SmitCare LSR24 Assembly instructions

250419 LSR24 instructions v1
Instructions for the assembly and safe use of the
SmitCare Lightweight Rollator
Assembly
-Remove walker from the box and open the frame to its maximum width (Fig. 1)
-Insert the handle stems in the frame at the required height. Insert the bolt through the frame
and handlebar, ensuring the hex head of the bolt is captive by the hex shape in the frame
(Fig 2), then securely tighten with the handwheel. Now repeat on the other handlebar.
-The backrest locates in place with two spring buttons (Fig 3).
-Remove the plastic covering from the tyres and check the brakes operate effectively (as
described in section 3) before each use.
Fig 1 Fig 2 Fig 3
Instructions for Using the Four Wheel Lightweight Walker
1. Unfolding
To unfold the walker, apply the brakes and push down on the handles; note that the folding side
brackets are horizontal when it is fully open. Fold the seat down and the walker is ready for use.
SmitCare
14 Camberley Business Centre
Camberley, Surrey, GU15 3DP
Web: www.smitcare.co.uk
Email:[e-mail]
Contents
1 x Four Wheel Walker with bag and
handles attached by brake cables
2 x Bolts & Handwheels
1 x Padded Backrest
Code: LSR24
Made in China
(Actual product may differ from that shown)

250419 LSR24 instructions v1
2. Walking
Unfold the walker and put the seat down (described above). Place the frame in front of you,
hold the handles and walk forward naturally. When the handle height is at the correct setting
your elbows should be slightly bent whilst you are walking.
To slow the walker down the lever brakes can be squeezed gently. Release them to return to
normal. When you want to stop apply the lever brakes and when you have stopped completely.
You can lock the brakes by pushing both the brake levers down until you feel them click & lock.
To release the brakes pull both the levers up so that you hear them unclick, they are now in the
middle “neutral” position and all the wheels run freely.
Note - The four-wheel lightweight walker should not be used on rough, uneven or soft ground.
3. Sitting/Standing
The seat may only be used when the walker is stationary. Both brakes must be put into the
locked position, check they are secure and that the wheels do not move.
When you want to stand up, first check that the brakes are in the locked position so that the
walker does not roll away from you as you push down on the handles to stand up.
4. Folding and Storage
To fold the walker, lift the seat and pull upwards on the handle that is located at the bottom of
the bag. As you pull the handle, the central bar lifts and closes the walker.
5. Cleaning
Remove bag, clean with a solution of mild detergent and household disinfectant in warm water
applied with a damp sponge. Dry thoroughly. Do not clean with harsh abrasives.
6. Maintenance
Although the Lightweight Walker should give many years of trouble free service, we recommend
that it should be checked monthly to ensure that all components are secure and function
correctly.
Items to check include brakes, wheels/tyres, handgrips, seat hinge, and folding mechanism.
The brakes may require minor adjustment to ensure they lock securely. They can be adjusted
using the threaded adjusters at the top or bottom of the brake cables to provide a gap between
the tyre and brake of approximately 3mm.
Should you require assistance, a mobility shop or bicycle shop would be able to help.
Dimensions
Handle heights 32” – 37” (810 –940mm)
Floor to seat height 21.5” (550mm)
Width between handles 17.5” (440mm)
Seat measurements 13.5” x 13” (340 x 330mm)
Footprint 20” x 23” (510 x 590mm)
Weight of product 7.5 kg (fitted with shopping bag)
Maximum user weight 24 stone (152kg)
Maximum load for vinyl bag 5 kg
Important Notes
A risk assessment should be carried out as to the suitability of this product.
Questions / comments? Please contact our customer services department on
Telephone : [phone]
Email : [email protected]
