SMH Technologies Flashrunner FR01LAN User manual



FlashRunner
FR01LAN
User’s Manual
High-Performance,
Standalone,
In-System Programmer
DC 10729

We want your feedback!
SMH Technologies is always on the lookout for new ways to improve its
Products and Services. For this reason feedback, comments,
suggestions or criticisms, however small, are always welcome.
Our policy at SMH Technologies is to comply with all applicable worldwide safety and EMC/EMI
regulations. Our products are certified to comply with the European New Approach Directives and the
CE mark is applied on all our products.
This product as shipped from the factory has been verified to meet with requirements FCC as a CLASS
A product.
In a domestic environment, this product may cause radio interference in which case the user may be
required to take adequate prevention measures.
Attaching additional wiring to this product or modifying the product operation from the factory default as
shipped may effect its performance and cause interference with other apparatus in the immediate
vicinity. If such interference is detected, suitable mitigating measures should be taken.
SMH Technologies
Web: http://www.smh-tech.com
Important
SMH Technologies reserves the right to make improvements to FlashRunner, its documentation and software routines, without
notice. Information in this manual is intended to be accurate and reliable. However, SMH Technologies assumes no
responsibility for its use; nor for any infringements of rights of third parties which may result from its use.
SMH TECHNOLOGIES WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF
PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.
Our policy at SMH Technologies is to comply with all applicable worldwide safety and
EMC/EMI regulations.
with the EN6100-6-2 and the EN61000-6-3 standards.
In a domestic environment, this product may cause radio interference in which case the
user may be required to take adequate prevention measures.
Attaching additional wiring to this product or modifying the product operation from the
factory default as shipped may eect its performance and cause interference with other
apparatus in the immediate vicinity. If such interference is detected, suitable mitigating
measures should be taken.
Disposal of Waste Electrical & Electronic Equipment (WEEE).
In the European Union, this label indicates that this product should not be disposed of
with household waste. It must be deposited in an appropriate facility to allow for recovery
and recycling. For more detailed information about the recycling of this product, please
you purchased this product.

FR01LAN User's Manual
Contents
0 Before Starting 9
0.1 Important Notice to Users 9
0.2 Safety 9
0.3 Getting Technical Support 10
0.4 Additional Documentation 10
1 Overview 11
1.1 What is FlashRunner FR01LAN? 11
1.1.1 General features 11
1.1.2 Hardware features 12
1.1.3 Software features 12
1.2 Package Checklist 13
1.3 Hardware Overview 13
1.3.1 Power Supply 15
1.3.2 LAN Connector 15
1.3.3 RS-232 Connector 15
1.3.4 Target Connectors 16
1.3.5 Start Push-Button 16
1.3.6 Optoisolation 16
1.4 Programming Algorithms and Licenses 16
1.4.1 Installing New Licenses 17
1.5 Upgrading the Firmware 17
2 System Setup 19
2.1 Overview 19
2.2 Software Setup 19
2.3 Hardware Setup 20
2.3.1 Interfacing FlashRunner with your Test/Programming
Equipment 20
2.3.2 Connecting FlashRunner to the Host PC System 21

Contents
2.3.3 Powering Up FlashRunner 21
2.3.4 Setting Up LAN Settings 21
2.4 Step-by-Step Tutorial: Sending Commands to FlashRunner 21
3 Connectors 29
3.1 Overview 29
3.2 ISP Connector 29
3.3 Control Connector 31
3.3.1 RS-232 Connector 32
4 Technical Specifications 35
4.1 Absolute Maximum Ratings 35
4.2 DC Characteristics and Functional Operating Range 36
4.3 AC Characteristics 38
4.4 Physical and Environmental Specifications 39

FR01LAN User's Manual
Index of Figures
Figure 1.1: FlashRunner FR01LAN 11
Figure 1.2: FR01LAN Top Layer 14
Figure 1.3: FR01LAN Programming Engine Layer 14
Figure 1.4: FR01LAN Connection Layer 15
Figure 2.1: FlashRunner Control Panel, Communication Settings 23
Figure 2.2: FlashRunner Control Panel, Target Device Configured 24
Figure 2.3: FlashRunner Control Panel, Binary File Conversion 25
Figure 2.4: FlashRunner Control Panel, File Transfer 26
Figure 2.5: FlashRunner Control Panel, Target Device Programmed 27
Figure 3.1: ISP Connector 30
Figure 3.2: Control Connector 31
Figure 3.3: RS-232 Connector 33
Figure 4.1: Load Conditions 39


FR01LAN User's Manual
Index of Tables
Table 3.1: ISP Connector Signals 30
Table 3.2: Control Connector Signals 32
Table 3.3: RS-232 Connector Signals 33
Table 4.1: Absolute Maximum Ratings 35
Table 4.2: DC Characteristics and Functional Operating Range 36
Table 4.3: AC Characteristics 38
Table 4.4: Physical and Environmental Specifications 39


0.1 Important Notice to Users
While every effort has been made to ensure the accuracy of all information in
this document, SMH Technologies assumes no liability to any party for any
loss or damage caused by errors or omissions or by statements of any kind
in this document, its updates, supplements, or special editions, whether such
errors are omissions or statements resulting from negligence, accidents, or
any other cause.
0.2 Safety
FlashRunner is a low-voltage device. However, when integrating it inside an
automatic test equipment or when interfacing it with other systems, take all
precautions in order to avoid electrical shocks due to, for example, different
ground references.
Make all connections to the target system before applying power to the
instrument.
To protect FlashRunner against electrostatic discharge (ESD), always
connect yourself to ground (e.g. via wrist straps) when handling the
instrument.
Always store FlashRunner inside an antistatic bag when not in use.
9
0
FR01LAN User's Manual
0 Before Starting
Note: the FlashRunner System Software CD-ROM and/or
SMH Technologies website (www.smh-tech.com) may con-
tain an updated version of this user’s manual. Please check
before continuing reading this documentation.

Before Starting
00.3 Getting Technical Support
SMH Technologies is continuously working to improve FlashRunner
firmware and to release programming algorithms for new devices. SMH
Technologies offers a fast and knowledgeable technical support to all of its
customers and is always available to solve specific problems or meet
specific needs.
To get in touch with SMH Technologies, please refer to the contact
information below.
Phone: +39 0434 421111
Fax: +39 0434 639021
Technical Support: support@smh-tech.com
0.4 Additional Documentation
This user’s manual provides information about how to setup FlashRunner
FR01LAN and its hardware characteristics.
For information about FlashRunner commands and their syntax, including
specific commands for specific family of microcontrollers, please refer to the
FlashRunner Programmer’s Manual, included (in PDF format) in the
FlashRunner CD-ROM.
10

1
FR01LAN User's Manual
1 Overview
1.1 What is FlashRunner FR01LAN?
FlashRunner FR01LAN is a member of the FlashRunner series of a high-
performance, standalone In-System Programmers specific for Flash-based
microcontrollers and serial memories.
FlashRunner FR01LAN is targeted at production environments, easily
interfaces to your programming system or Automatic Test Equipment (ATE)
and can work either in full standalone mode or controlled by a host system.
Figure 1.1: FlashRunner FR01LAN
1.1.1 General features
Fastest programming algorithms (as fast as target device’s memory
technology limit), approved by silicon manufacturers;
Easy ATE integration;
11

1
Overview
Standalone operations (projects and code images stored on a memory
card);
Also controllable by any host system via RS-232 or Ethernet;
Supports most ISP protocols (BDM, JTAG, SPI, I2C, MON, ICC, SCI,
etc.);
Flexible, fully configurable;
Compact and robust design for production environments;
Data integrity guaranteed (every data transfer to/from the host system
or Secure Digital card is CRC tagged).
1.1.2 Hardware features
9 to 24V power supply input;
Five digital I/O lines;
Two digital I/O or analog output lines;
Two programmable output voltages (0 to 15V, 0.25A and 0 to 5V, 0.5A);
One analog input line;
One programmable clock output;
Secure Digital memory card (up to 2 GB);
512 bytes on-board dynamic memory;
On-board timekeeper and calendar;
I/O protection;
Optoisolated inputs for project selection;
Two optoisolated command inputs (START and STOP);
Three optoisolated status outputs (FAIL, PASS, BUSY);
One optoisolated RS-232 channel;
One optoisolated Ethernet channel.
1.1.3 Software features
Fully autonomous standalone mode thanks to its SD memory card
(FAT16);
Controllable by any host system through a terminal utility and simple
ASCII protocol;
12

1
FR01LAN User's Manual
Up to 32 hardware-selectable projects (scripts), unlimited software-
selectable projects;
Log files;
Erase, blank check, program, read, verify, oscillator trimming, etc.
1.2 Package Checklist
The FlashRunner FR01LAN package includes the following items:
FlashRunner FR01LAN unit, including an SD card already pre-installed
with the programming algorithm(s) you specified at the time of
purchase;
An Ethernet cross cable;
A serial cable;
FlashRunner “System Software” CD-ROM, containing the FlashRunner
Control Panel utility and the FlashRunner Programmer’s Manual in PDF
format;
This user’s manual;
A registration card.
1.3 Hardware Overview
FlashRunner FR01LAN is composed of three layers. From bottom to top:
Connection Layer. Provides D-Sub connectors to interface to your
programming/testing system. Includes optoisolation circuitry and a LAN
and RS-232 connectors to interface to a host system.
Programming Engine Layer. Contains the FlashRunner programming
engine, the core of the instrument.
Cover Layer. The cover layer has the function of protecting the
underlying layers and replicating the programming engine’s status
LEDs. If space is an issue when integrating FlashRunner in your
programming/testing system, the cover layer can be easily removed.
13

1
Overview
The figures below illustrate the various FlashRunner FR01LAN layers.
Figure 1.2: FR01LAN Top Layer
Figure 1.3: FR01LAN Programming Engine Layer
14

1
FR01LAN User's Manual
Figure 1.4: FR01LAN Connection Layer
The Connection layer includes target connectors, optoisolated LAN and RS-
232 ports, a power connector, and a “START” push-button.
1.3.1 Power Supply
FlashRunner FR01LAN is powered through a 9-24V DC terminal block
connector.
1.3.2 LAN Connector
The LAN connector is used for communication with the host PC system. Use
the provided Ethernet cross cable to connect FlashRunner with your PC.
1.3.3 RS-232 Connector
Alternatively, communication with the host PC can be done with the RS-232
connector. Use the provided serial cable to connect FlashRunner with your
PC.
15

1
Overview
1.3.4 Target Connectors
The “ISP” and “CONTROL” D-Sub connectors are used to interface to an
external target system/programming equipment.
i Note: for the pinout of the “ISP” and “CONTROL” connector,
see “Connectors” on page 29.
1.3.5 Start Push-Button
The “START” push-button is directly connected to the FlashRunner START
line in the “CONTROL” D-Sub connector.
1.3.6 Optoisolation
All signals in the “CONTROL”, “LAN” and “RS-232” connectors are
optoisolated. See “Connectors” on page 29 for more information.
1.4 Programming Algorithms and Licenses
FlashRunner FR01LAN includes programming algorithms for several
devices. In order to program a specific device, however, a specific license
file for that device must be purchased.
i Note: FlashRunner FR01LAN comes already preinstalled
with the license(s) you specified at the moment of purchase.
You can purchase additional licenses at any future moment.
Programming algorithms and license files are stored in the SD card (see the
FlashRunner Programmer’s Manual for more information).
16

1
FR01LAN User's Manual
1.4.1 Installing New Licenses
When you buy an additional license for a specific device, you will get:
An algorithm file (.alg);
A license file (.lic);
A device-specific script example (.frs).
The .alg file contains the actual programming algorithm for the requested
device (and several other devices of the same family).
The .lic file contains an unlocking code that will let you use the programming
algorithm. A license file enables the use of a specific programming algorithm
on a specific FlashRunner instrument (licenses are serial number specific).
The script file contains an example of script to use as a starting point for your
specific programming needs (for more information on scripts, see the
FlashRunner Programmer’s Manual).
To install the new license, do the following:
1. Copy the .alg file into the \ALGOS directory of the SD card (if an
.alg file with the same name already exists, overwrite it);
2. Copy the .lic file into the \LICENSES directory of the SD card.
To copy files on the SD card, use either a standard card reader connected to
a PC or transfer the files using the FlashRunner FSSENDFILE command
(for more information on FlashRunner commands, see the FlashRunner
Programmer’s Manual).
Alternatively, you can use the FlashRunner Control Panel utility to install new
programming algorithms and licenses. For more information on the
FlashRunner Control Panel please refer to the FlashRunner Programmer’s
Manual.
1.5 Upgrading the Firmware
The FlashRunner firmware can be easily upgraded using the provided
Control Panel utility. For more information, please refer to the FlashRunner
Programmer’s Manual.
17
Table of contents
Other SMH Technologies Motherboard manuals

SMH Technologies
SMH Technologies Flashrunner FR3070A User manual

SMH Technologies
SMH Technologies FlashRunner LAN 2.0 User manual

SMH Technologies
SMH Technologies FlashRunner FR01ENG User manual

SMH Technologies
SMH Technologies FlashRunner Quattro Series User manual

SMH Technologies
SMH Technologies FlashRunner Cube Series User manual

SMH Technologies
SMH Technologies FlashRunner FR01AT0 User manual

SMH Technologies
SMH Technologies FlashRunner FR03 User manual
