machine is approved by “The Woolmark Company” for
washing machine-washable woolen products provided that the products are washed in
accordance with the instructions on the product tag and the instructions published by
the manufacturer of this machine. M1422"
In UK, Ireland, Hong Kong and India, the Woolmark trademark is a Certification trademark.
Indicative values for Synthetics programmes (EN)
Load (kg) Water Consumption (l) Energy Consumption (kWh) Programme Duration (min)
Remaining Moisture Content
(%) **
Remaining Moisture Content
(%) **
≤ 1000 rpm > 1000 rpm
Synthetics 60 5 84 1,50 135/160 45 40
Synthetics 40 5 84 0,95 135/160 45 40
* You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur
between the time shown on the display and the real washing time.
** Remaining moisture content values may differ according to the selected spin speed.

16 / EN Washing Machine / User’s Manual
•Baby Cycle
Use this programme for your laundry for which you require an anti-allergic and hygienic washing at high
temperature with intensive and long washing cycle. The high level of hygiene is ensured thanks to long heating
duration and additional rinsing step.
• Programme was tested by the “VDE” institute with the 20°C temperature option selected and it was
certified in terms of its efficacy in eliminating bacteria and mould.
• Programme was tested by “The British Allergy Foundation” (Allergy UK) with the 60°C temperature option
selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and mould.
Allergy UK, is the brand of the British Allergy Association. Seal of Approval is created to
guide people that require recommendation about a product that the related product restricts
/ reduces / eliminates the allergens or reduces the allergen content significantly in the
ambient where allergy patients exist. It aims to provide assurance that the products are
tested scientifically or examined in a way to provide measurable results.
•Duvet
Use this programme to wash your fiber duvets that bear "machine washable" tag. Check that you have loaded
the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading
the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the
machine paying attention to place it in a way that it will not contact the bellow or the glass.
C
Do not load more than 1 double fiber duvet (200 x 200 cm).
Do not wash your duvets, pillows and etc. that contain cotton in the machine.
A
CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Otherwise,
permanent damage will occur in the machine.
•Spin+Drain
You can use this function to remove the water on the garment of drain the water in the machine.
• Rinse
Use when you want to rinse or starch separately.
•Steam Refresh
Use this programme to reduce the creases and ironing times of a small amount of unspotted cotton, synthetic
or mixed laundry.
CWhen this programme is selected, it is normal to hear boiling noises since the steam generator boils water to produce
steam.
•Shirts
This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether.
It reduces wrinkles. When the quick wash function is selected, the Pre-treatment algorithm is executed.
• Apply the pre-treatment chemical on your garments directly or add it together with detergent when the
machine starts to take water from the main washing compartment. Thus, you can obtain the same performance
as you obtain with normal washing in a much shorter period of time. Usage life of your shirts increases.
• 14 Minutes
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme
duration can be reduced up to 14 minutes when the quick wash function is selected. When the quick wash
function is selected, maximum 2 (two) kg of laundry must be washed.
•Dark Wash
Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high performance
washing with special drum movement even if the temperature is low. It is recommended to use liquid detergent
or woolen shampoo for dark coloured laundry. Do not wash your delicate clothes containing wool or etc.

17 / EN
Washing Machine / User’s Manual
•Auto Program
Use to wash frequently washable cotton, synthetic or blended (cotton+synthetic) clothes. Programme detects
the type and quantity of the laundry to automatically adjust water consumption and programme time.
A
CAUTION: Do not wash your woolen and delicate clothes in this programme.
Select a suitable temperature if the temperature shown on the temperature display is not compatible with the warnings on
the garment label.
The maximum washing temperature in Automatic programme depending on the soiling level and laundry type
is 60ºC. Washing performance may not be at the desired level for heavily soiled whites and stubborn stains
(collar, sock soil, perspiration stain, etc.). In this case, it is recommended to select Cottons programme with
prewash and set the temperature to 50-60°C.
Many types of clothing are correctly detected and safely washed in Automatic programme.
•Delicate
You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It
washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20
degrees or by selecting the cold wash option.
•Sports
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and
water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special
rotating movements.
• Stain
The machine has a special stain programme which enables the removal of different types of stains in the
most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate
and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked
(recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes,
beddings, duvet cover, bed sheet, pillowcase, bath-beach towel, towel, socks, cotton underwear that are
suitable for washing at high temperature and long time). In the automatic stain programme, you can wash
24 types of stains divided into two different groups according to quick function selection. You can see stain
groups based on the selection of the quick function.
You can find stain groups based on quick function below:
When quick function is selected:
Blood Tea Red Wine
Chocolate Coffee Curry
Pudding Fruit juice Jam
Egg Ketchup Coal
When quick function is not selected:
Butter Sweat Salad Dressing
Grass Collar Soil Make-up
Mud Food Machine Oil
Coke Mayonnaise Baby Food
• Select the stain programme.
• Select the stain you want to clean by locating it in the groups above and selecting the related group with the
quick auxiliary function key.
• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.

18 / EN Washing Machine / User’s Manual
4.3.6 Temperature selection
Whenever a new programme is selected, the recommended temperature for the programme appears on the
temperature indicator. It is possible that the recommended temperature value is not the maximum temperature
that can be selected for the current programme.
1888
88:88
88
C
0
Press the Temperature Adjustment button to change the temperature. Temperature will decrease by steps
of 10 °C.
Finally, “-” symbol indicating the cold wash option appears on the display.
1888
88:88
-
C
0
CNo change can be made in programmes where temperature adjustment is not allowed.
You can also change the temperature after the washing starts. This change can be made if the washing steps
allow it. Changes cannot be made if the steps do not allow it.
CIf you scroll to cold wash option and press Temperature Adjustment button again, the recommended maximum temperature
for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the
temperature.
4.3.7 Spin speed selection
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the Spin Speed indicator.
CIt is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current
programme.
1888
88:88
88
C
0
Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually.
Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.
CSpin Speed Adjustment button only serves for decreasing the spin speed.
Rinse Hold option is indicated with “ı_ı” symbol and No Spin option is indicated with “_” symbol.
If you are not going to unload your laundry immediately after the programme completes, you can use Rinse
Hold function in order to prevent them from getting wrinkled when there is no water in the machine.
This function holds the laundry in the final rinsing water.
88:88
88
C
0

19 / EN
Washing Machine / User’s Manual
If you want to spin your laundry after the Rinse Hold function:
- Adjust the Spin Speed.
- Press Start / Pause / Cancel button. The programme will resume. Machine drains the water and spins the
laundry.
If you want to drain the water at the end of the programme without spinning, use No Spin function.
88:88
88
C
0
CNo change can be made in programmes where spin speed adjustment is not allowed.
You can change the spin speed after the washing starts if the washing steps allow it. Changes cannot be
made if the steps do not allow it.
Rinse hold
If you are not going to unload your clothes immediately after the programme completes, you can use rinse
hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled
when there is no water in the machine. Press Start / Pause button after this process if you want to drain the
water without spinning your laundry. Programme will resume and complete after draining the water.
If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button.
The programme will resume. Water is drained, laundry is spun and the programme is completed.
4.3.8 Auxiliary function selection
Select the desired auxiliary functions before starting the programme. Whenever a programme is selected,
frames of the auxiliary function symbol that can be selected together with it illuminates. And when you select
an auxiliary function, the interior area of the auxiliary function symbol also starts to illuminate.
1888
88:88
88
C
0
CFrame of the auxiliary function symbol that cannot be selected with the current programme does not illuminate.
Also the frames of the auxiliary function suitable for the current programme after the washing has started
remains illuminated. You can select or cancel the auxiliary functions whose frames are illuminated. If the wash
cycle has reached a point where you cannot select the auxiliary function, the function's frame turns off.
CSome functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before
starting the machine, the function selected first will be canceled and the second auxiliary function selection will remain
active. For example, if you want to select Quick Wash after you have selected the Additional Water, Additional Water will be
canceled and Quick Wash will remain active.
An auxiliary function that is not compatible with the programme cannot be selected. (See, "Programme and consumption table")
Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The
frame of the auxiliary function will not be illuminated, only inner area will be illuminated.

20 / EN Washing Machine / User’s Manual
4.3.8.1 Auxiliary functions
• Prewash
A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time.
• Extra Rinse
This function enables the product to make another rinsing in addition to the one already made after the main
wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the minimal detergent
remnants on the laundry can be reduced.
•Quick Wash
When this function is selected, the durations of the relevant programmes get shorter by 50%.
Thanks to the optimised washing steps, high mechanic activity and optimum water consumption,
high washing performance is achieved in spite of the reduced duration.
•Night Mode
Use to wash the cottons with lesser energy consumption and silently. Spin steps are cancelled for a silent washing
and the cycle ends with the Rinse Hold step. After completion of the programme, run Spin cycle to spin the laundry.
4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for 3 Seconds
•Self Clean
Press and hold the 1st auxiliary function key for 3 seconds to select the programme.
Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. Operate the
programme while the machine is completely empty. To obtain better results, put powder lime-scale remover
for washing machines into the detergent compartment no. “2”. When the programme is over, leave the loading
door ajar so that the inside of the machine gets dry.
CThis is not a washing programme. It is a maintenance programme.
Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is
load inside and aborts the programme.
• Child lock
Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes
in a running programme.
CYou can switch on and off the machine with On / Off button when the Child Lock is active. When you switch on the machine
again, programme will resume from where it has stopped.
When the Child Lock is enabled, an audio warning will be given if the buttons are pressed.Audio warning will be canceled if
the buttons are pressed five times consecutively.
To activate the Child Lock:
Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the
display is over, "CL On" symbol appears on the display. Release Auxiliary Function button 2 when this
warning is displayed.
To deactivate the Child Lock:
Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the
display is over, "CL Off" symbol disappears.
•AntiCrease+
This function is selected when the 4th auxiliary function is pressed and held for 3 seconds and the programme
follow-up light for the relevant step turns on. When the function is selected, the drum rotates for up to 8 hours
for preventing the laundry from creasing at the end of the programme. You can cancel the programme and take
your laundry out at any time during the 8-hour duration. Press the function selection key or the machine on/off
key to cancel the function. The programme follow-up light will remain on until the function is canceled or the
step is complete. If the function is not cancelled, it will be active in the subsequent washing cycles as well.
