Smeg B9040L User manual

B6040L –B9040L
MANUAL FOR INSTALLING INSTRUMENT
WASHERS ON THE RELATIVE STAND
USER MANUAL
TRANSLATION OF THE ORIGINAL INSTRUCTIONS

B6040-B9040
USER MANUAL
2
READ CAREFULLY
This document relates to Smeg optional components “B6040L – B9040L”.
The product may only be installed on Smeg devices.
For proper, safe use, this manual must be used together with the manual of the instrument or glassware washer on
which the accessory is installed.
Failure to read, any misunderstanding or incorrect interpretation of the instructions provided in this manual may lead
to misuse of the device, put the operator at risk and considerably impair the device’s performance.
The manufacturer declines all liability for uses other than those described in this manual.
Installation, maintenance and repairs may only be done by the manufacturer's authorised
technicians.
Using the device in any manner other than that specified by the manufacturer may void the
warranty.
In case of repairs or replacements, only use genuine Smeg spare parts.
The information in this manual is provided for guidance only. The contents and the equipment described may be
subject to change without notice.
KEY TO THE SYMBOLS USED IN THE MANUAL
SYMBOL
MEANING
Read with particular attention.
Symbol which appears beside particularly important instructions or warnings.
Warning
The symbol appears in the manual against safety instructions.
19 390 2911 06
11/05/2022
Rev.
Date

B6040-B9040
USER MANUAL
3
Table of Contents
1GENERAL NOTES ........................................................................................................................................................4
1.1 Technical Characteristics...................................................................................................................................4
2ACCESSORY - DEVICE COMPATIBILITY........................................................................................................................6
2.1 B6040L –STAND FOR DEVICES WIDTH 60 CM .................................................................................................. 6
2.2 B9040L –STAND FOR DEVICES WIDTH 90 CM .................................................................................................. 6
3INSTALLATION............................................................................................................................................................7
3.1 Preliminary operations......................................................................................................................................7
3.2 Placing the device on the stand. ....................................................................................................................... 8
3.3 Fixing. ................................................................................................................................................................9
3.4 Fitting the shield plate underneath the device ...............................................................................................10
4MANUFACTURER AND AFTER-SALES SERVICE CONTACT INFORMATION ................................................................ 11

B6040-B9040
USER MANUAL
4
1GENERAL NOTES
This manual is an integral part of the accessory.
Take good care of it and keep it to hand throughout the accessory’s life cycle
You must read this manual with care and comply with all the instructions it
contains.
1.1 Technical Characteristics
SMEG has produced these stands which allow the appliance’s loading level to be raised to a convenient height of
about 70 centimetres above the ground, and which also provide useful space in the integral cupboard with lock and
key.
B9040L
B6040L
Dimensions: W×D×H= 900×530×400 mm
Dimensions: W×D×H= 600×530×400 mm
This stand is not designed to support heavy loads
Do not place heavy items on the door, risk of overturning !
H
W
D
W
H
D

B6040-B9040
USER MANUAL
5
Accessories included:
4 (four) screws code 89937047200
4 (four) feet code 14890229000
1 shield plate
Tools required
The screws supplied are size 10 with hexagonal head; use of a socket wrench (or a ratchet wrench (fig.)) is
therefore recommended; to adjust the feet, we advise using pipe tongs and a spirit level.
Spirit level

B6040-B9040
USER MANUAL
6
2ACCESSORY - DEVICE COMPATIBILITY
2.1 B6040L –STAND FOR DEVICES WIDTH 60 CM
The accessory can be installed on the following devices:
GW RANGE - LABORATORY GLASSWARE WASHERS
GW1160
GW4060
GW1260
GW4260
WD RANGE - INSTRUMENT WASHERS FOR USE IN HOSPITALS
WD1160
WD1260
WD4060
WD4260
WARNING: If the AQUASTOP “AS4060” optional is installed on the device, use of the
additional “ASB6040L” kit essential for installation of the stand.
2.2 B9040L –STAND FOR DEVICES WIDTH 90 CM
The accessory can be installed on the following devices:
GW RANGE - LABORATORY GLASSWARE WASHERS
GW4190
GW4290
WD RANGE - INSTRUMENT WASHERS FOR USE IN HOSPITALS
WD4190
WD4290
WARNING: If the AQUASTOP “AS4060” optional is installed on the device, use of the
additional “ASB6040L” kit essential for installation of the stand.

B6040-B9040
USER MANUAL
7
3INSTALLATION
Remove the product from the packaging.
3.1 Preliminary operations
ILLUSTRATION
DESCRIPTION
Fitting the feet.
Remember that the height of the feet can be
adjusted.
IMPORTANT level perfectly before placing the
device on the stand.
If possible, to facilitate subsequent maintenance
work, remove the steel base shield for direct
access to the technical compartment.
To ensure the safety of the device, it is
ESSENTIAL to fit the shield plate provided
as described below when installing it on the
stand.
This does not apply if the aquastop AS4060
has already been installed.

B6040-B9040
USER MANUAL
8
3.2 Placing the device on the stand.
Using suitable equipment, place the device on the
stand. There is no need to remove the feet from
the device.
Also remember that the device is simply rested on
the stand, since there are no interlocking parts.
STAND B9040L STAND B6040L
Remove the protective films.

B6040-B9040
USER MANUAL
9
3.3 Fixing.
Once the device has been placed on the stand, they must be fixed
together. USING THE HOLES MARKED BY THE CIRCLES.
B9040L
B6040L
Holes in stand to be used.
Holes in stand to be used.
Fix the stand to the device using three of the four
screws in the bag.
Use the holes shown below, the 2 holes at the front and
back of the left-hand upright and 1 hole in the back of
the central upright.
Fix the stand to the device using the four
screws in the bag.
Use the holes shown below, the 2 holes at the
front and back of the left and right-hand
uprights.

B6040-B9040
USER MANUAL
10
3.4 Fitting the shield plate underneath the device
Installation of the shield plate is essential to ensure the safety of the device
It ABSOLUTELY ESSENTIAL to install this part with the greatest care!
ILLUSTRATION
DESCRIPTION
Fit the right-hand edge of the
top shield, resting it on the
upright
fix on the left using the screws
used to fix the device,
accessing through the stand.
Level the device on the stand with a spirit level by
simply adjusting the screws, screwing them in or
out a little.
STAND FOOT

B6040-B9040
USER MANUAL
11
Leaning or sitting on the open door of the instrument washer might cause
it to tip over, putting people in danger. The door is not designed primarily
to support loads. The maximum weight which can be loaded on the door,
including the weight of the instrument trolley, must never exceed 30 kg.
Therefore, take care not to overload the open door. It is equally important
never to overload the door of the stand.
Devices fitted with AS4060/4190 cannot be installed on stands.
4MANUFACTURER AND AFTER-SALES SERVICE CONTACT INFORMATION
Smeg S.p.A.
Via Leonardo da Vinci, 4
42016 Guastalla –Reggio Emilia - Italy
www.smeg-instruments.com
Italy
•After-Sales Service, Service and Technical Information, contact:
oSingle contact number for Italy +39 0522.160.60.50
oEmail: assistenza[email protected]
•For sales information
oEmail: [e-mail]
International Customers
Please contact your Local Smeg Distributor or write an email to service.ins[email protected]
Do not load on stand door.
