Smith-Victor PRO Series User manual

48” Bi-COLOR LED RING LIGHT SYSTEM
USER MANUAL
Model: SatPro48
Item: 401698
FEATURES
• The ultimate in Ring lights- 48" of soft wraparound light
• Ideal for portrait, glamour, fashion, product photography and more
• Produces 2200 Lux at 3’
• 1408 LEDs
• Adjustable Color Temperature: 3000~5500K
• High Quality 95 CRI LEDs
• Dimming from 1~100%
PRECAUTIONS
1) Review manual before operating.
2) Do not use if damaged.
3) Do not attempt to repair yourself. Contact Smith-Victor for service.
4) Do not use in wet areas.
5) Do not touch power cord with wet hands.
6) Never insert metal objects into cooling holes.
7) Use only the AC adapter packed in this set.
8) Avoid moving the light by pulling on the power cord.
9) Turn off light before unplugging.
10) Do not turn off by unplugging the cord from the wall.
Smith-Victor is a division of PromarkBRANDS
1268 Humbracht Circle, Bartlett, IL 60103 U.S.A.
800-348-9862 or 630-830-9200
[email protected] | www.smithvictor.com
www.promarkbrands.com
®
Smith-Victor warrants to the first commercial owner to be free from defects in the material and
workmanship for a period of one (1 ) year from the date of purchase and will repair or replace
product found to be defective under normal use. Warranty does not cover damage caused by
shipment, by product abuse, accident, modification, disassembly or use beyond intended use
specified by Smith-Victor.
This warranty is the only warranty made to any person by Smith-Victor and is in lieu of all other
expressed or implied warranties. The remedies set forth in this warranty shall be the exclusive
remedies available to any person for breach of this warranty. Under no circumstances shall
Smith-Victor be liable to any person for incidental or consequential damages, whether arising out
of breach of warranty or other contract, negligence, strict liability or other tort or otherwise.
®

POWER
• Connect the controller input (F) to the controller output (N) with the power cable (O).
• Connect the DC power input (L) to the AC/DC Adapter (Q) with the DC power input cable (P).
• Connect the AC/DC adapter (Q) to an AC power source with the AC adapter cable (R).
CONTROL MODULE CONTROLS
• Press the power button (K) to turn the light on. Press it again to turn the light off.
• Press the select button (G) to enter the settings.
• Press the up and down buttons (G) to scroll through the setting options.
• Press the select button (G) to select that option.
• Press the power button (K) to get back to the menu.
• Push the slider buttons (I, J) to adjust the color temperature and brightness, (when in local mode).
CONTENTS
(1 ) 48" Ring Light
(4) Diffusers
(1 ) Control Module with Control Cable
(1 ) AC Switching Power Supply
(2) Stands
(1 ) Fitted Carry Case
N
GH I J
ML
F
C
D
E
PARTS
A. Top/Bottom LED panel (2pcs)
B. Left/Right LED panel (2pcs)
C. Wing Nut (2pcs)
D. Light Stand Connector (2pcs)
E. Spigot Knob (2pcs)
F. Controller Input
G. Function/Selector
H. OLED Display
I. Brightness
J. Color Temp
K. Power On/Off
L. DC Power Input
M. DMX
N. Controller Output
O. Power Cable
P. DC Power Input Cable
Q. AC/DC Adapter
R. AC Adapter Cable
S. Stand Spigot
SPECIFICATIONS
Color Rendering Index ..............................>95
Lux..............................................................................2200 @ 3 ft
LED Count............................................................1408
LED Life Expectancy..................................50,000+ hrs
Variable Color temperature.................3000~5500K
Brightness Adjustment...........................1~100%
Beam Angle........................................................120º
Rotation.................................................................360º
AC Power Supply Input.........................100-240VAC 2A
AC Power Supply Output....................24VDC 6.25A
Input Power..................................................150W
Materials...........................................................ABS/Aluminum
Dimensions......................................................OD 47.5”, ID 42.25”
Weight .................................................................13.5 lb
A
BB
A
Fixing screw
1
S
23
Place all four LED panels face
down on a flat surface.
(A=top/bottom) (B=left/right,
with handles and connectors).
Connect LED panel A to B and
insert and tighten the fixing
screw, securing the panels
together.
Repeat step 2 for the remaining
2 LED panels.
LED ASSEMBLY
123
Extend both light stands 4’
apart.
Lift the SATURNPRO48 using
handles and place connectors (D)
over stand spigots (S). (two
people)
Tighten left and right spigot
knobs (E) and wing nut (C).
SATURNPRO48/STANDS ASSEMBLY
A
BB
A
K
O
R
Q
P
